Selecting Input Probability Distribution

1
Selecting Input Probability Distribution
2
Introduction

• need to specify probability distributions of
  random inputs
• processing times at a specific machine
• interarrival times of customers/pieces
• demand size
• evaluate data sets (if available)
• failure to choose the correct distribution can
  affect the accuracy of the models results!

3
Assessing Sample Independence

• correlation plot
• scatter diagram

4
Assessing Sample Independence

• important assumption
• observations are supposed to be independent
• graphical techniques for informally assessing
  whether data are independent
• correlation plot
• scatter diagram

5
correlation plot

• graph of sample correlation
• estimate of the true correlation between two
  observations that are j observations apart in
  time
• if observations X1, X2, , Xn are independent
• then ½j 0 for j 1, 2, , n-1
• estimates wont be exactly zero, even if Xis are
  independent, since its an observation of a random
  variable
• if estimates differ from 0 by a significant
  amount, then its strong evidence that the Xis
  are not independent

6
correlation plot (example)
7
correlation plot (example)
8
scatter diagram

• plot of pairs (Xi, Xi1)
• if Xis are independent, one would expect the
  points (Xi, Xi1) to be scattered randomly
  throughout the first quadrant of the plane
• nature of scattering depends on underlying
  distribution of the Xis
• if Xis are positively (negatively) correlated,
  points will tend to lie along a line with
  positive (negative) slope

9
scatter diagram (example)
10
scatter diagram (example 2)
11
Specifying Distribution

• useful distributions
• use values directly
• define empirical distribution
• fit theoretical distribution

12
useful probability distribution

• parameters of continuous distributions
• location parameter
• x-axis location
• usually the midpoint (mean for normal
  distribution) or lower endpoint
• also called shift-parameter
• changes in shift the distribution left or right
  without changing it otherwise
• scale parameter
• determines scale (unit) of measurement
• standard deviation ¾ for normal distribution
• changes in compress or expand the associated
  distribution without altering its basic form

13
useful probability distribution

• parameters of continuous distributions
• shape parameter
• determines basic form or shape of a distribution
  within the general family of distributions of
  interest
• a change in generally alters a distributions
  properties (skewness) more fundamentally than a
  change in location or scale

14
Approaches to specify distribution

• if data collection on an input random variable is
  possible
• use data values directly in simulation (trace
  driven)
• only reproduces what happened
• seldom enough data to make all simulation runs
• useful for model validation
• define empirical distribution
• at least (for continuous data) any value between
  min and max
• no values outside the range can be generated
• may have irregularities
• fit to theoretical distribution
• preferred method
• easy to change

15
Specifying Distribution

• useful distributions
• use values directly
• define empirical distribution
• fit theoretical distribution

16
Uniform U(a,b)

• application
• used as a first model for a quantity that is
  felt to be randomly varying between a and b about
  which little else is known

17
exponential distribution exp()

• application
• interarrival times of entities to a system that
  occur at a constant rate
• time to failure of a piece of equipment
• parameters
• scale parameter gt 0

18
gamma(k, µ)

• application
• time to complete some task (customer service,
  machine repair)
• parameters
• shape parameter k gt 0
• scale parameter µ gt 0

19
weibull(k, )

• application
• time to complete some task, time to failure of a
  piece of equipment
• used as a rough model in absence of data
• parameters
• shape parameter k gt 0, scale parameter gt 0

20
normal N(¹, ¾2)

• application
• errors of various types
• quantities that are the sum of a large number of
  other quantities
• parameters
• location parameter -1 lt ¹ lt 1 scale parameter ¾ gt
  0

21
triangular (a,b,m)

• application
• used as a rough model in absence of data
• a, b, m are real numbers (a lt m lt b)
• location parameter a
• scale parameter b-a
• shape parameter m

22
poisson()

• application
• number of events that occur in an interval of
  time when events are occurring at a constant rate
• number of items demanded from inventory

23
Specifying Distribution

• useful distributions
• use values directly
• define empirical distribution
• fit theoretical distribution

24
Empirical Distributions

• use observed data themselves to specify
  distribution directly
• generate random variables from empirical
  distribution
• (if no theoretical distribution can be fitted)
• define a continuous piecewise-linear distribution
  function
• sort Xjs into increasing order
• X(i) denotes the ith smallest value of all Xjs

