CS276: Information Retrieval and Web Search

1

• CS276 Information Retrieval and Web Search
• Pandu Nayak and Prabhakar Raghavan
• Lecture 6 Scoring, Term Weighting and the Vector
  Space Model

2
Recap of lecture 5

• Collection and vocabulary statistics Heaps and
  Zipfs laws
• Dictionary compression for Boolean indexes
• Dictionary string, blocks, front coding
• Postings compression Gap encoding, prefix-unique
  codes
• Variable-Byte and Gamma codes

collection (text, xml markup etc) 3,600.0
collection (text) 960.0
Term-doc incidence matrix 40,000.0
postings, uncompressed (32-bit words) 400.0
postings, uncompressed (20 bits) 250.0
postings, variable byte encoded 116.0
postings, g-encoded 101.0
MB
3
This lecture IIR Sections 6.2-6.4.3

• Ranked retrieval
• Scoring documents
• Term frequency
• Collection statistics
• Weighting schemes
• Vector space scoring

4
Ranked retrieval
Ch. 6

• Thus far, our queries have all been Boolean.
• Documents either match or dont.
• Good for expert users with precise understanding
  of their needs and the collection.
• Also good for applications Applications can
  easily consume 1000s of results.
• Not good for the majority of users.
• Most users incapable of writing Boolean queries
  (or they are, but they think its too much work).
• Most users dont want to wade through 1000s of
  results.
• This is particularly true of web search.

5
Problem with Boolean searchfeast or famine
Ch. 6

• Boolean queries often result in either too few
  (0) or too many (1000s) results.
• Query 1 standard user dlink 650 ? 200,000 hits
• Query 2 standard user dlink 650 no card found
  0 hits
• It takes a lot of skill to come up with a query
  that produces a manageable number of hits.
• AND gives too few OR gives too many

6
Ranked retrieval models

• Rather than a set of documents satisfying a query
  expression, in ranked retrieval, the system
  returns an ordering over the (top) documents in
  the collection for a query
• Free text queries Rather than a query language
  of operators and expressions, the users query is
  just one or more words in a human language
• In principle, there are two separate choices
  here, but in practice, ranked retrieval has
  normally been associated with free text queries
  and vice versa

7
Feast or famine not a problem in ranked retrieval
Ch. 6

• When a system produces a ranked result set, large
  result sets are not an issue
• Indeed, the size of the result set is not an
  issue
• We just show the top k ( 10) results
• We dont overwhelm the user
• Premise the ranking algorithm works

8
Scoring as the basis of ranked retrieval
Ch. 6

• We wish to return in order the documents most
  likely to be useful to the searcher
• How can we rank-order the documents in the
  collection with respect to a query?
• Assign a score say in 0, 1 to each document
• This score measures how well document and query
  match.

9
Query-document matching scores
Ch. 6

• We need a way of assigning a score to a
  query/document pair
• Lets start with a one-term query
• If the query term does not occur in the document
  score should be 0
• The more frequent the query term in the document,
  the higher the score (should be)
• We will look at a number of alternatives for this.

10
Take 1 Jaccard coefficient
Ch. 6

• Recall from Lecture 3 A commonly used measure of
  overlap of two sets A and B
• jaccard(A,B) A n B / A ? B
• jaccard(A,A) 1
• jaccard(A,B) 0 if A n B 0
• A and B dont have to be the same size.
• Always assigns a number between 0 and 1.

11
Jaccard coefficient Scoring example
Ch. 6

• What is the query-document match score that the
  Jaccard coefficient computes for each of the two
  documents below?
• Query ides of march
• Document 1 caesar died in march
• Document 2 the long march

12
Issues with Jaccard for scoring
Ch. 6

• It doesnt consider term frequency (how many
  times a term occurs in a document)
• Rare terms in a collection are more informative
  than frequent terms. Jaccard doesnt consider
  this information
• We need a more sophisticated way of normalizing
  for length
• Later in this lecture, well use
• . . . instead of A n B/A ? B (Jaccard) for
  length normalization.

13
Recall (Lecture 1) Binary term-document
incidence matrix
Sec. 6.2
Each document is represented by a binary vector ?
0,1V
14
Term-document count matrices
Sec. 6.2

• Consider the number of occurrences of a term in a
  document
• Each document is a count vector in Nv a column
  below

15
Bag of words model

• Vector representation doesnt consider the
  ordering of words in a document
• John is quicker than Mary and Mary is quicker
  than John have the same vectors
• This is called the bag of words model.
• In a sense, this is a step back The positional
  index was able to distinguish these two
  documents.
• We will look at recovering positional
  information later in this course.
• For now bag of words model

16
Term frequency tf

• The term frequency tft,d of term t in document d
  is defined as the number of times that t occurs
  in d.
• We want to use tf when computing query-document
  match scores. But how?
• Raw term frequency is not what we want
• A document with 10 occurrences of the term is
  more relevant than a document with 1 occurrence
  of the term.
• But not 10 times more relevant.
• Relevance does not increase proportionally with
  term frequency.

