XML, Schemas, and Queries

1
XML, Schemas, and Queries

• Zachary G. Ives
• University of Pennsylvania
• CIS 455 / 555 Internet and Web Systems
• December 8, 2015

2
Readings Reminders

• Reminder Homework 1 Milestone 2 due 2/15 _at_
  1159PM
• XML, DTD, Schema
• XPath
• XSLT
• For next week Altinel Franklin paper on XFilter

3
Kinds of Content

• Keyword search and inverted indices are great for
  locating text documents
• But what if we want to index and/or share other
  kinds of content?
• Spreadsheets
• Maps
• Purchase records
• Objects
• etc.
• Lets talk about structured data representation
  and transport, then later indexing and retrieval

4
Sending Data

• How do we send data within a program?
• What is the implicit model?
• How does this change when we need to make the
  data persistent?
• What happens when we are coupling systems?
• How do we send data between programs on the same
  machine?
• Between different machines?

5
Marshalling

• Converting from an in-memory data structure to
  something that can be sent elsewhere
• Pointers -gt something else
• Specific byte orderings
• Metadata
• Note that the same logical data gets a different
  physical encoding
• A specific case of Codds idea of
  logical-physical separation
• Data model vs. data

6
Communication and Streams

• When storing data to disk, we have a combination
  of sequential and random access
• When sending data on the wire, data is only
  sequential
• Stream-based communication based on packets
• What are the implications here?
• Pipelining, incremental evaluation,

7
Why Data Interchange Is Hard

• Need to be able to understand
• Data encoding (physical data model)
• May have syntactic heterogeneity
• Endian-ness, marshalling issues
• Impedance mismatches
• Data representation (logical data model)
• May have semantic heterogeneity
• Imprecise and ambiguous values/descriptions

8
Examples

• MP3 ID3 format record at end of file

offset length description
0 3 "TAG" identifier string.
3 30 Song title string.
33 30 Artist string.
63 30 Album string.
93 4 Year string.
97 28 Comment string.
125 1 Zero byte separator.
126 1 Track byte.
127 1 Genre byte.
9
Examples

• JPEG JFIF header
• Start of Image (SOI) marker -- two bytes (FFD8)
• JFIF marker (FFE0)
• length -- two bytes
• identifier -- five bytes 4A, 46, 49, 46, 00
  (the ASCII code equivalent of a zero terminated
  "JFIF" string)
• version -- two bytes often 01, 02
• the most significant byte is used for major
  revisions
• the least significant byte for minor revisions
• units -- one byte Units for the X and Y
  densities
• 0 gt no units, X and Y specify the pixel aspect
  ratio
• 1 gt X and Y are dots per inch
• 2 gt X and Y are dots per cm
• Xdensity -- two bytes
• Ydensity -- two bytes
• Xthumbnail -- one byte 0 no thumbnail
• Ythumbnail -- one byte 0 no thumbnail
• (RGB)n -- 3n bytes packed (24-bit) RGB values
  for the thumbnail pixels, n Xthumbnail
  Ythumbnail

10
Finding File Formats

• http//www.wikipedia.org/
• http//www.wotsit.org/
• etc.

11
The Problem

• You need to look into a manual to find file
  formats
• (At best, e.g., MS .DOC file format)
• The Web is about making data exchange easier
  Maybe we can do better!
• The mother of all file formats

12
Desiderata for Data Interchange

• Ability to represent many kinds of information
• Different data structures
• Hardware-independent encoding
• Endian-ness, UTF vs. ASCII vs. EBCDIC
• Standard tools and interfaces
• Ability to define shape of expected data
• With forwards- and backwards-compatibility!
• Thats XML

13
Consumers of XML

• A myriad of tools and interfaces, including
• DOM document object model
• Standard OO representation of an XML tree
• SAX simple API for XML
• An event-driven parser interface for XML
• startElement, endElement, etc.
• Ant Java-based make tool with XML makefile
• XPath, XQuery, XSL, XSLT
• Web service standards
• Anything AJAX (mash-ups)

