Surge Protective Devices

1

• Surge Protective Devices

Chris Martin Sales Manager Surge
Protection Devices
2
Where surges originate

• 80 - Internal Disturbances
• Load switching
• Variable frequency drives
• Lighting and air handlers
• 20 - External Disturbances
• Utility load switching
• Smart grid
• Lighting strikes
• Cloud to cloud
• Cloud to ground
• Cloud to man-made object

3
(No Transcript)
4
Surge damage

1. Cause disruptions in computer signals and
   processors
2. Degrade component junctions causing random
   delayed failure
3. Cause instant damage to electrical components

5
How SPDs work

• Cross Section of a MOV

20,000v
Eliminated Voltage

• Clamped Voltage (depends on surge level)
• Turn on Voltage (always the same)

Clamped Voltage
1,500v
SPD
Turn on Voltage
150v
Load
Source
6
UL 1449 2nd Edition 2005

• 2nd Edition 2005 Revision (effective 2/9/2007)
• Expanded OVERVOLTAGE Testing
• (2 x nominal voltage)
• Added 7 hour intermediate fault current levels
• 10 amps
• 100 amps
• 500 amps
• 1000 amps
• SPD manufacturers pass this new requirement by
  either adding fusing per MOV, thermal sensing
  technology, or requiring an external OCPD for the
  safe removal of the SPD

7
20 mm MOV Surge Current Rating Curve
10000
1
2
10
1000
10 2
10 3
10 4
100
10 5
Surge Current
10 6
Indef.
10
Impulse Duration (Microseconds)
1
10
100
1000
10000
At 20 micro-seconds the MOV can protect up to
6500Amps (1 time) at 5000 micro-seconds that
same MOV can only protect up to 30Amps
8
UL 1449 3rd Edition

• Creates SPD types (Type1, Type2, Type3, Type4)
• Surge Arrestor, Lightning Arrestor, TVSS
• New Nominal Discharge Surge Current test, In
  Thermal stress test
• Tested MCOV per mode. No longer a claimed value
• SVR 6kV, 500A replaced with VPR 6kV, 3kA
• Surge Arrestor incorporated into UL1449 as Type 1
  device

9
SPD Types - UL 1449 3rd Ed.
Competitors Surge Arrestor
Needs a breaker to pass UL testing

• Type 1 SPD (LINE SIDE)
• Permanently Connected SPD Installation between
  the secondary of the service transformer and the
  LINE side of the service disconnect over current
  device, as well as the LOAD side, including
  watt-hour meter socket enclosures. (Not
  exceeding 1000V)

Secondary Surge Arrestor
10
SPD Types (Continued)

• Type 2 SPD (LOAD SIDE)
• Permanently Connected SPD intended for
  installation on the LOAD side of the service
  disconnect over current device, including SPDs
  located at the branch panel.

11
SPD Types (Continued)

• Type 3 SPD
• Point of utilization SPDs, installed a minimum
  of 10 meters (30 feet) from the electrical
  service panel, for example cord connected, direct
  plug-in (DPI), receptacle type and SPDs installed
  at the utilization equipment being protected.

12
SPD Types (Continued)

• Type 4 SPD
• Component SPDs, including discrete components as
  well as component assemblies.
• (Note as proposed the 3rd Edition will allow
  Type 4 SPDs to be tested and applied where Types
  1 and 2 are allowed)

13
Measured Limiting Voltage (MLV)

• All SPD Types are to be tested to 6kV/3kA - 3
  pulses per mode with applied voltage. VPR is
  determined by averaging results. (Per 34.9 and
  Table 34.1)
• SVR 6kV/500A Good reading 400v or 500v
• VPR 6kV/3kA Good reading 700v, 800v,
  900v, or as high as 1000v
• Higher surge current results in higher clamping
  voltages

14
Nominal Discharge Current Test (In)

• Type 1 Choose 10kA or 20kA/Mode
• Type 2 Choose 3kA, 5kA, 10kA, or 20kA
• Surge unit at chosen surge value
• Apply chosen over voltage to unit within 1s for
  1min

15
2008 NEC

• COPS - Critical Operations Power Systems
• NEC guideline to increase protection and
  reliability of the power infrastructure for
  critical facilities
• What are Critical Facilities?
• Government agency (Federal, state, municipal)
• Facility engineering
• Facilities that if destroyed may disrupt
• National security, the economy, public health, or
  safety
• To include
• HVAC, fire alarm, security, communications, and
  signaling

16
2008 NEC

• NEC Section 708.20 (D)
• Surge Protective Devices must be used to comply
• SPDs must be used for each voltage at the
  facility
• Service Entrance
• Distribution panels

17
(No Transcript)
18
Improving SPD Installed Performance

• How does lead length affect the installed
  performance of a surge protective device?
• Does an internally mounted SPD outperform an
  externally mounted SPD?
• Impact of upstream OCPDs

19
How are SPDs Tested?

• 6 inches outside of the enclosure

The surge is injected here
Clamping characteristics are recorded by an
Oscilloscope

• Phase length Neutral length affect the
  performance of the SPD

20
The surge must travel through the phase through
the SPDand through Neutral
Internally Mounted Lead Length
Phase length Neutral length SPD clamping
voltage
21
Lead Length

• Lead length affects the installed performance of
  a SPD
• 10 sections of cable (commonly used sizes)
• 14 AWG
• 10 AWG
• 6 AWG
• Apply IEEE defined 20kV/10kA surge
• Measure the voltage drop

22
Wire size

• Voltage drop across 10 foot cable when exposed to
  a 20kV/10kA surge
• 14 AWG 2,650v
• 10 AWG 2,400v
• 6 AWG 2,350v
• What does this do to the installed performance of
  the SPD?

