Title: Johnson County Kansas ASTRO25 Public Safety Communication System


1
Johnson County Kansas ASTRO25 Public Safety
Communication System
  • Feb 2008 Contract Design Review (CDR)
  • REV. 0 Initial Submittal Week 2/5/2008

2
Introductions
  • Mike Repella Program Manager
  • Dave Pulver Systems Engineer
  • Thomas Lewis CFE Construction Manager
  • Bill Holcomb Commenco, Inc

3
DDR Objectives
  • Review the following subsystems
  • County Wide ASTRO25 Voice System
  • Master Site
  • Simulcast Prime Site
  • Simulcast Remote Sites
  • Dispatch Centers
  • Alarm Monitoring (SZ Mgr. LAN, FullVision
    MOSCAD)
  • T1 Interconnection Requirements
  • Antenna system Review
  • Rack Diagrams
  • Floor Plans
  • Act as the gateway into the formal MAKE ORDER
    process

4
Simulcast Subsystem
IP Network
9 Simulcast Sites
Network Mgr
CCC Master Site
Lenexa Dispatch Center (6)
Zone Controller
IP Network
IP Network
Overland Dispatch Center (6)
Prairie Village Dispatch Center (2)
IP Network
IP Network
IVDPDG
GGSN
IP Network
IP Network
Enterprise LAN
Leawood Dispatch Center (4)
ATIA INTERFACE
POP25 Host
Shawnee Dispatch Center (6)
NICE Trunking Recorder
CCC Olathe Dispatch (7)
CCC JC Dispatch (34)
Project 25 Subscribers
5
Digital Trunked Voice System
  • County Wide Area Coverage
  • Utilizes 9 RF Sites Throughout County
  • Alcatel 6GHz 11GHz Microwave (OC3)
  • 18 channels at each site
  • Growth Capacity to 24
  • Simulcast Prime Site
  • Olathe Central Site (480ft)
  • Remote Simulcast Sites
  • Tower Park (350 ft)
  • BPU (250 ft)
  • Sunflower (400 ft)
  • Shawnee Justice Center (300 ft)
  • Lenexa Police (160)
  • Sheraton (207 ft)
  • Fire Station 4 (180 ft)
  • Water One _at_ 159th (180 ft)

6
Coverage Requirements CATP Discussion

7
Digital Trunked Voice System
  • County Wide Area Trunked Coverage Requirements
  • 95 AREA Reliability
  • Motorolas coverage guaranty applies only to
    areas shown on Motorolas coverage maps as
    predicted to have 95 or greater coverage
    reliability.
  • Minimum Delivered Audio Quality (DAQ) 3.0
  • Speech understandable with repetition only
    rarely required. Some Noise/Distortion.
  • ASTRO Digital Only
  • 16 dB Building Loss Sector
  • 12 dB Building Loss Sector
  • 8 dB Building Loss Sector
  • XTS5000 Portable configuration is on hip in a
    swivel case using a ½ wave flex antenna. Users
    talks/listens using Speaker Mic at the users
    hip.
  • Inaccessible grids will be REMOVED FROM TEST

8
Coverage Acceptance Testing
  • Required Bit Error Rate (BER) Testing per RFP
  • Objective Drive Testing
  • 2.6
  • Subjective Delivered Audio Quality (DAQ)
    Evaluation
  • Measures the Real-World Performance

Bit Error Rate testing will occur on all roadway
accessible test sectors in the county. A 95
coverage reliability guarantee will exist for
those roadways in test sectors illustrated by
Motorola at that coverage level. Additionally, a
subjective DAQ evaluation will be conducted
simultaneously to assess system performance in
those areas with roadways illustrated as having
less than the Motorola guaranteed 95 coverage
reliability. The DAQ evaluation will not be used
as system acceptance criteria.
9
Coverage Test Sectors
10
Hydra Coverage Program
  • Close Integration of Motorola Equipment and
    Coverage Program
  • Hydra parameters specific to Motorola equipment
  • Increases Accuracy of Coverage Prediction
  • Integrated with Voyager Coverage Testing

11
(No Transcript)
12
Existing 800 MHz Smartnet System
13
16 dB Sector
14
12 dB Sector
15
8dB Sector
16
Composite All Sectors
17
Mobile Sector
18
Voyager Overview
  • All software solution no custom hardware
    required
  • Utilizes customer radios, consumer grade GPS
    receiver
  • USB radio support makes setup easy

