Lecture 6. Java I/O

1
Lecture 6. Java I/O

• Cheng-Chia Chen

2
Contents

1. Overview of I/O Streams
2. Using the Data Sink Streams
3. How to Use File Streams
4. How to Use Pipe Streams
5. Using the Processing Streams
6. How to Concatenate Files
7. Working with Filtered Streams
8. How to Use DataInputStream and DataOutputStream
9. Writing Your Own Filtered Streams
10. Object Serialization
11. Serializing Objects
12. Providing Object Serialization for Your Classes
13. Working with Random Access Files
14. Using Random Access Files
15. Writing Filters for Random Access Files

3
I/O Streams

• A stream is a sequence of bytes (or data or
  objects) that flow from a source to a destination
• In a program, we read information from an input
  stream and write information to an output stream

for output
for input
4
procedure for reading/writing data to/from an
input/output stream

• general program schema for for reading and
  writing data from/to an Input/output stream
• // for reading
• 1. open an input stream // open
• 2. while there is more information // reading
• read next data from the stream
• 3. close the stream. // close
• // for writing
• 1. open an output stream // open
• 2. while there is more information // writing
• write data to the stream
• 3. close the stream. // close

5
I/O Stream Categories

• The java.io package contains many classes that
  allow us to define various streams with specific
  characteristics
• The classes in the I/O package divide input and
  output streams into many categories
• An I/O stream is either a
• character stream, which deals with text data
• byte stream, which deal with byte data
• An I/O stream is also either a
• data stream, which acts as either a source or
  destination
• processing stream, which alters or manages
  information in the stream

6
classification of Java I/O streams and their
naming conventions

• By I/O Directions
• for Input gt Input
• for output gt Output
• By datatype of stream content
• char data gt Reader / Writer
• byte data gt InputStream / OutputStream
• other primitive data(int, long, float,) gt
  DataInputStream /DataOutputStream
• Objects gt ObjectInputStream
  /ObjectOutputStream
• By characteristic of stream source / destination
• 1. for final device data sink stream
• file, byte/char array, StringBuffer, pipe
• purpose serve as the source/destination of
  the stream.
• 2. for intermediate process processing streams
• Buffering, Filtering, Byte2Char,
  Char2Byte, etc.
• purpose alters or manages information in the
  stream

7
The java.io package
InputStream
OutputStream
Reader
Writer
8
java.io.InputStream and its subclasses

• gray gt data sink stream
• white gt processing stream // require other
  streams

9
The Java.io.OutputStream and its subclasses
10
java.io.Reader and its subclasses
11
java.io.Writer and its subclasses
12
Basic methods provided in java input classes

• Reader and InputStream define similar APIs but
  for different data types.
• Reader contains methods for reading characters
  and arrays of characters
• int read() // read one char, casted as an int.
• int read(char cbuf) // read chars into cbuf,
  return chars read.
• int read(char cbuf, int offset, int length)
• InputStream defines the same methods but for
  reading bytes and arrays of bytes
• int read()
• int read(byte cbuf)
• int read(byte cbuf, int offset, int length)
• Both classes provide methods for marking a
  location in the stream, skipping input, and
  resetting the current position.

13
Basic methods provided in java output streams

• Writer defines these methods for writing
  character, string and arrays of characters
• void write(int c) // 16 low-ordered bits of c
  is written
• void write(char cbuf , int off, int len )
• void write(String s , int off, int len )
• OutputStream defines the same methods but for
  bytes
• void write(int c) // 8 low-ordered bits of c is
  written
• void write(byte cbuf)
• void write(byte cbuf, int offset, int length)
• All of the streams--readers, writers, input
  streams, and output streams
• are automatically opened when created !
• can be closed by calling its close() method, or
  the garbage collector.
• will throw IOException on failure of IO
  operations.

14
Standard I/O

• There are three standard I/O streams
• standard input defined by System.in
• standard output defined by System.out
• standard error defined by System.err
• We use System.out when we execute println
  statements
• System.out and System.err are of the type
  PrintStream.
• System.in is declared to be a generic InputStream
  reference, and therefore usually must be mapped
  to a more useful stream with specific
  characteristics
• eg to read char instead of bytes gt
• InputStreamReader cin new InputStreamReader(Sys
  tem.in)

15
java.io.InputStream

• public abstract class InputStream extends Object
• Constructor
• InputStream() // default no-arg constuctor
• Method Summary
• int available()
• Returns the number of bytes that can be read (or
  skipped over) from this input stream without
  blocking by the next read() .
• void close()
• Closes this input stream and releases any system
  resources associated with the stream.
• abstract int read( byte b , int offset,
  int length )
• Reads the next byte of data from the input
  stream.
• Reads some number of bytes from the input stream
  and stores them into the buffer array b.
• long skip(long n)
• Skips over and discards n bytes of data from this
  input stream.

16
Methods for marking operaqtions

• void mark(int readlimit)
• Marks the current position in this input stream.
• readlimit is the number of bytes that can be read
  without invalidating this mark operation.
• void reset()
• Repositions this stream to the position at the
  time the mark method was last called on this
  input stream.
• boolean markSupported()
• Tests if this input stream supports the mark and
  reset methods.

17
java.io.Reader

• public abstract class Reader extends Object
• Abstract class for reading character streams.
• The only methods that a subclass must implement
  are read(char, int, int) and close().
• Most subclasses, however, will override some of
  the methods defined here in order to provide
  higher efficiency, additional functionality, or
  both.
• Field Summary
• protected Object lock
• The object used to synchronize operations on this
  stream.
• use lock instead of this or synchronized method
  for efficient time-critical operations
• Constructor Summary
• protected Reader()
• Create a new character-stream reader whose
  critical sections will synchronize on the reader
  itself.
• protected Reader(Object lock)
• Create a new character-stream reader whose
  critical sections will synchronize on the given
  object.

