Computer Security 3e

1
Computer Security 3e

• Dieter Gollmann

www.wiley.com/college/gollmann
2
Chapter 10Software Security
3
Secure Software

• Software is secure if it can handle intentionally
  malformed input the attacker picks (the
  probability distribution of) the inputs.
• Secure software Protect the integrity of the
  runtime system.
• Secure software ? software with security
  features.
• Networking software is a popular target
• Intended to receive external input.
• May construct instructions dynamically from
  input.
• May involve low level manipulations of buffers.

4
Security Reliability

• Reliability deals with accidental failures
  Failures are assumed to occur according to some
  given probability distribution.
• The probabilities for failures is given first,
  then the protection mechanisms are constructed.
• To make software more reliable, it is tested
  against typical usage patterns It does not
  matter how many bugs there are, it matters how
  often they are triggered.

5
Security Reliability

• In security, the defender has to move first the
  attacker picks inputs to exploit weak defences.
• To make software more secure, it has to be tested
  against untypical usage patterns (but there are
  typical attack patterns).
• On a PC, you are in control of the software
  components sending inputs to each other.
• On the Internet, hostile parties can provide
  input Do not trust your inputs.

6
Agenda

• Malware
• Dangers of abstraction
• Input validation
• Integers
• Buffer overflows
• Scripting languages
• Race conditions
• Defences Prevention Detection Reaction

7
Malware

• Malware software that has a malicious purpose.
• Computer virus self-replicating code attached to
  some other piece of code a virus infects a
  program by inserting itself into the program
  code.
• Worm replicating but not infecting program most
  reported virus attacks would be better described
  as worm attacks.
• Trojan horse program with hidden side effects,
  not intended by the user executing the program.
• Logic bomb program that is only executed when a
  specific trigger condition is met.

8
Preliminaries

• When writing code, programmers use elementary
  concepts like character, variable, array,
  integer, data program, address (resource
  locator), atomic transaction,
• These concepts have abstract meanings.
• For example, integers are an infinite set with
  operations add, multiply, less or equal,
• To execute a program, we need concrete
  implementations of these concepts.

9
Benefits of Abstraction

• Abstraction (hiding unnecessary detail) is an
  extremely valuable method for understanding
  complex systems.
• We dont have to know the inner details of a
  computer to be able to use it.
• We can write software using high level languages
  and graphical methods.
• Anthropomorphic images explain what computers do
  (send mail, sign document).

10
Dangers of Abstraction

• Software security problems typically arise when
  concrete implementation and the abstract
  intuition diverge.
• We will explore a few examples
• Address (location)
• Character
• Integer
• Variable (buffer overflows)
• Double-linked list
• Atomic transaction

11
Input Validation

• An application wants to give users access only to
  files in directory A/B/C/.
• Users enter filename as input full file name
  constructed as A/B/C/input.
• Attack use ../ a few times to step up to root
  directory first e.g. get password file with
  input /../../../../etc/passwd.
• Countermeasure input validation, filter out ../
  (but as you will see in a moment, life is not
  that easy).
• Do not trust your inputs.

12
Unicode Characters

• UTF-8 encoding of Unicode characters RFC 2279
• Multi-byte UTF-8 formats a character has more
  than one representation
• Example /
• format binary hex
• 1 byte 0xxx xxxx 0010 1111 2F
• 2 byte 110x xxxx 1100 0000 C0 10xx xxxx 1010
  1111 AF
• 3 byte 1110 xxxx 1110 0000 E0 10xx xxxx 1000
  0000 80 10xx xxxx 1010 1111 AF

13
Exploit Unicode bug

• Vulnerability in Microsoft IIS URL starting with
  IPaddress/scripts/..c0af../winnt/system32/
• Translated to directory C\winnt\system32
• The /scripts/ directory is usually
  C\inetpub\scripts
• Because c0af is the 2 byte UTF-8 encoding of /
• ..c0af../ becomes ../../
• ../../ steps up two levels in the directory
• IIS did not filter illegal Unicode
  representations using multi-byte UTF-8 formats
  for single byte characters.