19
CATP Configuration
20
Grid Map
21
  • Microwave System

22
Alcatel Microwave
  • Model MDR8000
  • 6GHz 11GHz
  • OC3 Bandwidth
  • Path Reliability 99.999
  • Licensed Channels
  • Loop Redundancy

23
Alcatel Carrier Grade Microwave system
24
Microwave Antennas
25
SONET OC3 Ring
ADTRAN OPTI-6100
RF Site
26
CCC Fiber Connectivity
11 GHz To Lenexa
Central Site
CCC
Dark Fiber
11 GHz To Olathe Courthouse
27
Orthogon Link
  • Dispatch Links
  • Licensed 4.9 GHz
  • 14.5x12x4.1
  • Ethernet 802.3
  • RJ45 Interface

28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
Orthogon Lets Fly the Paths!
  • Sheraton to Hemlock
  • PVPD to Tower Park
  • Sheraton to Leawood

32
Motorola MCC 7500 Dispatch Console IP Logging
Solution
  • Logging for Trunked ASTRO 25 Systems

33
Console System
  • MCC7500 Network
  • Interfaces Consoles into the ASTRO25 system via
    IP
  • Consists of
  • Operator positions with
  • A Motorola-certified personal computer
  • A voice card installed inside the computer
  • An optional Secure Card installed inside the
    computer
  • A general purpose input/output module (GPIOM)
  • Desktop speakers (4)
  • Headset jacks (2)
  • A footswitch
  • The GPIOM has connectors for the following
    devices
  • One desktop microphone
  • Two headset jacks
  • Desktop speakers (4)
  • One logging recorder
  • One public address system (supported in a future
    release)
  • One radio instant recall recorder
  • One external telephone set

34
Console System
  • Dispatch Center Position Quantity
  • Johnson County (CCC) 34
  • Olathe (CCC) 7
  • Lenexa 6
  • Overland Park 6
  • Shawnee 6
  • Leawood 4
  • Prairie Village 2

35
IP Network
MCC 7500 CONSOLES
NE Tower
Console Site Router
LAN
LAN
Leawood
Olathe CH
RF Site Router
MCC 7500 CONSOLES
LAN
WAN Link
WAN Link
RF Site Router
LAN
Console Site Router
Overland Park
LAN
UCS
ZDS
Router
Ethernet
NETWORK MANAGEMENT
ZONE CONTROLLER
CCC
Clients
ZONE CONTROLLER
FULLVISION
36
MCC 7500 Operator Position Hardware
Motorola designed, manufactured
Motorola-Certified HP PC (not as pictured)
H.100
Installed in PC
Voice Card

Crypto Card
LAN
MCC 7500 Software
Speakers, Audio Accessories connect to GPIOM
IEEE 1394 Digital Link Fire wire

Speakers (up to 4)
Analog peripherals connect to GPIOM
External Paging Encoder
Headset Jackbox (up to 2)
Plantronics SupraPlus Headset/Amplifier
External telephone set
  • General Purpose Input/Output Module
  • Converts between analog and digital
  • Placed on or near desktop

Instant Recall Recorder
Footswitch
Local Logging Recorder
Microphone
37
Intuitive Graphical User Interface
  • MCC 7500 re-uses the CENTRACOM Elite GUI
  • Intuitive and easy to use
  • Reduces dispatcher stress and reaction times.
  • Highly flexible and configurable
  • Industry proven design
  • Minimizes retraining of dispatchers

38
System Mgmt. Alarm Monitoring
  • Network Management terminals
  • Clearing house for alarm info from MOSCAD and
    other managed equipment (such as routers, hubs,
    etc.)
  • Monitors specific SmartZone equipment
  • Additional level of equipment monitoring
    (Forwarded from MOSCAD)
  • Monitor site environmental alarms(Forwarded from
    MOSCAD)
  • One Management Terminal at each Dispatch
    Center(Printer Optional at remote Centers)

39
MCC 7500 Logging Solution
A mission critical IP-based digital logging
solution for ASTRO 25 trunking systems
  • More than just audio recording
  • Information associated with a call
  • Fully compliant with Network Security
  • Events on radio channels
  • Agency Partitioning

