Proximal Tibia Fractures

• Kyle Dickson MD, MBA
• Professor of Orthopaedis Baylor College of
  Medicine, Houston
• Southwest Orthopaedic Group

3
Goals of Surgery

• Anatomical reduction of the articular fracture
  (absolute)
• Anatomical alignment of the limb (relative)

4
Case

• 55 yo boat captain on the Mississippi River
• Crushed leg between ship and 3,000 lb sheet metal
  roll Grade IIIC tibial plateau and distal femur
  fracture
• 10 days later with the worst tibial plateau and
  distal femur Ive seen. This patient needs a
  above knee amputation.

5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
(No Transcript)
12
Viable Treatment Options

• Closed reduction percutaneous screw fixation
  and/or fine wire fixation
• Arthroscopic visualization with closed reduction
  and fixation
• Open reduction internal fixation with standard or
  locked plating
• Tumor prosthesis

13
Mechanism

• Mechanism of injury is important when considering
  treatment options, timing and associated injuries

ForceMass x Accelleration KE1/2MV2
14
Evaluation

• Plain radiographs
• AP, lateral, and obliques of knee
• AP and lateral of entire tibia
• 10 degree caudal view
• CT scan indications
• MRI
• SOFT TISSUE

15
DC

• 32 yo ped vs mva
• Bilateral open tibias, open book pelvis, splenic
  and liver laceration
• SBP 80

16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
Lang, CORR 1995

• Proximal Third Tibia Shaft Fractures
• Should they be nailed?

24
Lang (cont.)

• 32 fractures (22 open 10 closed)
• 5 reamed nails in closed fractures
• 27 unreamed nails

25
Lang (cont.)

• 84 gt 5 angulation
• Valgus 56 gt 5 28 gt 10
• Apex anterior 59 gt 5 22 gt 10

26
Lang (cont.)

• 25 loss of fixation
• 2 patients required osteotomy
• 4 patients re-operation for realignment

27
Lang (cont.)

• 18 attendings
• RT nail - 15 bend 45 mm distally
• AO nail - 11 bend 100-140 mm distally

28
TOO SICK NOT TO FIX FRACTURES
29
Blood/FFP/Cryo/Plts 11 ratio !
30
Timing

• Within 24-48 hours injuries most mobile
• 2-5 days may be worst time to operate
• Soft tissue good (includes lung)
• Positive fluid balance

31
Damage Control Orthopaedics

• Prevent 2nd hit (MOF, MSOF, SIRS, ARDs)
• Hgb lt 8
• Base Deficit gt 5 mEq/l (pHlt7.2,lactategt2)
• Body temperature lt 33º
• INR gt 1.5

32
Proximal Metaphysis

• CT scan pre-op
• Optimal Entry Site
• Maintain Reduction
• Clamp
• Joy Stick
• Poller Screws
• Unicortical plate
• Multiple Locking Screws - spread

33
Problems

• Nail does not reduce the fracture and maintain
  reduction in the metaphysis
• Metaphysis good blood supply (healing potential)
  ? nail breakage through open screw holes
  (7cm-Hahn 1996)

34
Proximal Tibial Fractures Problems with IM Nail

• VALGUS Angulation
• Canal larger laterally
• Medial Entry Site Contributes
• Muscle Tension of Pes Anerinus
• Eccentric Proximal Reaming
• APEX-ANTERIOR Angulation
• Nailing in Flexion
• Distal Herzog Curve
• Eccentric (anterior) Entry Point

35
Poller Screws
Tighten medullary canal
Traffic Cone
Screw next to desired nail position blocks
displacement Place where you want the nail
NOT to go.
Krettek et al JBJS 81B964, 1999
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
Criteria

• Main fracture line below tibial tubercle or 13mm
  above plafond
• Joint extensions from main fracture line are
  minimal or simple impactions (no plateaus and
  plafonds)

40
CT Scan Proximal Distal Fractures

• Articular Involvement?
• Fx Orientation?
• Preliminary Lag Screws?
• To Plan Locking

41
(No Transcript)
42
(No Transcript)
43
Spanning External Fixation

• Restores and maintains length
• Restores axial alignment of leg
• Improves position of bone fragments by
  ligamentotaxis
• Reduces further soft tissue embarrassment
• Allows outpatient treatment

44
When I Use a Spanning Ex Fix for Tibial Plateaus

• Gross contamination
• Significant shortening (gt1cm)
• Subluxation or dislocation of knee
• Vascular injury
• Try to remove by 4 weeks
• Hinged ex fix?

