Currents

1
Currents
2
Essential Questions

• What are ocean currents?
• What is the purpose / role of ocean currents?
• What is the Coriolis Effect?
• What are thermohaline currents?
• What are the major global gyres?
• What are the major currents affecting Atlantic
  Canada?

3
What are ocean currents?
4
What is a current?

• is a continuous, directed movement of ocean water
  generated by the forces acting upon this mean
  flow, such as
• breaking waves,
• wind,
• Coriolis force,
• Temperature,
• salinity differences, and
• tides caused by the gravitational pull of the
  Moon and the Sun.

5
What is a gyre?

• Gyres are any large system of rotating ocean
  currents, particularly those involved with large
  wind movements.
• Gyres are caused by the Coriolis Effect
  planetary vorticity along with horizontal and
  vertical friction.

6

• Complete Investigating Ocean Currents Part 1 Lab

7
What is the purpose / role of ocean currents?
8
Purpose

• to carry heat from place to place in the Earth
  system
• affects regional climates
• they transport creatures around the world and
  affect the water temperature in ecosystems

9
Anomalies of surface currents

• Ocean Eddies
• form when a bend in a surface ocean current
  lengthens and eventually makes a loop, which
  separates from the main current.
• the swirling waters last for at least a few
  months
• Warm water eddies are sparse in marine life
  because the water does not have many nutrients
• Cold water eddies are usually full of nutrients
  and marine life.
• Upwelling
• where water from the deep sea travels up to the
  surface
• often happens where wind blows along a coastline
• upwelling areas are full of marine life

10
What is the Coriolis Effect?
11
Who discovered the Coriolis Effect?

• Gustave-Gaspard Coriolis
• in 1835
• he was a French engineer-mathematician

12
(No Transcript)
13
Coriolis Effect explained

• The rotation of the Earth causes an interesting
  phenomena on free moving objects on the Earth.
• Objects in the Northern Hemisphere are deflected
  to the right, while objects in the Southern
  Hemisphere are deflected to the left.
• The Coriolis effect, thus tries to force winds to
  shift towards the right or left. The Coriolis
  effect can at times cause winds to blow back up
  the pressure gradient.

14
Why does this happen?

• There are two reasons for this phenomenon
• the Earth rotates eastward
• the tangential velocity of a point on the Earth
  is a function of latitude (the velocity is
  essentially zero at the poles and it attains a
  maximum value at the Equator)

15
Analogous Example

• Thus, if a cannon were fired northward from a
  point on the Equator, the projectile would land
  to the east of its due north path. This variation
  would occur because the projectile was moving
  eastward faster at the Equator than was its
  target farther north.
• Similarly, if the weapon were fired toward the
  Equator from the North Pole, the projectile would
  again land to the right of its true path. In this
  case, the target area would have moved eastward
  before the shell reached it because of its
  greater eastward velocity. An exactly similar
  displacement occurs if the projectile is fired in
  any direction.

16
What does the Coriolis Effect affect?

• it affects the rotation of the oceanic currents
• it affects prevailing winds and the rotation of
  storms

17
What are thermohaline currents?
18
The Seas Greatest River

• http//vsx.onstreammedia.com/vsx/pbssaf/search/PBS
  Player?assetId68608ccstart97728pt0vidpbssaf
  1505entireNo
• Complete Investigating Ocean Currents Part 2
  after watching the video
• 632mins

19
How does it work?

• Thermohaline currents are driven by density
  differences in the water
• density depends on its temperature (thermo) and
  salinity (haline)
• At the earth's poles, when water freezes, the
  salt doesn't necessarily freeze with it, so a
  large volume of dense cold, salt water is left
  behind.
• When this dense water sinks to the ocean floor,
  more water moves in to replace it, creating a
  current.

20

• This current begins with the cold water near the
  North Pole and heads south between South America
  and Africa toward Antarctica, partly directed by
  the landmasses it encounters.
• In Antarctica, it gets recharged with more cold
  water and then splits in two directions -- one
  section heads to the Indian Ocean and the other
  to the Pacific Ocean.
• As the two sections near the equator, they warm
  up and rise to the surface as an upwelling.
• When they can't go any farther, the two sections
  loop back to the South Atlantic Ocean and finally
  back to the North Atlantic Ocean, where the cycle
  starts again.

