System Wide Information Management (SWIM)

1
System Wide Information Management (SWIM)
Program Overview
2
Agenda

• Program Overview
• Segment 1
• Segment 2
• Governance
• Cloud Computing

2
3
Program Concept
SWIM is an Information Technology (IT)
infrastructure program that operates in the
background to provide data to authorized users to
facilitate collaboration across National Airspace
System (NAS) domains

• SWIM will
• Implement a Service Oriented Architecture (SOA)
  in the NAS by providing Enterprise Infrastructure
  services that include messaging, security,
  enterprise service management, and interface
  management
• Oversee and govern the implementation of cloud
  computing in the NAS
• Ensure adherence to common standards (Governance)
• Allow the FAA to create new system interfaces
  more quickly and cost-effectively than is
  possible today
• Facilitate the data-sharing that is required for
  the Next Generation Air Transportation System
  (NextGen)

3
4
Business as Usual
State of the System

• More point-to-point unique interfaces
• Costly development, test, maintenance, CM
• New decisions linked to old data constructs
• Cumbersome data access outside the NAS

NAS System Interfaces in the Legacy Environment
SWIM-Compliant Government Systems
FAA Systems
ERAM
AIM
TFMS
Enterprise Management (SWIM)
CIWS
TDDS
ITWS
FTI

• Existing point-to-point hardwired NAS
• Unique interfaces, custom designs

TBFM
LEGEND
WMSCR
SWIM-Compliant Non-Government Systems
ATOP
SWIM Segment 1
SWIM Future Services
SWIM Adapter
4
5
Conceptual Overview
6
Segmented Approach to SWIM

• SWIM Segment 1
• Implementation of a set of federated services in
  the NAS with SWIM-provided governance, standards,
  and software to support development of reusable
  SOA services
• SWIM provides requirements, schedule, and funding
  to seven other NAS programs (i.e. SWIM
  Implementing Programs (SIPs)) tracks progress
  via formal monthly reviews
• Segment 1 results in SOA services deployed to all
  Air Route Traffic Control Centers (ARTCCs), 37
  Terminal Radar Approach Controls (TRACONs), the
  Air Traffic Control System Command Center, the
  William J. Hughes Technical Center (WJHTC), and
  NAS Enterprise Management Centers (NEMCs)
• SWIM Segment 2
• Continues provision of governance, standards, and
  software to additional NAS programs
• Implements enterprise messaging service for NAS
  programs and facilitates transition by Segment 1
  SIPs

6
7
Core Services Components

• Core Services supported by SWIM include
• Interface Management - interface specification,
  discovery, and schema management
• Messaging - reliable messaging as well as
  publish/subscribe services
• Security - authentication, authorization, and
  audit services
• Enterprise Service Management - service
  monitoring, service configuration, and system
  monitoring

7
8
SWIM Schedule
9
SWIM Segment 1 Capabilities
Aeronautical Information Management
(AIM) Community of Interest (COI)
Weather COI
Flight Flow Management (FFM) COI
Special Use Airspace (SUA) Automated Data Exchange
Corridor Integrated Weather System (CIWS)
Publication
Flight Data Publication Service (FDPS)
Integrated Terminal Weather System (ITWS)
Publication
SWIM Terminal Data Distribution System (STDDS)
Pilot Report (PIREP) Data Publication
Flow Information Publication
Runway Visual Range (RVR) Publication
Capabilities will be implemented as multiple
services by SIPs through FY15
Reroute Data Exchange
9
10
Capability Example ITWS Publication

• There are more than 10,000 airports in the US,
  yet fewer than 100 Air Traffic Control Towers
  have direct access to ITWS Situation Displays
• SWIM enables ITWS information to be accessed by
  those without direct access, facilitating common
  situational awareness

ITWS information accessed via Internet
ITWS information accessed through ITWS Situation
Display
11
Segment 1 Status

• SWIM Segment 1 commits to delivery of nine
  capabilities, eight of which are on track
• Two capabilities are complete and operational
• ITWS Data Publication
• CIWS Data Publication
• Four capabilities are complete and waiting for
  installation in FY12
• Weather Message Switching Center Replacement
  (WMSCR) PIREP Data Publication
• AIM SUA Automated Data Exchange
• Reroute Data Exchange
• STDDS
• Two capabilities are on schedule and within
  budget allocations
• Traffic Flow Management (TFM) Flow Information
  Publication Service (FIPS)
• RVR Data Publication
• One capability is being replanned and will be
  developed in-house
• FDPS

