Title: ECG


1
ECG
2
Fundamentals of Electrocardiography
  • The conduction system is the mechanism by which
    the heart contracts. Contraction is controlled
    by specialized cells within the heart that
    generate and distribute electrical impulses

3
Fundamentals of Electrocardiography Path of
Impulse
  • SA Node
  • ?
  • AV Node
  • ?
  • AV Bundle (Bundle of His)
  • ?
  • Right and Left Bundle Branches
  • ?
  • Purkinje Fibers
  • www.clevelandclinic.org/heartcenter/pub/guide/hert
    works/heratpics.htm

4
Fundamentals of ElectrocardiographyPath of
Impulse
  • The pulse begins in the sinoatrial (SA) node.
    The cells within the SA node spontaneously
    depolarize to trigger contraction. The
    contraction begins in the upper atria and spreads
    toward the atrioventricular (AV) valves. This
    helps move blood from the atria to the ventricles.

5
Fundamentals of Electrocardiography Path of
Impulse
  • The pulse travels to the AV node which is located
    within the interatrial septum. It than proceeds
    to the AV bundle (Bundle of His). The bundle of
    His then divides into the left and right bundle
    branches. Each branch travels down the septum.
    At the apex, the branches called purkinje fibers
    transverse the ventricles back toward the base of
    the heart.

6
Fundamentals of Electrocardiography
  • Depolarization causes contraction of heart
  • Repolarization causes relaxation of heart
  • Contraction state of heart is systole
  • Relaxation state of heart is diastole

7
Fundamentals of ElectrocardiographyPurpose of ECG
  • Identify cardiac rate
  • Identify any abnormalities in rhythm
  • Identify presence of abnormal transmission
    impulses through conduction system of heart

8
Fundamentals of ElectrocardiographyIndications
for ECG
  • Chest pain
  • Rhythm disturbances
  • Routine physical
  • Pre-Op evaluation

9
Fundamentals of ElectrocardiographyBasic ECG
Tracing
  • The basic ECG tracing consists of
  • P wave
  • Q wave
  • R wave
  • S wave
  • T wave

10
Fundamentals of ElectrocardiographyBasic ECG
Tracing
  • P wave (normal lt.2 sec or 5 boxes)
  • First deflection from baseline
  • Is a positive deflection (upward)
  • Corresponds to atrial depolarization
  • Q wave
  • Small negative (downward) deflection preceding
    the R wave

11
Fundamentals of ElectrocardiographyBasic ECG
Tracing
  • R wave
  • Large positive deflection preceding the S wave
  • S wave
  • Small negative deflection

12
Fundamentals of ElectrocardiographyBasic ECG
Tracing
  • QRS Complex
  • All 3 Q, R, and S waves together(normally lt 3
    boxes)
  • Corresponds with ventricular depolarization,
    resulting in ventricle contraction
  • If Q wave is absent, then QRS complex is measured
    from the beginning of the first positive
    deflection after the PR interval

13
Fundamentals of ElectrocardiographyBasic ECG
Tracing
  • T wave
  • Follows QRS complex
  • Positive deflection
  • Corresponds to ventricular repolarization and
    relaxation

14
Fundamentals of ElectrocardiographyBasic ECG
Tracing
  • ST Segment
  • Interval time from end of ventricular
    depolarization to beginning of ventricular
    repolarization
  • Should normally be at baseline
  • Hearts resting period between ventricular
    depolarization and repolarization

15
Fundamentals of ElectrocardiographyBasic ECG
Tracing
  • PR Interval
  • Measured from beginning of P wave to beginning of
    QRS Complex (normal lt.2 sec or 5 boxes)
  • Is the time between atrial depolarization and
    beginning of ventricular depolarization
  • The impulse travels from the SA node to the
    ventricle

16
Fundamentals of ElectrocardiographyBasic ECG
Tracing
  • QT Interval
  • Period between onset of QRS complex and end of T
    wave
  • It represents the entire time of ventricular
    depolarization and repolarization

