EEC 688/788 Secure and Dependable Computing

1
EEC 688/788Secure and Dependable Computing

• Lecture 7
• Wenbing Zhao
• Department of Electrical and Computer Engineering
• Cleveland State University
• wenbing_at_ieee.org

2
Outline

• Checkpointing and logging
• Checkpoint-based protocols
• Uncoordinted checkpointing
• Coordinated checkpointing
• Logging-based protocols
• Pessimistic logging
• Optimistic logging
• Causal logging

3
Chandy and Lamport Distributed Snapshot Protocol

• CL snapshot protocol is a nonblocking protocol
• TS checkpointing protocol is blocking
• CL protocol is more desirable for applications
  that do not wish to suspect normal operation
• However, CL protocol is only concerned how to
  obtain a consistent global checkpoint
• CL Protocol no coordinator, any node may
  initiate a global checkpointing
• Data structure
• Marker message equivalent to the CHECKPOINT
  message
• Marker certificate keep track to see a marker is
  received from every incoming channel

4
CL Distributed Snapshot Protocol
5
Example

• P0 channel state m0 (p1 to p0 channel)
• P1 channel state m1 (p2 to p1 channel)
• P2 channel state empty

6
Comparison of TS CL Protocols

• Similarity
• Both rely on control msgs to coordinate
  checkpointing
• Both capture channel state in virtually the same
  way
• Start logging channel state upon receiving the
  1st checkpoint msg from another channel
• Stop logging channel state after received
  checkpoint on the incoming channel
• Communication overhead similar

7
Comparison of TS CL Protocols

• Differences strategies in producing a global
  checkpoint
• TS protocol suspends normal operation upon 1st
  checkpoint msg while CL does not
• TS protocol captures channel state prior to
  taking a checkpoint, while CL captures channel
  state after taking a checkpoint
• TS protocol more complete and robust than CL
• Has fault handling mechanism

8
Log Based Protocols

• Work might be lost upon recovery using
  checkpoint-based protocols
• By logging messages, we may be able to recover
  the system to where it was prior to the failure
• System mode the execution of a process is
  modeled as a set of consecutive state intervals
• Each interval is initiated by a nondeterministic
  state or initial state
• We assume the only type of nondeterministic event
  is receiving of a message

9
Log Based Protocols

• In practice, logging is always used together with
  checkpointing
• Limits the recovery time start with the latest
  checkpoint instead of from the initial state
• Limits the size of the log after taking a
  checkpoint, previously logged events can be
  purged
• Logging protocol types
• Pessimistic logging msgs are logged prior to
  execution
• Optimistic logging msgs are logged
  asynchronously
• Causal logging nondeterministic events that not
  yet logged (to stable storage) are piggybacked
  with each msg sent
• For optimistic and causal logging, dependency of
  processes has to be tracked gt more complexity,
  longer recovery time

10
Pessimistic Logging

• Synchronously log every incoming message to
  stable storage prior to execution
• Each process periodically checkpoints its state
  no need for coordination
• Recovery a process restores its state using the
  last checkpoint and replay all logged incoming
  msgss

11
Pessimistic Logging Example

• Pessimistic logging can cope with concurrent
  failures and the recovery of two or more processes

12
Benefits of Pessimistic Logging

• Processes do not need to track their dependencies
• Logging mechanism is easy to implement and less
  error prone
• Output commit is automatically ensured
• No need to carry out coordinated global
  checkpointing
• By replaying the logged msgs, a process can
  always bring itself to be consistent with other
  processes
• Recovery can be done completely locally
• Only impact to other processes duplicate msgs
  (can be discarded)

13
Pessimistic Logging Discussion

• Reconnection
• A process must be able to cope with temporary
  connection failures and be ready to accept
  reconnections from other processes
• Application logic should be made independent from
  the transport level events event-based or
  document-based computing paradigm
• Message duplicate detection
• Messages may be replayed during recovery gt
  duplicate messages
• Transport level duplicate detection irrelevant.
  Must add mechanism in application level
  protocols, e.g., WS-ReliableMessaging
• Atomic message receiving and logging
• A process may fail right after the receiving of a
  message before it has a chance to log it to
  stable storage
• Need application-level reliable messaging
  mechanism

14
Application-Level Reliable Messaging

• Sender buffers message sent until receives an
  application-level ack
• Benefits of application-level reliable messaging
• Atomic message receiving and logging
• Facilitate distributed system recovery from
  process failures enables reconnection
• Enables optimization message received can be
  executed immediately and the logging can be
  deferred until another message is to be sent
• Logging and msg execution can be done
  concurrently
• If a process sends out a message after receiving
  several msgs, logging of msgs can be batched

15
Sender Based Message Logging

• Basic idea
• Log the message at the sending side in volatile
  memory
• Should the receiving process fail, it could
  obtain the messages logged at the sending
  processes for recovery.
• To avoid restarting from the initial state after
  a failure, a process can periodically checkpoint
  its local state and write the message log in
  stable storage (as part of the checkpoint)
  asynchronously
• Tradeoff
• Relative ordering of messages must be explicitly
  supplied by the receiver to the sender (quite
  counter-intuitive!)
• The receiver must wait for an explicit ack for
  the ordering message before it send any msgs to
  other processes (however, it can execute the
  message received immediately without delay)
• The mechanism is to prevent the formation of
  orphan messages and orphan processes

16
Orphan Message and Orphan Process

• An orphan message is one that was sent by a
  process prior to a failure, but cannot be
  guaranteed to be regenerated upon the recovery of
  the process
• An orphan process is a process that receives an
  orphan message
• If a process sends out a message and subsequently
  fails before the determinants of the messages it
  has received are properly logged, the message
  sent becomes an orphan message

