Nerve Physiology Notes

1
Nerve Physiology Notes
2
RESTING MEMBRANE POTENTIAL

• Nerve at rest or inactive
• Plasma membrane has electric voltage difference
  across membrane measured in Volts
• Membrane at rest is polarized fewer potassium
  (K) ions inside more sodium (Na) ions outside
  (less negative inside) -70 V

3
(No Transcript)
4
ACTION POTENTIAL

• Nerve impulse is transmitted during action
  potential (30)
• Strong enough stimulation cause Na gates to open
  ? Na rush into cell causing depolarization

5

• Na rushes into cell, membrane potential goes to
  0, and momentarily becomes positive
• If a strong enough depolarization occurs,
  threshold potential is reached and
  impulse is sent down axon

6
(No Transcript)
7

• If another stimulus of same type arrives before
  effect of first stimulus wears off, additive
  effect of two (or more) stimuli is called
  summation
• Graded response stronger stimulus stronger
  response will be

8
Threshold Potential
Resting Membrane Potential
9

• K rush out of neuron after Na rush in, which
  repolarizes membrane back to resting potential

10
(No Transcript)
11
(No Transcript)
12

• Refractory period is that time during which no
  stimulus can cause another action potential

13
(No Transcript)
14
TYPES OF CONDUCTION

• continuous conduction unmyelinated axon
  conducts an impulse over its entire surface
• saltatory conduction myelinated axon jump
  from one node to next much faster

15
(No Transcript)
16
SYNAPSE

• Gap between neuron
• presynaptic neuron neuron before the synapse
• postsynaptic neuron - neuron after synapse
• Nerve impulse travels from presynaptic to
  postsynaptic neuron

17
(No Transcript)
18

• An impulse traveling down an axon of a
  presynaptic neuron reaches synaptic end bulb,
  opens Ca channels
• Ca rushes into cell causes synaptic vesicles to
  fuse with cell membrane and release their
  neurotransmitter into the synaptic cleft

19

• Neurotransmitter binds with receptors on the
  postsynaptic neurons cell membrane

20
(No Transcript)
21
NEUROTRANSMITTERS

• At least 30 50 different neurotransmitters
  identified
• Synaptic end bulbs may contain 2 or 3 different
  neurotransmitters
• Needs to be removed or will influence nerve
  indefinitely
• Some degraded by enzymes
• Some reuptake into cells

22
(No Transcript)
23
(No Transcript)
24
REFLEX

• Reflex rapid, predictable, and involuntary
  responses to stimuli
• Reflex arc direct route from a sensory neuron,
  to an interneuron, to an effector