14
XML as a Data Model

• XML information set includes 7 types of nodes
• Document (root)
• Element
• Attribute
• Processing instruction
• Text (content)
• Namespace
• Comment
• XML data model includes this, plus typing info,
  plus order info and a few other things

15
Example XML Document
Processing Instr.

• lt?xml version"1.0" encoding"ISO-8859-1" ?gt
• ltdblpgt
• ltmastersthesis mdate"2002-01-03"
  key"ms/Brown92"gt
•   ltauthorgtKurt P. Brownlt/authorgt
•   lttitlegtPRPL A Database Workload
  Specification Languagelt/titlegt
•   ltyeargt1992lt/yeargt
•   ltschoolgtUniv. of Wisconsin-Madisonlt/schoolgt
•   lt/mastersthesisgt
• ltarticle mdate"2002-01-03" key"tr/dec/SRC1997-
  018"gt
•   lteditorgtPaul R. McJoneslt/editorgt
•   lttitlegtThe 1995 SQL Reunionlt/titlegt
•   ltjournalgtDigital System Research Center
  Reportlt/journalgt
•   ltvolumegtSRC1997-018lt/volumegt
•   ltyeargt1997lt/yeargt
•   lteegtdb/labs/dec/SRC1997-018.htmllt/eegt
•   lteegthttp//www.mcjones.org/System_R/SQL_Reunio
  n_95/lt/eegt
•   lt/articlegt

Open-tag
Element
Attribute
Close-tag
16
XML Data Model Visualized( Document Object
Model)
attribute
root
p-i
element
Root
text
dblp
?xml
mastersthesis
article
mdate
mdate
key
key
author
title
year
school
2002
editor
title
year
journal
volume
ee
ee
2002
1992
1997
The
ms/Brown92
tr/dec/
PRPL
Digital
db/labs/dec
Univ.
Paul R.
Kurt P.
SRC
http//www.
17
A Few Common Uses of XML

• Serves as an extensible HTML
• Allows custom tags (e.g., used by MS Word,
  openoffice)
• Supplement it with stylesheets (XSL) to define
  formatting
• Provides an exchange format for data (still need
  to agree on terminology)
• Tables, objects, etc.
• Format for marshalling and unmarshalling data in
  Web Services

18
XML as a Super-HTML(MS Word)

• lth1 class"Section1"gtlta name"_top /gtCIS 550
  Database and Information Systemslt/h1gt
• lth2 class"Section1"gtFall 2003lt/h2gt
• ltp class"MsoNormal"gt
• ltplacegt311 Townelt/placegt, Tuesday/Thursday
• lttime Hour"13" Minute"30"gt130PM
  300PMlt/timegt
• lt/pgt

19
XML Easily Encodes Relations
Student-course-grade
id course grade
1 330-f03 B
23 455-s04 A

• ltstudent-course-gradegt
• lttuplegt ltsidgt1lt/sidgtltcoursegt330-f03lt/coursegtltgra
  degtBlt/gradegtlt/tuplegt
• lttuplegt ltsidgt23lt/sidgtltcoursegt455-s04lt/coursegtltgr
  adegtAlt/gradegtlt/tuplegt
• lt/student-course-gradegt

20
It Also Encodes Objects (with Pointers
Represented as IDs)

• ltprojectsgt
• ltproject classcse455 gt
• lttypegtProgramminglt/typegtltmemberListgt
• ltteamMembergtJoanlt/teamMembergt
• ltteamMembergtJilllt/teamMembergt
• lt/memberListgtltcodeURLgtwww.lt/codeURLgtltincorpora
  tesProjectFrom classcse330 /gt
• lt/projectgt

21
XML and Code

• Web Services (.NET, Java web service toolkits)
  are using XML to pass parameters and make
  function calls marshalling as part of remote
  procedure calls
• SOAP WSDL
• Why?
• Easy to be forwards-compatible
• Easy to read over and validate (?)
• Generally firewall-compatible
• Drawbacks? XML is a verbose and inefficient
  encoding!
• But if the calls are only sending a few 100s of
  bytes, who cares?

