Lecture Outlines Natural Disasters, 5th edition

1
Plate Tectonics and Earthquakes
Natural Disasters, 5th edition, Chapter 3
2
Plate Tectonics

1. The Discovery of Plate Tectonics
2. The Mosaic of Plates
3. Rates and History of Motion
4. Mantle Convection

3
I. Discovery of Plate Tectonics

1. Continental Drift
2. Seafloor Spreading

4
A. Continental Drift

1. Continental drift large-scale movements of
   continents

5
A. Continental Drift (continued)

• Support
• Puzzle fit
• Suess (1900)-Gondwana
• Wegner (1915)-Pangea

6
A. Continental Drift (continued)

1. Similar rock ages
2. Similar geologic structures
3. Fossil Evidence
4. Climate Evidence

7
B. Seafloor Spreading

1. Convection currents move plates around
2. Mantle source
3. Post-WWII Mid-Atlantic Ridge
4. Hess Dietz (1960s) propose new and recycled
   seafloor

8
II. The Mosaic of Plates

1. Lithospheric Plates
2. Divergent Boundaries
3. Convergent Boundaries
4. Transform-Fault Boundaries

9
A. Lithospheric Plates

• Mosaic of large moving plates
• Geologic activities occur at plate boundaries
• Earthquakes
• Volcanoes
• Rifts
• Folding
• Faulting

10
B. Divergent Boundaries

1. Narrow rifts
2. Continental plate separation
3. Oceanic plate separation-spreading centers

11
Divergent Boundaries Oceanic Plate Separation
Mid- Atlantic Ridge
North American Plate
Eurasian Plate
12
Divergent Boundaries Oceanic Plate Separation
Volcanoes and earthquakes concentrate.
Mid- Atlantic Ridge
North American Plate
Eurasian Plate
13
Divergent Boundaries Continental Plate Separation
East African Rift Valley
Somali Subplate
African Plate
14
Divergent Boundaries Continental Plate Separation
Parallel valleys volcanoes and earthquakes.
East African Rift Valley
Somali Subplate
African Plate
15
C. Convergent Boundaries

1. Conservation of Earths surface area
2. Ocean-ocean convergence
3. Ocean-continent convergence
4. Continent-continent convergence

16
Convergent Boundaries Ocean-Ocean Convergence
Mariana Islands
Marianas Trench
Philippine Plate
Pacific Plate
17
Convergent Boundaries Ocean-Ocean Convergence
Deep-sea trench volcanic island arc.
Mariana Islands
Marianas Trench
Philippine Plate
Pacific Plate
18
Convergent Boundaries Ocean-Continent Convergence
Andes Mountains
Peru-Chile Trench
South American Plate
Nazca Plate
19
Convergent Boundaries Ocean-Continent Convergence
A volcanic belt of mountains forms.
Andes Mountains
Peru-Chile Trench
South American Plate
Nazca Plate
20
Convergent Boundaries Continent-Continent
Convergence
Tibetan Plateau
Himalaya
Main thrust fault
Indian-Australian Plate
Eurasian Plate
21
Convergent Boundaries Continent-Continent
Convergence
Crust crumbles, creating high mountains and a
wide plateau.
Tibetan Plateau
Himalaya
Main thrust fault
Indian-Australian Plate
Eurasian Plate
22
D. Transform-Fault Boundaries

1. Plates slide past one another
2. Fracture with relative displacement

23
Transform-Fault Boundaries Mid-Ocean Ridge
Transform Fault
Eurasian Plate
North American Plate
24
Transform-Fault Boundaries Mid-Ocean Ridge
Transform Fault
Spreading centers offset.
Eurasian Plate
North American Plate
25
Transform-Fault Boundaries Continental Transform
Fault
Pacific Plate
North American Plate
26
Transform-Fault Boundaries Continental Transform
Fault
Offset continental crust.
Pacific Plate
North American Plate
27
(No Transcript)
28
As plates move past each other...
29
(No Transcript)
30
As plates move past each other...
San Francisco
creek beds are offset
San Andreas
fault
Los Angeles
31
III. Rates and History of Motion