NB frequency count in IR
17
Log-frequency weighting
Sec. 6.2

• The log frequency weight of term t in d is
• 0 ? 0, 1 ? 1, 2 ? 1.3, 10 ? 2, 1000 ? 4, etc.
• Score for a document-query pair sum over terms t
  in both q and d
• score
• The score is 0 if none of the query terms is
  present in the document.

18
Document frequency
Sec. 6.2.1

• Rare terms are more informative than frequent
  terms
• Recall stop words
• Consider a term in the query that is rare in the
  collection (e.g., arachnocentric)
• A document containing this term is very likely to
  be relevant to the query arachnocentric
• ? We want a high weight for rare terms like
  arachnocentric.

19
Document frequency, continued
Sec. 6.2.1

• Frequent terms are less informative than rare
  terms
• Consider a query term that is frequent in the
  collection (e.g., high, increase, line)
• A document containing such a term is more likely
  to be relevant than a document that doesnt
• But its not a sure indicator of relevance.
• ? For frequent terms, we want high positive
  weights for words like high, increase, and line
• But lower weights than for rare terms.
• We will use document frequency (df) to capture
  this.

20
idf weight
Sec. 6.2.1

• dft is the document frequency of t the number of
  documents that contain t
• dft is an inverse measure of the informativeness
  of t
• dft ? N
• We define the idf (inverse document frequency) of
  t by
• We use log (N/dft) instead of N/dft to dampen
  the effect of idf.

Will turn out the base of the log is immaterial.
21
idf example, suppose N 1 million
Sec. 6.2.1
term dft idft
calpurnia 1
animal 100
sunday 1,000
fly 10,000
under 100,000
the 1,000,000
There is one idf value for each term t in a
collection.
22
Effect of idf on ranking

• Does idf have an effect on ranking for one-term
  queries, like
• iPhone
• idf has no effect on ranking one term queries
• idf affects the ranking of documents for queries
  with at least two terms
• For the query capricious person, idf weighting
  makes occurrences of capricious count for much
  more in the final document ranking than
  occurrences of person.

23
Collection vs. Document frequency
Sec. 6.2.1

• The collection frequency of t is the number of
  occurrences of t in the collection, counting
  multiple occurrences.
• Example
• Which word is a better search term (and should
  get a higher weight)?

Word Collection frequency Document frequency
insurance 10440 3997
try 10422 8760
24
tf-idf weighting
Sec. 6.2.2

• The tf-idf weight of a term is the product of its
  tf weight and its idf weight.
• Best known weighting scheme in information
  retrieval
• Note the - in tf-idf is a hyphen, not a minus
  sign!
• Alternative names tf.idf, tf x idf
• Increases with the number of occurrences within a
  document
• Increases with the rarity of the term in the
  collection

25
Score for a document given a query
Sec. 6.2.2

• There are many variants
• How tf is computed (with/without logs)
• Whether the terms in the query are also weighted

26
Binary ? count ? weight matrix
Sec. 6.3
Each document is now represented by a real-valued
vector of tf-idf weights ? RV
27
Documents as vectors
Sec. 6.3

• So we have a V-dimensional vector space
• Terms are axes of the space
• Documents are points or vectors in this space
• Very high-dimensional tens of millions of
  dimensions when you apply this to a web search
  engine
• These are very sparse vectors - most entries are
  zero.

28
Queries as vectors
Sec. 6.3

• Key idea 1 Do the same for queries represent
  them as vectors in the space
• Key idea 2 Rank documents according to their
  proximity to the query in this space
• proximity similarity of vectors
• proximity inverse of distance
• Recall We do this because we want to get away
  from the youre-either-in-or-out Boolean model.
• Instead rank more relevant documents higher than
  less relevant documents

29
Formalizing vector space proximity
Sec. 6.3

• First cut distance between two points
• ( distance between the end points of the two
  vectors)
• Euclidean distance?
• Euclidean distance is a bad idea . . .
• . . . because Euclidean distance is large for
  vectors of different lengths.

30
Why distance is a bad idea
Sec. 6.3

• The Euclidean distance between q
• and d2 is large even though the
• distribution of terms in the query q and the
  distribution of
• terms in the document d2 are
• very similar.

