DSP Algorithms on FPGA Part II Digital image Processing

1
DSP Algorithms on FPGAPart II Digital
image Processing
2
Content

• Overview image processing and FPGA
• Algorithm to FPGA Mapping Flow
• Nested Loop Algorithms and MODG
• Example Motion Estimation
• Conclusion and Future Trends

3
Video signal in different formats

• PAL 720576(pixels) 25 (f/s) 10.4 (Mp/s)

• NTSC 720480 29.97 10.4
• HDTV 19201080 30.0 62.2
• Common delivery form
• Analog (cable)
• USB
• Firewire

4
Image Processing Character

• Need available maximize logic by supporting N-D
  multiple configurable devices
• For Example
• Image

1 2 1
2 4 2
1 2 1
5
Challenges

• How to???
• Appropriate partitioning of algorithms between
  hardware and software
• Exploiting spatial and temporal parallelism
• Integration the configurable computer into the
  software framework
• Selecting a suitable configuration strategy
• How shall we deal with these challenges?

6
Why SRAM-Based FPGAs? (Pros)

• Higher logic/storage capacity
• Fast carry chain for adders /subtractors
• Built-in XOR gates/LUT
• Array of bit-parallel multipliers
• Fast and local storage array of SRAM
  blocks
• Interconnect supports three-state
  buffers/LUT
• Equivalent to fine-grained reconfigurable
  hardware
• Finer-gained pipeling can help preserve the
• performance at low power supply voltage
• More mature CMOS manufacturing technology

7
Algorithm to FPGA Mapping Flow
8
The Matrix Multiplication MODG
A number of different execution orders can be
carried out to achieve the same algorithm.
9
Nested Do Loop Algorithms and Inter-Iteration
Dependence Graph

• Do i1 to M
• Do j1 to N
• ci,j0
• Do k1 to K
• ci,j ci,jai,kbk,j
• EndDo k
• EndDo j
• EndDo I
• Dependence vectors
• da (i,j,k)t (0,1,0)t
• db (i,j,k)t (1,0,0)t
• dc (i,j,k)t (0,0,1)t
• Index Space J3 (i,j,k)t 1 i,j,k
  3(MNK3)
• Inter-Iteration Data Dependence graph (DG)

10
Systolic Mapping (space-time) of Matrix
Multiplication
11
Systolic Mapping of Matrix Multiplication, cont.
0
0
0
12
Why Space-Time Mapping is suitable for FPGAs?

• It can bridge the nested Do loop signal/image
  processing algorithms to the processor array
  implementation.
• The space-time array matches the modular and
  regular FPGA structure.
• The localized/pipelined interprocessor links can
  overcome the long programmable interconnect
  delay.
• The size of configuration storage can be
  significantly reduced because of the almost
  identical processing elements and interconnect
  structure.

13
Problems with Existing Design Methodologies/Tools

• The dependence graphs of many other algorithms
  are not uniform and must be predetermined by
  human designers.
• Existing methodologies
• cannot handle these complex algorithms use
  unrealistic cost functions (metrics)
• No built-in features of FPGAs have been
  incorporated.
• Longer interconnect delay in deep submicron CMOS
  technology
• Much lower hardware utilization due to
  programmable interconnect delay in FPGAs
•


  There is
  another problem--speed

14
What is Intra-PE Pipelining?

• Interconnect delay of FPGAs results in even
  longer clock period.
• To enhance the overall throughput,
  Intra-Iteration parallelism must be exploited.
• A simple vector dot product array
• It can be observed that the utilization of each
  operator is increased.
• Of course, the control mechanism is more complex.
•

  Tech done example

15
Examples of Nested Do Loop Algorithms

• Motion estimation
• One of the most time consuming operations (tasks)
  in digital video compression
• Stereo matching
• used to build disparity map for 3D robot/computer
  navigation
• Matrix/Vector Multiplication
• FFT, DCT, 2D/3D graphic etc.
• 2D Linear Transform/Operations
• 2D FFT, 2D DCT, etc.

16
Tennis frame 0
17
Tennis frame 1
18
Motion Vectors of 8x8-Pixel Blocks
19
Reconstructed Frame 1 from Frame 0 and Motion
Vectors
20
Illustration of Full Search Block Matching Motion
Estimation (6 level Nested do loop)
Motion vector(m,n)
21
Exp A Simpler PE Microarchitecture

• MAD(m,n) MAD(m,n)x(hNi,vNj)-y(hNim-p,vNjn
  -p)
• Xilinx Core Generator System
• Critical path delay 25 ns. based on Xilinx
  Virtex data
• 1,500-2,000 equivalent gate count
• Critical path (blue line) can be shortened
  further by the Intra-PE pipelining

22
Significance of the Contributions

• The MODG representation for nested Do loop
  algorithms
• The actual execution is not constrained to any
  predetermined order.
• keeps track of every variable instance so that
  there is no redundant memory access to save I/O,
  bandwidth and power consumption.
• can be automated using memory .
• Without the MODG,
• the motion estimation and many other nested DO
  loop algorithms can be written in many of
  different DGs,
• human must be involved to formulate a DG,
• the built-in ROM/RAM of FPGA may not be
  exploited, and

23
Significance of the Contributions, cont.

• Space-Time mapping for the MODG can be applied to
• any SRAM-based FPGA Architecture Constraints and
  Practical Cost functions
• any coarse-grained architecture
• Intra-PE pipelining
• enhances/preserves the throughput rate at low
  power mode.

24
Conclusion

• Users demand more communication/multimedia
  processing capabilities on the resource-limited
  Internet appliances.
• Reconfigurable SOC is the ultimate solution to
  design the challenging low-power/high performance
  platform.
• Its success lies on the embedded high-density
  FPGA core as a reconfigurable (programmable)
  accelerating hardware.
• As technology (supply voltage) scales down, logic
  (transistor) is virtually free while the
  interconnect becomes the bottleneck and power
  consuming.
• Parallel execution of nested Do loop algorithms
  by an array of localized processing elements at
  moderate clock frequency is a viable solution.
• It can compromise the three main issues design
  time, power consumption, and performance.

25
Future Trends

• Memory (storage) organization should be
  investigated due to multiple reads per-clock
  cycle in order to sustain such high throughput.
• The control mechanism of the entire array is one
  of the aspects that will determine its success.
• A given MODG may need to be partitioned of so
  that the resulting array fits the on-chip
  reconfigurable FPGA core.