22
XML When Tags Are Used by Different Sources

• Namespaces allow us to specify a context for
  different tags
• Two parts
• Binding of namespace to URI
• Qualified names
• lttag xmlnsmynshttp//www.fictitious.com/mypath
  xmlnshttp//www.default/mypathgt
• ltthistaggtis in default namespacelt/thistaggt
• ltmynsthistaggtthis a different
  taglt/mynsthistaggtlt/taggt

23
XML Isnt Enough on Its Own

• Its too unconstrained for many cases!
• How will we know when were getting garbage?
• How will we query?
• How will we understand what we got?

24
Document Type Definitions (DTDs)

• DTD is an EBNF grammar defining XML structure
• XML document specifies an associated DTD, plus
  the root element
• DTD specifies children of the root (and so on)
• DTD defines special significance for attributes
• IDs special attributes that are analogous to
  keys for elements
• IDREFs references to IDs
• IDREFS space-delimited list of IDREFs

25
An Example DTD

• Example DTD
• lt!ELEMENT dblp((mastersthesis article))gt
• lt!ELEMENT mastersthesis(author,title,year,school,c
  ommitteemember)gt
• lt!ATTLIST mastersthesis(mdate CDATA REQUIRED ke
  y ID REQUIRED
• advisor CDATA IMPLIEDgt
• lt!ELEMENT author(PCDATA)gt
• Example use of DTD in XML file
• lt?xml version"1.0" encoding"ISO-8859-1" ?gt
• lt!DOCTYPE dblp SYSTEM my.dtd"gt
• ltdblpgt

26
DTDs Are Very Limited

• DTDs capture grammatical structure, but have some
  drawbacks
• Only string scalar types
• Global ID/reference space is inconvenient
• No way of defining OO-like inheritance

27
XML Schema DTDs Rethought

• Features
• XML syntax
• Better way of defining keys using XPaths
• Type subclassing
• And, of course, built-in datatypes

28
Basic Constructs of Schema

• Separation of elements (and attributes) from
  types
• complexType is a structured type
• It can have sequences or choices
• element and attribute have name and type
• Elements may also have minOccurs and maxOccurs
• Subtyping, most commonly using
• ltcomplexContentgt ltextension baseprevTypegt
  lt/gt

29
Simple Schema Example

• ltxsdschema xmlnsxsd"http//www.w3.org/2001/XMLS
  chema"gt
• ltxsdelement namemastersthesis"
  typeThesisType"/gt
• ltxsdcomplexType nameThesisType"gt
• ltxsdattribute namemdate" type"xsddate"/gt
• ltxsdattribute namekey" type"xsdstring"/gt
• ltxsdattribute nameadvisor" type"xsdstring"/gt
• ltxsdsequencegt
• ltxsdelement nameauthor" typexsdstring"/gt
• ltxsdelement nametitle" typexsdstring"/gt
• ltxsdelement nameyear" typexsdinteger"/gt
• ltxsdelement nameschool" typexsdstring/gt
• ltxsdelement namecommitteemember"
  typeCommitteeType minOccurs0"/gt
• lt/xsdsequencegt
• lt/xsdcomplexTypegt

30
Embedding XML Schema

• ltroot xmlnsxsi"http//www.w3.org/2000/10/XMLSche
  ma-instance" xsinoNamespaceSchemaLocation"s1.xsd
  " gt ltgradegtalt/gradegt lt/rootgt
• lts1root xmlnss1"http//www.schemaValid.com/s1ns
  " xmlnsxsi"http//www.w3.org/2000/10/XMLSchema-i
  nstance" xsischemaLocation"http//www.schemaVali
  d.com/s1ns s1ns.xsd" gt lts1gradegtalt/s1gradegt
  lt/s1rootgt
• But the XML parser is actually free to ignore
  this the schema is typically specified from
  outside the document

31
Designing an XML Schema/DTD

• Often we are given a DTD/Schema if not, we need
  to design one
• We orient the XML tree around the central
  objects in a particular application

32
Manipulating XML

• Sometimes
• Need to restructure an XML document
• Or simply need to retrieve certain parts that
  satisfy a constraint, e.g.
• All books
• All books by author XYZ

