Title: CSE3213 Computer Network I


1
CSE3213 Computer Network I
  • Channelization (6.4.1-6.4.2)
  • LAN (6.6)
  • Ethernet(6.7)
  • Token-Ring (6.8.1)
  • Wireless LAN(6.10)
  • LAN Bridges(6.11.1)
  • Course page
  • http//www.cse.yorku.ca/course/3213

Slides modified from Alberto Leon-Garcia and
Indra Widjaja
2
Channelization
3
Why Channelization?
  • Channelization
  • Semi-static bandwidth allocation of portion of
    shared medium to a given user
  • Highly efficient for constant-bit rate traffic
  • Preferred approach in
  • Cellular telephone networks
  • Terrestrial satellite broadcast radio TV

4
Why not Channelization?
  • Inflexible in allocation of bandwidth to users
    with different requirements
  • Inefficient for bursty traffic
  • Does not scale well to large numbers of users
  • Average transfer delay increases with number of
    users M
  • Dynamic MAC much better at handling bursty traffic

5
Channelization Approaches
  • Frequency Division Multiple Access (FDMA)
  • Frequency band allocated to users
  • Broadcast radio TV, analog cellular phone
  • Time Division Multiple Access (TDMA)
  • Periodic time slots allocated to users
  • Telephone backbone, GSM digital cellular phone

6
Channelization FDMA
  • Divide channel into M frequency bands
  • Each station transmits and listens on assigned
    bands
  • Each station transmits at most R/M bps
  • Good for stream traffic Used in
    connection-oriented systems
  • Inefficient for bursty traffic

7
Channelization TDMA
  • Dedicate 1 slot per station in transmission
    cycles
  • Stations transmit data burst at full channel
    bandwidth
  • Each station transmits at R bps 1/M of the time
  • Excellent for stream traffic Used in
    connection-oriented systems
  • Inefficient for bursty traffic due to unused
    dedicated slots

8
Guardbands
  • FDMA
  • Frequency bands must be non-overlapping to
    prevent interference
  • Guardbands ensure separation form of overhead
  • TDMA
  • Stations must be synchronized to common clock
  • Time gaps between transmission bursts from
    different stations to prevent collisions form of
    overhead
  • Must take into account propagation delays

9
Overview of LANs
10
What is a LAN?
  • Local area means
  • Private ownership
  • freedom from regulatory constraints of WANs
  • Short distance (1km) between computers
  • low cost
  • very high-speed, relatively error-free
    communication
  • complex error control unnecessary
  • Machines are constantly moved
  • Keeping track of location of computers a chore
  • Simply give each machine a unique address
  • Broadcast all messages to all machines in the LAN
  • Need a medium access control protocol

11
Typical LAN Structure
  • Transmission Medium
  • Network Interface Card (NIC)
  • Unique MAC physical address

Ethernet Processor
ROM
12
Medium Access Control Sublayer
  • In IEEE 802.1, Data Link Layer divided into
  • Medium Access Control Sublayer
  • Coordinate access to medium
  • Connectionless frame transfer service
  • Machines identified by MAC/physical address
  • Broadcast frames with MAC addresses
  • Logical Link Control Sublayer
  • Between Network layer MAC sublayer

13
MAC Sub-layer
14
Logical Link Control Layer
  • IEEE 802.2 LLC enhances service provided by MAC

15
Encapsulation of MAC frames
16
Ethernet
17
IEEE 802.3 MAC Ethernet
  • MAC Protocol
  • CSMA/CD
  • Slot Time is the critical system parameter
  • upper bound on time to detect collision
  • upper bound on time to acquire channel
  • upper bound on length of frame segment generated
    by collision
  • quantum for retransmission scheduling
  • maxround-trip propagation, MAC jam time
  • Truncated binary exponential backoff
  • for retransmission n 0 lt r lt 2k, where
    kmin(n,10)
  • Give up after 16 retransmissions

18
IEEE 802.3 Original Parameters
  • Transmission Rate 10 Mbps
  • Min Frame 512 bits 64 bytes
  • Slot time 512 bits/10 Mbps 51.2 msec
  • 51.2 msec x 2x105 km/sec 10.24 km, 1 way
  • 5.12 km round trip distance
  • Max Length 2500 meters 4 repeaters
  • Each x10 increase in bit rate, must be
    accompanied by x10 decrease in distance

19
IEEE 802.3 MAC Frame
802.3 MAC Frame
7
1
6
6
2
4
Destination address
Source address
Information
FCS
Pad
Preamble
Length
SD
Synch
Start frame
64 - 1518 bytes
  • Every frame transmission begins from scratch
  • Preamble helps receivers synchronize their clocks
    to transmitter clock
  • 7 bytes of 10101010 generate a square wave
  • Start frame byte changes to 10101011
  • Receivers look for change in 10 pattern

