Welcome to Physics Jeopardy

1
Welcome to Physics Jeopardy
Chapter 17
2
Electric Current
Circuits
Capacitance

Voltage
Electric Powers
100
100
100
100
100
200
200
200
200
200
300
300
300
300
300
400
400
400
400
400
500
500
500
500
500
Final Jeopardy Question
3
Current 100 pts
What is the unit for current?
Back
4
current 100 pts Answer
Amp c/s
Back
5
Current 200 pts
How much charge must pass in 2s for the current
to be 4.0A?
Back
6
Current 200 pts
8 c
Back
7
Current 300 pts
The rate of flow of charge in a closed circuit?
Back
8
Current 300 pts
Current
Back
9
Electric current 400pts
What is the device used to measure current and
how is it placed in the circuit?
Back
10
Current 400 pts Answer
Ammeter, series
Back
11
Current 500 pts

• Which of the following would increase the current
  threw a light bulb in a circuit?
• Adding a battery in series
• Adding a battery in parallel
• Adding a switch
• Adding another light bulb

Back
12
Current 500pts Answer
Adding a battery in series
Back
13
Circuits 100pts
What are three necessary elements To complete a
circuit?
Back
14
Circuits 100 pts
Voltage source Resistance Conducting wire
Back
15
Which is true concerning charges in
Circuits? 200 pts

• Charges that leave the positive terminal of the
  battery
• Come back through the negative terminal
• b. Charges are lost as they come back into the
  battery
• c. Charges are lost as they enter the light
  source
• d. Charges are created inside the battery

Back
16
Electric Materials 200pts Answer
a. Charges that leave the positive terminal of
the battery come back into the negative terminal

Back
17
Circuits 300 pts
What potential difference is required to cause a
6.0 A to flow through a resistance of 2.0 ohms?
Back
18
Electric Materials 300 pts
12 Volts
Back
19
Electric circuits 400
If a light goes out in a string of Christmas
lights and the whole strand goes out. Those
lights must be connected in _________.
Back
20
Electric current 400 pts Answer
Series
Back
21
Electric Circuits 500 pts
A 12 volt battery is connected to two light bulbs
in parallel, if the one light goes out what
happens to the other light?
Back
22
Electric Materials 500 pts Answer
Nothing changes
Back
23
Electric Power 100 pts
A 500 W device is connected to a 100-V power
source. What Current flows through it?
Back
24
Electric Power 100 pts Answer
5 Amps
Back
25
Electric Power 200pts
Rate at which energy is transferred is called?
Back
26
Electric Forces 200pts Answer
Power
Back
27
Electric Power 300pts
What happens to the power dissipated in a circuit
if the current increases by a factor of four, and
the resistance is doubled?
Back
28
Electric Forces 300pts Answer
Increases by a factor of thirty two.
Back
29
Electric Power 400 pts
Electric energy can be conserved by using high
voltage lines because?
Back
30
Electric Forces 400 pts Answer
Current decreases and so does the loss of power
Back
31
Electrical Power 500 pts
What power is lost when a 6 Amp current flows
through a 5 ohm resistor?
Back
32
Horizontal Forces 500 pts Answer
180 Watts
Back
33
capacitance 100 pts
What is the capacitance on a Capacitor if with a
charge of 30C and a Voltage of 120 V?
Back
34
Capacitance 100 pts Answer
.25f
Back
35
Capacitance 200 pts
What does the capacitance of a parallel capacitor
depend on?
Back
36
Capacitance 200 pts Answer
Indirectly related to C kA/d Distance
between plates Directly related to a.
Insulators between plates b. Area of plates
Back
37
Capacitance 300 pts
What is the unit of capacitance?
Back
38
Capacitance 300 pts Answer
Farad
Back
39
Capacitance 400 pts Answer
What is the energy of a capacitor that has a
voltage of 6V and a capacitance of 10 f ?
Back
40
Capacitance 400 pts

180 J
Back
41
Capacitance 500 pts
A 4f capacitor provides 100 J of energy. What is
the charge on the capacitor?
Back
42
Capacitance 500 pts Answer

28C
Back
43
Voltage 100 pts
What is another name for potential difference?
Back
44
Voltage 100 pts Answer
Voltage
Back
45
Voltage 200 pts
What current is produced if an 3 ohm resistor is
connected in series with a 9 v battery?
Back
46
voltage 200 pts Answer
3 Amps
Back
47
Voltage 300 pts
How is voltage related to Electrical potential
energy?
Back
48
Voltage 300 pts Answer
Voltage PE / q
Back
49
Voltage 400 pts
What is the voltage across a region With a
distance of 5cm and an electric Field of 4N/C?
Back
50
Voltage 400 pts Answer
.2 volts
Back
51
Voltage 500 pts
The work done on a test charge Divided by that
test charge?
Back
52
Voltage 500 pts Answer
Voltage
Back
53
Final Jeopardy
When was the internet developed?
Back
54
Final Jeopardy Answer
1960s
Back
