INNOV-11: An Introduction to DataDirect Shadow Products

1
INNOV-11 An Introduction to DataDirect Shadow
Products
Brian Anderson
Director of Product Strategy, DataDirect
2
Agenda
Shadow/RTE A Unified Platform for Mainframe
Integration

• History of DataDirects Shadow/RTE
• Mainframe Primer
• Accidental Mainframe Integration Architectures
• Mainframe Operational Challenges
• Technical Architecture
• Customer Use Cases
• Questions

3
History of DataDirects Shadow Products

• Progress acquired NEON Systems in Jan. 2006
• NEON Systems was leading mainframe integration
  vendor
• Data
• Events
• Services
• NEON Systems was a market consolidator in
  mainframe integration space
• Acquired InnerAccess Technologies in July 2004
• Acquired ClientSoft in December 2004
• Products in existence back to 1987

4
Leader in Gartner MQ
5
Gartner Group on Mainframe Integration
The future of the programmatic integration
market is one of fewer vendors, more focused on
SOA or event-driven architectures. They are the
leading strategies selected by organizations as
part of their legacy modernization
initiatives...
Dale Vecchio, Research VP, Gartner Magic Quadrant
for Programmatic Integration Servers,
2005 Gartner Research, February 25, 2005
6
Mainframe Primer Introduction

• What is a Mainframe
• Proprietary hardware
• Proprietary OS
• Data throughput
• High availability
• Perceived Expensive
• Legacy code
• Backward compatibility

• Mainframe Manufacturers
• Stratus
• Bull
• Siemens
• ICL
• Unisys
• Hitachi
• Tandem (HP)
• Fujitsu
• IBM
• iSeries (formerly AS/400)
• z/Series
• VM
• VSE
• z/OS

7
Evolution of the IBM Mainframe from 1965

• z/Series
• z/OS
• 64bit

• z/Series
• z/OS
• 64bit

• ES/9000
• OS/390
• 31bit

• 3090
• MVS/ESA
• 31bit

• 3084Q
• MVS/XA
• 31bit

• 3033
• MVS/SP3
• 24 bit

• s/370
• MVS
• 24 bit

• s/360
• MFT

8
State of the Art

• IBM z/Series 2094/754
• 22m
• Known as z/9
• 17802 MIPS across multiple z/OS images
• 11687 MIPS in any single z/OS image
• 54 General Purpose CPUs
• 512GB main memory
• 1024 I/O Channel Processors
• 10gb/s Data Transfer rate
• Java Co-Processor (zAAP)
• Information Management Co-Processor (zIIP)
• Crypto Co-Processor
• Usage
• 14000 z/Series machines worldwide
• 50 z/OS (50 VSE, OS/390, VM, z/Linux)

9
Mainframe Subsystems Application Portfolio

• Subsystems
• Data
• Flat Files
• QSAM,VSAM
• Hierachical
• IMS/DB, Adabas, Datacom, IDMS, M204
• Relational
• DB2, Supra, IDMS/R, Oracle
• TP Monitors (App Servers)
• IBM
• CICS, IMS/TM
• Other
• IDMS/DC, Com-Plete
• Languages
• 2GL
• Assembler
• 3GL
• Cobol, PL/1, Fortran
• 4GL

• Business Applications (25-30 yeas old)
• Inventory management
• Credit card authorization
• Retail banking
• Risk management
• Parts tracking
• ATM
• Billing
• Supply chain
• General ledger
• Student registrations
• Logistics
• Payroll

10
Mainframe Integration Drivers

• Mainframe Relevance
• Greater than 60 of the world system of record
  data on mainframe
• More than 450 of Fortune 500 rely upon mainframes
• More commercial transactions processed on
  mainframe than any other platform
• Business Pressures
• Regulatory Compliance
• Real-time Enterprise
• Increased Agility
• Total Economic Impact
• Technological Initiatives
• Business Intelligence
• Business Process Optimization
• Business Activity Monitoring
• SOA EDA

11
Typical Mainframe Accidental Architecture
3270 Screen Scraping
Management consoles
12
Significant Operational Issues

• Quality of Service (QoS)
• End-to-end solutions as strong as the weakest
  link
• Fragile implementations often based on gateways
• Lack of consolidated diagnostics
• Latency due to increased complexity
• Agility
• Complexity slows support for new applications
• Additional hardware deployment often required
• Lack of clarity on which option to choose
  analysis paralysis
• Cost
• Redundant hardware gateways for resilience
• Software licensing fees for multiple products
• Multiple vendor management
• Training costs for administration of multiple
  product
• Additional employee costs for effective
  management of all products
• Cost of systems outage due to QoS issues