20
IEEE 802.3 MAC Frame
21
IEEE 802.3 MAC Frame
  • Length bytes in information field
  • Max frame 1518 bytes, excluding preamble SD
  • Max information 1500 bytes 05DC
  • Pad ensures min frame of 64 bytes
  • FCS CCITT-32 CRC, covers addresses, length,
    information, pad fields
  • NIC discards frames with improper lengths or
    failed CRC

22
IEEE 802.3 Physical Layer
Table 6.2 IEEE 802.3 10 Mbps medium alternatives
10base5 10base2 10baseT 10baseFX
Medium Thick coax Thin coax Twisted pair Optical fiber
Max. Segment Length 500 m 200 m 100 m 2 km
Topology Bus Bus Star Point-to-point link
Hubs Switches!
Thick Coax Stiff, hard to work with
T connectors flaky
23
Ethernet Hubs Switches
Twisted Pair Cheap Easy to work
with Reliable Star-topology CSMA-CD
Twisted Pair Cheap Bridging increases
scalability Separate collision domains Full
duplex operation
24
Ethernet Scalability
  • CSMA-CD maximum throughput depends on normalized
    delay-bandwidth product atprop/X
  • x10 increase in bit rate x10 decrease in X
  • To keep a constant need to either decrease
    tprop (distance) by x10 or increase frame length
    x10

25
Fast Ethernet
Table 6.4 IEEE 802.3 100 Mbps Ethernet medium
alternatives
100baseT4 100baseT 100baseFX
Medium Twisted pair category 3 UTP 4 pairs Twisted pair category 5 UTP two pairs Optical fiber multimode Two strands
Max. Segment Length 100 m 100 m 2 km
Topology Star Star Star
  • To preserve compatibility with 10 Mbps Ethernet
  • Same frame format, same interfaces, same
    protocols
  • Hub topology only with twisted pair fiber
  • Bus topology coaxial cable abandoned
  • Category 3 twisted pair (ordinary telephone
    grade) requires 4 pairs
  • Category 5 twisted pair requires 2 pairs (most
    popular)
  • Most prevalent LAN today

26
Gigabit Ethernet
Table 6.3 IEEE 802.3 1 Gbps Fast Ethernet medium
alternatives
1000baseSX 1000baseLX 1000baseCX 1000baseT
Medium Optical fiber multimode Two strands Optical fiber single mode Two strands Shielded copper cable Twisted pair category 5 UTP
Max. Segment Length 550 m 5 km 25 m 100 m
Topology Star Star Star Star
  • Slot time increased to 512 bytes
  • Small frames need to be extended to 512 B
  • Frame bursting to allow stations to transmit
    burst of short frames
  • Frame structure preserved but CSMA-CD essentially
    abandoned
  • Extensive deployment in backbone of enterprise
    data networks and in server farms

27
10 Gigabit Ethernet
Table 6.5 IEEE 802.3 10 Gbps Ethernet medium
alternatives
10GbaseSR 10GBaseLR 10GbaseEW 10GbaseLX4
Medium Two optical fibers Multimode at 850 nm 64B66B code Two optical fibers Single-mode at 1310 nm 64B66B Two optical fibers Single-mode at 1550 nm SONET compatibility Two optical fibers multimode/single-mode with four wavelengths at 1310 nm band 8B10B code
Max. Segment Length 300 m 10 km 40 km 300 m 10 km
  • Frame structure preserved
  • CSMA-CD protocol officially abandoned
  • LAN PHY for local network applications
  • WAN PHY for wide area interconnection using SONET
    OC-192c
  • Extensive deployment in metro networks
    anticipated

28
Token Ring
29
IEEE 802.5 Ring LAN
  • Unidirectional ring network
  • 4 Mbps and 16 Mbps on twisted pair
  • Differential Manchester line coding
  • Token passing protocol provides access
  • Fairness
  • Access priorities
  • Breaks in ring bring entire network down
  • Reliability by using star topology

30
Star Topology Ring LAN
  • Stations connected in star fashion to wiring
    closet
  • Use existing telephone wiring
  • Ring implemented inside equipment box
  • Relays can bypass failed links or stations

