Potential Underground Wiring

1
Potential Underground Wiring
Lower Lions Bay Water Line Replacement
The Village of Lions Bay
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project

• Meeting with Residents
• Wednesday, September 15, 2010

lionsbay.ca
2
4.0 Policies and Actions 4.7 Providing
Effective Services k) Underground
Wiring Improve aesthetics/views, enhances
safety, and reduce power outages by moving to
underground wiring over time
Official Community Plan Adopted April 6, 2009
The Village of Lions Bay

Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
3
Project Background
The Village of Lions Bay
Since 2008 VOLB has been working with AECOM, our
engineering firm, to develop the plans for
1) the Lower Lions Bay Water Line Replacement
Project 2) the
Potential Underground Wiring Project.
The water lines are about 50 yrs old.
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
4
Lower Lions Bay Water Line Replacement
The Village of Lions Bay
Building Canada Fund Grant
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
875,000 Federal/Provincial/Municipal
Grant VOLB contribution is 291,666 Latest
Completion Date by March 31, 2012
lionsbay.ca
5
Lower Lions Bay Water Line Replacement
The Village of Lions Bay
Underground Wiring Project Assumption
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
1) BC Hydro, Shaw and TELUS utilities would
share a common trench and all be
underground wired at the same time. 2) This will
create an economy with in the project.
lionsbay.ca
6
Potential Underground Wiring Project
Since Spring 2009, VOLB has been working with
BC Hydro to submit a Beautification Grant by
September 30, 2010. This submission has been
completed, the Grant award will be announced by
January 31, 2011. This potentially is up to a
1/3 Grant of the estimated cost of the Hydro
portion of this project. BC Hydro projects costs
at approx. 500,000.
The Village of Lions Bay
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
7
Potential Underground Wiring Project
The Village of Lions Bay
Since June 2009, VOLB has been working with
Shaw Cable regarding a Community Grant. Shaw has
confirmed a contribution of a) to the public
portion of 109,250 b) to the private portion on
a Shaw customer base of 51,300
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
8
Potential Underground Wiring Project
Since Fall 2009, VOLB has been working with
TELUS regarding project funding. TELUS
Contribution a) Cost of cable material on
public property, 50 rebate. b)
Efficiencies in combining utilities of up to
30 saving on labour and repaving of the
public cut asphalt.
The Village of Lions Bay
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
9
Lower Lions Bay Water Line Replacement
The Village of Lions Bay
AECOM Presentation by Stephen Bridger, P Eng, MA
Sc, LEEDLocations
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
1) Cloudview Place 2) Lions Bay Avenue 3)
Seaview Place
lionsbay.ca
10
Lower Lions Bay Water Line Replacement
The Village of Lions Bay
AECOM Presentation Water Main Information
1) Total Length of Water Main 1,400m a)
940m of 200mm diameter pipe b) 360m of 150mm
diameter pipe c) 100m of 100mm diameter pipe
2) Service connections 63 3) Fire Hydrants
12 4) Rail Crossing 1 5) Harvey Creek Crossing
1 6) Construction Time Estimate 10 weeks
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
11
The Village of Lions Bay
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
12
Lower Lions Bay Water Line Replacement
The Village of Lions Bay
BC Hydro Presentation
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
Marcel Eigenmann Design Specialist / Leader
Field Operations John Jessop
lionsbay.ca
13
DistributionField Operations

• Lions Bay
• September 15, 2010

14
Home Owners Responsibilities

• All civil work (supply, install, own the new
  duct) on private property.
• This may require a new meter base.
• Electrical Permit
• BC Hydro Connection Charge

15
BC Hydro Standard Charges
100A or 125A 605 taxes 200A 855
taxes 400A 1703 taxes

16
BC Hydro Contact Marcel Eigenmann 604
983-8235 Marcel.eigenmann_at_bchydro.com
17
Meter Base Location Options

• There are two options for the meter location.
• Meter Base on the houseBC Hydro installs the
  cable (in customer installed and owned duct 3
  minimum)
• Meter Base is located on private property near
  the street. Customer installs private cable to
  house from the meter base.

18
Meter Base Location Options
Meter Base located away from the house. BC Hydro
cable MUST be in a 3 duct to the Meter Base.
After the Meter Base the customer MUST use
private cable. It can be in a duct or a special
type of cable can be directly buried.
19
Meter Base Trench in Rock
Note the rock that needed to be worked with to
dig the trench.
20
The Village of Lions Bay
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
21
The Village of Lions Bay
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
22
Lower Lions Bay Water Line Replacement
The Village of Lions Bay
Shaw Presentation
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
Jeff Bray, Mgr Government Regulatory
Affairs Todd Musat, Mgr, Planning Technical
Projects Van Region
lionsbay.ca
23
The Village of Lions Bay
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
24
Potential Underground Wiring
The Village of Lions Bay
Shaw Summary The Municipality of The Village of
Lions Bay with partnership with others utilities
is undertaking a beautification project to remove
all existing utilities aerial plant and replace
it with the new underground plant. These include
Lions Bay Avenue, Cloudview Place, Seaview Place
including Park Marina. Our assumption is a
common trench to supply and install Shaws new
underground plant.
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project