40
MCC 7500 Logging SolutionWhat it Can Record
Calls and events - A call is the audio and
associated information for a trunked or
conventional call. An event is a non-voice
command on a talkgroup or conventional channel.
  • Talkgroup Calls Emergency Alarm
  • Announcement Group Calls Emergency
    Acknowledge/Knockdown
  • Emergency Calls Normal/Tactical
  • Encrypted Calls Repeat On/Off
  • Conventional Calls Frequency Selection
  • PL Selection
  • Wildcard I and II
  • PTT ID and Alias Mute Second Receiver
  • Talkgroup/Channel/Frequency/PL
  • Emergency or Non-emergency
  • Zone/Site ID
  • Encrypted/Unencrypted

Calls
Calls
Calls
Events
Events
Events
Info
Info
Info
41
MCC 7500 Logging Solution System Architecture
Zone Core
MCC 7500 Op
MCC 7500 Op
MCC 7500 Op
IP Networking Equipment
ZC and NM Equipment
Router
LAN Switch
Playback Station
LAN Switch
MCC 7500 Op
MCC 7500 Op
Logging Recorder
Playback Station
AIS
Remote Console Site
Archiving Interface Server (AIS) provides an
interface between a recorder and the radio
system. It functions very similarly to an MCC
7500 Op in that it affiliates with the ZC for
resources it wishes to monitor and the ZC routes
calls on those resources to it. AIS then passes
call info and audio packets to the recorder.
Co-Located Console Site
42
MCC 7500 Logging Solution Equipment Descriptions
The AIS consists of Motorola-developed hardware
and software in a PC workstation platform. A
clear-only AIS contains a voice card and supports
up to120 simultaneous clear transmissions. Red/bl
ack separation of coded and clear transmissions
is not possible.
Archiving Interface Server
Logging Recorder
The Logging Recorder is a modified version of
NICEs NiceLog recorder hosted on a PC server
platform
Playback Station
The Playback Station is a modified version of
NICEs Scenario Replay hosted on a PC workstation
platform
43
New Towers
  • EIA-222-G Compliant
  • Wind Load 90MPH
  • 1 inch Ice with 40MPH wind
  • 1.44 Degree Twist Sway _at_ 60MPH (No ICE)

44
Towers
  • Existing Olathe Central Site (480ft)
  • Existing Tower Park (350 ft)
  • Existing BPU (250 ft)
  • Existing Lenexa Police (160)
  • Sunflower (400 ft)
  • Shawnee Justice Center (300 ft)
  • Fire Station 4 (180 ft)
  • Water One _at_ 159th (180 ft)
  • Building Top Olathe Courthouse (107 ft)
  • Building Top Sheraton (207 ft)

45
Miller Telecom Equipment Shelters
46
Miller Telecom Equipment Shelters
47
Equipment Shelters
  • Dimensions 166L x 118W x 106H
  • Floor 6-3/4 Solid Concrete
  • Walls 4 Solid Concrete
  • Generator Onan 50KW
  • 200 AMP Load Center
  • Door 36 x 7
  • UPS Liebert 20KVA
  • HVAC (2) Bard 6 TON (Fully Redundant)
  • 5/8 Wall Board

48
Subscriber Portfolio
  • Key Differences Between Tiers
  • - Number of Talkgroups Supported
  • - Hardware Configurations Supported
  • Mobiles Dash/Remote Mounting, Dual Head,
    Motorcycle
  • - Encryption Capability
  • - Ability to work on P25 trunking and Legacy
    Motorola trunking systems at the same time.

49
Programming Over P25 (POP25)
  • Key Features
  • - Over The Air Programming of radio parameters
    while unit is deployed in the field.
  • - Relies on P25 Integrated Voice and Data Pipe,
    thus requires data capability both in the system
    and the subscriber.
  • - Provides access to all programming parameters
    in CPS
  • Motorola POP25 Advantage
  • - Radio remains fully functional. Transmission or
    reception of voice calls will not abort software
    download.
  • - User does not need to switch to a non-busy
    channel prior to software download.
  • - User does not need to be in a location with
    "good signal strength" for software download -
    works anywhere you have coverage from your system.