33
Document Object Model (DOM)vs. Queries

• Build a DOM tree (as we saw earlier) and access
  via Java (etc.) DOMNode object
• DOM objects have methods like getFirstChild(),
  getNextSibling
• Common way of traversing the tree
• Can also modify the DOM tree alter the XML
  via insertAfter(), etc.
• Alternate approach a query language
• Define some sort of a template describing
  traversals from the root of the directed graph
• In XML, the basis of this template is called an
  XPath
• Can also declare some constraints on the values
  you want
• The XPath returns a node set of matches

34
XPaths

• In its simplest form, an XPath is like a path in
  a file system
• /mypath/subpath//morepath
• The XPath returns a node set representing the XML
  nodes (and their subtrees) at the end of the path
• XPaths can have node tests at the end, returning
  only particular node types, e.g., text(),
  processing-instruction(), comment(), element(),
  attribute()
• XPath is fundamentally an ordered language it
  can query in order-aware fashion, and it returns
  nodes in order

35
Sample XML

• lt?xml version"1.0" encoding"ISO-8859-1" ?gt
• ltdblpgt
• ltmastersthesis mdate"2002-01-03"
  key"ms/Brown92"gt
•   ltauthorgtKurt P. Brownlt/authorgt
•   lttitlegtPRPL A Database Workload
  Specification Languagelt/titlegt
•   ltyeargt1992lt/yeargt
•   ltschoolgtUniv. of Wisconsin-Madisonlt/schoolgt
•   lt/mastersthesisgt
• ltarticle mdate"2002-01-03" key"tr/dec/SRC1997-
  018"gt
•   lteditorgtPaul R. McJoneslt/editorgt
•   lttitlegtThe 1995 SQL Reunionlt/titlegt
•   ltjournalgtDigital System Research Center
  Reportlt/journalgt
•   ltvolumegtSRC1997-018lt/volumegt
•   ltyeargt1997lt/yeargt
•   lteegtdb/labs/dec/SRC1997-018.htmllt/eegt
•   lteegthttp//www.mcjones.org/System_R/SQL_Reunio
  n_95/lt/eegt
•   lt/articlegt

36
XML Data Model Visualized
attribute
root
p-i
element
Root
text
dblp
?xml
mastersthesis
article
mdate
mdate
key
key
author
title
year
school
2002
editor
title
year
journal
volume
ee
ee
2002
1992
1997
The
ms/Brown92
tr/dec/
PRPL
Digital
db/labs/dec
Univ.
Paul R.
Kurt P.
SRC
http//www.
37
Some Example XPath Queries

• /dblp/mastersthesis/title
• /dblp//editor
• //title
• //title/text()

38
Context Nodes and Relative Paths

• XPath has a notion of a context node its
  analogous to a current directory
• . represents this context node
• .. represents the parent node
• We can express relative paths
• subpath/sub-subpath/../.. gets us back to the
  context node
• By default, the document root is the context node

39
Predicates Filtering Operations

• A predicate allows us to filter the node set
  based on selection-like conditions over
  sub-XPaths
• /dblp/articletitle Paper1
• which is equivalent to
• /dblp/article./title/text() Paper1
• because of type coercion. What does this do
• /dblp/article_at_key 123 and ./title/text()
  Paper1 and ./author//element()

40
Axes More Complex Traversals

• Thus far, weve seen XPath expressions that go
  down the tree (and up one step)
• But we might want to go up, left, right, etc.
• These are expressed with so-called axes
• selfpath-step
• childpath-step parentpath-step
• descendantpath-step ancestorpath-step
• descendant-or-selfpath-step ancestor-or-selfpa
  th-step
• preceding-siblingpath-step following-siblingpa
  th-step
• precedingpath-step followingpath-step
• The previous XPaths we saw were in abbreviated
  form

41
Users of XPath

• XML Schema uses simple XPaths in defining keys
  and uniqueness constraints
• XLink and XPointer, hyperlinks for XML
• XSLT useful for converting from XML to other
  representations (e.g., HTML, PDF, SVG)
• XQuery useful for restructuring an XML document
  or combining multiple documents
• Might well turn into the glue between Web
  Services, etc.