lionsbay.ca
25
Summary of Shaws Total Contribution Towards
Beautification Project
The Village of Lions Bay
This portion of work will be done utilizing a
common underground trench shared by Hydro, Shaw
TELUS Mainline Public Infrastructure (off-site,
along main Roads) Sharing underground common
trenching cost ? Civil cont.cost of installing
Shaws U/ground structures50 per
meter, 1635m 81,750 ? Shaws cost of supplying
all underground materials 25,000.00 ? Inspectio
n and engineering cost 2,500 ? Total Shaw
contribution for public cost 109,250
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
26
Summary of Shaws Total Contribution Towards
Beautification Project
The Village of Lions Bay
This portion of work will be done utilizing a
common underground trench shared by Hydro, Shaw
TELUS Service Entrance to each Home (on-site, on
subscribers property) Sharing underground common
trenching cost ? Civil contractors cost of
installing 11 per meter x 60m 660 per lot x
60 39,600 ? Shaws cost of supplying all
underground materials 170 x60
10,200 ? Inspection and engineering cost
1,500.00 ? Total Shaw contribution for private
portion 51,300 For Shaw Customers
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
27
Lower Lions Bay Water Line Replacement
The Village of Lions Bay
TELUS Presentation
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
Surinder Hoonjan, P Eng Valeriu Juverdeanu, P
Eng
lionsbay.ca
28
TELUS Project Comments
The Village of Lions Bay
Contractor Cost 1) We expect savings when BC
Hydro/TELUS/Shaw conduit is placed by the
same contractor at the same time on the
same tender. 2) Does not include the cost to
punch a pipe under the railway since cost
savings are possible when utilities are
placed jointly. 3) When the public portion of
the job is tendered, an optional separate
cost can be requested from the contractor
for the private property portion. Due to the
efficiencies of scale in doing the 62 lots at the
same time as the public portion, we expect
the cost to be lower than each homeowner
arranging for their own contractor.
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
29
Potential Underground Wiring
The Village of Lions Bay
Projected Cost to Residents of Lower Lions Bay
Based on Worst Case Scenario
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
Potential cost reductions 1) Consultants advise
a sole contractor for both the public and
private
portion will lead to cost savings, 2) Grants and
Grants-in-lieu will create cost reductions a) BC
Hydro Beatification Grant up to 1/3 of BC Hydro
Costs b) Shaw
Public Grant of 109,000 Shaw Private Grant
of 51,000 c) TELUS contribution-in-kind
lionsbay.ca
30
Projected Costs to Residents of Cloudview
Avenue , Lower Lions Bay Avenue and Seaview
Place
The Village of Lions Bay
Based on Worst Case Scenario Shared area
costs on Public Land 15,000 per
property Private Portion Costs Option One
Underground wiring from to your home 3,000 to
10,000 per property Option Two Installation
of a private pole, overhead wires from the road
to your home Minimum 3,000 per property
Based on experience of the Utility Companies
Utilities would bring wires underground up to the
pole at the property line
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
31
Projected Cost to Residents of Lower Lions
BayPublic Property Special Area Tax
The Village of Lions Bay
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
Public Underground Wiring Special Area Tax 1)
The cost will be paid by the Lower Lions Bay
Residents as a Special Area Tax 2)
Residents have the option to lump sum pay the
public portion 3) Council will
determine the amortization period (5, 10, 15 or
20 years) 4) The amortization is calculated
on a 5.50 interest.
lionsbay.ca
32
Projected Cost to Residents of Lower Lions
BayPrivate Property Special Area Tax
The Village of Lions Bay
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
Private Underground Wiring Special Area Tax 1)
The cost will be paid by the Lower Lions Bay
individual property owner as a Special Area
Tax, should they select this option 2)
Residents have the option to lump sum pay the
private portion 3) An amortization
program will be created for the individual
property owners that wish to
participate. Council will determine the
amortization period (5, 10, 15 or 20 years) 4)
The amortization is calculated on a 5.50
interest.
lionsbay.ca
33
Lower Lions Bay Potential Underground Wiring
The Village of Lions Bay
Amortization Period   5 YR 10 YR 15 YR 20 YR

OWNER PORTION 15,000 PER PARCEL (Public Land Improvement)   3,363.81
Due Yearly 1,823.73
  1,323.23
          1,082.45

OWNER PORTION IF 3,000 PER PARCEL (Private Land Improvement)   672.76
Due Yearly 364.75
  264.65
          216.49

OWNER PORTION IF 10,000 PER PARCEL (Private Land Improvement)   2,242.54
Due Yearly 1,215.82
  882.16
          721.64
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
lionsbay.ca
34
Lower Lions Bay Water Line Replacement
The Village of Lions Bay
We Invite Your Response
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
1) The Village will e-mail you in one week
inviting your preliminary response. 2) BC
Hydro is requesting a sense of your
response prior to the end of September,
2010 as the BC Hydro Beautification Grant
adjudication will be commencing.
lionsbay.ca
35
Lower Lions Bay Water Line Replacement
The Village of Lions Bay
Potential Underground Wiring
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
Questions ?
lionsbay.ca
36
Lower Lions Bay Water Line Replacement
The Village of Lions Bay
Potential Underground Wiring
Lower Lions Bay Water Line Replacement Potential
Underground Wiring Project
Thank you.
lionsbay.ca
