Title: Chapter 6 Delivery Forwarding, and Routing of IP Packets


1
Chapter 6Delivery Forwarding, and Routing of IP
Packets
2
Introduction
  • Delivery
  • Meaning the physical forwarding of the packets
  • Connectionless and connection-oriented services
  • Direct and indirect delivery
  • Routing
  • Related to finding the route (next hop) for a
    datagram

3
6.1 Delivery
  • Connection Types
  • Connection-oriented service
  • Using same path
  • The decision about the route of a sequence of
    packets with the same source and destination
    addresses can be made only once, when the
    connection is established
  • Connectionless service
  • Dealing with each packet independently
  • Packets may not travel the same path to their
    destination
  • IP is
  • Connectionless protocol

4
Direct versus Indirect Delivery
  • Two methods delivering a packet to its final
    destination
  • Direct
  • Indirect
  • Direct delivery
  • The final destination of the packet is a host to
    the same physical network as the deliverer or the
    delivery is between the last router and the
    destination host
  • Decision making whether delivery is direct or not
  • Extracting the network address of the destination
    packet (setting the hostid part to all 0s)
  • Then, comparing the addresses of the network to
    which it is connected

5
Direct versus Indirect Delivery (contd)
  • Direct delivery

6
Direct versus Indirect Delivery (contd)
  • Indirect delivery
  • The destination host is not on the same network
    as the deliverer
  • The packet goes from router to router until
    finding the final destination
  • Using ARP to find the next physical address
  • Mapping between the IP address of next router and
    the physical address of the next router

7
Direct versus Indirect Delivery (contd)
  • Indirect delivery

8
6.3 Forwarding
  • Forwarding means to place the packet in its
    route to its destination. So, it requires a host
    or a router a routing table.
  • Routing table
  • Used to find the route to the final destination

9
Forwarding Techniques
  • Next-hop Method
  • A technique to reduce the contents of a routing
    table
  • The routing table holds only the address of the
    next hop instead of holding information about the
    complete route
  • The entries of a routing table must be
    consistent with each other

10
Forwarding Techniques (contd)
11
Forwarding Techniques (contd)
  • Network-Specific Method
  • Having only one entry to define the address of
    network itself

12
Forwarding Techniques (contd)
  • Host-Specific Method
  • Destination host addresses is given in the
    routing table
  • The efficiency is sacrificed for the advantages
  • Giving to administrator more control over
    routing
  • Ex) if the administrator wants all packets
    arriving for host B delivered to router R3
    instead of R1, one single entry in the routing
    table of host A can explicitly define the route

13
Routing methods (contd)
14
Routing methods (contd)
  • Default Method
  • Instead of listing all networks in the entire
    Internet, host A can just have one entry called
    the default (network address 0.0.0.0)

15
Forwarding with Classful Addressing
  • Forwarding without Subnetting

16
Example 1
  • Figure 6.8 shows an imaginary part of the
    Internet. Show the routing tables for router R1.

17
Example 1 - Solution
18
Example 2
  • Router R1 in Figure 6.8 receives a packet with
    destination address 192.16.7.14. Show how the
    packet is forwarded.
  • Solution

19
Example 2 - Solution
  • The destination address in binary is 11000000
    00010000 00000111 00001110. A copy of the address
    is shifted 28 bits to the right. The result is
    00000000 00000000 00000000 00001100 or 12. The
    destination network is class C. The network
    address is extracted by masking off the leftmost
    24 bits of the destination address the result is
    192.16.7.0. The table for Class C is searched.
    The network address is found in the first row.
    The next-hop address 111.15.17.32. and the
    interface m0 are passed to ARP.

20
Example 3
  • Router R1 in Figure 6.8 receives a packet with
    destination address 167.24.160.5. Show how the
    packet is forwarded
  • Solution
  • The destination address in binary is 10100111
    00011000 10100000 00000101. A copy of the address
    is shifted 28 bits to the right. The result is
    00000000 00000000 00000000 00001010 or 10. The
    class is B. The network address can be found by
    masking off 16 bits of the destination address,
    the result is 167.24.0.0. The table for Class B
    is searched. No matching network address is
    found. The packet needs to be forwarded to the
    default router (the network is somewhere else in
    the Internet). The next-hop address 111.30.31.18
    and the interface number m0 are passed to ARP.

21
Forwarding with Subnetting
22
Example 4
  • Figure 6.11 shows a router connected to four
    subnets.

23
Example 5
  • The router in Figure 6.11 receives a packet with
    destination address 145.14.32.78. Show how the
    packet is forwarded.
  • Solution
  • The mask is /18. After applying the mask, the
    subnet address is 145.14.0.0. The packet is
    delivered to ARP with the next-hop address
    145.14.32.78 and the outgoing interface m0.