11
11
12
Anticipated Segment 1 Products
Capability Products Products Products
AIM SUA Data Exchange SUA data, dynamically via an improved ATC GUI SUA data, dynamically provided in the AIXM standard AIXM SUA definitions
ITWS Data Publication Airport Lightning Warning Configured Alerts Forecast Accuracy Forecast Contour Forecast Image Gust Front TRACON Map Microburst TRACON Map Precipitation 5nm Precipitation Long Range Precipitation TRACON SM SEP 5nm SM SEP Long Range SM SEP TRACON Terminal Weather Text Normal Tornado Alert Tornado Detections Wind Profile AP Indicated Precipitation AP Status Gust Front ETI Hazard Text 5nm Hazard Text Long Range Hazard Text TRACON ITWS Status Information Microburst ATIS Runway Configuration Storm Motion 5NM Storm Motion TRACON Terminal Weather Text Special Wind Shear ATIS
CIWS Data Publication VIL Mosaic (1km resolution) VIL 2-hr. Forecast Echo Tops Mosaic (1 km resolution) Echo Tops 2-hr. Forecast Satellite Mosaic Storm Info Echo Top Tags Storm Info Leading Edges Storm Info Motion Vectors VIL Forecast Contours (Std. Mode) VIL Forecast Contours (Winter Mode) Echo Tops Forecast Contours Growth Decay Contours Forecast Accuracy Echo Tops Forecast Accuracy Std. Precip Forecast Accuracy Winter Precip
13
Anticipated Segment 1 Products (cont.)
Capability Products Products Products
WMSCR PIREP Data Publication Transmission of voice PIREPs to WMSCR Stored PIREPs Altimeter settings
Reroute Data Exchange Pre-departure flight reroute information, from Traffic Managers to Air Traffic Controllers Pre-departure flight reroute information, from Traffic Managers to Air Traffic Controllers Pre-departure flight reroute information, from Traffic Managers to Air Traffic Controllers
STDDS Airport Surface Detection Equipment - Model X (ASDE-X) data Electronic Flight Strip Transfer System (EFSTS) data NextGen (NG)-RVR data Terminal Data Link System (TDLS) data
FIPS Flow Constrained Area (FCA) Airspace Flow Program (AFP) Ground Delay Program (GDP) Ground Stops (GSs) Reroutes Advisories
RVR Data Pub. Runway visibility data Runway visibility data Runway visibility data
FDPS Flight Information Track Information Sector Information General Information Restriction Information Beacon Code Mgmt. Information Operational Data Archive Information (Traffic Count, Instrument Approach Count, Sign In/Sign Out)
14
NAS Service Registry/Repository (NSRR)
The NSRR provides Interface Management for the NAS

• A Service Registry is a resource that provides
  controlled access to data necessary for the
  implementation and governance of SOA projects
• A Repository is a database containing the
  artifacts and metadata that constitutes a SOA
  registry
• The NSRR is SWIMs Registry/Repository for NAS
  Services
• Registering with the NSRR will be the only way to
  receive FAA NAS data

• The NSRR is open to external users
• https//swimrep.faa.gov/soa/web/login

14
15
SWIM Segment 2

• In November 2010, the FAA Joint Resources Council
  (JRC) created procedural path for SWIM to become
  the Governance Agent for SOA in the NAS
• SWIM to provide the enterprise SOA infrastructure
  within the NAS for individual programs to use
• SWIM will support efforts to ensure that SOA
  Governance complies with NAS Governance
• Specific SOA tools are being prototyped as
  Segment 2 candidates
• Segment 2 prototyping has identified new
  opportunities that may reduce cost and risk of
  Segment 1 services
• NAS Enterprise Messaging Service (NEMS) to be
  provided via FTI, building on the ASDE-X prototype