50
XTS 2500
  • Robust Mid Tier Radio
  • - 700/800MHz (3W)
  • - Four Models Available
  • 512 Channels (Model 2 3)
  • 96 Channels (Model 1.5)
  • 48 Channels (Model 1)
  • - System Support
  • Analog AND P25 Conventional
  • - Integrated Voice Data Capable
  • (P25 Conventional 9600 Trunking)
  • - Advanced Encryption Support

51
XTS 2500
3-Position Concentric Switch
16-Position Select Knob
4 Line 12 character Display
Power On/Off Volume Control
Menu Select Buttons
Control Top
Emergency/Top Button
Side Buttons
Alpha Button
Top Side Button
Home Button
Push-To-Talk (PTT) Button
4-Way Navigation Button
Side Button 1
Side Button 2
Front (Model III Shown)
52
XTL2500
  • Robust Mid Tier Radio
  • - 700/800MHz (35W)
  • Analog AND P25 Conventional
  • - Available Configurations
  • Dash Mount
  • Remote Mount
  • - 512 Channel Capacity
  • - Integrated Voice Data Capable

53
XTL2500
Emergency button
Home power button
Rotary Mode Control with detents
3-Level Dim button
Rotary Volume Control with stops
Navigation key
5 Large, backlit programmable soft-menu buttons
(no keycaps)
4 line / 16 Character Display
Programmable Backlight Color
54
XTS 5000
  • Robust High Tier Portable
  • - 700/800MHz (3W)
  • - High Channel Capacity
  • 850 Channels (Model 2 3)
  • 48 Channels (Model 1)
  • - System Support
  • Analog AND P25 Conventional
  • - Integrated Voice Data Capable
  • - Enhanced Ergonomics
  • - Unsurpassed Encryption Capability

55
XTS 5000
BacklitSelect Knob
2-Position Concentric Switch
3-Position Toggle Switch
Emergency/Top Button
Colored Display Lables
Top Side Button
Side Button 1
Side Button 2
Push-To-Talk (PTT) Button
56
XTL5000
  • Robust High Tier Mobile
  • - 700/800MHz (35W)
  • - Analog and P25 Conventional
  • - System Support
  • Analog AND P25 Conventional
  • - 850 Channel Capacity
  • - Available configurations
  • Dash, Remote or Motorcycle
  • - Integrated Voice Data Capable

57
XTL5000
Dedicated/protected emergency button
Dedicated home power button
Rotary Mode Control with detents
3-Level Dim button
Rotary Volume Control with stops
Navigation key
5 Large, backlit programmable soft-menu buttons
(no keycaps)
4 Line / 16 Character Display
Programmable Backlight Color
58
(No Transcript)
59
(No Transcript)
60
Questions?
61
Simulcast Prime Site
62
Central Site Simulcast Prime
To/From CCC
To/From Remote Sites (9)
63
Central Site Simulcast Prime Site
  • Simulcast Prime Site Equipment consists of
  • Qty(18) GCM8000 Comparators (Voters)
  • Qty(2) MTC9600 Prime Simulcast Trunking
    Controllers
  • Qty(2) Ethernet Switches for networking
    comparators controllers
  • Connected in an Even / Odd channel arrangement
  • Qty(2) Site Routers (Prime to Master Connection)
  • Redundant CWR Switching Center

64
Central Site Simulcast Prime Site
  • Simulcast Prime Site Equipment Contd
  • Qty(1) Co-located RF Remote Site
  • Qty(18) GTR8000 ASTRO25 Simulcast Base stations
  • 120VAC Operation
  • Linear Simulcast Modulation (P25 QPSK-LSM)
  • Qty(2) Ethernet Switches for networking GTR
    stations
  • Connected in an Even / Odd channel arrangement
  • Qty(1) TRAK9100 GPS/Rb/Xo Site Frequency Standard
  • Redundant GPS units (1 with crystal backup, 1
    with Rubidium backup)
  • Redundant 48VDC power supplies
  • 5MHz and 1pps outputs for ATACs and Transmitters
  • Framed T1 timing references for channel banks
  • Qty(2) Custom TXRX Combiners w/ ant. Arrays
  • Reuse Existing 800MHz Combiner Antenna System
  • Qty(2) Custom TXRX Receive Multi-couplers

65
  • Central Site
  • Simulcast Prime
  • (18) Comparators
  • (2) Site Controllers
  • (1) TRACK GPS
  • (2) Site Routers
  • (1) CWR
  • (1) MOSCAD
  • (1) CCGW

66
  • Central Site
  • Simulcast Prime
  • (18) GTR8000
  • (2) Site Routers
  • (2) 700 Combiners

67
  • Central Site
  • Simulcast Prime
  • -48VDC PLANT
  • Existing Combiner
  • Tsunami U-Wave

68
Central Site
69
Central Site
70
Central Site Antenna Systems
71
  • 700MHz TX Antenna System
  • TX/RX 9dB Omni
  • 1 ¼ LDF Main Line
  • Existing 800 MHz TX antenna system will be re-used