23
Lead Length Impact
24
The Low Impedance Cable
25
HPI Voltage Drop

• Voltage drop across 10 foot cable when exposed to
  a 20kV/10kA surge
• 10 AWG 560v
• 6 AWG 560v

26
Lead Length Impact
83 improvement
27
Breaker Impact

• Does a breaker upstream of an SPD limit the
  effectiveness of the SPD?
• Breakers have surge trip and surge failure
  values The SCCR value is based on 60Hz current,
  not surge current!
• Type 2 SPDs must be installed behind a breaker!

These values are based on testing performed by
Current Technologys Surge generator on
commercially available off the shelf breakers.
28
The ISMIntegrated Suppression Module
29
ISM Design

• Utilizes TPMOV technology
• Bus Bar construction
• N-G filter (removable)
• Improved L-N Filter
• 100 surge rated
• Reduced weight
• Individually monitored MOVs
• Advanced monitoring

300kA Model
30
The TPMOV
DRC contacts
DRC switch
50mm MOV
Thermal spring
Barrier
Barrier spring
31
Select3 (SL3)

• Listed by UL to UL1449 3rd Edition as a Type 1
  SPD
• 50kA, 100kA, 150kA, 200kA, 250kA, 300kA per mode
• TPMOV/Selenium Hybrid
• Option for enhanced selenium
• Test reports for single and repetitive surge
  testing
• Surge rated disconnect with line side barrier
• DTS-2 internal test port option
• 6 levels of monitoring
• 20 year warranty

THE SERVICE ENTRANCE SURGE PROTECTOR OF CHOICE
32
TransGuard3 (TG3)

• Listed by UL to UL1449 3rd Edition as a Type 1
  SPD
• 50kA, 100kA, 150kA, 200kA, 250kA, 300kA per mode
• TPMOV Technology
• RoHS compliant
• Test reports for single and repetitive surge
  testing
• Surge rated disconnect with line side barrier
• DTS-2 internal test port option
• 6 levels of monitoring
• 15 year warranty

33
Panel Extension (PX3)

• Listed by UL to UL1449 3rd Edition as a Type 1
  SPD
• 50kA, 100kA, 150kA, 200kA per mode
• 9 inch height for 50kA-100kA units
• TPMOV Technology
• RoHS compliant
• Test reports for single and repetitive surge
  testing
• DTS-2 internal test port option
• 6 levels of monitoring
• 15 year warranty

34
DTS-2 Tester

• The ONLY proactive test kit for SPDs on the
  market
• Updated test card for both MOV and TPMOV based
  products with or without selenium
• Validates health of surge components
• Compares installed clamping performance to
  original factory values
• Detects and provides early warning for stressed
  components
• Can be used to evaluation competitive products
  performance
• Part of any startup or commissioning
• Validates integrity of upstream Xo bond

35
M1 Standard Monitoring

• LED indication per phase
• Audible alarm
• Alarm silence switch
• 2 sets of dry relay contacts
• Tri-colored LED that reports on protection
• Green 75 or greater
• Orange 75 - 40
• Red 40 or less
• Extinguished Loss of protection

36
M2 Monitoring Option

• All M1 monitoring options
• Surge counter

37
M3 Option
M4E Option

• New Mastermind
• Includes all M1 monitoring features
• Time/Date stamp
• Duration and Magnitude
• User settable thresholds
• Tracks
• Sags, swells surges, dropouts,
• outages, THD, frequency, Volts
• RMS, protection
• Local character display
• ModBus and Ethernet remote communications
• Web based interface

• New Mastermind
• Includes all M1 monitoring features
• Time/Date stamp
• Duration and Magnitude
• User settable thresholds
• Tracks
• Sags, swells surges, dropouts,
• outages, THD, frequency, Volts
• RMS, protection
• Local character display
• ModBus remote communications

38
M5 Option
M6E Option

• Adds Large Graphics Display
• Includes all M1 monitoring features
• Time/Date stamp
• Duration and Magnitude
• User settable thresholds
• Tracks
• Sags, swells surges, dropouts,
• outages, THD, frequency, Volts
• RMS, protection
• Local character display
• ModBus and Ethernet remote communications
• Web based interface

• Adds Large Graphics Display
• Includes all M1 monitoring features
• Time/Date stamp
• Duration and Magnitude
• User settable thresholds
• Tracks
• Sags, swells surges, dropouts,
• outages, THD, frequency, Volts
• RMS, protection
• Local character display
• ModBus remote communications

39
Review

• Specs need to be Updated to include new
  requirements outlined in UL1449 3rd Edition
• Externally mounted SPDs offer a safer installed
  alternative without affecting performance
• External OCPDs can have an affect on the
  installed performance of the SPD
• Ask for documentation. Single surge, repetitive
  surge, and tested MCOV value
• Questions?
