Mapping of Traffic Flows on Delhi Road Network
using Trans CAD
Presentation by Dr. K. Ravinder Scientist
Transport Planning and Environment Central Road
Research Institute (CRRI), New Delhi (CSIR,
India) 21st January, 2011
3
Presentation outline

• Background
• Mapping of Traffic flows,
• Methodology
• Data Collection (Traffic Surveys / Studies)
• Traffic Volume Counts
• Mid-blocks,
• Intersections
• Outer Cordon ( mid block surveys)
• Traffic flows on various links
• Conclusions

4
Growth of Population in Metropolitan Cities
Delhi has more than 5 per annum (Mumbai
3,Kolkata 2, Chennai 3)
Delhi has 1.3 of India Population (Area is only
0.05 of country) Presently Delhi has about 17.5
millions
5
Growth Trend of Motor Vehicles in Four Mega
Cities
Vehicle Pop in Delhi gt Veh Pop (Mumbai
Kolkata Chennai) In 2008, Delhi has about 5.63
millions (more than 12 of India)
6
Growth Trend of Motor Vehicles in Delhi
Two Wheelers more than 60
Cars about 30
Delhi has growth about 10 per annum Two wheeler
growth is slightly more than Cars
7
Methodology
8
Locations of Traffic Surveys
24 Mid-blocks, 6 Intersections, 9 Outer Cordon
and 30 Fuel Stations/ Parking Areas
9
Summary of Traffic Volume Counts at Selected
Mid-block Locations
Maximum Traffic Flow at ITO Bridge (Mid-block)
2.3 Lakh veh/day and NH-8 Toll Plaza (Outer
Cordon) with 2.27 Lakh veh/day
Summary of Traffic Volume Counts at Selected
Intersections
Maximum Traffic Flow at Ashram Chowk (Mid-block)
with 3.65 Lakh veh/day (Flyover Traffic with 1.35
Lakh veh/day)
10
Typical Hourly Variation and Traffic Composition
Total Vehicles 1,92,395/day
Lala Lajpath Rai Marg
Total Vehicles 3,64,871 vehicles/day (1,35,173
v/d flyover traffic)
At Ashram Intersection
11
Pattern of External Traffic
12
Assignment of traffic flows
13
Traffic Flow Pattern in Delhi
14
Conclusions

• High Traffic flows observed are observed at CBD
  areas and on Major National Highways
• ITO bridge carries maximum traffic flow around
  2.3 lac /day
• NH8 Delhi- Gurgaon Expressway carries Maximum
  Traffic Flow 2.27 lac/day
• Ashram Intersection carries maximum around
  3.6lac/day
• Future Applications
• For Traffic Congestion management
• For Traffic Pollution Loads from Traffic
• For Dynamic Traffic Assignment

15
Thank You
