Flash and FOIL

1
Flash and FOILFrame Wall Insulation
2
Module 1Masonry Wall Insulation
Hybrid Spray Foam and Reflective Insulation
System Fi-Foil Company Introduces
3
What is Flash Foil?
Flash Foil is a National Solution for Frame
Wall Foam Insulation

• Fi-Foils new Flash Foil Frame Wall Insulation
  is an improved insulation solution designed to
  save you money. This solution has advantages to
  Flash and Batt systems.
• Combine Fi-Foils VR Plus Shield Reflective
  Insulation with spray foam insulation to reduce
  costs and provide code-compliant R-Values in any
  frame wall construction.
• Drop the Batt - Flash Foil!

4
Why replace fiberglass batt with Fi-Foils
VR Plus Shield Reflective Insulation?

• Code Compliant Wall R-ValuesR-values for Flash
  Foil in 2 x 4 inch wall range from R-11 to R-19,
  based on the foam manufacturers R per inch and
  the thickness of the foam. A complete table of
  R-Values determined by the thickness and type of
  spray foam to follow on separate slide (Table 1).
• Less Cost typical savings of 25 versus
  fiberglass batts.
• Stops Radiationas a reflective insulation, VR
  Plus Shields multiple layers separate to create
  three reflective air spaces to virtually
  eliminate heat transfer.
• Less Storage Space500 square foot rolls are easy
  to store and transport.
• Vapor Retarderavailable in Hi-Perm (perforated
  version) that allows vapor transmission and in
  Standard (non-perforated version) that functions
  as a vapor retarder, if required by code.
• Green Building Materialcontributes to Green
  Building Certification credits for Energy
  Efficiency.

5
Offered in 16 and 24 width rolls with tape tab
for installing over Metal Framing or with staple
tab for Wood Framing.
VR Plus has a Class A Flammability Rating
Also available in Hi-Perm (perforated version) to
allow vapor transmission or in Standard
(non-perforated version) to perform as a vapor
retarder.
6
How does Flash Foil work?

• Step 1 Spray the desired thickness of foam
• insulation on the inside of the frame wall
• which seals the joints and provides thermal
• protection by reducing air infiltration and
• adding thermal resistance. Instead of 3-1/2
• or 5-1/2 of spray foam in a 2 x 4 inch or
• 2 x 6 inch cavity respectively, a thinner layer
• of foam (flash) is used to air seal the cavity.
• Step 2 Apply VR Plus Shield reflective
• insulation (foil) to the face of the studs. The
• three layers of VR Plus Shield expand to
• form reflective air spaces in the remaining
• portion of the 2 x 4 inch or 2 x 6 inch cavity.
• REQUIRES 1-1/2 INCH AIR SPACE FOR
• VR PLUS TO EXPAND INNER LAYERS

7
How are R-Values calculated for Nominal 2 x 4
inch and 2 x 6 inch Wood Frame Wall Cavities
insulated with VR Plus Shield and Spray-applied
Cellular Foam Plastic Insulation?
The thermal resistance (R-values) for
combinations of Fi-Foil VR Plus Shield Reflective
Insulation and spray-applied cellular foam
plastic insulation have been calculated using a
procedure published in ASTM STP 1116.
1 Spray Foam
Exterior Sheathing
3 ½ Studs 24 on Center
VR Plus Shield Hi-Perm (requires minimum 1-1/2
air space)
Figure 1. Top View of Wall Cavity with Foam and
Reflective Insulation Assembly
8
Table 1. R-Values for Flash FOIL Frame Wall
Application
(All cavity R-Values are reported in customary
U.S. units at mean temperature of 75F)
      2x4 Frame Walls 2x4 Frame Walls 2x6 Frame Walls 2x6 Frame Walls
System Inches of Spray Foam Foam R Reflective System R Total R Reflective System R Total R
Foam R6.0 2" 12 7.42 19 7.66 20
Foam R6.0 1.5" 9 8.09 17 7.41 16
Foam R6.0 1.0" 6 7.64 14 7.16 13
Foam R5.0 2" 10 7.39 17 7.56 18
Foam R5.0 1.5" 7.5 8.02 16 7.31 15
Foam R5.0 1.0" 5 7.57 13 7.10 12
Foam R3.5 2" 7 7.33 14 7.40 14
Foam R3.5 1.5" 5.25 7.87 13 7.19 12
Foam R3.5 1.0" 3.5 7.44 11 7.00 11
R - thermal resistance per inch of thickness
ft²hF/Btuin R - thermal resistance
ft²hF/Btu - rounded in accordance with FTC
Rule 460 (R-Value Rule)
9
Flash FOIL Thermal Performance with Closed Cell Foam Flash FOIL Thermal Performance with Closed Cell Foam Flash FOIL Thermal Performance with Closed Cell Foam
1 Closed Cell Foam R - 6 R - 14
VR Plus Shield Hi-Perm R - 7.6 R - 14
2 Closed Cell Foam R - 12 R - 19
VR Plus Shield Hi-Perm R - 7.4 R - 19
Flash FOIL Thermal Performance with Closed Cell Foam Flash FOIL Thermal Performance with Closed Cell Foam Flash FOIL Thermal Performance with Closed Cell Foam
1 Closed Cell Foam R - 6 R - 14
VR Plus Shield Hi-Perm R - 7.6 R - 14
2 Closed Cell Foam R - 12 R - 19
VR Plus Shield Hi-Perm R - 7.4 R - 19
Closed Cell Foam now available in R-6.5
Flash FOIL Thermal Performance with Closed Cell Foam Flash FOIL Thermal Performance with Closed Cell Foam Flash FOIL Thermal Performance with Closed Cell Foam
1 of Closed Cell Foam R 6.5 R 14
VR Plus Shield Hi-Perm R - 7.6 R 14
2 of Closed Cell Foam R - 13 R 20
VR Plus Shield Hi-Perm R - 7.4 R 20
10
Flash FOIL Frame Wall Application
2 x 4 or 2 x 6 Frame Walls
2 Spray Foam (2 lb. or Closed Cell)
OSB
Reflective Air Spaces
Reflective Air Space (determined by depth of
framing and thickness of foam)
VR Plus Shield Hi-Perm(adds at least R-7.0)
11
Overall Benefits of Flash Foil

• Spray Foam
• Seals Wall Cavities
• Reduces Air Infiltration
• Adds a High R-Value per inch
• VR Plus Shield Reflective Insulation
• No Fibers
• Cost-effective
• Vapor Retarder Option
• Meets Code Compliance
• Simple Installation Process!
• Class A Flammability Rating
