Chapter 11: Monohybrid Cross

1
Chapter 11 Monohybrid Cross
Higher Human Biology
Unit 1 Cell Function and Inheritance
2
Lesson Aims

• To revise and consolidate understanding of
  monohybrid crosses
• To examine Rhesus and Rhesus- blood groups
• To learn about different conditions caused by
  genetic mutations
• To find out the difference between incomplete
  dominance and co-dominance

3
You need to know these words
Recessive
Haploid
Gene
Co-dominant
Genotype
Dominant
Diploid
F1 Generation
F2 Generation
Allele
Phenotype
Incompletely dominant
Heterozygous
Homozygous
4
Things you need to know

• Monohybrid inheritance
• i The pattern of inheritance of a pair of
• alleles where one is dominant and one is
  recessive.
• ii The effects of alleles exhibiting dominance,
  co-dominance and incomplete dominance.
• iii Possible combinations of multiple alleles.

ALSO REMEMBER Dominant and co-dominant alleles
should be represented by upper case letters and
recessive alleles by lower case letters.
5
History

• Gregor Mendel - The Father of Genetics
• Monk who used science and maths to
• establish patterns in how traits were
  inherited2. Year 1857 carried out early
  monohybrid cross.3. He used the garden pea as
  his test subjects
• Some Vocabulary
• Character - a heritable feature (e.g. flower
  colour)
• Trait - a variant of each character (e.g. purple
  or white)
• Cross Pollination - one plant fertilizes a
  different plant
• Self Pollination - a plant fertilizes itself
• True-Breeding - plants that over several
  generations only produce plants like themselves

6
Monohybrid cross.

• A cross between two parents who possess
  different forms of a gene referred to as a
  MONOHYBRID INHERITANCE.

7
Mendels Experiments - Monohybrid Cross (pea
plant cross).

• Monohybrid Cross involved plants that differed
  for a single character tall x short, purple
  flower x white flower, round seed x wrinkled
  seed.
• P (Parental Generation) True breeding plants
• F1 (First Filial) The offspring of the P
  generation --gt they always displayed a single
  trait, the dominant one.
• F2 (Second Filial) The offspring of the F1
  generation, self fertilized --gt always had a 31
  ratio.

8
Pea plant cross

• Since wrinkled seeds were absent in the F1 and
  reappears in the F2, something has to be
  transmitted undetected in the gametes from
  generation to generation. Today we call this a
  GENE. In this case it is a gene for seed shape,
  which has two alleles, round and wrinkled.
• Since the presence of round allele masks the
  presence of the wrinkled allele, round is said to
  be DOMINANT and wrinkled RESSESSIVE.

Parent plant true breeding for round seeds
x
Parent plant true breeding for wrinkled
Cross-pollination
First filial generation (F1 ) ALL ROUND SEEDS
Self-pollination
Second filial generation (F2) 3 ROUND 1
WRINKLED SEEDS
9
Phenotypes and genotypes

• An organisms genotype is its genetic
  constitution (i.e. Alleles of genes) that is
  inherited from parents.
• These instructions are intimately involved with
  all aspects of the life of a cell or an organism

• An organisms phenotype is its appearance
  resulting from this inherited information
  (Genotype).
• This is anything that is part of the observable
  structure, function or behaviour of a living
  organism. e.g. Eye colour

10
Mendels Law of Segregation

• StatesThe alleles of a gene exist in pairs but
  hen gametes are formed, the members if each pair
  pass into different gametes. Thus each gamete
  contains only one allele of each gene.
• For example a Tt parent can produce both T sperm,
  and t sperm.

11
Locus - spot on the chromosome where an allele
(gene) is located.
12
Punnet squares

• A punnet square is a representation of the law of
  segregation, showing how gametes separate and
  then come together during fertilization.

ALSO REMEMBER Dominant and co-dominant alleles
should be represented by upper case letters and
recessive alleles by lower case letters.
13
Homozygous and Heterozygous

• When an individual possesses two similar alleles
  of a gene (e.g. R and R or r and r), its genotype
  is said to be HOMOZYGOUS (true-breeding) and all
  of its gametes are identical with respect to
  that characteristic.
• When an individual possesses two different
  alleles of a gene (e.g. R and r), its genotype is
  said to be HETEROZYGOUS. It produces two
  different types of gamete with respect to that
  characteristic.

14
Task Torrance pg 83 Qus 1-4
15
CAN YOU ROLL YOUR TOUNGE?
16
Monohybrid Inheritance in Humans
Genetics of tongue rolling

• Tongue rolling is inherited as a simple Mendelian
  trait.
• R is the allele for roller
• r is the allele for non-roller.

R
r
RR Rr
Rr rr
R
r
17
Monohybrid inheritance in humans Rhesus D Antigen

• In addition to the ABO system of antigens, most
  people have a further antigen on the surface of
  their red cells. This is called Antigen D.
• Most people are Rh (rhesus positive) as they
  posses this antigen
• A minority of people are Rh- (rhesus negative)
  they do not possess this antigen. But these
  people react to the presence of antigen D by
  forming anti-D antibodies

18
Rhesus D Antigen Cont

• If a Rh- person is given Rh red blood cells
  during a transfusion the persons immune system
  responds by producing anti-D antibodies. This
  leaves the person sensitised.
• If this person receives more Rh red blood cells
  they suffer from severe or fatal agglutination.