72
  • 700 MHz Receive antenna system
  • TX.RX 9dB Omni
  • 7/8 LDF Line
  • TX/RX Model 428-83-H01
  • Existing 800 MHz Receive antenna system will be
    re-used

73
Simulcast Remote Sites
74
Simulcast Remote Site
  • Each Simulcast Remote Site Equipment consists of
  • Qty(18) GTR8000 ASTRO25 Simulcast Base stations
  • 120VAC operation
  • Linear Simulcast Modulation (P25 QPSK-LSM)
  • Qty(1) TRAK9100 GPS/Rb/Xo Site Frequency Standard
  • Redundant GPS units (1 with crystal backup, 1
    with Rubidium backup)
  • Redundant 48VDC power supplies
  • 5MHz and 1pps outputs for Transmitters
  • Framed T1 timing references for channel banks
  • Qty(2) Ethernet Switches
  • Qty(2) Site Routers (Redundant Site Links)
  • Qty(2) Custom TXRX Combiners w/ ant. Arrays
  • Qty(2) Custom TXRX Receive Multi-couplers

75
Remote transmitter Site
1
18
76
Simulcast Remote Site
77
Simulcast Remote Site Floor Plan
78
Remote Site Antenna Systems
79
  • 800MHz TX Antenna System
  • RFS Model BMR10
  • 1 ¼ LDF Main Line

80
  • 700MHz TX Antenna System
  • RFS Model BPS10
  • 1 ¼ LDF Main Line

81
  • 800 MHz Receive antenna system
  • RFS Model BMR10
  • 7/8 LDF Line
  • TX/RX Model 428-83-H01

82
  • 700 MHz Receive antenna system
  • RFS Model BPS10
  • 7/8 LDF Line
  • TX/RX Model 428-83-H01

83
Site Plans
84
Tower Park
85
Water One159th
86
Central Site
87
Fire Station 4
88
Lenexa
89
Shawnee Justice Center
90
Sunflower
91
ASTRO25 Master Site
  • Johnson Co. CCC

92
Break
  • - Back in 15 Minutes -

93
County Wide Voice
  • Multiple Site/System Interconnection via ASTRO25
  • MCC5000 Zone controller monitors/controls all
    voice traffic from each sub-system or zone to
    now include conventional traffic from any
    conventional stations interfaced via MCC7500
    (CCGW)
  • Allows for roaming / call interconnection between
    each system and/or dispatch

94
ASTRO25 Master Site Johnson Co. CCC
  • Master Site Equipment Consists of
  • Qty(1) Enterprise LAN Switch
  • Aggregates all the Ethernet interfaces at the
    Zone Core
  • Consists of Qty(2) HP ProCurve 5300 Series
    switches each with
  • Redundant power supply modules
  • Qty(72) 10/100-TX ports installed and 3 open
    module slots
  • Qty(2) 100/1000T Modules
  • Qty(1) Cooperative Router WAN
  • Interfaces the Zone Master site to the remote
    sites and other Zones Master Sites
  • S6000 Router Based
  • Redundant Router Configuration
  • Integrated network management system

95
ASTRO25 Master Site Johnson Co. CCC
  • Master Site Equipment Consists of
  • Qty(1) GGSN Router
  • Interface between the Enterprise LAN Switch and
    the Customers existing Enterprise Network
  • Qty(1) BORDER ROUTER LAN Switch
  • Provides the interface between ASTRO25 LAN and
    customer provided CAD server equipment
  • Broadcast ATIA information (PTT ID)

96
ASTRO25 Master Site Johnson Co. CCC
  • Master Site Equipment Consists of
  • Qty(1) Transport Network Management Server
  • Provides the backup and restore services for the
    Routers in an ASTRO 25 Release 7.4 System
  • Qty(1) Data Collection Device
  • The Data Collection Device (DCD) is a packet
    capture and analysis tool that makes it possible
    to monitor control plane, data plane, voice
    plane, and Interzone traffic. The DCD consists of
  • DCD Console
  • DCD Probe
  • Qty(1) Core Security Suite
  • RSA ACE Authentication Server
  • Symantec Antivirus PC Anywhere
  • Switched Firewall
  • Intrusion Detection Device

