G. Tyler Miller

1
G. Tyler MillersLiving in the Environment
Ecosystems Components, Energy Flow, and Matter
Cycling Chapter 3
2
What is ecology?

• The study of how organisms interact with one
  another and with their non-living environment.
• (oikos place to live logos study of)
• How nature is connected.

3
Universe
Galaxies
Biosphere
Solar systems
Planets
Earth
Biosphere
Ecosystems
Ecosystems
Communities
Populations
Realm of ecology
Organisms
Communities
Organ systems
Organs
Tissues
Cells
Populations
Protoplasm
Molecules
Atoms
Organisms
Subatomic Particles
4
The Nature of Ecology
Ecosystem Organization

• Organism
• Any form of life

5
The Nature of Ecology
Ecosystem Organization

• Organism
• Any form of life
• Species
• Group of organisms that resemble one another
• Actually or potentially breed with one another
• Produce live, fertile offspring

6
The Nature of Ecology
Ecosystem Organization

• Communities
• Populations of the different species occupying a
  particular place
• Biological community
• Populations
• Group of interacting individual of the same
  species that occupy a specific area a the same
  time.
• Organisms
• Any living organism

7
The Nature of Ecology
Ecosystem Organization

• Biosphere
• All of the earths ecosystems
• Ecosystem
• A community of different species interacting with
  one another and their nonliving environment

8
The Earths Life-Support Systems

• Atmosphere
• Troposphere
• Stratosphere
• Hydrosphere
• Lithosphere
• Biosphere

Fig. 4-6 p. 68
9
Sustaining Life of Earth

• One-way flow of energy
• Sun
• Living materials and living things
• Into the environment
• Cycling of matter
• Atoms, ions, molecules needed for survival
• Gravity

10
The Source of Energy
Fig. 4-8 p. 69
11
Ecosystem Concepts and Components

• Biomes
• By-ohms
• Land ecosystems
• Distinct climate and specific life-forms
• Role of climate
• Long term patterns of weather
• Determines what type of life will thrive
• Aquatic life zones
• freshwater
• ocean or marine life

Fig. 4-9 p. 70
12
Ecosystem Boundaries Ecotones
Fig. 4-10 p. 71
13
Figure 4-11 Page 72
Sun
Producers (rooted plants)
Producers (phytoplankton)
Primary consumers (zooplankton)
Secondary consumers (fish)
Dissolved chemicals
Tertiary consumers (turtles)
Sediment
Decomposers (bacteria and fungi)
Major components of freshwater ecosystem
14
Figure 4-12 page 72
Major components of a terrestrial ecosystem
Sun
Oxygen (O2)
Producer
Carbon dioxide (CO2)
Secondary consumer (fox)
Primary consumer (rabbit)
Producers
Falling leaves and twigs
Precipitation
Soil decomposers
Water
Soluble mineral nutrients
15
Principles of Ecological Factors
Terrestrial Ecosystems
Aquatic Life Zones

• Abiotic factors-
• nonliving

Sunlight Temperature Precipitation Wind
Latitude (distance from equator) Altitude
(distance above sea level) Fire frequency Soil
Light penetration Water currents Dissolved
nutrient concentrations (especially N and P)
Suspended solids Salinity
Figure 4-13Page 73
16
The Biotic Components of Ecosystems

• Producers (autotrophs)
• Transform energy by Photosynthesis
• Consumers (heterotrophs)
• Transform energy by Aerobic Respiration
• Decomposers

Fig. 4-16 p. 75
17
Ecosystems Use Sunlight As Their Source of Energy
18
Law of Conservation of Matter
Photosynthesis 6 CO2 6 H20
C6H12O6 6 O2
Respiration C6H12O6 6 O2
6 CO2 6 H20
19
Trophic Feeding Levels

• First Trophic Level
• Second Trophic Level
• Third Trophic Level
• Fourth Trophic Level