25
Empirical Distribution (example)

• observation X1 3, X2 8, X3 18,
  X4 10, X5 13, X6 6
• sorted observation X(1) 3, X(2) 6, X(3)
  8, X(4) 10, X(5) 13, X(6) 18
• distribution
• F(X(i))
• F(X(i)) (i-1)/(n-1)
• F(X(1)) F(3) 0/5 0
• F(X(2)) F(6) 1/5
• F(X(3)) F(8) 2/5
• etc

• F(X) if X(i) X X(i1)
• F(X) (i-1)/(n-1) (X X(i))/((n-1)(X(i1)-X(i)
  )
• F(12) ??
• interval X(4) 12 lt X(5)
• (n 6, i 4)
• F(12) 3/5 2/(53) 0.68

26
Empirical Distribution (example)
27
Specifying Distribution

• useful distributions
• use values directly
• define empirical distribution
• fit theoretical distribution

28
Necessary Steps for fitting a theoretical
distribution

• hypothesize family
• summary statistics
• histogram
• quantile summary box plots
• estimate parameters
• how representative is fitted distribution?
• Chi-Square Goodness of fit test
• Kolmogorov-Smirnoff Test

29
Hypothesizing families of distributions

• first step in selecting a particular input
  distribution
• decide upon general family appears to be
  appropriate
• prior knowledge might be helpful
• service times should never be generated from a
  normal distribution WHY????
• approaches
• summary statistics
• histograms
• quantile summaries and box plots

30
Summary Statistics

• some distributions are characterized at least
  partially by functions of their true paramters
• sample estimate
• estimate for range
• minimum X(1)
• maxiumum X(n)
• measure of tendency
• mean ¹
• median x0.5

31
Summary Statistics (cont.)

• sample estimate
• measure of variability
• variance ¾2
• coefficient of variation cv
• measure of symmetry
• skewness n

32
Histograms

• graphic estimate of the plot of the density
  function corresponding to the distribution of
  data
• density functions tend to have recognizable
  shapes in many cases
• graphical estimate of a density should provide a
  good clue to the distribution that might be tried
  as a model for the data

33
Histograms

• how to
• break up range of values into k disjoint adjacent
  intervals (same width)
• b0, b1), b1, b2), , bk-1, bk) b bj
  bj-1
• you might want to throw out a few extremely large
  or small Xis to avoid getting an
  unwidely-looking histogram plot
• let hj be the proportion of Xis that are in the
  jth interval bj-1, bj)
• hint try several values of b and choose the
  smallest one that gives a smooth histogram

34
Histogram (example)

• create 1000 random variables N(0,1)
• create histogram

35
Quantile Summaries

• useful for determining whether the underlying
  probability density function is skewed to the
  right or left
• if F(x) is the distribution function for a
  continuous random variable
• q-quantile of F(x) is that number xq such that
  F(xq) q
• median x0.5
• lower/upper quartiles x0.25 / x0.75
• lower/upper octiles x0.125 / x0.875

36
Quantile Summaries

• Quantile Depth Sample Values Midpoint
• Median i (n1)/2 X(i) X(i)
• Quartiles j (floor(i)1)/2 X(j)
  X(n-j1) X(j) Xn-j1)/2
• Octiles k (floor(j)1)/2 X(k) X(n-k1) X(k)
  Xn-k1)/2
• Extremes 1 X(1) X(n) (X(1) X(n)/2
• if the underlying distribution of the Xis is
  symmetric, then the midpoints should be
  approximately equal
• if the underlying distribution is skewed to the
  right (left), then the midpoints should be
  increasing (decreasing)

37
Box Plots (example)

• graphical representation of quantile summary
• fifty percent of observations fall within the
  horizontal boundaries of the box x0.25, x0.75

38
Necessary Steps for fitting a theoretical
distribution

• hypothesize family
• summary statistics
• histogram
• quantile summary box plots
• estimate parameters
• how representative is fitted distribution?
• Chi-Square Goodness of fit test
• Kolmogorov-Smirnoff Test

39
Estimation of Parameters

• After one ore more candidate families of
  distributions have been hypothesized we most
  somehow specify the values of their parameters in
  order to have a completely specified
  distributions for possible use in simulation
• maximum likelihood estimators (MLEs)
• estimator numerical function of the data
• unknown parameter µ
• hypothesized density function fµ(x)
• likelihood function L(µ)
• estimator is value µ that maximizes Lµ over
  all permissible values of µ

