Lecture 3. Error Detection and Correction, Logic Gates

1
Lecture 3. Error Detection and Correction, Logic
Gates
CS147
2x

• Prof. Sin-Min Lee
• Department of Computer Science

2
Chapter Goals

• Error Detection and Correction
• Identify the basic gates and describe the
  behavior of each
• Combine basic gates into circuits
• Describe the behavior of a gate or circuit using
  Boolean expressions, truth tables, and logic
  diagrams

3
Error Detection

• EDC Error Detection and Correction bits
  (redundancy)
• D Data protected by error checking, may
  include header fields
• Error detection not 100 reliable!
• protocol may miss some errors, but rarely
• larger EDC field yields better detection and
  correction

4
Parity Checking
Two Dimensional Bit Parity Detect and correct
single bit errors
Single Bit Parity Detect single bit errors
0
0
5
Internet checksum

• Goal detect errors (e.g., flipped bits) in
  transmitted segment (note used at transport
  layer only)

• Receiver
• compute checksum of received segment
• check if computed checksum equals checksum field
  value
• NO - error detected
• YES - no error detected. But maybe errors
  nonetheless? More later .

• Sender
• treat segment contents as sequence of 16-bit
  integers
• checksum addition (1s complement sum) of
  segment contents
• sender puts checksum value into UDP checksum
  field

6
Checksumming Cyclic Redundancy Check

• view data bits, D, as a binary number
• choose r1 bit pattern (generator), G
• goal choose r CRC bits, R, such that
• ltD,Rgt exactly divisible by G (modulo 2)
• receiver knows G, divides ltD,Rgt by G. If
  non-zero remainder error detected!
• can detect all burst errors less than r1 bits
• widely used in practice (ATM, HDCL)

7
CRC Example

• Want
• D.2r XOR R nG
• equivalently
• D.2r nG XOR R
• equivalently
• if we divide D.2r by G, want remainder R

D.2r G
R remainder
8
What is a gate?

• Combination of transistors that perform
• binary logic
• So called because one logic state enables
• or gates another logic state
• For each gate, the symbol, the truth table,
• and the formula are shown

9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
Computers

• There are three different, but equally powerful,
  notational methods for describing the behavior
  of gates and circuits
• Boolean expressions
• logic diagrams
• truth tables

15
Boolean algebra

• Boolean algebra expressions in this algebraic
  notation are an elegant and powerful way to
  demonstrate the activity of electrical circuits

16
Truth Table

• Logic diagram a graphical representation of a
  circuit
• Each type of gate is represented by a specific
  graphical symbol
• Truth table defines the function of a gate by
  listing all possible input combinations that the
  gate could encounter, and the corresponding output

17
Gates

• Lets examine the processing of the following
  six types of gates
• NOT
• AND
• OR
• XOR
• NAND
• NOR

18
NOT Gate

• A NOT gate accepts one input value and produces
  one output value

Figure 4.1 Various representations of a NOT gate
19
NOT Gate

• By definition, if the input value for a NOT gate
  is 0, the output value is 1, and if the input
  value is 1, the output is 0
• A NOT gate is sometimes referred to as an
  inverter because it inverts the input value

20
AND Gate

• An AND gate accepts two input signals
• If the two input values for an AND gate are both
  1, the output is 1 otherwise, the output is 0

Figure 4.2 Various representations of an AND gate
21
OR Gate

• If the two input values are both 0, the output
  value is 0 otherwise, the output is 1

Figure 4.3 Various representations of a OR gate
22
XOR Gate

• XOR, or exclusive OR, gate
• An XOR gate produces 0 if its two inputs are the
  same, and a 1 otherwise
• Note the difference between the XOR gate and the
  OR gate they differ only in one input situation
• When both input signals are 1, the OR gate
  produces a 1 and the XOR produces a 0

23
XOR Gate
Figure 4.4 Various representations of an XOR gate
24
NAND and NOR Gates

• The NAND and NOR gates are essentially the
  opposite of the AND and OR gates, respectively

Figure 4.5 Various representations of a NAND gate
Figure 4.6 Various representations of a NOR gate
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
Gates with More Inputs

• Gates can be designed to accept three or more
  input values
• A three-input AND gate, for example, produces an
  output of 1 only if all input values are 1

Figure 4.7 Various representations of a
three-input AND gate
29
3-Input And gate
A B C Y 0 0 0 0 0 0 1
0 0 1 0 0 0 1 1 0 1
0 0 0 1 0 1 0 1 1 0
0 1 1 1 1
Y A . B . C
30
Constructing Gates

• A transistor is a device that acts, depending on
  the voltage level of an input signal, either as a
  wire that conducts electricity or as a resistor
  that blocks the flow of electricity
• A transistor has no moving parts, yet acts like
  a switch
• It is made of a semiconductor material, which is
  neither a particularly good conductor of
  electricity, such as copper, nor a particularly
  good insulator, such as rubber

31
Circuits

• Two general categories
• In a combinational circuit, the input values
  explicitly determine the output
• In a sequential circuit, the output is a function
  of the input values as well as the existing state
  of the circuit
• As with gates, we can describe the operations of
  entire circuits using three notations
• Boolean expressions
• logic diagrams
• truth tables

32
Combinational Circuits

• Gates are combined into circuits by using the
  output of one gate as the input for another

AND
OR
AND
Page 99
33
Combinational Circuits
jasonm Redo to get white space around table
(p100)
Page 100

• Because there are three inputs to this circuit,
  eight rows are required to describe all possible
  input combinations
• This same circuit using Boolean algebra
• (AB AC)

34
Now lets go the other way lets take a Boolean
expression and draw
jasonm Redo table to get white space (p101)

• Consider the following Boolean expression A(B
  C)