1. Seafloor Magnetic Tape Recorder
2. Geodesy

32
A. Seafloor Magnetic Tape Recorder

• Magnetic reversals
• Switching strength to the south
• Preserved in lava
• Age can be dated
• Magnetic chrons- ½ million years
• Magnetic subchrons 200 000 years

33
(No Transcript)
34
(No Transcript)
35
Magnetic anomalies also in volcanic lava.
Earths magnetic field reverses direction.
Normal
Layers remember.
Reversed
Older layers preserve their direction.
Scientists constructed a magnetic time scale.
36
Subchrons
5.0 Ma
Present
4.0
3.0
2.0
1.0
Gilbert reversed chron
Gauss normal chron
Matuyama reversed chron
Brunhes normal chron
37
Mid-ocean ridge
Million years ago (Ma)
4.0
3.0
2.0
Ocean crust today
5.0
3.3
2.5
0.7
0
0.7
2.5
3.3
5.0 million years old
38
A. Seafloor Magnetic Tape Recorder (continued)

• Magnetic anomaly
• Normal-positive anomaly
• Reverse-negative anomaly
• Seafloor ages
• a. Speed distance / time

39
Magnetic mapping can measure the rate of seafloor
spreading An oceanic survey over the Reykjanes
Ridge, part of the Mid-Atlantic Ridge southwest
of Iceland, showed an oscillating pattern of
magnetic field strength. This figure illustrates
how scientists worked out the explanation of this
pattern.
Mid-Atlantic Ridge
High intensity
Low intensity
40
Magnetic mapping can measure the rate of seafloor
spreading An oceanic survey over the Reykjanes
Ridge, part of the Mid-Atlantic Ridge southwest
of Iceland, showed an oscillating pattern of
magnetic field strength. This figure illustrates
how scientists worked out the explanation of this
pattern.
A sensitive magnetometer records magnetic
anomalies,
Mid-Atlantic Ridge
High intensity
Low intensity
41
Magnetic mapping can measure the rate of seafloor
spreading An oceanic survey over the Reykjanes
Ridge, part of the Mid-Atlantic Ridge southwest
of Iceland, showed an oscillating pattern of
magnetic field strength. This figure illustrates
how scientists worked out the explanation of this
pattern.
A sensitive magnetometer records magnetic
anomalies,
Iceland
Mid-Atlantic Ridge
Mid-Atlantic Ridge
High intensity
Low intensity
42
Magnetic mapping can measure the rate of seafloor
spreading An oceanic survey over the Reykjanes
Ridge, part of the Mid-Atlantic Ridge southwest
of Iceland, showed an oscillating pattern of
magnetic field strength. This figure illustrates
how scientists worked out the explanation of this
pattern.
A sensitive magnetometer records magnetic
anomalies,
alternating bands of high and low magnetism.
Iceland
Mid-Atlantic Ridge
Mid-Atlantic Ridge
High intensity
Symmetrical bands on both sides. Why?
Low intensity
43
B. Geodesy

• Astronomical Positioning
• Position with respect to fixed stars
• 100 m error
• Global Positioning
• 24 Earth-orbiting satellites
• Measure plate movement

44
IV. Mantle Convection

1. Driving Forces
2. Plate Recycling
3. Convection Currents

45
A. Driving Forces

1. Mantle convection
2. Gravitational pull

46
B. Plate Recyling

1. New lithosphere-ridges
2. Old lithosphere-subduction
3. Recycling within upper and lower mantle-seismic
   waves

47
Whole-mantle convection
Mantle
Upper mantle
Outer core
Inner core
700 km
Lower mantle
2900 km Outer core
48
Whole-mantle convection
Upper mantle
700 km
Lower mantle
2900 km Outer core
49
Stratified convection
Boundary near 700 km separates the two
convection systems.
50
C. Convection Currents

• Movement of lithospheric plates
• Mantle plumes
• Hot spots
• Deep mantle

51
Plate Tectonics

1. The Discovery of Plate Tectonics
2. The Mosaic of Plates
3. Rates and History of Motion
4. Mantle Convection