18
Methods summary of java.io.Reader

• abstract void close() // Close the
  stream.
• int read() // Read a single character.
• abstract int read( char cbuf ,int off, int
  len )
• Read characters into an array.
• boolean ready() // replacement of available()
  in java.InputStream
• Tell whether this stream is ready to be read
• without causing I/Oblocking in next read().
• long skip(long n) // Skip characters.
• void mark(int limit)
• Mark the present position in the stream. limit is
  the number of chars that can be read without
  causing failure of the following reset().
• void reset() // Reset the stream.
• boolean markSupported()
• Tell whether this stream supports the mark()
  operation.

19
Java.io.OutputStream

• public abstract class OutputStream extends Object
• the superclass of all classes representing an
  output stream of bytes.
• An output stream accepts output bytes and sends
  them to some sink.
• Subclasses must always provide at least a method
  that writes one byte of output.
• Constructor Summary
• OutputStream() // will automatically open this
  stream for writing
• Methods summary
• void close() // Closes this output stream and
  releases system resources.
• void flush()
• Flushes this output stream and forces any
  buffered output bytes to be written out.
• void write(byte b , int off, int len )
• Writes len bytes from the specified byte array
  starting at offset off to this output stream.
• abstract void write( int b) // Writes the
  specified byte to this output stream.

20
java.io.Writer

• public abstract class Writer extends Object
• Abstract class for writing to character streams.
• Subclass must implement write(char, int, int),
  flush(), and close().
• subclasses may override some of the methods
  defined here in order to provide higher
  efficiency, additional functionality, or both.
• Field Summary
• protected Object lock
• The object used to synchronize operations on this
  stream.
• Constructor Summary
• protected Writer()
• Create a new character-stream writer whose
  critical sections will synchronize on the writer
  itself.
• protected Writer(Object lock)
• Create a new character-stream writer whose
  critical sections will synchronize on the given
  object.

21
java.io.Writer method summary

• abstract void close() // Close the
  stream, flushing it first.
• abstract void flush() // Flush the
  stream.
• abstract void write(char cbuf , int
  off, int len)
• Write a portion of an array of characters.
• void write(int c) // Write a single
  character.
• void write(String str) // Write a string.
• void write(String str, int off, int len)
• Write a portion of a string.

22
JDK s implementation of write( int )

• protected Object lock // for synchronization
• private char writeBuffer // for chars to be
  output
• private final int writeBufferSize 1024
• public void write( int c) throws IOException
• synchronized (lock)
• if (writeBuffer null)
• writeBuffer new charwriteBufferSize
• writeBuffer0 (char) c
• write(writeBuffer, 0, 1)
• Subclasses that intend to support efficient
  single-character output
• should override this method.

23
2. The Data Sink Streams

• Types of data sinks memoryarray, strings,
  files, or pipes
• Naming convention ltsinkTypegtltI/OCharOrBytegt

Sink type character stream byte stream
array CharArrayReader, CharArrayWriter ByteArrayInputStream, ByteArrayOutputStream
String StringReader, StringWriter StringBufferInputStream (deprecated) ?
Pipe PipedReader, PipedWriter PipedInputStream, PipedOutputStream
File FileReader, FileWriter FileInputStream, FileOutputStream
Input
Output
Input
Output
Input
Output
Input
Output
24
Summary of the data sink streams

• FileReader, FileWriter FileInputStream,
  FileOutputStream
• Collectively called file streams used to read
  from or write to a file on the native file
  system.
• CharArrayReader, CharArrayWriter
  ByteArrayInputStream, ByteArrayOutputStream
• Use these streams to read from and write to
  memory array.
• create these streams on an existing array and
  then use the read and write methods to read from
  or write to the array.
• Constructors ltTypegt( char byte , int
  offset, int length )
• Ex CharArrayWriter cwr new CharArrayWriter(
  new char100 )
• CharArrayWriter cw new CharArrayWriter( new
  char1024, 256,512 )
• ByteArrayInputstream bi new
  ByteArrayInputStream
• ( new byte \011,\022, \0xff )

25
String Streams

• StringReader, StringWriter, StringBufferInputStre
  am
• StringReader used to read characters from a
  String.
• StringWriter used to write to a String.
  StringWriter collects the characters written to
  it in an implicit StringBuffer, which can then be
  converted to a String.
• StringBufferInputStream similar to
  StringReader, except that it reads bytes from a
  StringBuffer. (deprecated since it cannot
  correctly convert a char to bytes use
  StringReader instead)
• Constructors
• StringReader(String)
• StringWriter( int initSize ) // initial buffer
  size use toString() to get the written String
• StringBufferInputStrean(String) // deprecated !
  Only the low eight bits of each character in the
  string are used by this class.

26
Piped Streams

• PipedReader, PipedWriter
• PipedInputStream, PipedOutputStream
• Implement the input and output components of a
  pipe.
• Pipes are used to channel the output from one
  program (or thread) into the input of another.
• PipedReader and PipedInputStream get data from
  the output of another thread, while PipedWriter
  and PipedOutputStream output data for processing
  by other thread.