17
Fundamentals of ElectrocardiographyStandard
12-Lead ECG
  • Consists of 6 chest leads and 6 limb leads
  • Only ten electrodes are utilized to obtain a
    12-Lead ECG

18
Fundamentals of ElectrocardiographyLead Placement
  • Limb Leads
  • Right arm
  • Right leg
  • Left arm
  • Left Leg
  • Chest Leads
  • V1 just to the right of the sternum
  • V2 just to the left of the sternum
  • V3 placed next to below V2
  • V4 placed next to below V3
  • V5 laterally and over to the left side of the
    heart
  • V6 laterally next to V5

19
Fundamentals of ElectrocardiographyBasic ECG
Tracing-Limb Leads
  • Lead I Right arm and Left arm
  • Lead II Right arm and Left leg
  • Lead III Left arm and Left leg
  • AVR midway between left arm and left leg to
    right arm
  • AVL midway between right arm and left leg to
    left arm
  • AVF midpoint between right and left arms to
    left leg

20
Fundamentals of ElectrocardiographyBasic ECG
Tracing
  • Right leg lead is the ground lead
  • V1, V2 and AVR are the right heart leads
  • V3 and V4 are the septal leads (transition
    between right and left sides of heart)
  • V5, V6, I and AVL are the lateral leads (left
    side of the heart)
  • II, III, and AVF are the inferior heart leads

21
Fundamentals of ElectrocardiographyLead Placement
  • Lead placement of the six chest leads

22
Fundamentals of ElectrocardiographyHeart Rates
Rhythm
  • Sinus rhythm 60-100 bpm and rhythm originates
    in SA node (Normal rhythm is when there is equal
    distance between the R-R intervals)
  • Sinus tachycardia SA node paces the heart
    faster than 100 bpm
  • Sinus bradycardia SA node paces the heart
    slower than 60 bpm
  • Flutter 250-350 bpm
  • Fibrillation gt350 bpm

23
Fundamentals of ElectrocardiographyRate
Determination
  • On ECG paper, count the number of R waves in any
    6 sec. interval. Multiply that number by 10 to
    calculate HR
  • 300, 150, 100, 75, 60, 50 method

24
Fundamentals of ElectrocardiographyCauses of
Arrhythmias
  • Fast or slow HR
  • Skipped beats
  • Heart disease
  • Smoking
  • Caffeine
  • Alcohol
  • Medications
  • Stress

25
Fundamentals of ElectrocardiographyAtrial Flutter
  • Saw-tooth appearance

26
Fundamentals of ElectrocardiographyAtrial
Fibrillation
  • Caused by continuous, uncontrolled firing of
    multiple foci in atria, resulting in an
    ineffective quivering of the cardiac muscle
  • Characterized by irregular ventricular rhythm and
    absence of P wave
  • Difficult to get adequate pacing trigger for
    gated studies

27
Fundamentals of ElectrocardiographyPVCs
  • Premature ventricular contractions
  • Originate from an ectopic focus in the ventricle
  • It produces a wide QRS complex
  • Can be unifocal or multifocal (couplet, triplet
    or a run) and can occur as bigeminy or trigeminy

28
Fundamentals of ElectrocardiographyVentricular
Bigeminy
  • A repeating pattern followed by a normal beat

29
Fundamentals of ElectrocardiographyVentricular
Trigeminy
  • A pattern of PVCs followed by two normal beats

30
Fundamentals of ElectrocardiographyVentricular
Tachycardia
  • The appearance of 3 or more rapid consecutive
    PVCs.
  • If not controlled, can lead to V-flutter or V-fib

31
Fundamentals of ElectrocardiographyVentricular
Flutter
  • ECG tracing becomes wavy and irregular with no
    discernible QRS complex or P wave