24
Example 6
  • A host in network 145.14.0.0 in Figure 6.11 has
    a packet to send to the host with address
    7.22.67.91. Show how the packet is routed.
  • Solution
  • The router receives the packet and applies the
    mask (/18). The network address is 7.22.64.0. The
    table is searched and the address is not found.
    The router uses the address of the default router
    (not shown in figure) and sends the packet to
    that router.

25
Forwarding with Classless Addressing
  • In classful addressing we can have a routing
    table with three columns in classless
    addressing, we need at least four columns.

Figure 6.12 Simplified forwarding module in
classless address
26
Example 7
  • Make a routing table for router R1 using the
    configuration in Figure 6.13.

27
Example 7 - Solution
  • SolutionTable 6.1 shows the corresponding table

Table 6.1 Routing table for router R1 in Figure
6.13
28
Example 8
  • Show the forwarding process if a packet arrives
    at R1 in Figure 6.13 with the destination address
    180.70.65.140.

29
Example 8 - Solution
  • SolutionThe router performs the following
    steps
  • 1. The first mask (/26) is applied to the
    destination address. The result is 180.70.65.128,
    which does not match the corresponding network
    address.
  • 2. The second mask (/25) is applied to the
    destination address. The result is 180.70.65.128,
    which matches the corresponding network address.
    The next-hop address (the destination address of
    the packet in this case) and the interface number
    m0 are passed to ARP for further processing.

30
Example 9
  • Show the forwarding process if a packet arrives
    at R1 in Figure 6.13 with the destination address
    201.4.22.35.

31
Example 9 - Solution
  • SolutionThe router performs the following
    steps
  • 1. The first mask (/26) is applied to the
    destination address. The result is 201.4.22.0,
    which does not match the corresponding network
    address (row 1).
  • 2. The second mask (/25) is applied to the
    destination address. The result is 201.4.22.0,
    which does not match the corresponding network
    address (row 2).
  • 3. The third mask (/24) is applied to the
    destination address. The result is 201.4.22.0,
    which matches the corresponding network address.
    The destination address of the package and the
    interface number m3 are passed to ARP.

32
Example 10
  • Show the forwarding process if a packet arrives
    at R1 in Figure 6.13 with the destination address
    18.24.32.78.
  • SolutionThis time all masks are applied to the
    destination address, but no matching network
    address is found. When it reaches the end of the
    table, the module gives the next-hop address
    180.70.65.200 and interface number m2 to ARP.
    This is probably an outgoing package that needs
    to be sent, via the default router, to some place
    else in the Internet.

33
Example 11
  • Now let us give a different type of example. Can
    we find the configuration of a router, if we know
    only its routing table? The routing table for
    router R1 is given in Table 6.2. Can we draw its
    topology?
  • Table 6.2 Routing table for Example 11

34
Example 11 - Solution
35
Address Aggregation
  • Figure 6.15 Address aggregation

36
Longest Mask Matching
  • The routing table is sorted from the longest
    mask to the shortest mask.

37
Hierarchical Routing
  • To solve the problem of gigantic routing tables,
    creating a sense of the routing tables
  • Routing table can decrease in size

38
Example 12
  • As an example of hierarchical routing, let us
    consider Figure 6.17. A regional ISP is granted
    16,384 addresses starting from 120.14.64.0. The
    regional ISP has decided to divide this block
    into four subblocks, each with 4096 addresses.
    Three of these subblocks are assigned to three
    local ISPs, the second subblock is reserved for
    future use. Note that the mask for each block is
    /20 because the original block with mask /18 is
    divided into 4 blocks.

39
Example 12
40
6.3 Routing - Static versus Dynamic Routing
  • Static routing table
  • Containing information entered manually
  • Cannot update automatically when there is a
    change in the internet
  • Used in small internet that does not change very
    much, or in an experimental internet for
    troubleshooting
  • Dynamic routing table
  • is updated periodically using one of the dynamic
    routing protocols such RIP, OSPF, or BGP (see
    Chap. 14)
  • Updating the routing table corresponding to
    shutdown of a router or breaking of a link

41
Routing Module
42
Routing Table
  • Routing table
  • In classless addressing, routing table has a
    minimum of four columns.
  • - Some routers have even more columns