17
Sender Based Message Logging Protocol Data
Structures

• A counter, seq_counter, used to assign a sequence
  number (using the current value of the counter)
  to each outgoing message
• Needed for duplicate detection
• A table for duplicate detection
• Each entry has the form ltprocess_id,max_seqgt,
  where max_seq is the maximum sequence number that
  the current process has received from a process
  with an identifier of process_id.
• A message is deemed as a duplicate if it carries
  a sequence number lower or equal to max_seq for
  the corresponding process
• Another counter, rsn_counter, used to record the
  receiving/execution order of an incoming message
• The counter is initialized to 0 and incremented
  by one for each message received

18
Sender Based Message Logging Protocol Data
Structures

• A message log (in volatile memory) for msg sent
  by the process. In addition to the msg sent, the
  following meta data is also recorded
• Destination process id, receiver_id
• Sending sequence number, seq
• Receiving sequence number, rsn.
• A history list for the messages received since
  the last checkpoint. It is used to find the
  receiving order number for a duplicate msg.
• Upon receiving a duplicate message, the process
  should supply the corresponding (original)
  receiving order number so that the sender of the
  message can log such ordering information
  properly
• Each entry in the list has the following
  information
• Sending process id, sender_id
• Sending sequence number, seq
• Receiving sequence number, rsn (assigned by the
  current process).

19
What Should be Checkpointed?

• All the data structures described above except
  the history list must be checkpointed together
  with the process state
• The two counters, one for assigning the message
  sequence number and the other for assigning the
  message receiving order, are needed so that the
  process can continue doing so upon recovery using
  the checkpoint
• The table for duplicate detection is needed for a
  similar reason.
• Why the message log must be checkpointed?
• The log is needed for the receiving processes to
  recover from a failure, and hence, cannot be
  garbage collected upon a checkpointing operation
• Additional mechanism is necessary to ensure that
  the message log does not grow indefinitely

20
Sender Based Message Logging Protocol Message
Types

• REGULAR It is used for sending regular messages
  generated by the application process, and it has
  the form ltREGULAR, seq, rsn,mgt
• ORDER It is used for the receiving process is
  notify the sending process the receiving order of
  the message. An order message carries the form
  ltORDER, m, rsngt,
• m is the message identifier consisting of a
  tuple ltsender_id, receiver_id, seqgt
• ACK It is used for the sending process (of a
  regular message) to acknowledge the receipt of
  the order message. It assumes the form ltACK, mgt

21
Sender Based Message Logging Protocol Normal
Operation

• The protocol operates in three steps for each
  message
• A regular message, ltREGULAR,seq, rsn,mgt, is sent
  from one process, e.g., Pi, to another process,
  e.g., Pj .
• Process Pj determines the receiving/execution
  order, rsn, of the regular message and informs
  the determinant information to Pi in an order
  message ltORDER, m, rsngt.
• Process Pj waits until it has received the
  corresponding acknowledgment message, ltACK, mgt,
  before it sends out any regular message.

22
(No Transcript)
23
Sender Based Message Logging Protocol Recovery
Mechanism

• On recovering from a failure, a process first
  restores its state using the latest local
  checkpoint, and then it must broadcast a request
  to all other processes in the system to
  retransmit all their logged messages that were
  sent to the process
• The recovering process retransmit the regular
  messages or the ack messages based on the
  following rule
• If the entry in the log for a message contains no
  rsn value, then a regular message is
  retransmitted because the intended receiving
  process might not have received this message.
• If the entry in the log for a message contains a
  valid rsn value, then an ack message is sent so
  that the receiving process can send regular
  messages
• When a process receives a regular message, it
  always sends a corresponding order message in
  response

24
Actions upon Receiving a Regular Message

• A process always sends a corresponding order msg
  in response
• Three scenarios with recovery
• The msg is a not duplicate the current rsn
  counter value is assigned to the msg and the
  order msg is sent. The process must wait until it
  receives the ack msg before it can send any
  regular msg
• The msg is a duplicate, and the corresponding rsn
  is found in the history list actions are
  identical to above except rsn is not newly
  assigned
• The msg is a duplicate, and no rsn is found in
  the history list the process must have
  checkpointed its state after receiving the msg
  and the msg is no longer needed for recovery.
  Hence, the order msg includes a special constant
  indicating so. The sender can then purge the msg
  in its log
• The recovering process may receive two types of
  retransmitted regular messages
• Those with a valid rsn value the rsn must be
  already part of the checkpoint. It executes the
  msg according to the order
• Those without can assign the msg to any order

25
Limitations of Sender Based Msg Logging Protocol

• Wont work in the presence of 2 or more
  concurrent failures
• Determinant for some regular msgs (i.e., rsn)
  might be lost gt orphan processes and cascading
  rollbacks

P2 may become an orphan process if P0 and P1 both
crash received mt that no one has sent
26
Truncating Senders Message Log

• Once a process completes a local checkpoint, it
  broadcasts a message containing the highest rsn
  value for the messages that it has executed prior
  to the checkpoint.
• All messages sent by other processes to this
  process that were assigned a value that is
  smaller or equal to this rsn value can now to
  purged from its message log (including those in
  stable storage as part of a checkpoint)
• Alternatively, this highest rsn value can be
  piggybacked with each message (regular or control
  messages) sent to another process to enable
  asynchronous purging of the logged messages that
  are no longer needed
