Initial steps towards digital AIMD-AIMAIXM5
User group MeetingWashington DC27 February 2007
Sam Van der Stricht AIM GIS Expert EUROCONTROL
European Organisation for the Safety of Air
Navigation
2
Content

• Introduction
• Digital-AIM
• Demo
• Conclusion

3
EUROCONTROL AIM UnitDirectorate ATM Programmes

• Core business
• Defining strategy
• AIS gtgt AIM gtgt SWIM
• Standardising AI exchange
• Content models define meaning of data
• Exchange models define data exchange, AIXM,
  AMXM, WXXM
• Support to implementation
• Trials xNOTAM, D-AIM
• Architecture future European ATM Architecture
• definition (Single European Sky)
• Programmes CHAIN

4
Current Situation Lack of collaborative sharing
Flow Data
NOTAM
Flight Data
Obstacles Data
Application Data
Application Data
Terrain Data
Airspace Data
Route Net Data
Navigation Data
Aerodrome Mapping
Location Data
Weather Data
Environmental Data
5
Future situation Standardised data exchange
Common Data Bus
Aerodrome Mapping Data
Airspace Data
Route Net Data
Navigation Data
Location Data
Weather Data
Environmental Data
Flight Data
Flow Data
NOTAM
Obstacles Data
Terrain Data
6
Future situation Standardised data exchange
D-AIM ISO/OGC based
Aerodrome Mapping Data
Airspace Data
Route Net Data
Navigation Data
Location Data
Weather Data
Environmental Data
Flight Data
Flow Data
NOTAM
Obstacles Data
Terrain Data
7
Experimental ExampleSeamless Data Fusion
SkyView2
Topography FIR Jetstream
Pressure IR clouds
8
Content

• Introduction
• D-AIM
• Demo
• Conclusion

9
Digital AIM (D-AIM)

• AIM Requirements
• Deliver timely and filtered quality information
  into user contexts
• Move towards a state of information exchange and
  sharing
• EC 552/2004 interoperability regulation
• D-AIM high level principles
• Investigate new digital services in addition to
  current AIS output
• System-wide approach
• Separate data transport from data application
• Open and interoperable data sharing
• Focus on geo-spatial increment
• Leverage existing standards
• LFV Sweden EUROCONTROL collaboration

10
D-AIM PositioningCurrent AIS flow versus D-AIM
Data Users
Data Sources
Flight Briefing
Airports
Data Outputs
ATSP
CNS Infra structure
Pilots
AIP, Amd Supp AICs NOTAM PIB
AIS Organisation
Airspace Designers
Airlines
ATC
Other Airspace User
Commercial Database Providers
Digital AIM Services
Others
Other States
11
D-AIM featuring (1)

• D-AIM architectural approach based on a Service
  Oriented Architecture
• Loose coupling service dependencies are
  minimized
• Autonomy services have control over the logic
  that they encapsulate
• Abstraction services hide logic from the outside
  world
• Reusability logic is divided into services with
  the intention to promote reuse
• Discoverability services are designed to be
  outwardly descriptive so they can be found and
  assessed via available discovery mechanisms.
• Use of OGC web services specifications
• D-AIM embeds AIM standards into the current
  system to achieve geospatial information sharing
• AIXM, AMXM, WXXM
• OGC-OWS WMS, WFS, WCS, CSW

12
D-AIM featuring (2)

• D-AIM Services increment geo-enabled ATM

AIS
Distribution
Capabilities
Users
Voice AFTN (paper/text) SITA (paper/text) ACARS
(text)

• MET
• NOTAM
• TSA activation
• Navaid failure
• Route closure
• RWY/TWY closure

Voice Text
ATS Aircraft Airport
Graphic, geo-enabled, location based, timely,
filtered
D-AIM Standards AIXM AMXM (Aerodrome
Map) WFS FIS-B
SUR
ADS-B
13
D-AIM featuring (3)

• Chain generic data offerings with specific data
  needs
• Standardised D-AIM services exposed through
  standardised interfaces
• Service chaining
• Upstream generic services feed downstream
  specific services

14
D-AIM high level architecture
15
D-AIM geo server
16
Trial DefinitionTemporary Segregated Area (TSA)
AIS
FIS
AIRCRAFT
CDTI
Moving Map
Broadcast (Push)
GND Station A
GeoTemporal AIM DB
TVA
Push
Pull
GND Station B
D-AIM WFS
FIS Server
TVB
GND Station C
TVC
ATS
Broadcast Push
Active TSA Closed
Receive
Sleeping TSA Open
Moving Map
FIS-B GND Stations
17
TSA Broadcast ScenarioActivity Diagram
18
More use cases

• Runway/Taxiway closure scenario
• Creating common geo-spatial intelligence on the
  airport
• NAV, SUR, AIS plugged into common data pool
• AMDB WFS
• TRAFFIC WFS (ADS-B location)
• AMDB-TRAFFIC overlay
• MET scenarios
• SIGMET WFS
• METAR WFS
• METREPORT WFS
• Support services
• GeoBin WFS for B-XML encoding
• Catalogue service

19
D-AIM changes
20
D-AIM Benefits

• Geo-enable content provider output to enable
  downstream location based information filtering
  and decision making support
• Increase safety by making information available
  WHEN and WHERE needed
• Increase situational awareness through geospatial
  information
• Database driven common views
• Common timely geospatial intelligence
  (en-route/aerodrome)
• Fusion of multiple information sources

21
D-AIM Project Workflow
Architecture Design Use Case definition
Generic Services Implementation
Functional Services Implementation
Use Case Execution
Reporting and Demonstrations
22
Content

• Introduction
• Digital-AIM
• Demo
• Conclusion

23
Demo
24
Content

• EUROCONTROL AIM
• Digital-AIM
• Demo
• Conclusion

25
D-AIMInteroperability Objectives

• ltGeo-enabledgt
• ltTime-enabledgt
• ltSeamlessgt
• ltOpengt

Use
Produce Distribute Share
Interoperable Data Exchange
26
Inside D-AIMCross Domain Concepts View

Temporality
Services
Geometry
MetaData
Quality
AIS
AIXM
Aerodrome
AIXM,AMXM
Terrain
Grid
Data Domains
Obstacles
AIXM
Flow management
AIXM
WXXM
Weather
AIXM
Airspace management
ENXM
Environment
Common ISO/OGC concepts
27
Inside D-AIMCross Domain Services View
GeoSpatial Services
Portrayal Services
Catalogie Services

AIS
AIXM
Aerodrome
AIXM,AMXM
Terrain
Grid
AIXM
Obstacles
Data Domains
AIXM
Flow management
Weather
WXXM
Airspace management
AIXM
ENXM
Environment
ISO/OGC Standardised Services
ISO/OGC Standard Interface
28
Interoperable Data ExchangeData centric
Information Management
29
Managing Data Exchange
30
Questions?Thank you!