45
Principles of Spanning Ex-fix

• Put pins away from your eventual incision and
  fixation (plan to use as femoral distractor)
• Stability (pin clamps less stable)
• Dont put in hardware

46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
Lateral Starting Hole
50
26 M s/p machine accident, grade II open Tibia fx
51
(No Transcript)
52
Other Reduction Aids

• Femoral distractor
• Schanz pin (closed fractures away from fracture
  site)
• Interlock in extension (? pull of quadriceps)
• Unicortical plate (locking holes)

53
Solutions

• Anatomical alignment pre nailing
• Center center both proximally and distally both
  on the AP and lateral both with the starting hole
  and the direction blocking pins
• No open holes next to the fracture site

54
(No Transcript)
55
(No Transcript)
56
Supine Image TableLeg Support (?)
KNEE BENT gt 90
57
Key Points

• Central starting hole on both the AP and lateral
• Entry point superior tibia (subchondral bone)
• Tibia reduction with pelvic clamps or unicortical
  3.5 or 4.5 plate (open wound)
• Liberal use of blocking screws

58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
(No Transcript)
62
(No Transcript)
63
Knee Pain

• 30-70 incidence (40 opposite knee pain)
• ? Incision length, patellar splitting vs. medial
  parapatellar

64
New incision
65
Semi-extended Nailing

• Suprapatellar quadriceps splitting
• 22 (4/18) knees had iatrogenic damage to
  articular surfaces of the patella and
  intercondylar notch
• Early in the study, poor technique

OTA 2010 Zamorano
66
Technique (cont.)

• Canulated awl or guide pin 2-3 mm lateral to
  center tibial spines on good AP
• Lateral subchondral bone ? straight down shaft

67
(No Transcript)
68
(No Transcript)
69
(No Transcript)
70
(No Transcript)
71
(No Transcript)
72
Technique (cont.)

• Straight reamer or curved awl proximally for 8,
  9, 10 mm
• Center guide pin proximally distally AP Lat

73
(No Transcript)
74
(No Transcript)
75
(No Transcript)
76
(No Transcript)
77
(No Transcript)
78
(No Transcript)
79
(No Transcript)
80
(No Transcript)
81
(No Transcript)
82
(No Transcript)
83
Blocking Pin vs Blocking Screw
84
Pearls

• Blocking screws may be used in any long bone
  nailing where the fracture extends outside the
  diaphyseal bone
• Use a guide pin (3.2mm) initially
• Place the pin where you dont want the nail to go

85
(No Transcript)
86
Soft Tissue Complications in Treatment of Complex
Fractures of Proximal Tibia with use of the Less
Invasive Stabilization System

• OTA 2003

87
Results

• 14 (7/49) soft tissue complications
• 3 free flaps
• No nonunions or malunions

88
Fracture ClassificationSchatzker
Complete Articular Fractures
Parital Articular Fractures
89
Universal Classification

• Type A-Extra-articular
• Type B-Partial articular
• Type C- Complete articular

x
Schatzker I-IV
Schatzker V-VI
90
Operative Tactic
91
Associated with a Bad Result

• Instability (missed posteromedial or
  posterolateral piece)
• gt1cm articular step off (need to be perfect)
• Malalignment
• Widening of the plateau

92
Incision

• Anterolateral and posteromedial
• More direct with less stripping
• Difficult to do a TKA
• Anteror and posteromedial
• Careful soft tissue, raise the meniscus
• Easier TKA incision
• Be aware of postero-medial or lateral piece

93
Approaches
Posteromedial
Anterolateral
94
Antero-lateral Approach
95
(No Transcript)
96
(No Transcript)
97
(No Transcript)
98
(No Transcript)
99
(No Transcript)
100
Femoral Distractor

• Cant change a tire without a jack and cant fix
  a tibial plateau without a femoral distractor
• Visualization
• Adequate elevation of the joint
• Limb alignment (two in this case)

101
Technique

• Articular reduction anatomic (start with least
  comminuted side lag screws 3.0, 4.0, and 4.5mm
  cannulated screws)
• Anatomic alignment of the limb

102
Partial Articular
Schatzker I
Schatzker II
Schatzker IV
Schatzker III
103
Operative TacticPartial Articular

• Aritcular Reduction
• Direct reduction Universal distractor
• Indirect reduction C-arm, arthroscopy
• Stabilization
• Interfragmentary screws
• Buttress plate
• 3.5 mm screws

104
Schatzker Type I

• Split fracture
• Open vs percutaneous treatment
• Lag screws/- buttress plate

105
Schatzker Type II

• Split depression fracture
• Submeniscal arthrotomy
• Elevation / bone graft
• Lag screws/buttress plate

106
Surgical TreatmentSplit Depression Fractures
(Schatzker 2)
107
(No Transcript)
108
21 year old wake boarding
109
(No Transcript)
110
(No Transcript)
111
(No Transcript)
112
Schatzker Type III

• Pure depression fracture
• Amenable to percutaneous techniques with fluoro
  /- arthroscopy
• Metaphyseal window for elevation and grafting
• Screws beneath subchondral bone

113
Surgical TreatmentDepressed Fractures (Schatzker
3)
114
(No Transcript)
115
(No Transcript)
116
(No Transcript)
117
(No Transcript)
118
(No Transcript)
119
(No Transcript)
120
(No Transcript)
121
(No Transcript)
122
(No Transcript)
123
Elevate the depressed central fragment from
below.
124
(No Transcript)
125
(No Transcript)
126
(No Transcript)
127
(No Transcript)
128
(No Transcript)
129
(No Transcript)
130
(No Transcript)
131
(No Transcript)
132
(No Transcript)
133
(No Transcript)
134
(No Transcript)
135
Depression pre-op
EN 31 year old
136
CT articular depression
EN
137
Arthroscopic findings
Medial depression
Fragment elevation
138
Post-op
EN
139
(No Transcript)
140
(No Transcript)
141
Schatzker Type IV Medial tibial plateau fracture
142
Type IV Fractures are frequently a realigned knee
dislocation!

