Covariance and correlation

1
Covariance and correlation

• Dr David Field

2
Summary

• Correlation is covered in Chapter 6 of Andy
  Field, 3rd Edition, Discovering statistics using
  SPSS
• Assessing the co-variation of two variables
• Scatter plots
• Calculating the covariance and the Pearson
  product moment correlation between two variables

• Statistical significance of correlations
• Interpretation of correlations
• Limitations and non-parametric alternatives

3
Introduction

• Sometimes it is not possible for researchers to
  experimentally manipulate an IV using random
  allocation to conditions and measure a dependent
  variable
• e.g. relationship between income and self esteem
• But you can still measure two or more variables
  and ask what relationship, if any, they have
• One way to assess this relationship is using the
  Pearson product moment correlation
• another example would be to look at the
  relationship between alcohol consumption and exam
  performance in students
• it would be unethical to manipulate alcohol intake

4
Units alcohol per week Exam
13 63
10 60
24 55
3 70
5 80
35 41
20 50
14 58
17 61
19 63

• For each participant we record units of alcohol
  consumed per week and exam
• Dont forget that this is not an experiment, and
  any observed dependence of the 2 variables on
  each other could be due to both variables being
  caused by a 3rd variable (e.g. stress)
• Before performing any statistical analysis the
  first step is to visualise the relationship
  between the two variables using a scatter plot.

5
alcohol Exam
13 63
10 60
24 55
3 70
5 80
35 41
20 50
14 58
17 61
19 63
4.8.1
Scatterplot
6
Calculating the covariance of two variables
6.3.1

• Covariance is a measure of how much two variables
  change together
• presumes that for each participant in the sample
  two variables have been measured
• If two variables tend to vary together (that is,
  when one of them is above its mean, then the
  other variable tends to be above its mean too),
  then the covariance between the two variables
  will be positive.
• If, when one of them is above its mean value the
  other variable tends to be below its mean value,
  then the covariance between the two variables
  will be negative.
• First, lets revisit variance

7
Variance of one variable

• To calculate variance
• subtract the mean from each score
• Square the results
• Add up the squared scores
• Divide by the number of scores -1
• Squaring makes sure that the variance will not be
  negative, and it emphasizes the effect of very
  large and very small scores that are far from the
  mean
• If all the scores are close to the mean the
  variable has restricted variance and it is
  unlikely that any other variable will co-vary
  with it

8
Covariance of two variables, X and Y

• For each pair of scores
• subtract the mean of variable X from each score
  in X
• subtract the mean of variable Y from each score
  in Y
• Multiply each of the pairs of difference scores
  together
• Sum the results
• Divide by the number of scores 1
• The -1 has negligible effect on the estimate of
  the population covariance when the sample is
  large
• But when the sample is small it has a noticeable
  effect
• The -1 is included because it has been shown that
  small samples tend to underestimate the
  underlying population covariance (as is also the
  case for variance)

9
alcohol exam alcohol mean (16) exam mean (60.1) Multiply difference scores
13 63 -3 2.9 -8.7
10 60 -6 -0.1 0.6
24 55 8 -5.1 -40.8
3 70 -13 9.9 -128.7
5 80 -11 19.9 -218.9
35 41 19 -19.1 -362.9
20 50 4 -10.1 -40.4
14 58 -2 -2.1 4.2
17 61 1 0.9 0.9
19 63 3 2.9 8.7
Sum right hand column and divide by number of
participants -1 to find the population
covariance -786 / 9 -87.3
10
Covariance formula
The bar on top refers to the mean of the variable
Sigma (the sum of)
å
)
(
-
Y
Y
)
(
-
X
X
X

cov(x,y)
N - 1
Under what circumstances would cov(x,y) equal
approximately zero?
11
Converting covariance to correlation
6.3.2

• Knowing that the covariance of two variables is
  positive is useful as it indicates that as one
  increases, so does the other
• But, the actual value of covariance is dependent
  up the measurement units of the variables
• if the exam scores had been given out of 45,
  instead of as percentages, then the covariance
  with alcohol consumption would be -39.3 instead
  of -87.3
• but the real strength of the relationship is the
  same
• because the covariance is dependent upon the
  measurement units used it is hard to interpret
  unless we first standardize it.