13
Typical Mainframe Accidental Architecture
Wouldnt it Be Nice?
Shadow RTE A Single Unified Platform
Management consoles
14
Quality of Service

• Reliable messaging
• Support for WebSphere/MQ transport for SOAP
  additions in w/MQ 6
• RFH2 header support for URI
• Supports ErrorQ processing
• In conjunction with SDSRM enables Async
  Transactional Messaging for Web Services
• SC34-6651-00 (May 2005) details the
  implementation
• NEON implementation using MQMD for service/action
  and MQSTR structure
• Instrumentation
• Extensive. Low-overhead event tracing for all
  mainframe integrated workloads
• All nodes in the Sysplex log to the coupling
  facility
• Central correlation point for Sysplex
  transactions
• Eclipse viewing tool

• Scalability
• Sysplex routing and load balancing
• WLM support
• Proven to support thousands of transactions per
  second
• Security
• SAF interface for all interactions
• Optimizations for session-less integration
• SSL encryption of conversation
• Client SSL certificate based authentication
• Audit/chargeback
• Transactions
• Exposes XA protocol to JTS via Shadow JDBC/J2CA
  adapters
• Server Distributed Syncpoint Resource Manager
  (SDSRM)
• Full Resource Recovery Services (RRS) integration
• In Doubt transaction management

15
Shadow RTE Pluggable Features

• z/Direct SQL access to mainframe resources Data
  and Applications via ODBC, JDBC or J2CA (JCA).
• z/Services Mainframe Web services (Publish and
  Consume)
• z/Events Real-time capture, enrichment and
  publishing of critical mainframe business events.
• z/Presentation Mainframe Web enablement
• Shadow Studio Full featured, Eclipse-based IDE

16
Shadow z/Direct

• Direct SQL/Data access to
• DB2, IDMS/DB, IMS/DB, VSAM and Adabas
• Supports programs using industry standard ODBC,
  JDBC or J2CA (JCA) without any intermediate
  hardware gateways
• Makes mainframe applications appear as database
  stored procedures, supporting
• CICS, IMS/TM, Natural and IDMS/DC programs and
  presentation layer
• Scales to thousands of transactions per second
• Supports two-phase commit
• (2PC) for data integrity

17
Shadow z/Services

• Web services - SOAP-based mainframe integration
• SLI, BLI, DLI
• Sources - CICS, IMS, IDEAL, IDMS, Natural,
  databases
• Supports both Publish and Consumption
• Simplifies mainframe integration
• Flexible deployments
• Mainframe
• Shadow RTE
• CICS
• Distributed

18
SOA Mainframe Perspective

• Specific Relevance to Mainframe SOA
• Arcane systems
• Original tightly coupled development
• Fancy programming for technical expediency of a
  bygone era
• Existing mainframe integration methods force
  tight coupling
• Web Services
• Not a solution to organizational loose coupling
• Without SOA, Web Services are just 21st century
  RPCs

• Web Services with SOA

Web Services without SOA
ltSOAP-ENVBody xmlnsSI"HTTP//DEV1.NEONSYS.COM
8093/MJC/MARK01"gt lts0QSTAFFgt lts0QSTAFFInputgt lts0
ID xsitype"xsdshort"gt10lt/s0IDgt lt/s0QSTAFFInp
utgt lt/s0QSTAFFgt lt/SOAP-ENVBodygt
ltSOAP-ENVBody xmlnsSI"HTTP//DEV1.NEONSYS.COM
8093/MJC/MARK01"gt lts0QSTAFFgt lts0QSTAFFInputgt lts0
ID xsitype"xsdshort"gt10lt/s0IDgt lts0FLAG
xsitype"xsdchar"gtXlt/s0FLAGgt lts0ACCODE
xsitype"xsdshort"gt8lt/s0ACCODEgt lts0STAT
xsitype"xsdshort"gt5lt/s0STATgt lt/s0QSTAFFInputgt
lt/s0QSTAFFgt lt/SOAP-ENVBodygt
19
Shadow z/Events

• Mainframe Business Event Management
• Real-time Change Data Capture
• Maintain data consistency with mainframe system
  of record
• Automate heterogeneous business processes
• Non-invasive event capture
• ADABAS, DB2, Native VSAM, CICS VSAM, IDMS and IMS
  DB
• Messaging support
• WMQ, HTTP/HTTPS,
• as well as inbound
• J2CA communications

20
Shadow z/Presentation

• Mainframe screen access via Web browser
• Development of web channels
• Access mainframe screen-based applications
• Repurpose/Rejuvenation user interface
• Screen aggregration for process reengineering
• Non-invasive
• Integrate with other Web components

21
Success Story - ABN/AMROShadow/RTE

• Why DataDirect?
• Shadow RTE selected through exhaustive RFI/RFP
  process
• Shadow RTE achieved technical win during POC
• ABN/AMRO advised that early metrics show gt50
  development time reduction and a 30 reduction in
  mainframe MIPS
• Shadow RTE enables ABN/AMRO systems to achieve
  application agility escaping the limitations of
  their previous technologies
• PERFORMANCE PERFORMANCE PERFORMANCE!