27
2.1 How to Use File Streams

• File streams are the easiest streams to
  understand.
• Create (and open )the file stream
• ltFileStreamgt f new ltFileStreamgt( ltfilegt )
• where ltFileStreamgt is any of FileReader,
  FileWriter, FileInputStream, and FileOutputStream
  and
• ltfilegt is either a string for file name, a File
  object, or a FileDescriptor object (low-level
  handle to open file or socket).
• EX
• FileReader reader1 new FileReader(example1.txt
  )
• File file1 new File(d\\java\\examples\\ex1.jav
  a)
• FilerWriter writer1 new FileWriter(file1)
• FileInputStream in1 new FileInputStream(ex2)
• FileOutputStream out1 new FileOutputStream (
  java.io.FileDescriptor out )

28
A simple file-copy program

• Copy the contents of a file named input.txt into
  a file called output.txt
• import java.io.
• public class Copy
• public static void main(String args)
  throws IOException
• File inputFile new File(input.txt")
• File outputFile new
  File("output.txt")
• FileReader in new FileReader(
  inputFile )
• FileWriter out new FileWriter(
  outputFile )
• int c
• while ((c in.read()) ! -1)
  out.write(c)
• in.close()
• out.close()

29
Copy bytes

• import java.io.
• public class CopyBytes
• public static void main(String args) throws
  IOException
• File inputFile new File(input.txt")
• File outputFile new File("output.txt")
• FileInputStream in new
  FileInputStream(inputFile)
• FileOutputStream out new
  FileOutputStream(outputFile)
• int c
• while ((c in.read()) ! -1)
  out.write(c)
• in.close()
• out.close()

30
2.2 How to Use Pipe Streams

• A pipe is a channel for receiving data from one
  program (or thread) and sending the received data
  to the input of another.
• PipedReader, PipedWriter PipedInputStream,
  PipedOutputStream
• implement the input and output components of a
  pipe.
• for p2, p is an PipedWriter ( or
  PipedOutputStream )
• for p1, p is a PipedReader ( or PipedInputstream
  )

31
Pipe example

• a simple program to reverse, sort and reverse
  words in a file.
• Note without pipe, programmers would need 2
  additional temporary files/buffers to store the
  intermediate results.

sink (words)
sink (rhymedWords)
32
The program

• import java.io.
• public class RhymingWords
• public static void main(String args) throws
  IOException
• FileReader words new FileReader("words.t
  xt")
• // do the reversing and sorting
• Reader rhymedWords reverse(sort(reverse(
  words)))
• // write new list to standard out
• BufferedReader in new BufferedReader(
  rhymedWords )
• String input
• while ((input in.readLine()) ! null)
  out.println(input)
• in.close()

33
the reverse method

• public static Reader reverse(Reader source)
  throws IOException
• BufferedReader in new BufferedReader(source)
• PipedWriter pipeOut new PipedWriter()
• PipedReader pipeIn new PipedReader( pipeOut )
• // PipedReader pipeIn new PipedReader( )
  // alternative codes for
• // PipedWriter pipeOut new PipedWriter( pipeIn
  ) // the above two lines
• PrintWriter out new PrintWriter(pipeOut) //
  wrap pipeOut for easy write
• new ReverseThread(out, in).start() return
  pipeIn

pipeOut
in(source)
pipeIn
reverse Thread
out(pipeOut)
34

• // source is a PipedReader
• public static Reader sort(Reader source) throws
  IOException
• BufferedReader in new
  BufferedReader(source)
• PipedWriter pipeOut new PipedWriter()
• PipedReader pipeIn new
  PipedReader(pipeOut)
• PrintWriter out new PrintWriter(pipeOut)

• new SortThread(out, in).start()
• return pipeIn

35
ReverseThread.java

• import java.io.
• public class ReverseThread extends Thread
• private PrintWriter out private
  BufferedReader in
• public ReverseThread(PrintWriter out,
  BufferedReader in)
• this.out out this.in in
• public void run() // entry point of a
  thread (invoked by start()),
• // like
  main() of a java program
• if (out ! null in ! null)
• try String input
• while ((input
  in.readLine()) ! null)
•
  out.println(reverseIt(input)) out.flush()

• out.close()
• catch (IOException e)
  err.println("ReverseThread run " e)
• private String reverseIt(String source)
  // reverse source

36
SortThread.java

• import java.io.
• public class SortThread extends Thread
• private PrintWriter out null private
  BufferedReader in null
• public SortThread( PrintWriter out,
  BufferedReader in )
• this.out out this.in in

• public void run() int MAXWORDS 50
• if (out ! null in ! null)
  try
• String listOfWords new
  StringMAXWORDS
• int numwords 0 // read words from
  in into listOfWords
• while ((listOfWordsnumwords
  in.readLine()) ! null) numwords
• quicksort(listOfWords, 0, numwords-1)
  // sort
• for (int i 0 i lt numwords i)
  out.println(listOfWordsi) // output
• out.close()
• catch (IOException e)
  System.err.println("SortThread run " e)

37
quicksort

• private static void quicksort(String a, int
  lo0, int hi0)
• int lo lo0 int hi hi0
• if (lo gt hi) return
• String mid a(lo hi) / 2
• while (lo lt hi)
• while (lolthi alo.compareTo(mid)
  lt 0) lo
• while (lolthi ahi.compareTo(mid)
  gt 0) hi--
• if (lo lt hi)
• String T alo alo
  ahi ahi T
• lo hi--
• if (hi lt lo) int T hi
  hi lo lo T
• quicksort(a, lo0, lo)
• quicksort(a, lo lo0 ? lo1 lo, hi0)

38
3. Using the processing streams

• Using Streams to Wrap Other Streams
• The reverse method contains some other
  interesting code in particular, these two
  statements
• BufferedReader in new
  BufferedReader(source) ...
• PrintWriter out new PrintWriter(pipeOut)

• general format
• WrappedClass w new WrappedClass( rawObject )
• where rawObjwect is an obejct of type RawClass
  which does not provide the needed method, while
  Wrapped class is an extension of rawClass with
  intended methods provided.
• In revserse() method
• source is a file pipe Reader, which does not
  provide the readLine() method.
• pipeOut is a piped writer, which does not
  provide the convenient println() method.