21
(No Transcript)
22
Interesting details

• an underwater current circles the globe with a
  force 16 times as strong as all the world's
  rivers combined
• moves much more slowly than surface currents -- a
  few centimeters per second, compared to tens or
  hundreds of centimeters per second

23
Purpose

• It is crucial to the base of the world's food
  chain
• it transports water around the globe, it enriches
  carbon dioxide-poor, nutrient-depleted surface
  waters by carrying them through the ocean's
  deeper layers where those elements are abundant.
• nutrients and carbon dioxide from the bottom
  layers that are distributed through the upper
  layers enable the growth of algae and seaweed
  that ultimately support all forms of life
• also helps to regulate temperatures.

24
Deep ConnectionsThe Endless Voyage Series

• http//learning.aliant.net/Player/ALC_Player.asp?P
  rogIDINT_ENDVOY08
• Complete the Self test after watching the video
• 27mins

25
What are the major global gyres?
26
Major gyres

• North Atlantic Gyre
• South Atlantic Gyre
• Indian Ocean Gyre
• North Pacific Gyre
• South Pacific Gyre

27
North Atlantic Gyre

• located in the Atlantic Ocean
• contains the Sargasso Sea
• circulates clockwise
• traps man-made ocean debris in the North Atlantic
  Garbage Patch

28
South Atlantic Gyre

• the southern branch of the subtropical gyre in
  the south Atlantic
• circulates counter-clockwise
• this current allows Antarctica to maintain its
  huge ice sheet by keeping warm ocean waters away
• is the largest ocean current

29
Indian Ocean Gyre

• is located in the Indian Ocean
• circulates counter-clockwise

30
North Pacific Gyre

• located in the northern Pacific Ocean
• comprises most of the northern Pacific Ocean
• circulates clockwise
• is the largest ecosystem on our planet
• an accumulation of man-made marine debris, known
  as the Great Pacific Garbage Patch

31
South Pacific Gyre

• located south of the equator between South
  America and Australia
• circulates counter-clockwise
• is the Earth's biggest system of ocean currents
• it is mostly inactive and contains little marine
  life

32
(No Transcript)
33
What are the major currents affecting Atlantic
Canada?
34
The currents of the North Atlantic

• The Gulf Stream
• The North Atlantic Current
• The Irminger Current
• The Labrador Current
• The Greenland Current

35
(No Transcript)
36
(No Transcript)
37
The Gulf Stream

• is a powerful, warm, and swift Atlantic ocean
  current
• it originates at the tip of Florida, and follows
  the eastern coastlines of the United States and
  Newfoundland before crossing the Atlantic Ocean
• The Gulf Stream influences the climate of the
  east coast of North America from Florida to
  Newfoundland, and the west coast of Europe
• is also a significant potential source of
  renewable power generation

38
The North Atlantic Current

• is a powerful warm ocean current
• it continues the Gulf Stream northeast.
• West of Ireland it splits in two.
• one branch (the Canary Current) goes south
• the other continues north along the coast of
  northwestern Europe where it has a considerable
  warming influence on the climate.

39
The Irminger Current

• is a north Atlantic ocean current setting
  westward off the southwest coast of Iceland

40
The Labrador Current

• is a cold current in the North Atlantic Ocean
• it flows from the Arctic Ocean south along the
  coast of Labrador and passes around Newfoundland,
  continuing south along the east coast of Nova
  Scotia
• It meets the warm Gulf Stream at the Grand Banks
  southeast of Newfoundland and again north of the
  Outer Banks of North Carolina. The combination of
  these two currents produces heavy fogs and also
  created one of the richest fishing grounds in the
  world.
• In spring and early summer, this current
  transports icebergs from the glaciers of
  Greenland southwards into the trans-Atlantic
  shipping lanes.
• have a cooling effect on the Canadian Atlantic
  provinces and coastal New England

41
The Greenland Current

• is a weak cold water current that flows to the
  north along the west coast of Greenland