14
Double Decode

• Consider URL starting with addr./scripts/..253
  266../winnt/system32/
• This URL is decoded to addr./scripts/..2f../win
  nt/system32/
• Convert 253266 to Unicode 00100101
  00110010 01100110 ? 2f ( /)
• If the URL is decoded a second time, it gets
  translated to directory C\winnt\system32
• Beware of mistranslations (between levels of
  abstraction) that change the meaning of texts.

15
Unix rlogin

• Unix login command
• login -p -hlthostgt -fltusergt
• -f option forces log in user is not asked for
  password
• Unix rlogin command for remote login
• rlogin -lltusergt ltmachinegt
• The rlogin daemon sends a login request for
  ltusergt to ltmachinegt
• Attack (some versions of Linux, AIX)
• rlogin -l -froot ltmachinegt
• Results in forced login as root at the designated
  machine
• login -froot ltmachinegt

16
Unix rlogin

• Problem Composition of two commands.
• Each command on its own is not vulnerable.
• However, rlogin does not check whether the
  username has special properties when passed to
  login.

17
Programming with Integers

• In mathematics integers form an infinite set.
• On a computer systems, integers are represented
  in binary.
• The representation of an integer is a binary
  string of fixed length (precision), so there is
  only a finite number of integers.
• Programming languages signed unsigned
  integers, short long ( long long) integers,

18
What will happen here?

• int i 1
• while (i gt 0)
• i i 2

19
Computing with Integers

• Unsigned 8-bit integers
• 255 1 0 16 ? 17 16
• 0 1 255
• Signed 8-bit integers
• 127 1 -128 -128/-1 -1
• In mathematics a b ? a for b ? 0
• As you can see, such obvious facts are no
  longer true.

20
Twos Complement

• Signed integers are usually represented as 2s
  complement numbers.
• Most significant bit (sign bit) indicates the
  sign of the integer
• If sign bit is zero, the number is positive.
• If sign bit is one, the number is negative.
• Positive numbers given in normal binary
  representation.
• Negative numbers are represented as the binary
  number that when added to a positive number of
  the same magnitude equals zero.

21
Code Example 2

• OS kernel system-call handler checks string
  lengths to defend against buffer overruns.

len1 lt sizeof(buf)
char buf128 combine(char s1, size_t len1,
char s2, size_t len2) if (len1 len2 1 lt
sizeof(buf)) strncpy(buf, s1,
len1) strncat(buf, s2, len2)
len2 0xffffffff
len2 1 232-1 1 0 mod 232
strncat will be executed
Example from Markus Kuhns lecture notes
22
Array

• You are given an array starting at memory
  location 0xBBBB (on a 16-bit machine)
• Array elements are single words.
• Which index do you write to so that memory
  location 0x8000 is overwritten?
• You also must check lower bounds for array
  indices.

0xBBBB
base
48059
0xC445
-15291
0x8000
32768
23
Canonicalization

• Canonicalization the process that determines how
  various equivalent forms of a name are resolved
  to a single standard name.
• The single standard name is also known as the
  canonical name.
• In general, an issue whenever an object has
  different but equivalent representations
• Example XML documents
• Canonicalization must be idempotent.

24
Napster File Filtering

• Napster was ordered by court to block access to
  certain songs.
• Napster implemented a filter that blocked
  downloads based on the name of the song.
• Napster users found a way around by using
  variations of the name of songs.
• This is a particularly difficult problem because
  the users decide which names are equivalent.

25
Case-sensitive?

• Security mechanism is case sensitive
• MYFILE is different from MyFile
• File system is case-insensitive
• MYFILE is the same as MyFile
• Permissions are defined for one version of the
  name only
• Attacker requests access to another version.
• The security mechanism grants the request.
• The file system gives access to the resource that
  should have been protected.
• Vulnerability in Apache web server with HFS

26
Directory Traversal

• An application may try to keep users in a
  specific directory.
• Attack walk out of the directory using ../
  attack may try to hide .. by using alternative
  UTF-8 encodings.
• Relative file names system starts from a list of
  predefined directories to look for the file.
• Attack put malicious code in a directory that is
  searched before the directory used by the
  application being attacked.
• Dont filter for patterns, filter for results.

27
Memory configuration

• Stack contains return address, local variables
  and function arguments relatively easy to decide
  in advance where a particular buffer will be
  placed on the stack.
• Heap dynamically allocated memory more
  difficult but not impossible to decide in advance
  where a particular buffer will be placed on the
  heap.