39
3.1 Types of the Processing Streams
process character stream byte stream
Buffering BufferedReader, BufferedWriter BufferedInputStream, BufferedOutputStream
Filtering FilterReader, FilterWriter FilterInputStream, FilterOutputStream
B2C and C2B InputStreamReader, OutputStreamWriter StringBufferInputStream (deprecated)
Concatenation SequenceInputStream
Object Serialization ObjectInputStream, ObjectOutputStream
Data Conversion DataInputStream, DataOutputStream
Counting LineNumberReader LineNumberInputStream
printing PrintWriter PrintStream
Peeking Ahead PushbackReader PushbackInputStream
40
3.2 Summary of the processing streams

• Buffered Streams
• Buffer data while reading or writing, thereby
  reducing the number of accesses required on the
  original data source.
• typically more efficient than similar nonbuffered
  streams suggest always wrap a buffer stream
  around any stream such as a file stream whose
  read/write operations are costly.
• BufferedReader f new BufferedReader(new
  FileReader(data.txt))
• BufferedOutputStream b new BufferedOutputStream
  (
• new FileOutputStream(dataout))

41
Filter Streams

• Filter streams
• contains some other input stream as its basic
  source of data, possibly transforming the data
  along the way or providing additional
  functionality.
• Abstract classes, same as their parent streams
  (without new methods).
• They define the interface for filter streams,
  which filter data as it's being read or written.

(InputStream/Writer etc)
42
Byte2Char and char2Byte

• A reader and writer pair that forms the bridge
  between byte streams and character streams.
• default encoding from system property
  file.encoding
• Ex
• InputStreamReader reader new InputStreamReader(

• new
  FileInputStream(data.txt) , Big5 )
• OutputStreamWriter writer new
  OutputStreamWriter(
• new
  FileOutputStream(out.txt))

43

• SequenceInputStream
• Concatenates multiple input streams into one
  input stream.
• ex SequenceInputStream sin new
  SequenceInputStream(s1,s2)
• ObjectInputStream and ObjectOutputStream
• Used to serialize objects.
• DataInputStream and DataOutputStream
• Read / write primitive Java data types in a
  machine-independent format.
• subclass of filter stream

44

• LineNumberReader, LineNumberInputStream
• Keeps track of line numbers while reading.
• PushbackReader, PushbackInputStream
• Two input streams each with a character (or byte)
  pushback buffer.
• Sometimes, when reading data from a stream, you
  will find it useful to peek at the next item in
  the stream in order to decide what to do next.
  However, if you do peek ahead, you'll need to put
  the item back so that it can be read again and
  processed normally.
• PrintWriter, PrintStream
• Contain convenient printing methods.
• public void print(Type), and println(Type),
  where the argument Type can be any type, either
  primitive or not.
• These are the easiest streams to write to, so you
  will often see other writable streams wrapped in
  one of these.
• c.f. PrintWriter(wrapping a writer) can not write
  byte .

45
How to Concatenate Files using the
sequenceInputStream

• a concatenation utility that sequentially
  concatenates files together in the order they are
  listed on the command line.
• The main program
• import java.io.
• public class Concatenate
• public static void main(String args) throws
  IOException
• ListOfFiles mylist new
  ListOfFiles(args)
• // mylist is an enumeration of objects of
  type InputStream
• SequenceInputStream s new
  SequenceInputStream(mylist)
• int c
• while ((c s.read()) ! -1)
  System.out.write(c)
• s.close()

46
ListOfFiles.java

• import java.util. import java.io.
• public class ListOfFiles implements Enumeration
• private String listOfFiles
  private int current 0
• public ListOfFiles(String listOfFiles)
  this.listOfFiles listOfFiles
• public boolean hasMoreElements()
• if (current lt listOfFiles.length) return
  true else return false
• public Object nextElement() InputStream in
  null
• if (!hasMoreElements())
• throw new NoSuchElementException("NoMor
  eFiles.")
• String nextElement listOfFilescurrent
  current
• try in new FileInputStream(nextElement)

• catch (FileNotFoundException e)
• return in

47
The SequenceInputerStream class

• public class SequenceInputStream extends
  InputStream
• Constructor Summary
• SequenceInputStream(Enumeration e)
• e is an Enumeration of objects whose runtime type
  is InputStream.
• SequenceInputStream(InputStream s1, InputStream
  s2)
• Method Summary All overriding those from
  inputStream.
• int available(),
• void close(),
• int read(),
• int read(byte b , int off, int len)

48
Working with Filtered Streams

• You attach a filtered stream to another stream to
  filter the data as it's read from or written to
  the original stream.
• Subclasses of either FilterInputStream or
  FilterOutputStream
• DataInputStream and DataOutputStream primitive
  data ? bytes
• BufferedInputStream and BufferedOutputStream
• LineNumberInputStream (deprecated)
• PushbackInputStream
• PrintStream
• Subclasses of FilterReader and FilterWriter
• BushbackReader, LineNumberReader,
• Note FilterReader/Writer use a character stream
  as its underlying stream while FilterInputStream/O
  utputStream use a byte stream as its underlying
  stream.