• Challenges
• Due to compliance issues, ABNs commercial
  banking unit required a replacement of MDp
• Essentially all business applications are
  embedded into MDp, MQ, Gideon and Sybase servers,
  including mortgage, teller, commercial loans,
  small business, VRU
• Over 1M request/day flow through Gideon
• Wanted to eliminate need for MDp developer and
  reduce development time by 50
• More importantly, they required a solution that
  would preserve and use much of the existing
  business logic and client code

22
Success Story - Her Majestys Land Registry (UK)
z/Direct

• Results
• Shadow provided enterprise-class integration for
  business-critical, distributed applications with
  the companys DB2 mainframe database.
• Faster, reliable access to DB2 data resulted in
  higher quality of service.
• Performance metrics exceed 30,000,000 SQL calls
  per hour (peak), 300,000,000 SQL calls per day
  every day
• Reduced management complexity

• Challenges
• Needed an easy-to-use, industrial-strength
  mechanism to deliver access to mainframe data in
  a mission-critical application from a Java
  environment
• Required support for both ODBC and JDBC
  applications accessing DB2 without a middle-tier
• Performance was an absolute requirement
• 4th largest DB2 shop in the world

23
Success Story - Sempra UtilitiesShadow
z/Services

• Why DataDirect?
• Deal signed on 9/29/05
• Initially whittled vendors down to InnerAccess
  and ClientSoft in 2004
• Decision suspended for a few months
• Sempra called us back in April 2005 to move
  forward with ClientSoft due to superior
  development environment
• When customer found out ClientSoft had merged
  with NEON, they were extremely pleased
• Sempra views Shadow RTE as a truly strategic
  offering a unified platform for mainframe
  integration, not just a tactical Web services
  generator

• Challenges
• Facilitate development of mainframe Web services
  for eServices customer portal (self-service) and
  new business contractor
• Key problem was sheer complexity and time
  requirements of hand-coding of mainframe Web
  services.
• No mainframe-based in-house Web services talent

24
Success Story Wells Fargo

• Results?
• Customer since 1996
• Leveraged Shadow RTE to create customer portal
  driven primarily from existing mainframe
  functionality
• Contains an assortment of Web services for
  servicing customer accounts through a variety of
  channels e.g. internet banking, customer
  services, etc.
• Accesses primarily legacy data and transactions
  in DB2 and VSAM/CICS environment via XML, SOAP,
  and proprietary messaging.
• Over 7mm invocations of mainframe Web services
  per day

• Challenges
• Open up existing legacy databases and
  applications
• Facilitate development of mainframe customer
  portal
• Expand channels to service customer
• No mainframe-based in-house Web services talent

25
Success Story - Miami-Dade County, Florida

• Results
• Standardizing access to core mainframe
  functionality across 40 county departments
• Easily incorporated mainframe into new J2EE
  applications via Web services
• Reduced IT development and maintenance costs
  moving forward
• Enhanced services to county employees and
  taxpayers

• Challenges
• Needed to create a service-oriented architecture
  that would standardize access to multiple
  disparate mainframe systems
• In an effort to build new Web wireless
  applications, needed to enable effective reuse of
  mainframe functionality via Web services to build
  new apps
• Wanted to eliminate need for expensive
  point-to-point integration

26
Success Story - Electric Insurance Company

• Results
• Projected revenue increases of 30 by enabling
  more efficient pricing changes
• Eliminated need for redundant COBOL rating engine
• Enabled mainframe to consume .NET Web service
  from more modern Web-based rating engine
• By incorporating mainframe into new SOA, now have
  ability to offer umbrella coverage nationwide via
  the Internet

• Challenges
• Needed to enhance revenues by bringing pricing
  changes to market in a more efficient manner
• Wanted to eliminate the need for redundant policy
  rating functionality
• Needed to enable the mainframe to directly
  consume rating data from an external, Web-based
  rating engine via Web services
• Required interoperability within Microsoft .NET

27
For More Information, go to

• PSDN
• www.shadowrte.com
• www.datadirect.com
• A complete series of detailed product webinars
  including demonstrations are available at the
  above URLs.

28
Questions?
29
Thank you foryour time
30
(No Transcript)