97
ASTRO25 Master Site Johnson Co. CCC
  • Master Site Equipment Consists of
  • Qty(1) Network Timing Protocol Server
  • TRAK9100 GPS/Xo/Rb Frequency and Timing Standard
  • Dual GPS References
  • 1 with fall back crystal
  • 1 with fall back Rubidium Osc.
  • Provides Stratum-1 timing reference to the
    Enterprise LAN Switch, WAN Switch, DCS, Consoles
    and local channel bank(s)
  • Qty(1) SUN Netra based Zone Server Cabinet (see
    Network Mgmt Section)
  • Qty(1) SUN Netra based System Level Server
    Chassis (see Network Mgmt Section)
  • Qty(3) Network Management Terminals (see NMS
    Section)
  • Qty(2) Out of Band Management (OBM) Remote Access
    Servers
  • 4 port server 40 port server
  • 4 port is for remote NMS dial-in purposes
  • 40 port is for SSC service access to console
    ports of managed devices
  • 4 port OBM has Qty(2) dial-in modems
  • 40 port OBM has Qty(2) dial-in modem

98
ASTRO25 Master Site Johnson Co. CCC
  • Master Site Equipment Consists of
  • Qty(1) Redundant ASTRO25 MZC5000 Zone Controller
    (NEW STYLE)
  • Two Sun UltraSPARC servers with Intelligent
    Switchover capability
  • Each chassis has redundant power supplies
  • Qty(41) MCC7500 Console Operator Positions (see
    Console Section)
  • HEADSET PHONE INTERFACE TO SYSTEM WILL BE VIA
    DISPATCHER CONTROLLED GPIOM PHONE REQUIRES
    DESKSET PHONE WITH AVAILABLE ANALOG PHONE AUDIO
    AND ON/OFF HOOK INDICATE CLOSURES
  • Qty(3) Ethernet Switch for Console LAN (see
    Console Section)

99
ASTRO25 Master Site Johnson Co. CCC
  • Qty(1) Archiving Interface Server (AIS)
  • The following types of radio system calls are
    capable of being processed via the AIS.
  • Conventional PTT Call
  • Trunking Talkgroup Call
  • Trunking Announcement Group Call
  • Trunking Emergency Call
  • The following types of trunking radio system
    events are capable of being processed via the
    AIS.
  • Emergency Alarm
  • Emergency Acknowledge
  • Emergency Knockdown
  • Repeater On/Off
  • System Access Priority Selection
    (Tactical/Normal)
  • Qty(1) NICE De-Trunked Logging Recorder
  • 120 Channel Capacity as per RFP
  • Qty(6) NICE Playback Station Licenses for LAN
    Playback

100
Network Management Alarm Monitoring
  • ASTRO25 Network Management System (NMS)
  • Motorola MOSCAD
  • FullVision Integrated Network Manger (INM)

101
ASTRO25 Network Management System (NMS)

102
ASTRO25 NMS Management
  • Configuration Management
  • Subscriber Level
  • Radio (physical)
  • Radio User (capabilities access)
  • Talkgroup/Multi-group
  • Regrouping (Storm Plans)
  • Infrastructure Level
  • Zone Zone controller
  • Site

103
ASTRO25 NMS Management
  • Infrastructure Level Contd
  • Audio Switch
  • Local Area Network Level
  • Fault Management
  • Current Alerts / Alarms
  • System Health
  • Technician Messages
  • Diagnostics
  • System Capabilities
  • Alert Notes

104
ASTRO25 NMS Management
  • Performance Management
  • Accounting Management
  • Security Management
  • Dispatch Management
  • Dynamic Regrouping
  • Storm Plans
  • Selective Inhibit
  • Call Alert
  • ID/Emergency/Alias

105
ASTRO25 NMS Network
Mgt. Term. 1 (CCC Equip Rm in Rack)
Qty. 1 Laser Printer
  • Zone Level Chassis
  • Zone Database Server
  • FullVision Server
  • Air Traffic Router
  • Zone Statistics Server
  • System Level Chassis
  • User Configuration Server
  • Switch Mgt. Servers

106
ASTRO25 NMS Network
  • NMS Zone Level Servers
  • Air Traffic Router (ATR)
  • Zone Database Server (ZDS)
  • Zone Statistics Server (ZSS)
  • FullVision INM Server (FVS)
  • NMS System Level Servers
  • User Configuration Server (UCS)
  • Switch Management Server
  • Systemwide Statistical Server (NOT INCLUDED)
  • Only required for multi-zone systems