15
16
SWIM Segment 2 Enterprise Infrastructure

• Domain Name Service (DNS) provides naming and
  name-to-address resolution services across the
  Enterprise
• Network Time Protocol (NTP) and Precision Time
  Protocol (PTP) provides time synchronization
  services across the Enterprise
• NAS Enterprise Messaging Service (NEMS)

17
NEMS Overview
NEMS is providing Messaging Services for the NAS

• NEMS support for NAS Reliability,
  Maintainability, and Availability (RMA)
  requirements
• Any service available on one NEMS node will be
  available on any other NEMS node
• Intelligent Routing, routing decisions made based
  on certain data attributes or pre-defined
  conditions
• Data Filtering, based on Java Messaging Service
  (JMS) message header contents or attributes of
  the Extensible Markup Language (XML) schema
• Meets Enterprise Boundary Protection (EBP)
  requirements through integration with the NESG

17
18
NEMS Messaging Capabilities

• NEMS supports two Message Exchange Patterns
  (MEPs)
• Publish/Subscribe
• Request/Response
• In the Publish/Subscribe MEP, senders
  (Publishers) send messages to receivers
  (Subscribers) through Message Broker service
• Subscribers express interest in receiving only
  specific messages, based on a message topic
• Two main advantage of the Publish/Subscribe
  pattern are
• loose coupling
• scalability

18
19
NEMS Messaging Capabilities (cont.)

• In the Request/Response MEP, a requestor sends a
  request message to a producer that receives and
  processes the request, ultimately returning a
  message in response
• Request/Response allows two systems to have a
  two-way conversation with one another over a
  messaging channel
• Request/Response is typically (but not always)
  implemented as a SOAP-based Web Service
• NEMS provides a simple proxy capability and
  transports the data via HTTP from the Message
  Producer to the Message Consumer
• Most commonly this pattern is implemented
  synchronously

19
20
NEMS Deployment Highlights

• Current NEMS deployment includes messaging nodes
  at
• Atlanta and Atlantic City NESGs
• FTI National Test Bed (FNTB) (Atlantic City)
• Research and Development (RD) Domain (Atlantic
  City)
• Dedicated messaging nodes in the NESG are
  utilized as an interface between NAS and non-NAS
  entities
• Four internal NAS nodes will be installed at the
  beginning of 2012
• Used for NAS-to-NAS distribution of SOA data
  products
• Node Locations ACY, ZTL, OEX, ZLC
• Tentative end-state architecture will utilize 23
  internal NAS nodes
• 21 Air Route Traffic Control Centers (ARTCCs)
  (including Alaska)
• ACY and OEX

20
21
Producer/Consumer Deployment Status
Producer Consumer(s) Product(s) Cutover
TFMS (ASDE-X) Airlines/ External Users ASDE-X (Track reports) April 2011
WARP OASIS Harris Weather Data Service Products Feb. 2012
WARP CIWS (MIT/LL) NEXRAD Products March 2012
WMSCR (Phase 1) NIEC PIREPs and Altimeter Settings June 2012
CIWS Data Distribution Service (CDDS) (Phase 1) Time Based Flow Management (TBFM)/Traffic Management Adviser (TMA) CIWS Products (Static) Feb. 2013
TBFM Information Sharing (IS) Service TBD Collaborative Arrival Planning (CAP) Data Sept. 2013
STDDS TFMS ASDE-X (Tracks), Runway Visual Range, EFSTS, and TDLS Data 2013
TFMS/FIPS TBD FIPS Products 2013
22
Producer/Consumer Deployment Status (cont.)
Producer Consumer(s) Product(s) Cutover
WMSCR (Phases 2 and 3) TBD Web services for Requests for PIREPs and Altimeter Settings 2013
CDDS (Phase 2) TBFM/TMA CWIS Products (Dynamic) 2013
Enhanced Weather Information Network Server (WINS) Disseminations (EWD) TBD Weather Data 2013
AIM TFMS SUA Information 2014
ITWS Airlines/ Other External ITWS Products 2014
SWIM FDPS TBD FDPS Products 2015
23
NEMS Data-flows NAS-to-NAS
23
24
NEMS Data-flows Non-NAS Consumer
24
25
NEMS Data-flows Non-NAS Producer
25
26
SWIM Governance