12
Converting covariance to correlation

• Ideally wed like to be able to ask if the
  covariation of alcohol consumption and exam
  scores is stronger or weaker than the covariation
  of alcohol consumption and hours studied
• The standard deviation provides the answer,
  because it is a universal unit of measurement
  into which any other scale of measurement can be
  converted
• because the covariance uses the deviation scores
  of two variables, to standardize the covariance
  we need to make use of the SD of both variables

13
Pearsons r correlation coefficient
cov(x,y)
r

SDx SDy
This means divide by the total variation in both
variables
What is the biggest value r could take?
14
Pearsons r correlation coefficient

• The result of standardisation is that r has a
  minimum of -1 and a maximum of 1
• -1 perfect negative relationship
• 0 no relationship
• 1 perfect positive relationship
• -0.5 moderate negative relationship
• 0.5 moderate positive relationship
• To achieve a correlation of 1 (or -1) the shared
  variation, cov(x,y) has to be as big as the total
  variation in the data, represented by the two
  SDs multiplied together

15

• covariance of percentage exam score and alcohol
  units is -87.3
• SD of exam scores is 10.58
• SD of alcohol units per week is 9.37
• Pearsons r -87.3 / 99.20
• r -.88

-87.3

r
10.58 9.37
16
Scatter plots and correlation values
17
Scatter plots and correlation values
18
Scatter plots and correlation values
The scatter plot with 0 correlation provides a
null hypothesis and null distribution for
calculating an inferential statistic. The
correlation coefficient between two variables is
itself a descriptive statistic, analogous to the
effect size of the difference between two sample
means. We can also calculate the p value of an
observed correlation (data) being obtained by
random sampling from the null scatter plot.
19
Statistical significance of correlations
6.3.3

• SPSS reports a 2 tailed p value for correlations
• this is the probability of obtaining the data by
  random sampling from a population scatter plot
  with 0 correlation
• If p is less than 0.05 you can reject the null
  hypothesis, and declare the correlation to be
  statistically significant
• if you predicted the direction of correlation,
  then the p value can be divided by 2 (one tailed
  test)
• The p value is very dependent on sample size
• if sample size is large then very small values of
  the correlation coefficient (e.g. -0.15) will
  easily reach significance
• Only report correlations that reach significance,
  but beyond this you should place more emphasis on
  interpretation of the direction and size of the
  correlation coefficient itself

20
The coefficient of determination (R2)
6.5.2.3
0 correlation
Venn diagrams showing proportion of variance
shared between X and Y
Weak correlation
Strong (but not perfect) correlation
21
The coefficient of determination

• To express quantitatively what is expressed
  visually by the Venn diagrams
• square the correlation coefficient (multiply it
  by itself)
• the result will always be a positive number
• it describes the proportion of variance that the
  two variables have in common
• it is also referred to as R2

22
Note the rapid decline of the coefficient as the
correlation reduces. r 0.9 81 shared
variance r 0.5 25 shared variance r 0.3
9 shared variance
23
Correlation - limitations

• Before running a correlation between any pair of
  variables produce a scatter plot in SPSS
• If there is a relationship between the two
  variables, but it appears to be non-linear, then
  correlation is not an appropriate statistic
• non-linear relationships can be u shaped or n
  shaped, or like the graph on the previous slide

24
Nonparametric correlations
6.5.3

• Spearman's rho may be used instead of Pearson's r
  if
• frequency histograms of the individual variables
  are skewed
• A scatter plot of X and Y reveals outliers
• (Outliers will have a disproportionate influence
  on the value of Pearson's r)
• Individual variables are ordinal with few levels
• Spearman's rho is computationally identical to
  Pearson's r
• the difference is that the data is first
  converted to ranks so that any extreme scores are
  no longer very different from the bulk of scores

25

• Pearson's r for the example data is -0.88
• Spearmen's rho is -0.82
• This is very similar
• In the next slide, we will consider what happens
  if we replace one data point, which was already
  the most extreme, with an outlier

26

• Pearson's r for the modified data has increased
  in size to -0.95
• But you can see that this is driven by the
  extreme case
• Whats the value of Spearman's rho for the
  modified data?

• It remains unchanged at -0.82

27
An example of perfect correlation.

• My age and my brothers age have a positive
  correlation of 1
• But our ages are not causally related
• Remember that correlation causation!