107
ASTRO25 NMS Zone Level Server Chassis
  • Air Traffic Router (ATR)
  • Back-end of optional Affiliation Display
  • Processes real time call transactions to provide
    info to ZoneWatch and Radio Control Manger
  • Source of Air Traffic Information Access (ATIA)
    data stream to 3rd party applications
  • Genesis (GenSZAI) (Genesis SmartZone ATIA
    Interface)
  • Logs to disk Air Traffic Information Access
    (ATIA) data for viewing or exporting to a text
    file.
  • Routes RCM packets to/from SZC
  • Routes call logging packets from SZC to ZSS
  • Hosts the statistics proxy agent for SZC sourcing
    Dynamic and Historical Report statistics

108
Genesis Routed ATIA
109
ASTRO25 NMS Zone Level Server Chassis
  • Zone Database Server (ZDS)
  • Hosts the zone configuration database
  • Administrates the standard and optional
    application licenses
  • Authenticates network manager users accessing the
    system
  • Security Management
  • Super Manager-
  • determines the rights of the Manager users
  • Security Partitioning Option allows partitioning
    of configurable items (radios, talkgroups, etc.)
    into Security Groups and assign rights
  • Managers-
  • have different Application or Operations
    Access Rights as assigned by the Super Manager
  • Performs back-end support service for user
    applications

110
ASTRO25 NMS Zone Level Server Chassis
  • Zone Statistics Server (ZSS)
  • Data repository for data statistics to drive
    Historical Reports feature
  • Statistics such as the number of Calls,
    Push-To-Talks, and Busies are accumulated over
    preset time intervals
  • Data can be accumulated two ways
  • 1 hour intervals / retained up to 10 days
  • 1 month intervals / retained up to 1 year
  • FullVision INM Server (FVS)
  • Hosts the HP OpenView Network Node Manager (NNM)
  • Interfaces to SSC and local FullVision terminal
  • Also integrates with MOSCAD via IP Gateway

111
FullVision INM
  • Clearinghouse for monitoring alarm info from NMS,
    MOSCAD and other equipment such as
  • Centracom Elite hardware server, dispatch PC
    hubs
  • Selected site alarms interfaced to MOSCAD
  • Vehicle by which Motorola SSC remotely monitors
    the system
  • Accessible via the (6) SZ Network Mgt. Terms.
  • Includes Alphanumeric Paging option w/modem
  • Requires county provided dial-up phone line and
    data capable paging service

112
ASTRO25 NMS System Level Server Chassis
  • User Configuration Server (UCS)
  • Provides database storage and back-end processes
    required for most system-wide functions
  • Radio records
  • Talkgroup records

113
ASTRO25 NMS Network Mgt. Terminals
  • Qty(6) LCD SZ Network Manager terminals
  • Qty(1) with 19 screens at CCC Equipment Room.
  • Qty(5) with 19 screens (One at each of five
    remote Dispatch Centers)
  • Monitors system alarms, alerts, and status of SZ
    system interfaced components
  • Examples of devices monitored
  • Zone Controller Servers
  • Zone Mgr. User Terminals
  • Prime Remote Site Controllers
  • GTR8000 Base Stations

114
Included ASTRO25 NMS Software Licenses
  • Qty(10) LOT (500) Radio User Licenses
  • Radio Ids count against total
  • Qty(9) Sites/subsystem License
  • Simulcast Sites count against total
  • Qty(1) Security Partitioning
  • Allow the creation of Security Groups and
    assignment/restriction of access privileges
  • Qty(1) FullVision HP OpenView unlimited node
    license
  • Qty (13) LOT (5) console licenses

115
Included ASTRO25 NMS Software Licenses
  • Qty(1) MOSCAD Interface Option
  • Ties MOSCAD to FullVision
  • Qty(1) Router Manager Interface License
  • Qty(1) Air Traffic Information Access
  • Allows an external computer (customer provided)
    to access non-buffered Air Traffic Information.

  • Qty(1) Alphanumeric Paging
  • This feature has been specifically tested with
    SKYTEL paging service and RAM-PAGE paging service.