• WHO is responsible
• Governance Authority
• Initial Service Candidate Approval by Technical
  Review Board (TRB)
• SWIM manages remainder of lifecycle for approved
  programs
• Service Providers responsibilities documented
• Service Consumers responsibilities documented
• WHAT must they do
• SWIM Governance Policies v1.1
• SWIM Service Lifecycle Management Processes v1.0
• HOW must they do it
• Technical Standards coordinated with NAS
  Enterprise Architecture
• TV-1 Technical Standards Profile
• TV-2 Technical Standards Forecast
• FAA Standards
• FAA-STD-063 XML Namespaces
• FAA-STD-064 Web Service Registration
• FAA-STD-065 Web Service Description Documents
• FAA-STD-066 Web Service Taxonomies
• SWIM Version Management Processes v1.0

26
27
Scope of SWIM Governance
Its a part of FAA Governance
FAA Governance
What is FAA/ATO/NAS governance?
ATO Governance
NAS Governance
Establishing decision making rights associated
with the FAA/ATO/NAS Establishing mechanisms and
policies used to measure and control the way
FAA/ATO/NAS decisions are made and carried out
SWIMGovernance
What is SWIM governance?
Extension of NAS governance focused on the
lifecycle of services to ensure the business
value of SWIM
SWIM Governance is a catalyst for improving
overall NAS, Air Traffic Organization (ATO) and
FAA governance
27
28
SWIM Compliance

• SWIM Compliance Definition
• Verified conformance to SWIM Policies. (SWIM
  Service Lifecycle Management Processes v1.0)
• Verification Mechanisms
• Manual review of artifacts
• Governance-enabling technology
• NSRR
• Testing Tools (Actional, Lisa, etc)
• SWIM Web Service Security Compliance Test Kit
  (SWIM WS-S CTK)
• Policy Servers
• XML Gateways
• Enterprise Service Management (ESM) software

28
29
Service Lifecycle Management Decisions

• Technical Review Board (TRB)
• Investment Decision Authority
• SWIM Governance Team

In Service Decision (ISD) Authority
29
30
SOA Suitability Criteria

• NAS Enterprise View
• Potential for existing SWIM service to be
  utilized or tailored to meet the requirement
• Potential for other users to benefit from the
  information exchange
• Potential hazards for exposing data through SWIM
  (e.g., proprietary data, non-FAA user access)
• Program View (Cost, Schedule, Technical)
• Life-Cycle Cost of SWIM versus other solutions
• System performance requirements latency,
  transmission rate, bandwidth, response time,
  overhead, etc.
• Safety/certification requirements
• Information security requirements
• Existing architecture/vendor solution impacts

30
30
31
International Coordination

• International Civil Aviation Organization (ICAO)
• Air Traffic Management (ATM) Requirements and
  Performance Panel (ATMRPP)
• ICAO SWIM Concept of Operations (ConOps)
  (November 2012)
• SWIM Guidance Document (December 2013)
• Single European Sky ATM Research Joint
  Undertaking (SESAR JU)
• SWIM Interoperability Workgroup
• Japan Civil Aviation Bureau (JCAB)
• Future Air Transportation System (FATS) Working
  Group
• May 2011, United States
• October 2011, Japan
• May 2012, United States
• Asia/Pacific Flight Data Object Demo (May 2012)
• Civil Aviation Authority of China/
• Air Traffic Management Bureau (CAAC/ATMB)
• December 2010, China
• March 2011, United States
• September 2011, United States
• October 2011, China
• Airservices Australia (ASA)

32
FAA Cloud Computing Approach

• FAA NAS and non-NAS organizations are working
  collaboratively on adoption of cloud computing
  under the leadership of the FAA Chief Information
  Officer (CIO)
• SWIM is responsible for managing the
  implementation of cloud computing in in the NAS
• The FAA Information Technology (IT) Operations
  Lead Team is responsible for oversight and
  guidance for FAAs non-NAS IT infrastructure,
  including cloud computing

33
There are several ways to learn more about SWIM
The SWIM website describes the SWIM program and
provides news, announcements, and information on
current issues It also contains key
documentation, including select briefings, the
SWIM Newsletter, and the SWIM QA
www.faa.gov/nextgen/swim
34
Questions and Comments?
34