49
Writing Your Own Filtered Streams

• Steps
• Create a subclass of FilterInputStream and
  FilterOutputStream.
• Override the read and write methods.
• Override and/or define any other methods that you
  might need.
• Make sure the input and output streams work
  together.
• Example
• Use Adler32 to implement a CheckedInputStream and
  CheckedOutputStream to ensure that the data read
  match those written in other program now
  included in java.util.zip package
• Four classes and one interface make up this
  example program
• 1. CheckedOutputStream, CheckedInputStream.
• 2. The Checksum interface and the Adler32 class
  compute a checksum for the streams.
• 3. The CheckedIOTest class defines the main
  method for the program.

50
CheckedOutputStream

• import java.io.
• public class CheckedOutputStream extends
  FilterOutputStream
• private Checksum cksum
• public CheckedOutputStream(OutputStream out,
  Checksum cksum)
• super(out) this.cksum cksum

• public void write(int b) throws IOException
• out.write(b) cksum.update(b)

• public void write(byte b) throws
  IOException
• out.write(b, 0, b.length)
  cksum.update(b, 0, b.length)
• public void write(byte b, int off, int len)
  throws IOException
• out.write(b, off, len)
  cksum.update(b, off, len)
• public Checksum getChecksum() //
  additional functionality
• return cksum

51
the CheckedInputStream

• import java.io.FilterInputStream,
  java.io.InputStream, java.io.IOException
• public class CheckedInputStream extends
  FilterInputStream
• private Checksum cksum
• public CheckedInputStream(InputStream in,
  Checksum cksum)
• super(in) this.cksum cksum

• public int read() throws IOException int b
  in.read()
• if
  (b ! -1) cksum.update(b) return b
• public int read(byte b) throws IOException

• int len len in.read(b, 0, b.length)
• if (len ! -1) cksum.update(b, 0,
  len)
• return len
• public int read(byte b, int off, int len)
  throws IOException
• len in.read(b, off, len)
• if (len ! -1) cksum.update(b, off,
  len) return len
• public Checksum getChecksum() return
  cksum

52
Checksum and Adler32

• public interface Checksum
• public void update(int b)
• public void update(byte b, int off, int
  len)
• public long getValue() // return checksum
  value
• public void reset()
• public class Adler32 implements Checksum
• private int value 1 // state of the
  checksum
• private static final int BASE 65521 //
  largest prime lt 65536
• // NMAX is the largest n with 255n(n1)/2
  (n1)(BASE-1)lt 232-1
• private static final int NMAX 5552

53

• public void update(int b)
• int s1 value 0xffff int s2
  (value gtgt 16) 0xffff
• s1 b 0xff s2 s1
• value ((s2 BASE) ltlt 16) (s1
  BASE)
• public void update(byte b, int off, int len)
• int s1 value 0xffff int s2
  (value gtgt 16) 0xffff
• while (len gt 0)
• int k len lt NMAX ? len NMAX
  len - k
• while (k-- gt 0) s1 boff
  0xff s2 s1
• s1 BASE s2 BASE

• value (s2 ltlt 16) s1
• public void reset() value 1
• public long getValue() return (long) value
  0xffffffff

54
The test

• import java.io.
• public class CheckedIOTest
• public static void main(String args) throws
  IOException
• Adler32 inChecker new Adler32() Adler32
  outChecker new Adler32()
• CheckedInputStream in null
  CheckedOutputStream out null
• try in new CheckedInputStream( new
  FileInputStream(input.txt"),
•
  inChecker)
• out new CheckedOutputStream(new
  FileOutputStream("output.txt"),
•
  outChecker)
• catch (FileNotFoundException e)

• catch (IOException e)

• int c while ((c in.read()) ! -1)
  out.write(c)
• System.out.println("Input stream check sum "
  inChecker.getValue())
• System.out.println("Output stream check sum
  " outChecker.getValue())
• in.close() out.close()


55
The java.io.DataInputStream class

• public class DataInputStream extends
  FilterInputStream implements DataInput
• // allow to read primitive data in machine indep.
  way
• Constructor Summary
• DataInputStream(InputStream in)
• Method Summary
• int read(byte b , int offset , int length
  ) // read to array b
• void readFully(byte int,int) // throws
  EOFException if not fully read
• lttypegt readltTypegt( ) // read one data item
• lttypegt is one of boolean, byte, short, int,
  long, float, double, char
• String readUTF() // read a string in UTF8 format
  (instead of
  unicode/native)
• String readLine() // read next line, deprecated
• int readUnsignedltTypegt() // ltTypegt is either
  Byte or Short
• int skipBytes(int n) // always returns n if no
  exception

56
java.io.DataOutputStream

• public class DataOutputStream extends
  FilterOutputStream implements DataOutput
• Constructor Summary
• DataOutputStream(OutputStream out)
• Method summary
• void flush() int size() // return of bytes
  written into this stream
• void write(byte b , int off, int len )
• void writeltTypegt(lttypegt v) throws IOException
• lttypegt is any of int, long, float, double.
• void writeltTypegt(int v) throws IOException
• lttypegt is one of boolean, byte, short or char.
• void writeltTypegt( String s)
• ltTypegt is either Bytes or Chars for Bytes only
  low-bytes of s are written
• Writes out the string to the underlying output
  stream as a sequence of bytes or chars.
• void writeUTF(String str)
• Write str in UTF8 format (first 2 byte bytes
  written) ! str.size() in general.