31
Use angle instead of distance
Sec. 6.3

• Thought experiment take a document d and append
  it to itself. Call this document d'.
• Semantically d and d' have the same content
• The Euclidean distance between the two documents
  can be quite large
• The angle between the two documents is 0,
  corresponding to maximal similarity.
• Key idea Rank documents according to angle with
  query.

32
From angles to cosines
Sec. 6.3

• The following two notions are equivalent.
• Rank documents in decreasing order of the angle
  between query and document
• Rank documents in increasing order of
  cosine(query,document)
• Cosine is a monotonically decreasing function for
  the interval 0o, 180o

33
From angles to cosines
Sec. 6.3

• But how and why should we be computing
  cosines?

34
Length normalization
Sec. 6.3

• A vector can be (length-) normalized by dividing
  each of its components by its length for this
  we use the L2 norm
• Dividing a vector by its L2 norm makes it a unit
  (length) vector (on surface of unit hypersphere)
• Effect on the two documents d and d' (d appended
  to itself) from earlier slide they have
  identical vectors after length-normalization.
• Long and short documents now have comparable
  weights

35
cosine(query,document)
Sec. 6.3
Dot product
qi is the tf-idf weight of term i in the query di
is the tf-idf weight of term i in the
document cos(q,d) is the cosine similarity of q
and d or, equivalently, the cosine of the angle
between q and d.
36
Cosine for length-normalized vectors

• For length-normalized vectors, cosine similarity
  is simply the dot product (or scalar product)
• for q, d
  length-normalized.

37
Cosine similarity illustrated
38
Cosine similarity amongst 3 documents
Sec. 6.3

• How similar are
• the novels
• SaS Sense and
• Sensibility
• PaP Pride and
• Prejudice, and
• WH Wuthering
• Heights?

term SaS PaP WH
affection 115 58 20
jealous 10 7 11
gossip 2 0 6
wuthering 0 0 38
Term frequencies (counts)
Note To simplify this example, we dont do idf
weighting.
39
3 documents example contd.
Sec. 6.3

• Log frequency weighting

• After length normalization

term SaS PaP WH
affection 3.06 2.76 2.30
jealous 2.00 1.85 2.04
gossip 1.30 0 1.78
wuthering 0 0 2.58
term SaS PaP WH
affection 0.789 0.832 0.524
jealous 0.515 0.555 0.465
gossip 0.335 0 0.405
wuthering 0 0 0.588
cos(SaS,PaP) 0.789 0.832 0.515 0.555
0.335 0.0 0.0 0.0 0.94 cos(SaS,WH)
0.79 cos(PaP,WH) 0.69
Why do we have cos(SaS,PaP) gt cos(SaS,WH)?
40
Computing cosine scores
Sec. 6.3
41
tf-idf weighting has many variants
Sec. 6.4
Columns headed n are acronyms for weight
schemes.
Why is the base of the log in idf immaterial?
42
Weighting may differ in queries vs documents
Sec. 6.4

• Many search engines allow for different
  weightings for queries vs. documents
• SMART Notation denotes the combination in use in
  an engine, with the notation ddd.qqq, using the
  acronyms from the previous table
• A very standard weighting scheme is lnc.ltc
• Document logarithmic tf (l as first character),
  no idf and cosine normalization
• Query logarithmic tf (l in leftmost column), idf
  (t in second column), no normalization

A bad idea?
43
tf-idf example lnc.ltc
Sec. 6.4
Document car insurance auto insurance Query
best car insurance
Term Query Query Query Query Query Query Document Document Document Document Prod
tf-raw tf-wt df idf wt nlize tf-raw tf-wt wt nlize
auto 0 0 5000 2.3 0 0 1 1 1 0.52 0
best 1 1 50000 1.3 1.3 0.34 0 0 0 0 0
car 1 1 10000 2.0 2.0 0.52 1 1 1 0.52 0.27
insurance 1 1 1000 3.0 3.0 0.78 2 1.3 1.3 0.68 0.53
Exercise what is N, the number of docs?
Score 000.270.53 0.8
44
Summary vector space ranking

• Represent the query as a weighted tf-idf vector
• Represent each document as a weighted tf-idf
  vector
• Compute the cosine similarity score for the query
  vector and each document vector
• Rank documents with respect to the query by score
• Return the top K (e.g., K 10) to the user

45
Resources for todays lecture
Ch. 6

• IIR 6.2 6.4.3
• http//www.miislita.com/information-retrieval-tuto
  rial/cosine-similarity-tutorial.html
• Term weighting and cosine similarity tutorial for
  SEO folk!
