Animal Cells and Tissues

1
Animal Cells and Tissues

• AP Biology

2
Animal Cells and Tissues

• Four tissue types
• Epithelial
• Connective
• Muscle
• Nervous

3
Cells, Tissues and Organs
4
Epithelial Tissue

• Covers body surfaces and lines body cavities
• Three types
• Squamous epithelium comprised of flattened cells
• Cuboidal epithelium is made up of cube-shaped
  cells
• Columnar epithelium consists of elongated cells

5
Squamous Epithelial Cells

• Squamous cells have the appearance of thin, flat
  plates
• Have horizontally flattened, elliptical nuclei
  because of the thin flattened form of the cell
• Form the lining of cavities such as the mouth,
  blood vessels, heart and lungs and make up the
  outer layers of the skin

6
Squamous Epithelial Cells
7
Squamous Epithelial Cells
8
Cuboidal Epithelial Cells

• Cuboidal cells are roughly square or cuboidal in
  shape
• Each cell has a spherical nucleus in the center
• Found in glands and in the lining of the kidney
  tubules

9
Cuboidal Epithelial Cells
10
Cuboidal Epithelial Cells
11
Columnar Epithelial Cells

• Cells are elongated and column-shaped
• Nuclei are elongated and are usually located near
  the base of the cells
• Columnar epithelium forms the lining of the
  stomach and intestines
• Some columnar cells are specialized for sensory
  reception such as in the nose, ears and the taste
  buds of the tongue

12
Columnar Epithelial Cells
13
Columnar Epithelial Cells
14
Epithelial Tissue

• Simple epithelium made up of only one cell layer

• Stratified epithelium has more than a single
  layer of cells

15
Simple (Squamous)
16
Simple (Squamous)
17
Stratified (Squamous)
18
Functions of Epithelial Tissue

• Movement of materials into, out of, or around the
  body
• Protection of the internal environment against
  the external environment
• Secretion of a product

19
Examples of Epithelial Tissues

• Glands
• Intestinal goblet cells (single epithelial cells)
• Endocrine glands (multicellular)
• Many animals have skin that is composed of
  epithelium
• Vertebrates have keratin in their epithelial
  cells to reduce water loss
• Many invertebrates secrete mucus or other
  materials from their skin (earthworms)

20
Connective Tissue

• Serve many purposes in the body including
• Support
• Protection
• Binding
• Blood formation
• Fat storage
• Fill space

21
Connective Tissue

• Cells are separated from one another by a
  non-cellular matrix
• This matrix may be
• Solid as in bone
• Soft as in loose connective tissue
• Liquid as in blood

22
Types of Connective Tissue

• There are 3 main types of connective tissue
• Loose Connective Tissue
• Fibrous Connective Tissue
• Specialized Connective Tissues
• Adipose Tissue (Fat)
• Cartilage
• Bone
• Blood

23
Loose Connective Tissue (LCT)

• Fibroblasts are separated by a collagen
  fiber-containing matrix
• Collagen provides elasticity and flexibility
• Occurs beneath epithelium in skin and many
  internal organs
• Forms a protective layer over muscle, nerves and
  blood vessels

24
Fibrous Connective Tissue (FCT)

• Consists of many collagen fibers closely packed
  together
• Occurs in tendons, connecting muscle to bone
• Make up ligaments, connecting bone-to-bone at a
  joint

25
Specialized Connective Tissue Fat
26
Cartilage

• Soft
• Structural proteins deposited in the matrix
  between cells
• Forms embryonic skeletons
• Occurs in mature human adults in ears, joints and
  tip of nose

27
Cartilage
28
Bone

• Hard
• Calcium salts deposited in matrix
• Serve as a sink for calcium
• Proteins provide elasticity while minerals
  provide strength
• Dense bone has osteocytes located in lacunae
  (Haversian canals)
• Spongy bone occurs at the end of bones and absorb
  stress

29
Bone
30
Blood

• Connective tissue separated by a liquid matrix
  called plasma
• Red blood cells (erythrocytes) carry oxygen
• White blood cells (leukocytes) function in the
  immune system
• Platelets are cell fragments important in blood
  clotting
• Plasma transports glucose, wastes, CO2, hormones
  and regulate water balance for the blood

31
Blood
32
Blood
33
Muscle Tissue

• Facilitates movement by contraction of individual
  muscle cells referred to as muscle fibers
• Found only in members of the animal kingdom
• Three types
• Skeletal (Striated)
• Smooth
• Cardiac

34
Muscle Fibers

• Multinucleated with nuclei just beneath the
  plasma membrane
• Prominent striated, thread-like myofibrils
• The fundamental unit of the muscle is the
  sarcomere
• Each sarcomere consists of
• Thick filaments made of myosin at the center
• Thin filaments made of actin attached to the Z
  line

35
Muscle
36
Skeletal Muscle

• Function in conjunction with the skeletal system
  in voluntary muscle movement
• Striated with alternating bands at right angles
  to the long axis of the cell
• The bands are areas of actin and myosin deposition

37
Skeletal Muscle
38
Smooth Muscle

• Lack banding
• Spindle shaped cells that form masses
• Function in involuntary movements and/or
  autonomic responses like breathing, secretion,
  etc.
• Make up structures in the digestive system,
  reproductive tract and blood vessels

39
Smooth Muscle
40
Cardiac Muscle

• Striated
• Limited to the heart
• Cells are forked, with nucleus near the center
• Cells are connected together by disks
• Intercalated disks

41
Cardiac Muscle
42
Nervous Tissue

• Important in the integration of stimulus and
  control of the response to that stimulus
• Made of nerve cells called neurons and glial
  cells (helper cells)
• Neurons transmit nerve messages
• Glial cells are in direct contact with neurons
  and often surround them

43
Nervous Tissue

• The neuron is the functional unit of the nervous
  system
• Variable in size and shape
• Humans have about 100,000,000,000 (100 billion)
  neurons in their brain! Wow!

44
Neuron
45
Nervous Tissue

• Each neuron has a cell body, an axon and many
  dendrites
• The cell body contains the nucleus, mitochondria
  and other organelles
• The axon conducts messages away from the cell
  body
• Dendrites receive information from other cells
  and direct them to the cell body

46
Neuron Structure