57
How to Use DataInputStream and DataOutputStream

• import java.io.
• public class DataIOTest
• public static void main(String args) throws
  IOException
• // write the data out
• DataOutputStream out new
  DataOutputStream(new
•
  FileOutputStream("invoice1.txt"))
• double prices 19.99, 9.99, 15.99,
  3.99, 4.99
• int units 12, 8, 13, 29, 50
• String descs "Java T-shirt", "Java
  Mug", "Duke Juggling Dolls",
• "Java Pin", "Java
  Key Chain"
• for (int i 0 i lt prices.length i )

• out.writeDouble(pricesi)
  out.writeChar('\t')
• out.writeInt(unitsi)
  out.writeChar('\t')
• out.writeChars(descsi)
  out.writeChar('\n')
• out.close()

58

• // read it in again
• DataInputStream in new DataInputStream(new
  FileInputStream("invoice1.t
  xt"))
• double price int unit String desc
  double total 0.0
• try while (true)
• price in.readDouble()
  in.readChar() // throws out the tab
• unit in.readInt()
  in.readChar() // throws out the tab
• desc in.readLine()
• System.out.println("You've
  ordered " unit " units of "
• desc " at
  " price)
• total total unit price
• catch (EOFException e)
• System.out.println("For a TOTAL of "
  total)
• in.close()

59
How read/writeUFT8() work

• Note There is no
• writeUnsignedByte() or writeUnsignedShort() in
  DataOutputStream.
• writeByte(-128) gt readByte() -128 and
•
  readUnsignedByte() 128.
• Modified UTF8 format (also used in .class for
  representing strings)
• '\u0001' '\u007F' represented by a single
  byte 0xxx xxxx (1127)
• \u0000 and '\u0080' '\u07FF' 110x xxxx
  10xx xxxx (0,1282047)
• '\u0800' '\uFFFF' 1110 xxxx 10xxxxxx 10xxxxxx
  (204865535)
• Note \u0000 is represented by 2 bytes1100 0000
  1000 0000 instead of
•
  0000 0000.
• when writeUTF(String) the first 2 bytes are an
  unsigned short indicating the number of bytes
  required to write the string.

60
File Management

• Have learned how to read/write data from a file,
• But how about file management besides read/write
  ?
• create new file/directory,
• set/get file properties (access permission, last
  update date, owner, file name, full path etc.)
• The class java.io.File
• Represents a file on the native file system.
• encapsulates the functionality that you will need
  to work with the file system on a machine.
• You can create a File object for a file on the
  native file system and then query the object for
  information about that file (such as its full
  pathname).

61
Path Name vs Abstract path name

• Pathname strings are system-dependant strings
  for identifying directories or files in a system,
  while abstract pathnames are system independent
  strings for identifying directories or files.
• pathname sys-dep-prefix ( DirName
  FileSpearator)
•
  DirName FileName
• FileSeparator is / for UNIX and \ for WIN32.
• Default determined by file.separator system
  property given at field File.separator
• abstract pathname sys-dep-prefix DirName
  DirName FileName
• where sys-dep-prefix is an optional
  system-dependent prefix string,
• Unix gt / for UNIX root directory.
• win32 gt Driver, Driver\" , or
• "\\" for a Win32 UNC(universal Naming
  Convention)pathname, and
• A sequence of zero or more string names.
• Each name in an abstract pathname except for the
  last denotes a directory the last name may
  denote either a directory or a file.

62
relative vs absolute pathnames

• Pathnames and abstract pathname can be either
  absolute or relative.
• An absolute pathname contains full information to
  locate the file or directory that it denotes.
• A relative pathname, in contrast, must be
  interpreted in terms of information taken from
  some other base directory pathname.
• absolute_pathname base_directory
  relative_pathname
• where by default base_directory is the current
  user directory, which can be got by the system
  property user.dir.

63
jva.io.File

• public class File extends Object implements
  Serializable, Comparable
• File constructors
• File(String pathname) // pathname can be
  relative or absolute
• Creates a new File instance by converting the
  given system dependant pathname string into an
  system independent abstract pathname.
• File(File dir, String child) // child is
  interpreted as relative
• Creates a new File instance from a parent
  abstract pathname and a child pathname string.
• f1 new File(a/b/, c\\d\\e) // returns
  a\b\c\d\e, / doesnt care!
• File(String parentDir, String child)
• Creates a new File instance from a parent
  pathname string and a child pathname string.

64
File constructor examples

• // create File using absolute pathname
• File barDir new File( C\\tmp\\bar" ) // bar
  need not exist in advance!
• barDir.exists() // return false iff C\temp\bar
  does not exist.
• File fooFile new File( /tmp/foo.txt" ) // ok
  for WIN32 and UNIX
• barFile.getPath() // return \tmp\foo.txt for
  WIN32
• // create a file with a relative path
• File f1 new File( "foo" ) // f.getPath()
  returns foo.
• String dir System.getProperty(user.dir) //
  suppose it returns c\java
• File f2 new File( dir, foo) // f2.getPath()
  returns c\java\foo
• File userDir new File( dir )
• File f3 new File(userDir, foo)
• f2.equals(f3) // return true
• f2.equals(f1) // return false
• f2.equals( f1.getAbsoluteFile()) // return true

65
Field Summary

• static String pathSeparator
• The system-dependent path-separator character,
  represented as a string for convenience. (
  path.separator system property)
• for WIN32 and FOR UNIX
• static char pathSeparatorChar
• The system-dependent path-separator character.
• static String separator
• The system-dependent default name-separator
  character, represented as a string for
  convenience. ( file.separator system
  property)
• \ for WIN32 and / for UNIX
• static char separatorChar
• The system-dependent default name-separator
  character.