19
Agglutination of Red Blood Cells
20

• Presence of Antigen D is genetically dominant (D)
• Lack of antigen D is due to a recessive allele
  (d)
• P DD x dd or P dd x Dd
• (Rh)(Rh-) (Rh-) (Rh)
• F1 all Dd (Rh) F1 Dd (Rh) and dd
  (Rh-)

D
D
D
d
d
Dd Dd
Dd Dd
Dd dd
Dd dd
d
d
d
21
Examples RECESSIVE monohybrid inheritance in
humans

• Albinism - inability of the body to make melanin
  - inherited as simple Mendelian recessive trait.
• Cystic Fibrosis - disorder of the mucus secreting
  glands - simple Mendelian recessive trait..
• PKU inborn error of metabolism simple
  Mendelain recessive trait

22
Huntingdons Chorea
Example of a DOMINANT monohybrid inheritance in
humans

• Degeneration of the nervous system which leads to
  premature death.
• Determined by dominant allele.
• Allele not expressed in phenotype until about 38
  years of age when sufferer will probably have had
  a family and passed on the allele.

23
Huntingtons Chorea The genetics

• H allele for Huntington's, h allele for
  normal condition
• 5 combinations HH x HH, HH x Hh, Hh x Hh, HH x
  hh, hh x hh.
• HH x HH all offspring HH none survive
• HH x Hh offspring HH, HH, HH, Hh None survive
• Hh x Hh offspring HH, Hh, Hh, hh 75 dont
  survive (hh lives)

24
Huntingtons Chorea The genetics

• H allele for Huntington's, h allele for
  normal condition
• Most likely combination Hh (but doesnt know yet
  breeds with hh.......
• Potentially tragic situation 1 in 2 inherit
  condition.
• Hh x hh - offspring Hh, Hh, hh, hh 50 dont
  survive (hh lives) but no one will know till
  mid thirties.

25
Task Torrance pg 85 Qus a-h
26
Incomplete Dominance

• Sometimes one allele is not completely dominant
  over the other,
• Occurs when the recessive allele has some effect
  on the heterozygote.
• Here the heterozygote exhibits a phenotype which
  is different from both of the hetrozygotes .
• e.g.
• Sickle Cell Anaemia
• Resistance to malaria

27
Incomplete dominance Example Sickle cell
anaemia.
Can see the cells have the typical sickle cell
shape.

• An example of incomplete dominance is illustrated
  in the condition known as sickle cell anaemia.
• Here one of the genes which codes for haemoglobin
  (Hb) undergoes a mutation The Hb produced is an
  unusual type called Hb- which is an inefficient
  carrier of oxygen.

28
Homozygous for the mutant allele SS

• Homozygous for the mutant allele SS

• Disastrous consequences, sufferers SICKLE CELLED
  ANAEMIA, they have the abnormally shaped sickle
  cell blood, RBCs fail to perform function well.
• Causes shortage of oxygen, damage of internal
  organs and in many cases death.

Picture shows blood containing only Haemoglobin
wit the Sickle shape.
29
Heterozygous for the mutant allele HS (Hnormal
Ssickle both uppercase because neither is
dominant)

• Heterozygous for the mutant allele

• Do not suffer from Sickle Cell Anaemia,
• Instead RBCs contain both forms of Hb giving a
  milder condition called SICKLE CELL TRAIT.
• Causes slight anaemia, which does not prevent
  moderate activity.

Picture shows blood containing both forms of
Haemoglobin (although the mutant cells are not
completely sickle)
This in-between situation where the mutant
allele is partially expressed, neither allele is
completely dominant over the other
30
Resistance to malaria (HS genotype)

• The S is rare in most populations.
• However, in some parts of Africa up to 40 of the
  population has the heterozygous genotype HS.
• This is because the parasite cannon make use of
  the RBCs containing haemoglobin S.
• People with the normal homozygous genotype HH
  are susceptible to malaria (and may die).

31
Co-dominance

• Describes the situation where two alleles can be
  expressed in the heterozygote, neither
  suppressing the other, e.g. MN blood grouping.
• Blood groups are determined by the presence of
  antigens on the surface of RBCs.
• In addition to the ABO and Rhesus D-Antigen
  system, a further example is the MN blood group
  system.

32
MN Blood Group

• Controlled by two alleles M and N which are
  co-dominant (both alleles expressed in the
  phenotype of the heterozygote).
• Heterozygous MN blood group have both M and N
  antigens on rbc
• Homozygous MM blood group have M antigens on rbc
• Homozygous NN blood group have N antigens on rbc

33
Multiple Alleles

• Each of the genes considered so far has two
  alleles ( which display complete, incomplete or
  co-dominance).
• Some genes are found to possess 3 or more
  different alleles for a certain
  characteristic.... It has multiple alleles.
• If 3 alleles of a gene exist, and since a diploid
  individual has 1 or 2 of these alleles, then
  there are 6 genotype combinations possible.
• The phenotype depends on whether the alleles are
  complete, incomplete or co-dominant.

34
ABO Blood Group

• Antigens coded by a gene that has three alleles
  A, B and O.
• 6 possible genotypes AA, AO, BB, BO, AB, OO
• 4 Phenotypes, A, B, AB, or Neither A or B...
• Allele A produces antigen A.
• Allele B produces antigen B.
• Allele O produces no antigens.
• Alleles A and B are co-dominant to one another
  and completely dominant over allele O.

35
TASK Complete Torrance TYK questions on page 87
36
Essay Question Guide to H essays pg 58

• Discuss inheritance under the following headings
• (a) Patterns of dominance (8)
• (b) Multiple Alleles. (7)

37
Essay Question Guide to H essays pg 58

• Discuss monohybrid inheritance in humans. (15)