28
Variables

• Buffer concrete implementation of a variable.
• If the value assigned to a variable exceeds the
  size of the allocated buffer, memory locations
  not allocated to this variable are overwritten.
• If the memory location overwritten had been
  allocated to some other variable, the value of
  that other variable is changed.
• Depending on circumstances, an attacker can
  change the value of a sensitive variable A by
  assigning a deliberately malformed value to some
  other variable B.

29
Buffer Overruns

• Unintentional buffer overruns crash software, and
  have been a focus for reliability testing.
• Intentional buffer overruns are a concern if an
  attacker can modify security relevant data.
• Attractive targets are return addresses (specify
  the next piece of code to be executed) and
  security settings.
• In languages like C or C the programmer
  allocates and de-allocates memory.
• Type-safe languages like Java guarantee that
  memory management is error-free.

30
Buffer Overrun (1980s)

• Login in one version of Digitals VMS operating
  system to log in to a particular machine, enter
• username/DEVICE ltmachinegt
• The length of the argument machine was not
  checked a device name of more than 132 bytes
  overwrote the privilege mask of the process
  started by login users could thus set their own
  privileges.

31
System Stack

• Function call stack frame containing function
  arguments, return address, statically allocated
  buffers pushed on the stack.
• When the call returns, execution continues at the
  return address specified.
• Stack usually starts at the top of memory and
  grows downwards.
• Layout of stack frames is reasonably predictable.

32
Stack Frame Layout
extended instruction pointer (return address)
extended base pointer (reference point for
relative addressing) a.k.a. frame pointer
33
Stack-based Overflows

• Find a buffer on the runtime stack of a
  privileged program that can overflow the return
  address.
• Overwrite the return address with the start
  address of the code you want to execute.
• Your code is now privileged too.

return address
write to A value1 value2 my_address
buffer for variable A
34
Code Example

• Declare a local short string variable
• char buffer80
• use the standard C library routine call
• gets(buffer)
• to read a single text line from standard input
  and save it into buffer.
• Works fine for normal-length lines, but corrupts
  the stack if the input is longer than 79
  characters.
• Attacker loads malicious code into buffer and
  redirects return address to start of attack code.

35
Shellcode

• Overwrite return address so that execution jumps
  to the attack code (shellcode).
• Where to put the shellcode?
• Shellcode may be put on the stack as part of the
  malicious input a.k.a. argv-method.
• To guess the location, guess distance between
  return address and address of the input
  containing the shellcode.
• Details e.g. in Smashing the Stack for Fun and
  Profit.
• return-to-libc method attack calls system
  library change to control flow, but no shellcode
  inserted.

36
Heap Overruns

• More difficult to determine how to overwrite a
  specific buffer.
• More difficult to determine which other buffers
  will be overwritten in the process if you are an
  attacker, you may not want to crash the system
  before you have taken over.
• Even attacks that do not succeed all the time are
  a threat.
• Can overwrite filenames and function pointers,
  and mess up memory management.

37
Memory Allocation
38
Overwriting Pointers

• Modify return address with buffer overrun on
  stack.
• Attacker can fairly easily guess the location of
  this pointer relative to a vulnerable buffer.
• Defender knows which target to protect.
• More powerful attack overwrite arbitrary pointer
  with an arbitrary value.
• More targets, hence more difficult to defend
  against.
• Attacker does not even have to overwrite the
  pointer!
• Attacker can lure the operating system into
  reading malformed input and then do the job for
  the attacker.

39
Managing Memory in C

• Allocating memory
• void malloc (size_t size)
• Returns pointer to newly allocated block of size
  bytes.
• Contents of the block are not initialized.
• Returns null pointer if block cannot be
  allocated.
• Deallocating memory
• void free (void ptr)
• ptr must have been returned by a previous call
  to malloc(), calloc()or realloc().
• If ptr is null, no operation is performed.
• Behaviour undefined if free(ptr) has already been
  called.