66
Method Summary

• // class methods
• static File createTempFile(String prefix, String
  suffix , File dir)
• Creates an empty file in the dir directory, using
  the given prefix and suffix to generate its
  name.
• suffix null gtuse tmp as default prefix
  gt 2.
• dir null or not given gt use system property
  java.io.tmpdir, which is /tmp or /var/tmp on
  UNIX and c\temp on WIN32
• static File listRoots()
• List the available filesystem roots.
• Ex
• File fs File.listRoots()
• for ( int i 0 i lt fs.length() i)
  System.out.println(fsi.getPath())
• the output
• gtA\
• gtC\
• gtD\

67
instance methods

• // File properties getter/setter
• boolean exists(), isDirectory(), isFile() ,
  isHidden()
• boolean isAbsolute()
• Tests whether this abstract pathname is absolute.
• boolean canRead(), canWrite() // current
  application can read/write ?
• long length() // the length of the file denoted
  by this 0 for directory.
• long lastModified()
• Returns the time that the file denoted by this
  abstract pathname was last modified.
• boolean setLastModified (long time)
• boolean setReadOnly()
• boolean equals(Object obj)
• Tests this abstract pathname for equality with
  the given object.
• int hashCode()
• Computes a hash code for this abstract pathname.
• int compareTo(File pathname), compareTo(Object
  o)
• Compares two abstract pathnames
  lexicographically.

68
pathname/ File transformations

• File getAbsoluteFile() String
  getAbsolutePath()
• Returns the absolute pathname string of this
  abstract pathname.
• File getCanonicalFile() String
  getCanonicalPath()
• Returns the canonical form of this abstract
  pathname.
• new File(/a/b/../).getCanonicalPath() //
  return C\a but C\a\b\.. for getAbsolutePth()
• String getParent() File getParentFile()
• Returns the pathname string or abstract pathname
  of this abstract pathname's parent, or null if
  this pathname does not name a parent directory.
• String getName() // Returns the name of the
  file/directory denoted by this.
• String getPath() // File ? pathname String
• Converts this abstract pathname into a pathname
  string.
• boolean renameTo(File dest)
• Renames the file denoted by this abstract
  pathname.
• String toString() Returns the pathname
  string of this abstract pathname.
• URL toURL()
• Converts this abstract pathname into a file URL.
• c\a\b\c.txt ? file/c/a/b/c.txt
  \\host\sh\b\c.txt ? file//host/sh/b/c.txt

69
Directory and File operations

• // File operations
• boolean createNewFile() // atomically check and
  create new file if not existing.
• boolean delete() // delete this file or
  directory
• void deleteOnExit() // delete when on system
  exits
• // directory operations
• boolean mkdirs() , mkdir()
• Creates the directory named by this Fie, mkdirs()
  will also create any necessary nonexistent
  parent directories.
• String list(), list(FilenameFilter filter)
• Returns an array of strings naming the files and
  directories in the directory denoted by this
  abstract pathname that satisfy the specified
  filter.
• File listFiles(), listFiles(FileFilter filter),
  listFiles(FilenameFilter filter)
• Returns an array of abstract pathnames denoting
  the files and directories in the directory
  denoted by this abstract pathname that satisfy
  the specified filter.

70
FilenameFilter and FileFilter

• public interface FilenameFilter public boolean
  accept(File dir, String name)
• public interface FileFilter public boolean
  accept(File dir)
• Implementation of listFiles(FilenameFilter)
• public File listFiles( FilenameFilter filter)

• String ss list() if (ss null) return
  null
• ArrayList v new ArrayList()
• for (int i 0 i lt ss.length i)
• if (( filter null) filter.accept(this,
  ssi) )
• v.add(new File( this.getpath() ,
  ssi))
• return (File)(v.toArray(new File0))

71
Example

• Find all java source files lastly modified in one
  day in current user directory
• File userDir new File (System.getProperty(user.
  dir))
• int now new Date().getTime() // now is
  current time in ms.
• String rlts dir.list( new FilenameFilter()
• boolean accept( File dir, String name)
• File f new File (dir, name) // dir
  bound to this at runtime
• return name.endWith(.java)
• (now - f.lastModified() lt
  1000606024)
• )
• for(int i 0 i lt rlts.length i)
• System.out.println(rltsi)

72
Object Serialization

• The process of reading and writing objects is
  called object serialization
• ObjectInputStream and ObjectOutputStream are
  streams used to read/write objects.
• when to use object serialization
• Remote Method Invocation (RMI)--communication
  between objects via sockets
• Lightweight persistence--storage of an object for
  use in a later invocation of the same program
• What a Java programmer need to know about object
  serialization
• How to serialize objects by writing them to an
  ObjectOutputStream and reading them in again
  using an ObjectInputStream.
• how to write a class so that its instances can be
  serialized.

73
Serializing Objects

• How to Write to an ObjectOutputStream ?
  straight-forward!
• Ex
• FileOutputStream out new
  FileOutputStream("theTime")
• ObjectOutputStream s new
  ObjectOutputStream(out)
• s.writeInt( 12345 )
• s.writeObject("Today")
• s.writeObject(new Date())
• s.flush()

74
Notes about ObjectOutputStreams

• If an object refers to other objects, then all of
  the objects that are reachable from the first
  must be written at the same time
• ObjectOutputStream stream implements the
  DataOutput interface that defines many methods
  for writing primitive data types, such as
  writeInt, writeFloat, or writeUTF.
• You can use these methods to write primitive
  data types to an ObjectOutputStream.
• The writeObject method throws a
  NotSerializableException if it's given an object
  that is not serializable.
• An object is serializable only if its class
  implements the Serializable interface.
• Serializable is a marker interface you just
  declare you implement it but do not need to
  implement any additional method.