32
Fundamentals of ElectrocardiographyHeart Block
  • An electrical conduction disorder from the SA, AV
    nodes or Purkinje fibers
  • Heart blocks are classified by the extent of the
    conduction abnormality

33
Fundamentals of ElectrocardiographyHeart Block
  • First-Degree
  • Electrical impulse is conducted more slowly than
    normal
  • Second-Degree
  • The electrical impulse may or may not be
    conducted
  • Third-Degree
  • The electrical impulse is totally blocked

34
Fundamentals of ElectrocardiographyHeart Blocks
  • Sinus block
  • Atrioventricular block
  • Bundle branch block (BBB)

35
Fundamentals of ElectrocardiographyHeart
Block-AV Block
  • The AV block delays the stimulation of the
    ventricles

36
Fundamentals of ElectrocardiographyHeart
Block-AV Blocks
  • First-Degree
  • PR interval is prolonged beyond 0.2 second
    because of a delay in conduction through the AV
    node
  • Second-Degree
  • PR interval becomes gradually longer and QRS
    complex fails to occur
  • Third-Degree
  • None of the atrial impulses are conducted to the
    ventricles and the ventricles pace independently

37
Fundamentals of ElectrocardiographyHeart
Block-Bundle Branch Blocks
  • BBB are the most common block. It originates in
    the left or right bundle branches. BBBs are
    caused by a block of depolarization in the right
    or left bundle branches. The peak of the QRS
    complex is notched.

38
Bundle Branch Blocks
  • Right bundle branch blocks appear in leads V1 and
    V2
  • Left bundle branch blocks appear in leads V5 and
    V6

39
Fundamentals of ElectrocardiographyIschemia/Infar
ction
  • ST segment depression may be seen in
    subendocardial infarction, in patients on
    Digitalis and in transient exercise-induced
    ischemia.
  • T wave inversion represents ischemia. Its
    appearance may be anything from moderately
    flattened to significantly inverted.

40
Fundamentals of Electrocardiography
  • ST Depression
  • T wave inversion

41
Fundamentals of ElectrocardiographyIschemia/Infar
ction
  • ST segment elevation represents acute ischemia
    resulting in injury. Degree of elevation denotes
    severity of ischemic injury.
  • Presence of Q wave denotes myocardial infarction.
    Q wave is not usually visualized. The
    anatomical location of the infarction is
    determined by the presence of a Q wave on a given
    lead.

42
Fundamentals of Electrocardiography
  • ST segment elevation
  • Presence of Q wave

43
Fundamentals of ElectrocardiographyAbnormalities
on ECG Determines Infarct Location
  • Anteroseptal V2 V3
  • Anterior V3 V4, not on V5 or V6
  • Anterolateral V4 V5
  • Lateral I, AVL, V5 V6
  • Inferior II, III, AVF

44
Fundamentals of ElectrocardiographyArtificial
Pacemakers
  • An electric device used to stimulate the heart to
    beat when the electrical conduction system is
    unable to function properly. Can be used for
    atrial, ventricular or dual-chamber pacing. It
    causes a narrow line (the pacemaker spike) in the
    ECG tracing.

45
Fundamentals of ElectrocardiographyArtificial
Pacemakers
46
References
  • Crawford, MS, CNMT, Elpida S., and Syed Sajid
    Husain, MD, MAS. Nuclear Cardiac Imaging,
    Terminology and Technical Aspects. Reston
    Society of Nuclear Medicine, 2003.
  • Taylor, MD, Andrew, David Schuster, MD, and Naomi
    Alazraki, MD. A Clinicians Guide to Nuclear
    Medicine. Reston Society of Nuclear Medicine,
    2000.
  • Introduction to Nuclear Cardiology (Third
    Edition). Du Pont Pharma ( a professional
    education service), 1993.

47
References
  • University of Utah School of Medicine website,
    www.medstat.med.utah.edu/kw/ecg