40
Estimation for Parameters (example)

• exponential distribution with unknown parameter
  (µ )
• f(x) (1/) e-x/ for x 0
• likelihood function L()
• we seek value of that maximizes L() over all
  gt 0
• easier to work with its logarithm
• (maximize l() instead of L())
• maximize set derivative equal to zero and solve
  for

41
Necessary Steps for fitting a theoretical
distribution

• hypothesize family
• summary statistics
• histogram
• quantile summary box plots
• estimate parameters
• how representative is fitted distribution?
• Chi-Square Goodness of fit test
• Kolmogorov-Smirnoff Test

42
Goodness-of-Fit Tests

• Statistical hypothesis tests
• used to assess formally whether the observations
  X1, X2, Xn are independent samples form a
  particular distribution with distribution
  function
• H0 the Xis are IID random variables with
  distribution function
• be careful failure to reject H0 should not be
  interpreted as accepting H0 as being true.
• well concentrate on two different ones
• chi-square test
• Kolmogorov-Smirnoff tests

43
Chi-Square Goodness-of-Fit Test

• more formal comparison of a histogram with the
  fitted density or mass function
• how to
• divide range into k adjacent intervals a0, a1),
  a1, a2), , ak-1, ak)
• how to choose number and size of intervals? !
  equiprobable
• determine Nj (number of Xis in the jth interval
  aj-1, aj)
• compute pj (expected proportion of the Xis that
  would fall in the jth interval if we were
  sampling from the fitted distribution
• determine test statistic ?² and reject H0 if its
  too large

44
Chi-Square Goodness-of-Fit Test (cont.)

• case 1 all parameters of the fitted distribution
  are known
• if H0 is true, Â2 converges in distribution (as n
  ? 1) to a chi-square distribution with k-1
  degrees of freedom
• for large n, a test with approximate level is
  obtained by rejecting H0 if
• upper 1 - critical point for a
  chi-square distribution with k-1 dfs

45
Chi-Square Goodness-of-Fit Test (cont.)

• case 2 m parameters had to be estimated to
  specify fitted distribution
• if H0 is true, then as n ! 1 the distribution
  function of ?2 converges to a distribution
  function that lies between the distribution
  function with k-1 and k-m-1 degrees of freedom
• the upper 1 - critical point of
  the asymptotic distribution of ?2 (in general not
  known)
• reject H0 if
• do not reject H0 if
• ambiguous situation if
• recommendation reject H0 if (conservative)

46
Kolmogorov-Smirnov Goodness-of-Fit Test

• compares an empirical distribution function with
  the distribution function of the hypothesized
  distribution
• not necessary to group data
• valid for any sample size n
• tend to be more powerful than chi-squared tests
• but only valid if all parameters of the
  hypothesized distribution are known and the
  distribution is continuous

47
Kolmogorov-Smirnov Goodness-of-Fit Test (cont.)

• compute tests statistics
• define empirical distribution function
• test statistic Dn corresponds to largest
  (vertical) distance between Fn(x) and
  hypothesized distribution function of

48
Kolmogorov-Smirnov Goodness-of-Fit Test (cont.)

• case 1 all parameters of estimated distribution
  function are known
• distribution of Dn does not depend on
  (if is continuous)
• reject H0 if
• c1- (does not depend on n) given in the
  following table
• 1 - 0.85 0.9 0.95 0.975 0.99
• c1- 1.138 1.224 1.358 1.48 1.628

49
Kolmogorov-Smirnov Goodness-of-Fit Test (cont.)

• case 2
• hypothesized distribution is N(¹, ¾2) with both ¹
  and ¾2 unknown (estimated) , estimated
  distribution function
• Dn is calculated the same way as in case 1 -
  different critical points
• reject H0 if
• c1- (does not depend on n) given in the
  following table
• 1 - 0.85 0.9 0.95 0.975 0.99
• c1- 0.775 0.819 0.895 0.955 1.035

50
Kolmogorov-Smirnov Goodness-of-Fit Test (cont.)

• case 3
• hypothesized distribution is exponentially
  distributed (exp())
• with unknown (estimated using )
• estimated distribution function
• reject H0 if
• c1- (does not depend on n) given in the
  following table
• 1 - 0.85 0.9 0.95 0.975 0.99
• c1- 0.926 0.990 1.094 1.19 1.308