40
Memory Organization

• Case study Doug Lea malloc.
• Memory divided into chunks.
• A chunk contains user data and control data.
• Chunks allocated by malloc contain boundary tags.
• Free chunks are placed in bins a bin is a double
  linked lists.
• Several bins, for chunks of different sizes.
• Free chunks contain boundary tags and forward and
  backward pointer to their neighbours in the bin.

41
Allocated and Free Chunks
previously used for data
size of chunk
size of previous chunk
42
Control Flags

• Values for size always given in multiples of 8.
• Three last bits of size may be used for control
  flags
• PREV_INUSE 0x1
• IS_MAPPED 0x2
• Some libraries also use the third bit.
• When a chunk is freed it is coalesced into a
  single chunk with neighbouring free chunks.
• No adjacent free chunks in memory.
• Technicality prev_size not used when the
  previous chunk is allocated.

43
Coalescing Chunks
PREV_INUSE 0 so merge chunks A and B and remove
B from bin
user data
chunk C allocated
size C 0x0
prev_size
go to next chunk using size as offset and check
PREV_INUSE
unused
bk
chunk B free
fd
size B 0x1
prev_size
go to next chunk using size as offset
user data
chunk A to be freed
size A
prev_size
44
Managing a Bin

• Bin double-linked lists of free chunks, ordered
  by increasing size to facilitate fast
  smallest-first search.
• To allocate a buffer, take a suitable block from
  the list using unlink().
• When a block is freed, it is inserted in this
  list using frontlink().

45
Frontlink() Simplified

• define frontlink(A, P, S, IDX, BK, FD)
• ...
• 1 FD start_of_bin(IDX)
• 2 while ( FD ! BK S lt chunksize(FD) )

• 3 FD FD-gtfd
• 4 BK FD-gtbk
• 5 P-gtbk BK
• 6 P-gtfd FD
• 7 FD-gtbk BK-gtfd P

46
Frontlink() Macro

• Store chunk of size S, pointed to by P, at
  appropriate position in the double linked list of
  bin with index IDX.
• 1 FD initialized with a pointer to the start of
  the list of the given bin.
• 2 Loop searches the double linked list to find
  first chunk smaller than P or the end of the list
  by following consecutive forward pointers (line
  3).
• 4 Follow back pointer BK to previous element in
  list.
• 56 Set backward and forward pointers for
  chunk.
• 7 Update backward pointer of next chunk and
  forward pointer of previous chunk to address of
  chunk P (field fd at 8 byte offset within a
  boundary tag).

47
Unlink
define unlink(P, BK, FD) 1 FD P-gtfd
2 BK P-gtbk 3 FD-gtbk BK 4 BK-gtfd
FD

• Save pointers in chunk P to FD and BK.
• Update backward pointer of next chunk in the
  list address located at FD plus 12 bytes (offset
  of bk field in boundary tag) overwritten with
  value stored in BK.
• Update forward pointer of previous chunk in the
  list.

48
Mental Exercise

• What will happen if we free a chunk that has
  already been freed?
• Add a chunk B3 into the following list.
• Then add it again

49
Insert chunk B before B3

• Assume loop terminates with FD equal to B3
• 4 BK FD-gtbk BK B2
• 5 P-gtbk BK B-gtbk B2
• 6 P-gtfd FD B-gtfd B3
• 7 FD-gtbk BK-gtfd P
• B3-gtbk B2-gtfd B

50
Insert chunk B again

• Loop ends with FD equals to B
• 4 BK FD-gtbk BK B2
• 5 P-gtbk BK B-gtbk B2
• 6 P-gtfd FD B-gtfd B
• 7 FD-gtbk BK-gtfd P B-gtbk B2-gtfd
  B

51
Unlink double-freed chunk B

• 1 FD P-gtfd FD B-gtfd B
• 2 BK P-gtbk BK B-gtbk B
• 3 FD-gtbk BK FD-gtbk B-gtbk B
• 4 BK-gtfd FD BK-gtfd B-gtfd B
• Nothing changes the chunk removed from the list
  of free chunks is still on the list!

B1
B3
B
B2
52
Double-free vulnerabilities

• Double Free Bug in zlib Compression Library
  (v1.1.3)
• CERT Advisory CA-2002-07

53
Double-free

• Allocate memory chunk A.
• Call free(A), with forward or backward
  consolidation to create larger chunk.
• Allocate larger chunk B likely to get space just
  freed.
• Copy fake chunk into B that appears as an
  unallocated chunk adjacent to A, with fake
  pointers fd and bk chosen by the attacker.