• Producers (plants)
• Primary consumers (herbivores)
• Feed directly on producers
• Secondary consumer (carnivores)
• Feed on Primary Consumers
• Tertiary consumer
• Feed on other carnivores

20
Trophic Levels

• Omnivore
• Eat plants and animals
• Detritivores and Scavengers
• Feed on detritus, dead organisms, and waste
• Decomposers
• Break down dead organic material
• Release the resulting simpler compounds into the
  soil
• Anaerobic respiration (absence of oxygen)
• Methane, ethyl alcohol, acetic acid, hydrogen
  sulfide

21
Figure 4-15 page 75
Detritus feeders
Decomposers
Bark beetle engraving
Carpenter ant galleries
Termite and carpenter ant work
Long-horned beetle holes
Dry rot fungus
Wood reduced to powder
Mushroom
Powder broken down by decomposers into plant
nutrients in soil
Time progression
22
BiodiversityWhat is it and why is it important?

• The different life-forms and life-sustaining
  processes.

23
BiodiversityWhat is it and why is it important?

• Kinds of biodiversity include
• Genetic diversity
• Variety in the genetic makeup among individuals
  within a species
• Species diversity
• Variety among species found in different habitats
  of the planet
• Ecological diversity
• Variety of biological communities
• Functional diversity
• Biological and chemical processes or functions
  needed for survival

24
Connections Food Webs and Energy Flow in
Ecosystems
Food chains sequence of organisms each of which
is a food source for the next.
25
Connections Food Webs and Energy Flow in
Ecosystems
Food webs a network of interconnected food
chains
26
ECOLOGY
Ecological Pyramid A food chain that shows the
relationship between the organisms in each
trophic level.
27
Ecological Pyramids

• Pyramid of energy flow
• Ecological efficiency
• Range 5-20
• Typically 10
• Pyramid of biomass
• Pyramid of numbers

Fig. 4-20 p. 79
28
Ecological Pyramids of Numbers
The figures represent number of individuals
counted at each trophic level.
29
Ecological Pyramids of Biomass

• The total dry weight of organisms in a particular
  trophic level is referenced as biomass.

BIOMASS of organisms x the weight of an
average individual
biomass
30
Ecological Pyramids of Biomass
31
Ecological Pyramids of Energy

• Energy in ecosystems flows from producers to
  consumers.
• Energy is depicted in kilocalories.
• The average amount of energy that is available to
  the next trophic level is about 10.

32
Ecological Pyramids of Energy
33
Primary Productivity of Ecosystems

• Gross Primary Productivity (GPP)
• Rate at which an ecosystems producers convert
  solar energy into chemical energy as biomass
• Net Primary Productivity (NPP)
• Difference between the rate at which producers
  store energy as biomass and the rate at which
  producers use chemical energy stored as biomass

34
Primary Productivity of Ecosystems
35
Connections Matter Cycling in Ecosystems

• Biogeochemical (nutrient) cycles
• Hydrologic cycle (H2O)
• Atmospheric cycles (C,N)
• Sedimentary cycles (S,P)
• Cycles Book Review

36
Hydrologic (Water) Cycle
Fig. 4-27 p. 83
?
37
Carbon Cycle
38
Human Activities Affecting the Carbon Cycle

• Clearing tree
• Burning fossil fuels and wood

39
Nitrogen Cycle
40
Human Activities Affecting The Nitrogen Cycle

• Burning fossil fuels
• Acid rain
• Animal waste
• Removing N from topsoil
• Adding N to aquatic systems

41
The Phosphorus Cycle
Fig. 4-30 p. 88
42
Human Activities Affecting the Phosphorus Cycle

• Mining
• Forest removal
• Adding phosphorus to aquatic systems
• eutrophication

43
The Sulfur Cycle
Fig. 4-31 p. 89
44
Ecosystem Servicesand Sustainability

• Using renewable solar energy as an energy source
• Recycling the chemical nutrients organisms need
  for survival, growth, and reproduction.

Fig. 4-34 p. 92