75
How to Read from an ObjectInputStream

• EX
• FileInputStream in new
  FileInputStream("theTime")
• ObjectInputStream s new
  ObjectInputStream(in)
• int d s.readInt()
• String today (String)s.readObject()
• Date date (Date)s.readObject()
• ObjectInputStream stream implements the DataInput
  interface that defines methods for reading
  primitive data types. Use these methods to read
  primitive data types from an ObjectInputStream.
• The order and types of objects read in must be
  the same as they were written out using
  ObjectOutputStream.

76
The java.io.datainput interface

• public abstract interface java.io.DataInput
  // Methods
• public abstract lttypegt readltTypegt()
• // lttypegt is any of 8 primitive types byte,
  short, char, int, long, float, dobule, boolean.
• public abstract void readFully(byte b , int
  off, int len )
• public abstract String readLine()
• public abstract int readUnsignedByte()
• public abstract int readUnsignedShort()
• public abstract String readUTF()
• public abstract int skipBytes(int n)

77
The java.io.ObjectInput Interface

• public abstract interface java.io.ObjectInput
  extends java.io.DataInput
• // Methods
• public abstract int available()
• public abstract void close()
• public abstract int read()
• public abstract int read(byte b)
• public abstract int read(byte b, int off, int
  len)
• public abstract Object readObject()
• public abstract long skip(long n)

78
java.io.ObjectInputStream

• public class java.io.ObjectInputStream extends
  java.io.InputStream
• implements java.io.ObjectInput
• // Constructors
• public ObjectInputStream(InputStream in)
• // Public Instance Methods implementation of
  ObjectInput
• readObject(), readInt() ,
• // Read the non-static and non-transient fields
  of the current class from this stream. may only
  be called by readObject() of the object to be
  deserialized.
• public final void defaultReadObject()
• public synchronized void registerValidation(Objec
  tInputValidation obj, int prioity)
• ObjectInputValidation.validateObject() can be
  used to validate read-in object.
• There can be more than one validation objects
  registered, each called back according to prioity
  ( 0 ? first ).
• See this reference for an explanation of
  objectInputValidation

79

• // Protected Instance Methods
• protected final boolean enableResolveObject(bool
  ean enable)
• protected void readStreamHeader()
• protected Class resolveClass(ObjectInputStreamCl
  ass v)
• protected Object resolveObject(Object obj)

80
The DataOutput interface

• public abstract interface java.io.DataOutput
  // Methods
• public abstract void write(byte b)
• public abstract void write(byte b, int off,
  int len)
• public abstract void write(int b)
• public abstract void writeltTypegt(lttypegt v)
• where ltTypegt is any of Boolean, Byte, Char,
  Short, Int, Long, Float, Double., and
  corresponding ltTypegt is int, int, int, int, long,
  float and double.
• public abstract void writeUTF(String str)

81
The DataOutput Stream

• public abstract interface java.io.ObjectOutput
  extends java.io.DataOutput
• // Methods
• public abstract void close()
• public abstract void flush()
• public abstract void write(int b)
• public abstract void write(byte b)
• public abstract void write(byte b, int off,
  int len)
• public abstract void writeObject(Object obj)

82
the ObejctOutputStream

• public class java.io.ObjectOutputStream extends
  java.io.OutputStream
• implements java.io.ObjectOutput
• // Constructors
• public ObjectOutputStream(OutputStream out)
• // Instance Methods implementation of
  ObjectOutput.
• .
• // Write the non-static and non-transient fields
  of the current class to this stream. may only be
  called by writeObject() of the object to be
  serialized.
• public final void defaultWriteObject()
• public void flush() public void reset()
• // Protected Instance Methods used only if you
  need to extend this class.
• protected void annotateClass(Class cl)
  protected void drain()
• protected final boolean enableReplaceObject(bool
  ean enable)
• protected Object replaceObject(Object obj)
• protected void writeStreamHeader()

83
Providing Object Serialization for Your Classes

• Implementing the Serializable Interface
• package java.io public interface
  Serializable
• Customizing Serialization
• Implementing the Externalizable Interface
• Protecting Sensitive Information

84
Customizing Serialization

• The default serialization mechanism
  (ObjectInputStream.readXXX() ObjectOutputStream.
  writeXXX())
• will read/write the type and content of every
  target object, and recursively all types and
  contents of all subobjects.
• Sometimes it is needless to read/write all fields
  of an object
• ex public class Point int x,y float r,
  theta
• For point object, we may want to save x and y
  only.
• Solution use the transient modifier
• pubilc class Point int x,y transient float
  r, theta
• Every transiant field will not be read/written by
  during object serialization.
• Problem How to recover r, theta from read x and
  y ?
• Customizing serialization!!

85

• public class Point implement Serializable
• int x,y
• transiant float r, theta
• private readObject(ObjectInputStream oin )
• oin.defaultReadObject() // this will set x
  and y only.
• r Math.sqrt( x x y y )
• theta (float ) Math.arcTan( (double) y / x
  )

86
More Example

• public class LabeledPoint implements Serializable

• private String label
• private transient Point2D.Double point
• pri