42
A Functional Language for XML

• XSLT is based on a series of templates that match
  different parts of an XML document
• Theres a policy for what rule or template is
  applied if more than one matches (its not what
  youd think!)
• XSLT templates can invoke other templates
• XSLT templates can be nonterminating (beware!)
• XSLT templates are based on XPath matches, and
  we can also apply other templates (potentially to
  selected XPaths)
• Within each template, directly describe what
  should be output

43
An XSLT Template

• An XML document itself
• XML tags create output OR are XSL operations
• All XSL tags are prefixed with xsl namespace
• All non-XSL tags are part of the XML output
• Common XSL operations
• template with a match XPath
• Recursive call to apply-templates, which may also
  select where it should be applied
• Attach to XML document with a processing-instructi
  on
• lt?xml version 1.0 ?gtlt?xml-stylesheet
  typetext/xsl hrefhttp//www.com/my.xsl ?gt

44
An Example XSLT Stylesheet

• ltxslstylesheet version1.1gt
• ltxsltemplate match/dblpgt
• lthtmlgtltheadgtThis is DBLPlt/headgt
• ltbodygt
• ltxslapply-templates /gt
• lt/bodygt
• lt/htmlgt
• lt/xsltemplategt
• ltxsltemplate matchinproceedingsgt
• lth2gtltxslapply-templates selecttitle /gtlt/h2gt
• ltpgtltxslapply-templates selectauthor/gtlt/pgt
• lt/xsltemplategt
• lt/xslstylesheetgt

45
XSLT Processing Model

• List of source nodes ? result tree fragment(s)
• Start with root
• Find all template rules with matching patterns
  from root
• Find best match according to some heuristics
• Set the current node list to be the set of things
  it maches
• Iterate over each node in the current node list
• Apply the operations of the template
• Append the results of the matching template
  rule to the result tree structure
• Repeat recursively if specified to by
  apply-templates

46
What If Theres More than One Match?

• Eliminate rules of lower precedence due to
  importing
• Break a rule into any branches and consider
  separately
• Choose rule with highest computed or specified
  priority
• Simple rules for computing priority based on
  precision
• QName preceded by XPath child/axis specifier
  priority 0
• NCName preceded by child/axis specifier priority
  -0.25
• NodeTest preceded by child/axis specifier
  pririty -0.5
• else priority 0.5

47
Other Common Operations

• Iteration
• ltxslfor-each selectpathgtlt/xslfor-eachgt
• Conditionals
• ltxslif test./text() lt abcgtlt/xslifgt
• Copying current node and children to the result
  set
• ltxslcopygt ltxslapply-templates /gtlt/xslcopygt

48
Creating Output Nodes

• Return text/attribute data (this is a default
  rule)
• ltxsltemplate matchtext()_at_gt ltxslvalue-of
  select./gtlt/xsltemplategt
• Create an element from text (attribute is
  similar)
• ltxslelement nametext()gt ltxslapply-templates
  /gtlt/xslelementgt
• Copy nodes matching a path
• ltxslcopy-of select/gt

49
Embedding Stylesheets

• You can import or include one stylesheet from
  another
• ltxslimport hrefhttp//www.com/my.xsl/gt
• ltxslinclude hrefhttp//www.com/my.xsl/gt
• Include the rules get same precedence as in
  including template
• Import the rules are given lower precedence

50
XSLT Summary

• A very powerful, template-based transformation
  language for XML document ? other structured
  document
• Commonly used to convert XML ? PDF, SVG, GraphViz
  DOT format, HTML, WML,
• Primarily useful for presentation of XML or for
  very simple conversions
• But sometimes we need more complex operations
  when converting data from one source to another
• Joins combining and correlating information
  from multiple sources
• Aggregation computing averages, counts, etc.

51
XSLT and Alternatives

• XSLT is focused on reformatting documents
• Stylesheets are focused around one XML file
• XML file must reference the stylesheet
• What if we want to
• Manage and combine collections of XML documents?
• Make Web service requests for XML?
• Glue together different Web service requests?
• Query for keywords within documents, with ranked
  answers
• This is where XQuery plays a role see CIS 330 /
  550 for details