54
Double-free

• Call free(A) again unlinking the free fake
  chunk overwrites memory using fake pointers fd
  and bk
• 1 FDfd
• 2 BKbk
• 3 fd-gtbkbk
• Value bk written to memory address fd12.
• Second call of free(A) has desired effect only if
  the pointer to A had not been set to null when A
  was freed the first time.
• free(ptr) If ptr is null, no operation is
  performed.

55
Double-free Attack
large free chunk
allocated as chunk B
Now free A again A will be coalesced with
neighbouring fake free chunk unlink is applied
to fake chunk.
fake free chunk
chunk A
free chunk
56
Type Confusion
57
Type Safety Java

• Type safety (memory safety) programs cannot
  access memory in inappropriate ways.
• Each Java object has a class only certain
  operations are allowed to manipulate objects of
  that class.
• Every object in memory is labelled with a class
  tag.
• When a Java program has a reference to an object,
  it has internally a pointer to the memory address
  storing the object.
• Pointer can be thought of as tagged with a type
  that says what kind of object the pointer is
  pointing to.

58
Type Confusion

• Dynamic type checking check the class tag when
  access is requested.
• Static type checking check all possible
  executions of the program to see whether a type
  violation could occur.
• If there is a mistake in the type checking
  procedure, a malicious applet might be able to
  launch a type confusion attack by creating two
  pointers to the same object-with incompatible
  type tags.

59
Type Confusion

• Assume the attacker manages to let two pointers
  point to the same location.

class T SecurityManager x class U
MyObject x
class definitions
T t the pointer tagged T U u the pointer
tagged U t.x System.getSecurity() MyObject m
u.x
malicious applet
60
Type Confusion
object 1
t type T
u type U
v type V
object 2

Reference Table
memory
61
Type Confusion

• The SecurityManager field can now also be
  manipulated from MyObject.
• We sketch a type confusion attack in Netscape
  Navigator 3.0?5 (discovered by Drew Dean), fixed
  in version 3.0?6.
• Source Gary McGraw Edward W. Felten Java
  Security, John Wiley Sons, 1997.

62
Netscape Vulnerability

• Java allows a program that uses type T also to
  use type array of T.
• Array types are defined by the VM for internal
  use their name begins with the character .
• A programmer defined classname is not allowed to
  start with this character.
• Hence, there should be no danger of conflict.
• However, a Java byte code file could declare its
  own name to be a special array types name, thus
  redefining one of Javas array types.

63
Data and Code
64
Scripting

• Scripting languages used to construct commands
  (scripts) from predefined code fragments and user
  input.
• Script is then passed to another software
  component where it is executed.
• Attacker may hide additional commands in user
  input.
• Defender has to check and sanitize user inputs.
• Both have to be aware of certain technical
  details of the component executing the script
• Symbols that terminate command parameters.
• Symbols that terminate commands.
• Dangerous commands, e.g. commands for executing
  the commands they receive as input ( eval, exec,
  system, ).

65
Scripting

• Scripting languages Perl, PHP, Python, Tcl,
  Safe-Tcl, JavaScript,
• Example A CGI script for a Unix server that
  sends file to clientaddress
• cat file mail clientaddress
• With the mail address to_at_me rm -rf / as input
  the server executes
• cat file mail to_at_me rm -rf /
• After mailing the file to_at_me, all files the
  script has permission to delete are deleted.

66
SQL Injection

• Strings in SQL commands placed between single
  quotes.
• Example query from SQL database
• sql "SELECT FROM client WHERE name
  name"
• Intention insert legal user name like Bob into
  query.
• Attack enters as user name Bob OR 11 --
• SQL command becomes
• SELECT FROM client WHERE name Bob OR 11--
• Because 11 is TRUE, name Bob OR 11 is TRUE,
  and the entire client database is selected -- is
  a comment erasing anything that would follow.

67
SQL Injection

• Countermeasures against code injection
• Input validation make sure that no unsafe input
  is used in the construction of a command.
• Change the modus operandi modify the way
  commands are constructed and executed so that
  unsafe input can do no harm.
• Parametrized queries with bound parameters (DBI
  placeholders in Perl) follow the second approach.

