Cellular Respiration

1
Cellular Respiration
2
Cellular Respiration

• L. respirare, to breathe
• (1) the oxygen-requiring stage in the breakdown
  release of energy from fuel molecules
• (2) the most prevalent efficient catabolic
  pathway for the production of ATP, in which
  oxygen is consumed as a reactant along with the
  organic fuel

3
Got ATP?

• ATP Adenosine Triphosphate
• ALL cells must produce ATP to survive
• it is the energy currency of the cell

4

• this ATP molecule allows work to be done by
  releasing energy with the breakage of the
  terminal high energy phosphate bond (between
  section C D in this diagram)

5
Cellular Respiration

• an aerobic (oxygen-requiring) process that
  produces 36 ATPs
• MOST occurs in the mitochondriathe powerhouse
  of the cell

6
Cellular Respiration

• Equation
• C6H12O6 (glucose) 6O2 ? 6CO2 6H2O energy
  (ATP)
• this is the overall net equationit is actually
  a complex reaction occurring in many steps
• note that it is the reverse of the net equation
  for photosynthesis
• produces CO2 that plants (autotrophs) need for
  photosynthesis

7
Cellular Respiration

• 3 Steps
• Glycolysis
• Krebs Cycle
• Electron Transport Chain

8
Glycolysis

• occurs in cytosol (outside the mitochondria)
• glucose is converted to pyruvate
• net gain of 2 ATPs 2 NADH
• ___
• - the coenzyme NAD is a key electron carrier in
  cellular respiration
• - another electron carrier, FADH, also plays a
  role

9
Krebs Cycle

• occurs within the mitochondrial matrix
• pyruvate enters this multi-step cycle
• net gain of 2 ATPs, NADH FADH2

10
Electron Transport Chain

• occurs within the inner membrane (cristae) of the
  mitochondria
• NADH FADH2 supply electrons
• produces of 32 ATPs
• oxygen (O2) is final electron acceptor in this
  reaction this is why we ( all animals)
  must have O2 to live!

11
Fermentation

• a process much less efficient that cellular
  respiration which occurs in the absence of oxygen
  (an anaerobic process)
• produces a net gain of 2 ATPs (vs. 36 ATPs with
  respiration)
• occurs both in cells of organisms that live away
  from oxygen, and in cells that normally perform
  cellular respirationbut at times of insufficient
  O2 availability
• example lactic acid fermentation in human muscle
  cells during intense, anaerobic exercise (e.g.
  sprinting)

12
Cellular Respiration Animation
from University of Rochester Medical Centers
Life Science Learning Center
Click on the hyperlink button below. Then hit
okay. Click on the message pull down select
Allow Blocked Content Then hit
yes Remember click, okay, allow yes!
C\Documents and Settings\pchandleriii1\Desktop\Re
spiration presentation\respiration.html
13
Chemical Pathways
14
Cell Membrane
15
Cellular Respiration Mini Quiz

• 1. Photosynthesis is to chloroplasts as cellular
  respiration is to
• a. chloroplasts
• b. mitochondria
• c. cytoplasm
• d. nuclei

16
Cellular Respiration Mini Quiz

• 1. Photosynthesis is to chloroplasts as cellular
  respiration is to
• a. chloroplasts
• b. mitochondria
• c. cytoplasm
• d. nuclei

17
Cellular Respiration Mini Quiz

• 2. The products of photosynthesis are the
• a. products of cellular respiration
• b. products of glycolysis
• c. reactants of cellular respiration
• d. reactants of fermentation

18
Cellular Respiration Mini Quiz

• 2. The products of photosynthesis are the
• a. products of cellular respiration
• b. products of glycolysis
• c. reactants of cellular respiration
• d. reactants of fermentation

19
Cellular Respiration Mini Quiz

• 3. Which of the following is the correct sequence
  of events in cellular respiration?
• a. glycolysis ? fermentation ? Krebs cycle
• b. Krebs cycle ? electron transport ? glycolysis
• c. glycolysis ? Krebs cycle ? electron transport
• d. Krebs cycle ? glycolysis ? electron transport

20
Cellular Respiration Mini Quiz

• 3. Which of the following is the correct sequence
  of events in cellular respiration?
• a. glycolysis ? fermentation ? Krebs cycle
• b. Krebs cycle ? electron transport ? glycolysis
• c. glycolysis ? Krebs cycle ? electron transport
• d. Krebs cycle ? glycolysis ? electron transport

21
Cellular Respiration Mini Quiz

• 4. Which of these processes takes place in the
  cytoplasm of a cell (NOT in the mitochondria)?
• a. glycolysis
• b. Krebs cycle
• c. electron transport
• d. ALL of the above

22
Cellular Respiration Mini Quiz

• 4. Which of these processes takes place in the
  cytoplasm of a cell (NOT in the mitochondria)?
• a. glycolysis
• b. Krebs cycle
• c. electron transport
• d. ALL of the above

23
Cellular Respiration Mini Quiz

• 5. What is the correct equation for
  cellular respiration?
• a. 6O2 C6H12O6 ? 6CO2 6H2O Energy
• b. 6O2 C6H12O6 Energy ? 6CO2 6H2O
• c. 6CO2 6H2O ? 6O2 C6H12O6 Energy
• d. 6CO2 6H2O Energy ? 6O2 C6H12O6

24
Cellular Respiration Mini Quiz

• 5. What is the correct equation for
  cellular respiration?
• a. 6O2 C6H12O6 ? 6CO2 6H2O Energy
• b. 6O2 C6H12O6 Energy ? 6CO2 6H2O
• c. 6CO2 6H2O ? 6O2 C6H12O6 Energy
• d. 6CO2 6H2O Energy ? 6O2 C6H12O6