31
Token Frame Format
Token frame format
J, K nondata symbols (line code) J begins as
0 but no transition K begins as 1 but no
transition
Starting delimiter
Access control
PPPpriority Ttoken bit Mmonitor bit
RRRreservation T0 token T1 data
I intermediate-frame bit E error-detection bit
Ending delimiter
32
802.11 Wireless LAN
33
Wireless Data Communications
  • Wireless communications compelling
  • Easy, low-cost deployment
  • Mobility roaming Access information anywhere
  • Supports personal devices
  • PDAs, laptops, data-cell-phones
  • Supports communicating devices
  • Cameras, location devices, wireless
    identification
  • Signal strength varies in space time
  • Signal can be captured by snoopers
  • Spectrum is limited usually regulated

34
Ad Hoc Communications
  • Temporary association of group of stations
  • Within range of each other
  • Need to exchange information
  • E.g. Presentation in meeting, or distributed
    computer game, or both

35
Infrastructure Network
  • Permanent Access Points provide access to Internet

36
Hidden Terminal Problem
(a)
Data Frame
A transmits data frame
C senses medium, station A is hidden from C
  • New MAC CSMA with Collision Avoidance

37
CSMA with Collision Avoidance
38
IEEE 802.11 Physical Layer Options
Frequency Band Bit Rate Modulation Scheme
802.11 2.4 GHz 1-2 Mbps Frequency-Hopping Spread Spectrum, Direct Sequence Spread Spectrum
802.11b 2.4 GHz 11 Mbps Complementary Code Keying QPSK
802.11g 2.4 GHz 54 Mbps Orthogonal Frequency Division Multiplexing CCK for backward compatibility with 802.11b
802.11a 5-6 GHz 54 Mbps Orthogonal Frequency Division Multiplexing
39
LAN Bridges
40
Hubs, Bridges Routers
  • Hub Active central element in a star topology
  • Twisted Pair inexpensive, easy to insall
  • Simple repeater in Ethernet LANs
  • Intelligent hub fault isolation, net
    configuration, statistics
  • Requirements that arise

User community grows, need to interconnect hubs
Hubs are for different types of LANs
?
Hub
Two Twisted Pairs
Station
Station
Station
41
Hubs, Bridges Routers
  • Interconnecting Hubs
  • Repeater Signal regeneration
  • All traffic appears in both LANs
  • Bridge MAC address filtering
  • Local traffic stays in own LAN
  • Routers Internet routing
  • All traffic stays in own LAN

Higher Scalability
?
42
General Bridge Issues
Network
Network
LLC
LLC
MAC
MAC
802.5
802.3
802.3
802.5
802.3
802.5
PHY
802.3
802.5
PHY
802.5
802.3
Token Ring
CSMA/CD
  • Operation at data link level implies capability
    to work with multiple network layers
  • However, must deal with
  • Difference in MAC formats
  • Difference in data rates buffering timers
  • Difference in maximum frame length

43
Bridges of Same Type
  • Common case involves LANs of same type
  • Bridging is done at MAC level

44
Transparent Bridges
  • Interconnection of IEEE LANs with complete
    transparency
  • Use table lookup, and
  • discard frame, if source destination in same
    LAN
  • forward frame, if source destination in
    different LAN
  • use flooding, if destination unknown
  • Use backward learning to build table
  • observe source address of arriving LANs
  • handle topology changes by removing old entries

45
S5
S1
S2
S3
S4
LAN1
LAN2
LAN3
B1
B2
Port 1
Port 2
Port 1
Port 2
46
S1?S5
S5
S1
S2
S3
S4
S1 to S5
S1 to S5
S1 to S5
S1 to S5
LAN1
LAN2
LAN3
B1
B2
Port 1
Port 2
Port 1
Port 2
Address Port
Address Port
S1
1
S1
1
47
S3?S2
S5
S1
S2
S3
S4
S3?S2
S3?S2
S3?S2
S3?S2
S3?S2
LAN1
LAN2
LAN3
B1
B2
Port 1
Port 2
Port 1
Port 2
Address Port
Address Port
S1
1
S1
1
S3
1
S3
1
48
S4?S3
S5
S1
S2
S3
S4
S4 S3
S4?S3
S4?S3
LAN1
LAN2
LAN3
S4?S3
B1
B2
Port 1
Port 2
Port 1
Port 2
Address Port
Address Port
S1
1
S1
1
S3
2
S3
1
2
2
S4
S4
49
S2?S1
S5
S1
S2
S3
S4
S2?S1
S2?S1
LAN1
LAN2
LAN3
B1
B2
Port 1
Port 2
Port 1
Port 2
Address Port
S1
1
S3
2
2
S4
1
S2
50
Adaptive Learning
  • In a static network, tables eventually store all
    addresses learning stops
  • In practice, stations are added moved all the
    time
  • Introduce timer (minutes) to age each entry
    force it to be relearned periodically
  • If frame arrives on port that differs from frame
    address port in table, update immediately
Write a Comment
User Comments (0)
About PowerShow.com