• Scripts compiled with placeholders instead of
  user input.
• Commands called by transmitting the name of the
  procedure and the parameter values.
• During execution, placeholders are replaced by
  the actual input.
• This defence does not work for parametrized
  procedures containing eval() statements that
  accept user inputs as arguments.

68
Race Conditions
69
Race Conditions

• Multiple computations access shared data in a way
  that their results depend on the sequence of
  accesses.
• Multiple processes accessing the same variable.
• Multiple threads in multi-threaded processes (as
  in Java servlets).
• An attacker can try to change a value after it
  has been checked but before it is being used.
• TOCTTOU (time-to-check-to-time-of use) is a
  well-known security issue.

70
Example CTSS (1960s)

• Password file shown as message of the day.
• Every user had a unique home directory.
• When a user invoked the editor, a scratch file
  with fixed name SCRATCH was created in this
  directory .
• Innovation Several users may work concurrently
  system manager.

71
Race Conditions
The abstraction atomic transaction has been
broken.
72
Defences
73
Prevention Hardware

• Hardware features can stop buffer overflow
  attacks from overwrite control information.
• For example, a secure return address stack (SRAS)
  could protect the return address.
• Separate register for the return address in
  Intels Itanium processor.
• With protection mechanisms at the hardware layer
  there is no need to rewrite or recompile
  programs only some processor instructions have
  to be modified.
• Drawback existing software, e.g. code that uses
  multi-threading, may work no longer.

74
Prevention Non-executable Stack

• Stops attack code from being executed from the
  stack.
• Memory management unit configured to disable code
  execution on the stack.
• Not trivial to implement if existing O/S routines
  are executing code on the stack.
• General issue backwards compatibility security
  measures may break existing code.
• Attackers may find ways of circumventing this
  protection mechanism.

75
Prevention Safer Functions

• C is infamous for its unsafe string handling
  functions strcpy, sprintf, gets,
• Example strcpy
• char strcpy( char strDest, const char
  strSource )
• Exception if source or destination buffer are
  null.
• Undefined if strings are not null-terminated.
• No check whether the destination buffer is large
  enough.

76
Prevention Safer Functions

• Replace unsafe string functions by functions
  where the number of bytes/characters to be
  handled are specified
• strncpy, _snprintf, fgets,
• Example strncpy
• char strncpy( char strDest, const char
  strSource, size_t count )
• You still have to get the byte count right.
• Easy if data structure used only within a
  function.
• More difficult for shared data structures.

77
Prevention Filtering

• Filtering inputs has been a recommended defence
  several times before in this course.
• Whitelisting Specify legal inputs accept legal
  inputs, block anything else.
• Conservative, but if you forget about some
  specific legal inputs a legitimate action might
  be blocked.
• Blacklisting Specify forbidden inputs block
  forbidden inputs, accept anything else.
• If you forget about some specific dangerous
  input, attacks may still get through.
• Taint analysis Mark inputs from untrusted
  sources as tainted, stop execution if a security
  critical function gets tainted input sanitizing
  functions produce clean output from tainted input.

78
Prevention Filtering

• White lists work well when valid inputs can be
  characterized by clear rules, preferably
  expressed as regular expressions.
• Filtering rules could also refer to the type of
  an input e.g., an is_numeric() check could be
  applied when an integer is expected as input.
• Dangerous characters can be sanitized by using
  safe encodings.
• E.g., in HTML lt, gt and should be encoded as
  lt, gt, and amp.
• Escaping places a special symbol, often
  backslash, in front of the dangerous character.
• E.g., escaping single quotes will turn dHondt
  into d\Hondt.

79
Interaction between Layers

• addslashes() inserts backslash as guard in
  front of every single quote or does it?
• GBK character set for Simplified Chinese, has
  one and two byte characters.
• 0xbf27 is not a valid GBK multi-byte character
  as single-byte characters, we get '.
• Note 0x27 is the single quote 0x5c is the
  slash.
• Add a slash in front of the single quote
  0xbf5c27
• Valid multi-byte character 0xbf5c followed by a
  single quote the single quote has survived
  unguarded!
• Lesson Danger of abstraction manipulation at
  lower layer does not have the desired effect.