• Associated with
• Peroneal nerve injury 5-50
• Popliteal artery injury 13-50

143
(No Transcript)
144
Medial Plateau
145
(No Transcript)
146
(No Transcript)
147
Complete Articular
Schatzker V
Schatzker VI
148
Operative TacticComplex Tibial Plateau Fractures

• Require lateral and medial stabilization of
  fractures
• Stabilization
• double plating,
• locked plating
• external fixators

149
When/Why does it work better?

• Osteopenic Bone
• Metaphyseal Areas
• Comminution

150
Locked Plate Problems

• Poor timing of surgery (MIS ? sooner surgery)
• Shark bite failure (longer plate, bicortical, and
  prestressed straight plate on a contoured bone)
• Cold welding with hardware removal

151
Problems With Locked Plates

• Cost
• Stiffness
• Restricted screw placement and one size fits all
• Less of a reduction aid

152
Evolution
Or something completely different?
You be the judge!
153
Axial Load
154
Conventional Plate Fixation
Patient Load
155
Locked Plate and Screw Fixation
156
Standard versus Locked Loading
157
Bending Force
158
Conventional Plate
First Screw Failure
MLJ
159
Conventional Plate
Sequential Screw Failure
MLJ
160
Conventional Plate
Plate/Bone Dissociation
MLJ
161
Locking Plate
Threaded Head
Locked Screws are Fixed Angle Constructs
MLJ
162
Locking Plate
MLJ
163
Locking Plate
Catastrophic Failure Less Likely
MLJ
164
When/Why does it work better?
Traditional Plating Stripped screw hole
165
When/Why does it work better?
Locked Plating Stripped screw hole
166
Locked Plate and Screw Testing

• Osteopenic Bone Model (Low density foam)

1.7X
1.5X
167
Locked Plate and Screw Testing

• Bone Model (High density foam)

168
Locked PlatingSurgical Technique
169
Locking Plates

• Tapered tip ? submuscular insertion

170
lt 2 months
171
gt 1 year
172
Biologically Friendly4 weeks post-op
173
Indications

• Better fixation to prevent medial and lateral
  fixation (bicondylar tibial plateau, distal
  femur)
• Osteoporotic bone
• Really Smashed fractures

174
Indications cont.

• Metaphyseal fractures
• Articular reduction maintenance

175
78 yo F lt Schatzker VI Tibial Plateau
176
(No Transcript)
177
(No Transcript)
178
Stabilization of Medial Fragment
179
Knee in External Fixator
180
6 Months Post-Op
181
Double Plating Complete Articular Fractures

• Two incisions
• Anterior and posteromedial
• Wound complications acceptable
• Indications
• Displaced posteromedial fragment needs to be
  buttressed with posterior plate
• Medial articular involvement with shaft
  comminution
• Displacement of medial column

182
Fixation Complete Articular

• Fragmented lateral plateau
• Simple medial plateau
• Reduce joint
• Stabilize both sides
• medial first to give landmark for lateral
  reduction

183
Fixation Complete articular
184
Fixation Complete Articular
185
Intra-Op
186
Intra-Op
187
Post Op
188
Posteromedial fragment
189
(No Transcript)
190
(No Transcript)
191
(No Transcript)
192
Problems

• Soft tissue problems (coverage and infection)
• Comminution of the joint - gt10 articular pieces
  (Reconstructable?)
• Articular reduction and limb alignment

193
Viable Treatment Options

• Closed reduction percutaneous screw fixation
  and/or fine wire fixation
• Arthroscopic visualization with closed reduction
  and fixation
• Open reduction internal fixation with standard or
  locked plating
• Tumor prosthesis

194
Technical Considerations

• Open the joint absolute fixation maintain
  biology to shaft relative fixation
• Generally femoral articular fractures shear and
  tibial articular impact
• Direct lag screw fixation in the femur Indirect
  elevation of a bed of cancellous bone for tibial
  articular surface (under the meniscus and through
  fracture line)

195
(No Transcript)
196
(No Transcript)
197
(No Transcript)
198
(No Transcript)
199
Summary

• Anatomical articular reduction -
  inter-fragmentary screws and Buttress plates for
  partial articular fractures
• Anatomic alignment - inter-fragmentary screws
  for joint and double plating or Locked plates for
  bicondylar fractures
• Double plating best when complex medial fracture
  or postero-medial fragment
• Locked plates for articular maintenace and
  cominution

200
Thank You