116
Included ASTRO25 NMS Software Licenses
  • The following licenses indicate the number of
    simultaneous sessions available on NMS Terminals
  • Qty(6) Configuration Management User
  • Provides the capability for a user to enter
    configuration information for all zone level
    objects
  • Qty(2) Zone Historical Report User
  • Provides the capability to manually or
    automatically generate historical performance
    reports
  • Qty(2) Dynamic Historical Report User
  • Provides the capability to generate near
    real-time graphical reports showing the total
    system utilization for talkgroup, private, and
    interconnect calls. 1-5 user licenses are allowed
  • Qty(1) Zone Watch Session including (1-5 user
    licenses are allowed)
  • Zone Watch Grid Control User
  • Zone Watch Channel Utilization User
  • Zone Watch Affiliation User
  • Qty(6) Radio Control Manager User including
  • Basic Radio Control Manager User
  • Dynamic Regrouping (up to 50 storm plans)
  • Status User

117
CCC
To Olathe Courthouse
118
CCC Racks 1 - 4
119
CCC Racks 5 - 8
120
CCC Racks 9 - 11
121
CCC Floor Plan
122
MOSCAD Alarm Monitoring
  • Monitors equipment alarms for the following
  • GTR8000 Stations (alarms and RSS)
  • ASTROTAC 9600 Comparators
  • TRAK GPS/Rb Frequency Standards
  • Shelter/Room alarms (48-Digital Inputs, 16-Relay
    Outputs, 8-Analog Inputs at each site)
  • Alcatel Microwave Radios
  • COMPLEMENTARY TO ALCATEL MANAGEMENT SYSTEM

123
MOSCAD Alarm Monitoring
  • MOSCAD system equipment consists of
  • Qty(1) Front End Processor (FEP) RTU
  • at CCC Mastersite
  • Based on new SDM3000 RTU (replaces NFM RTU)
  • Qty(1) Graphics Master Central (GMC) terminal
    w/alarm line printer
  • Qty(1) 19 inch LCD monitor
  • Qty(1) Report Generator Option
  • includes software and HP Laser printer
  • Qty(1) Alphanumeric Paging Option
  • Includes dial-up modem at GMC
  • Required phone line and access to paging service
    which accepts data
  • Qty(1) Remote dial-in GWS laptop
  • includes dial modem at GMC
  • requires phone line
  • Qty(9) Remote Site RTUs (interconnect via IP)
  • Based on SDM3000 RTU

124
MOSCAD Fault Management
  • Input Definition

125
Johnson County CCC
  • Console Dispatch Center

126
Console Dispatch Centers
  • CCC Dispatch Consists of
  • Qty(25) Conventional Channel Gate-Way Routers
    (CCGW)
  • Qty (8) _at_ CCC
  • Qty (6) Olathe Courthouse
  • Qty (1) Central Site
  • Qty (6) Northeast Tower
  • Qty (1) New Century Airport
  • Qty (3) Lenexa PD
  • Qty(41) MCC7500 Operator positions each
    consisting of
  • Qty (1) General Purpose Interface (GPIO) with
  • Qty(4) Outboard Speakers
  • Qty(2) Headset jacks
  • Qty(1) Dual footswitch
  • Qty(1) Telephone headset interface cable
  • Qty (1) Client PC
  • 17 Touch LCD, black monitor
  • Software based Instant Recall Recorder (IRR)
  • ASTRO BACK-UP Control Stations
  • Qty (12) Johnson county

127
CCC Conventional CCGWs
128
Remote Conventional CCGWs Allocation
129
Olathe Courthouse
  • Console Upgrade

130
CEB Configuration
131
AEB Configuration
132
MARCER
133
MARCER Requirements
  • CCC must be able to patch between MARCER
    Talkgroup and UHF Medical Channels
  • Cross patching is done today at the ECC on Elite
    consoles
  • Direct cross patches between conventional
    channels and 800MHz Smartnet talkgroups are not
    supported by the MCC7500
  • Too many MARCER talkgroups to maintain permanent
    crosspatches to P25 talkgroups
  • JC desires to maintain the audio delay
    implemented on UHF MED stations

134
MARCER Solution
  • CCC will have 34 operator positions available
  • Not all 34 positions will be required to support
    dispatch operations
  • Extend Elite LAN from ECC to the CCC
  • Setup remote desktop sessions between vacant ECC
    (Smartnet) Operator positions and unused CCC
    operator positions.
  • CCC Dispatchers will use remote desktop sessions
    to remotely setup cross MARCER patches at ECC
    (6000 Lamar)

135
CONTRACTED FREQUENCY PLAN REVIEW
136
Projected Frequency Plan
137
Preliminary Power Requirements
JOCO Power BTU

138
T1 Interface Requirements
T1 Plan

139
SUBSCRIBERS/ACCESSORIES STILL NEEDED
  • CHANGE ORDER FORTHCOMING

140
The End
Write a Comment
User Comments (0)
About PowerShow.com