?'
http//shiflett.org/blog/2006/jan/addslashes-versu
s-mysql-real-escape-string
80
Prevention Type Safety

• Type safety guarantees absence of untrapped
  errors by static checks and by runtime checks.
• The precise meaning of type safety depends on the
  definition of error.
• Examples Java, Ada, C, Perl, Python, etc.
• Languages neednt be typed to be safe LISP
• Type safety is difficult to prove completely.

81
Detection Canaries

• Detect attempts at overwriting the return
  address.
• Place a check value (canary) in the memory
  location just below the return address.
• Before returning, check that the canary has not
  been changed.
• Stackguard random canaries.
• Alternatives null canary, terminator canary
• Source code has to be recompiled to insert
  placing and checking of the canary.

82
Canaries
return address
my_address
write to A value1 value2 my_address to A
check value
value2 ? check value
canary
value1
buffer for variable A
attack detected
83
Detection Code Inspection

• Code inspection is tedious we need automation.
• K. Ashcraft D. Engler Using Programmer-Written
  Compiler Extensions to Catch Security Holes, IEEE
  Symposium on Security Privacy 2002.
• Meta-compilation for C source code expert
  system incorporating rules for known issues
  untrustworthy sources ? sanitizing checks ? trust
  sinks raises alarm if untrustworthy input gets
  to sink without proper checks.
• Code analysis to learn new design rules Where is
  the sink that belongs to the check we see?
• Microsoft has internal code inspection tools.

84
Detection Testing

• White box testing tester has access to source
  code.
• Black-box testing when source code is not
  available.
• You do not need source code to observe how memory
  is used or to test how inputs are checked.
• Example syntax testing of protocols based on
  formal interface specification, valid cases,
  anomalies.
• Applied to SNMP implementations vulnerabilities
  in trap handling and request handling found
  http//www.cert.org/advisories/CA-2002-03.html
• Found by Oulu University Secure Programming Group
  http//www.ee.oulu.fi/research/ouspg/

85
Mitigation Least Privilege

• Limit privileges required to run code if code
  running with few privileges is compromised, the
  damage is limited.
• Do not give users more access rights than
  necessary do not activate options not needed.
• Example debug option in Unix sendmail when
  switched on at the destination, mail messages can
  contain commands that will be executed on the
  destination system.
• Useful for system managers but need not be
  switched on all the time exploited by the
  Internet Worm of 1988.

86
Lesson Learned

• In the past, software was shipped in open
  configurations (generous access permissions, all
  features activated) user had to harden the
  system by removing features and restricting
  access rights.
• Today, software often shipped in locked-down
  configurations users have to activate the
  features they want to use.

87
Reaction Keeping Up-to-date

• Information sources CERT advisories, BugTraq at
  www.securityfocus.com, security bulletins from
  software vendors.
• Hacking tools use attack scripts that
  automatically search for and exploit known type
  of vulnerabilities.
• Analysis tools following the same ideas will
  cover most real attacks.
• Patching vulnerable systems is not easy you have
  to get the patches to the users and avoid
  introducing new vulnerabilities through the
  patches.

88
Intrusion Patterns
patch released
W. Arbaugh, B. Fithen, J. McHugh Windows of
Vulnerability A Case Study Analysis, IEEE
Computer, 12/2000
89
Broken Abstractions

• Treating the problems presented individually,
  would amount to penetrate-and-patch at a
  meta-level.
• We looking for general patterns in insecure
  software, we see that familiar programming
  abstractions like variable, array, integer, data
  code, address, or atomic transaction are being
  implemented in a way that breaks the abstraction.
• Software security problems can be addressed
• in the processor architecture,
• in the programming language we are using,
• in the coding discipline we adhere to,
• through checks added at compile time (e.g.
  canaries),
• and during software development and deployment.

90
Summary

• Many of the problems listed may look trivial.
• There is no silver bullet
• Code-inspection better at catching known
  problems, may raise false alarms.
• Black-box testing better at catching known
  problems.
• Type safety guarantees from an abstract
  (partial) model need not carry over to the real
  system.
• Experience in high-level programming languages
  may be a disadvantage when writing low level
  network routines.