Page 100
Page 101

• Now compare the final result column in this truth
  table to the truth table for the previous example
• They are identical

35
Simple design problem

• A calculation has been done and its results
• are stored in a 3-bit number
• Check that the result is negative by anding
• the result with the binary mask 100
• Hint a mask is a value that is anded with
• a value and leaves only the important bit

36
Using And gates to mask
37
Shorthand way to draw this

• If the values shown had 32 bits, you would
• have a lot of wires and and gates on the
• drawing.
• Here is a shorthand way to draw this

38
Masked value
Using And gates to mask
39
and in Java, C, C

• means AND, bit-by-bit
• What we just did was the equivalent of
• Y A B
• means AND, on a word, boolean basis
• 101 010 is true
• 101 010 is zero

40
Now lets go the other way lets take a Boolean
expression and draw

• We have therefore just demonstrated circuit
  equivalence
• That is, both circuits produce the exact same
  output for each input value combination
• Boolean algebra allows us to apply provable
  mathematical principles to help us design
  logical circuits

41
Properties of Boolean Algebra
jasonm Redo table (p101)
Page 101
42
Adders

• At the digital logic level, addition is performed
  in binary
• Addition operations are carried out by special
  circuits called, appropriately, adders

43
Adders
jasonm Redo table (p103)

• The result of adding two binary digits could
  produce a carry value
• Recall that 1 1 10 in base two
• A circuit that computes the sum of two bits and
  produces the correct carry bit is called a half
  adder
• Notice the Sum Carry are NEVER both 1.

(XOR)
(AND)
Page 103
44
Adders

• Circuit diagram representing a half adder
• Two Boolean expressions
• sum A ? B
• carry AB

Page 103
45
Adders

• A circuit called a full adder takes the carry-in
  value into account

Figure 4.10 A full adder
46
Adding Many Bits

• To add 2 8-bit values, we can duplicate a
  full-adder circuit 8 times. The carry-out from
  one place value is used as the carry in for the
  next place value. The value of the carry-in for
  the rightmost position is assumed to be zero, and
  the carry-out of the leftmost bit position is
  discarded (potentially creating an overflow
  error).

47
Universal Gates
How to use NOR gate to build a NOT gate?
Truth Table
A B C Q
0 0 0 1
1 1 1 0
Logic Gates
Hint! Link inputs B C together (to a same
source).
When A 0, B C A 0 When A 1, B C A
1
48
Universal Gates
How to use NOR gates to build an OR gate?
Truth Table
A B C D E Q
0 0 1 1 1 0
0 1 0 0 0 1
1 0 0 0 0 1
1 1 0 0 0 1
NOT
NOR
D
A
C
Q
B
E
Hint 1 Use 2 NOR gates
Hint 2 From a NOR gate, build a NOT gate
Hint 3 Put this NOT gate after a NOR gate
49
Universal Gates
How to use NOR gates to build an AND gate?
Truth Table
A B C D Q
0 0 1 1 0
0 1 1 0 0
1 0 0 1 0
1 1 0 0 1
Hint 1 Use 3 NOR gates
Hint 2 From 2 NOR gates, build 2 NOT gates
Hint 3 Each NOT gate is an
input to the 3rd NOR gate
50
Universal Gates
How to use NOR gates to build a NAND gate?
Truth Table
A B C D E Q
0 0 1 1 0 1
0 1 1 0 0 1
1 0 0 1 0 1
1 1 0 0 1 0
Hint 1 Use 4 NOR gates
Hint 2 Use 3 NOR gates to build
a NAND gate (previous lesson)
Hint 3 Use the 4th NOR gate to build a NOT gate
Hint 4 Insert NOT gate after NAND gate
Hint 5 NOT-NAND AND
51
Universal Gates
How to use NAND gates to build a NOT gate?
Truth Table
A B C Q
0 0 0 1
1 1 1 0
Logic Gates
Hint! Link inputs B C together (to a same
source).
When A 0, B C A 0 When A 1, B C A
1
52
Universal Gates
How to use NAND gates to build an AND gate?
Truth Table
A B C Q
0 0 1 0
0 1 1 0
1 0 1 0
1 1 0 1
NOT
NAND
C
A
Q
B
Hint 1 Use 2 NAND gates
Logic Gates
Hint 2 From a NAND gate, build a NOT gate
Hint 3 Put this NOT gate after a NAND gate
Hint 4 NOT-NAND AND
53
Universal Gates
How to use NAND gates to build an OR gate?
Truth Table
A B C D Q
0 0 1 1 0
0 1 1 0 1
1 0 0 1 1
1 1 0 0 1
Hint 1 Use 3 NAND gates
Logic Gates
Hint 2 Use 2 NAND gates to build 2 NOT gates
Hint 3 Put the 3rd NAND gate
after the 2 NOT gates
54
Universal Gates
How to use NAND gates to build a NOR gate?
Truth Table
A B C D E Q
0 0 1 1 0 1
0 1 1 0 1 0
1 0 0 1 1 0
1 1 0 0 1 0
Hint 1 Use 4 NAND gates
Logic Gates
Hint 2 Use 3 NAND gates to build an OR gate
Hint 3 Use a NOR gate to build a NOT gate
Hint 4 Put the NOT gate after OR gate
55
(No Transcript)
56
(No Transcript)
57
as Universal Logic Gates
NAND and NOR

• Any logic circuit can be built using only NAND
  gates, or only NOR gates. They are the only
  logic gate needed.
• Here are the NAND equivalents

58
NAND and NOR as Universal Logic Gates (cont)

• Here are the NOR equivalents
• NAND and NOR can be used to reduce the number of
  required gates in a circuit.

59
Reading Assignment
Chapter Two, Four
Practice Assignment
P.43 1, 10, 11, 100,111, 1001. p.94 2
