VCE IT Theory Slideshows

1
VCE IT Theory Slideshows
Problem Solving Methodology 3 Development

• By Mark Kelly
• Vceit.com

2
Contents

• Activities
• Validation
• Informal Testing
• User documentation
• Formal testing

3
Development

• Often involves a coordinated team using project
  management to monitor their progress and manage
  their actions and resources.

4
Acquire equipment

• Hardware is bought off-the-shelf or custom built.
• Software is bought off-the-shelf or custom
  programmed.
• Custom equipment is very expensive and slow to
  create, but suits the users needs perfectly.
• Off-the-shelf equipment is far cheaper, easier to
  get and has more support, but needs to offer all
  the functionality the user needs.

5
Validation

• Checks for the reasonableness of data being
  input, mainly
• Range checks
• Existence checks
• Type checks
• Can be done manually or electronically

6
INFORMAL TESTING
7
Informal testing

• Software and hardware are assembled
• Informal testing carried out at each stage of
  development
• Component testing ensures each component works
  as it should in isolation (e.g. a software
  module, a hardware device)
• Integration testing ensures components work
  properly together. e.g. a memory chip can
  communicate properly with a CPU a software
  module receives the right data from another
  module.

8
Testing Activities

• Deciding
• What needs to be tested (e.g. Formulas, buttons,
  media, links, communications)?
• How will each thing be tested?
• What test data, if any, will be used?
• What are the expected results?
• Conducting the tests
• Recording the actual results
• Correcting any identified errors.

9
Testing types

• Unit testing tests system components in
  isolation to see if they behave properly
• Integration testing tests components once they
  have been integrated with other components.
• Often components are all fine by themselves, but
  errors arise when they try to exchange data.

10
User Documentation

• Once the system is finished and mature,
  documentation is written.
• See here for the documentation slideshow
• See Onscreen user doc slideshow

11
After development formal testing

• Informal check as you go testing occurred
  during development
• Formal testing is an official procedure that
  proves the system works as it should
• The objectives specified in the analysis phases
  logical designare confirmed one by one

12
Formal testing

• May also involve user acceptance testing (UAT)
• The customer, or typical people who will be using
  the system for real, use it and report their
  findings.

13
Formal testing

• Client Show me that it can produce 10,000
  invoices in 5 hours
• Developer OK. Watch
• Time passes
• Client OK. Now show me the improved
  readability
• Developer Compare this new output with sample
  output from the old system.
• Client - Good. Now show me
• etc
