Running the GFS Parallel System Hybrid GSI/EnKF on Zeus

1
Running the GFS Parallel System Hybrid
GSI/EnKF on Zeus
NOAA/NWS/NCEP/EMC
2
This presentation contains

• Overview of Hybrid GDAS structure
• Running an experiment on Zeus w/ Hybrid (DEMO)
• New variables in configuration file
• New model input
• Submitting jobs with the Hybrid EnKF
• New model output
• Suggestions for running experiments with the
  Hybrid EnKF

3
Documentation Help

• Website http//www.emc.ncep.noaa.gov/GFS/exp.php
• Listserv (Glopara Support)
• NCEP.List.EMC.Glopara-Support_at_noaa.gov
• In Person
• Stop by my cube next to the 2nd floor breakroom,
  I dont bite ?

4
Hybrid Var-EnKF

• Whats hybrid in the hybrid GDAS?
• Augment fixed background error with information
  from ensemble forecasts
• Benefits
• Improve forecasts
• mid-latitude mass fields
• tropical winds
• fits to observations
• cool season CONUS precipitation

5
(No Transcript)
6
GDAS Hybrid Var-EnKF Flow Chart
prep
anal
fcst
post
angu
arch
echk
echk
vrfy
eobs
eomn
eupd
ecen
efmn
epos
eomg01
efcs01
earc
eomg02
efcs02
eomg03
efcs03
eomg04
efcs04
eomg05
efcs05
eomg06
efcs06
eomg07
efcs07
eomg08
efcs08
eomg09
efcs09
eomg10
efcs10
7
EnKF job steps (start to update)

• echk
• check file availability
• eobs
• select observations used in ensemble innovations
• eomn
• submit and monitor ensemble innovation jobs
• eomg01,, eomg10
• compute ensemble innovations (8 members/job)
• eupd
• compute ensemble analyses (EnKF update code)

8
EnKF job steps (re-center to archive)

• ecen
• recenter ensemble analyses about hires analysis
• efmn
• submit and monitor ensemble forecast jobs
• efcs01,, efcs10
• run ens fcst (8 members/job)
• epos
• compute ensemble mean
• spectrally smooth ens fcst
• earc
• save data cleanup

9
WARNING!!!

• Hybrid GDAS generates a LOT of output
• 80 member T254L64 ensemble
• 1316 files / cycle
• 90.8 Gbytes / cycle

10
Alternatives

• Ask yourself - Do I really need to run hybrid
  GDAS?
• Can I use a lower resolution?
• T382 hires, T190 ensemble
• T254 hires, T126 ensemble
• Can I just run the GFS long forecast?
• Use ICs from Hybrid EnKF control runs

11
GFS Hybrid EnKF Experiment (DEMO)

• New variables in configuration file
• New model input
• Submitting jobs with the Hybrid EnKF
• New model output
• Demo matches Zeus control prhy2s
• /NCEPDEV/hpssuser/g01/wx24kh/Zeus/para_gfs/prhy2s

12
Demo time

• Needed files
• Config file rlist/scratch2/portfolios/NCEPDEV
  /global/save/Kate.Howard/TUTORIAL/prhy2s
• Input/output in COMROT
• /scratch2/portfolios/NCEPDEV/global/noscrub/Kate.
  Howard/TUTORIAL/prhy2s

13
Demo time

• Experiment prhy2s
• CDATE 2012072512
• CDUMP gdas
• CSTEP fcst1
• gfs_cyc 1 (run only 00z GFS)
• DOENKF DOHYBVAR YES (Hybrid EnKF DA)
• EDATE 2012072600
• EDUMP gdas
• ESTEP prep

14
Configuration File New Variables

• To turn the Hybrid EnKF on
• DOHYBVARYES
• Tells analysis to use ensemble product
• DOENKFYES
• Turns on ensemble process scripts

15
Initial Conditions in COMROT

• Acquire initial condition files and place in
  COMROT
• biascr.CDUMP.CDATE
• satang.CDUMP.CDATE
• sfcanl.CDUMP.CDATE
• siganl.CDUMP.CDATE
• sfcanl_CDATE_memMEM (MEM member 1-80)
• siganl_CDATE_memMEM
• Where do I find Hybrid EnKF ICs?

16
Where to find ICs

• Places to acquire Hybrid EnKF control ICs for
  Zeus
• prhy2s - Summer 2012 control (July September)
• HPSS /NCEPDEV/hpssuser/g01/wx24kh/Zeus/para_gfs/p
  rhy2s
• Tutorial input
• HPSS /NCEPDEV/hpssuser/g01/wx24kh/Zeus/TUTORIAL/p
  rhy2s

17
Submitting the GFS w/ Hybrid EnKF

• While in EXPDIR, using the psub script from
  config file, type the following on the command
  line
• PSUB CONFIG CDATE gdas fcst1
• PSUB CONFIG CDATE gdas efmn

prep
anal
fcst
post
angu
arch
echk
echk
vrfy
eobs
eomn
eupd
ecen
efmn
epos
eomg
efcs
earc
18
GFS Output - Dayfiles

• Text output files containing details of run, as
  well as error messages for troubleshooting, found
  in COMROT
• Naming convention
• PSLOTCDATECDUMPCSTEP.dayfile
• New Hybrid EnKF CSTEPs

echk eobs eomn eomg eupd ecen efmn efcs epos earc
echk epre
19
GFS Output New Hybrid EnKF Data
http//www.emc.ncep.noaa.gov/GFS/exp.phpAll_files
20
Documentation Help

• Website http//www.emc.ncep.noaa.gov/GFS/exp.php
• Listserv (Glopara Support)
• NCEP.List.EMC.Glopara-Support_at_noaa.gov
• In Person
• Stop by my cube next to the 2nd floor breakroom ?

21
Questions?