Flags U (up) The router is up and running. G
(gateway) The destination is in another
network. H Host-specific address. D Added
by redirection. M Modified by redirection.
43
Routing Table (contd)
  • Flags
  • U (Up) indicating the routers running
  • G (Gateway) meaning that the destination is
    another network
  • H (Host-specific) indicating that the entry in
    the destination is a host-specific address
  • D (Added by redirection) indicating that
    routing information for this destination has been
    added to the host routing table by a redirection
    message from ICMP
  • M (Modified by redirection) indicating that
    routing information for this destination has been
    modified by a redirection message from ICMP
  • Reference count giving the number of users that
    are using this route at any moment
  • Use showing the number of packets transmitted
    through this router for the corresponding
    destination
  • Interface showing the name of the interface

44
Example 13
  • One utility that can be used to find the contents
    of a routing table for a host or router is
    netstat in UNIX or LINUX. The following shows the
    listing of the contents of the default server. We
    have used two options, r and n. The option r
    indicates that we are interested in the routing
    table and the option n indicates that we are
    looking for numeric addresses. Note that this is
    a routing table for a host, not a router.
    Although we discussed the routing table for a
    router throughout the chapter, a host also needs
    a routing table.

45
Example 13 (contd)
netstat -rnKernel IP routing table Destination
Gateway Mask Flags
Iface 153.18.16.0 0.0.0.0 255.255.240.0 U
eth0 127.0.0.0 0.0.0.0 255.0.0.0 U
lo 0.0.0.0 153.18.31. 254 0.0.0.0 UG eth0.
Loopback interface
46
Example 13 (contd)
More information about the IP address and
physical address of the server can be found using
the ifconfig command on the given interface
(eth0).
ifconfig eth0 eth0 Link encapEthernet
HWaddr 00B0D0DF095D inet addr153.18.17.11
Bcast153.18.31.255
Mask255.255.240.0 ....
From the above information, we can deduce the
configuration of the server as shown in Figure
6.19.
47
Example 13 (contd)
Ifconfig command gives us the IP address and the
physical address (hardware) address of the
interface
48
6.4 Structure of a Router
49
Components
  • Input port
  • Output port

50
Components (contd)
  • Routing Processor
  • performing the functions of the network layer
  • destination address is used to find the address
    of the next hop and output port number table
    lookup

51
Switching fabrics
  • Crossbar switch

52
Switching Fabrics
  • Banyan switch
  • log2 (n) stages with n/2 microswitches

53
Switching Fabrics (contd)
  • Examples of routing in a banyan switch

54
Switching Fabrics (contd)
  • Possibility of internal collision even when two
    packets are not heading for the same output port
    in banyan switch
  • solving the problem by sorting the arriving
    packets based on their destination port
  • Trap module preventing duplicate packets
    (packets with the same output destination) from
    passing to the banyan switch simultaneously

55
Switching Fabrics (contd)
  • Batcher-banyan switch

56
Summary(1)
  • In a connection-oriented service, the local
    network layer protocol first makes a connection
    with the network layer protocol at the remote
    site before sending a packet.
  • In a connectionless service, the network layer
    protocol treats each packet independently, with
    each packet having no relationship to any other
    packet. The packets in a message may or may not
    travel the same path to their destination. The IP
    protocol is a connectionless protocol.
  • The delivery of a packet is called direct if the
    deliverer(host or router) and the destination are
    on the same network.
  • The delivery of a packet is called indirect if
    the deliverer(host or router) and the destination
    are on different networks.
  • In the next-hop method, instead of a complete
    list of the stops the packet must make, only the
    address of the next hop is listed in the routing
    table.
  • In the network-specific method, all hosts on a
    network share one entry in the routing table.
  • In the host-specific method, the full IP address
    of a host is given in the routing table.

57
Summary(2)
  • In the default method, a router is assigned to
    receive all packets with no match in the routing
    table.
  • The routing table for classful forwarding can
    have three columns.
  • The routing table for classless addressing needs
    at least four columns.
  • The number of columns in a routing table is
    vendor dependent.
  • Address aggregation simplifies the forwarding
    process in classless addressing.
  • Longest mask matching is required in classless
    addressing.
  • Classless addressing requires hierarchical and
    geographical routing to prevent immense routing
    tables.
  • Search algorithms for classful addressing are not
    efficient for classless addressing.
  • A static routing table's entries are updated
    manually by an administrator.
  • A dynamic routing table's entries are updated
    automatically by a routing protocol.
  • A router is normally made of four components
    input ports, output ports, the routing processor,
    and the switching fabric.
Write a Comment
User Comments (0)
About PowerShow.com
