Sediments and Sedimentary Rocks

1
Sediments and Sedimentary Rocks
L - 6 cd/EM - E
Tom Bean/DRK
2
Sedimentary rocks

• 5 by volume of the upper crust
• 75 by area of continental areas
• Often the only record of geologic events
• e.g. The Himalayas will someday be sandstone

3
Sedimentary Stages in the Rock Cycle
4
2 KINDS OF SEDIMENTARY ROCKS

1. DETRITAL CLASTIC - Rock resulting from the
   consolidation of loose sediment that has been
   derived from previously existing rocks and
   accumulated in layers
2. CHEMICAL - Rock formed by the precipitation of
   minerals from solution by either organic or
   inorganic processes

5
Transport and deposition of clastic sediments

• Movement of sediment by wind, ice or water
  (GEOLOGIC AGENTS).
• Mode of transport produces distinctive deposits.
• Deposit as layers - beds/strata

6
Transport affects the sediment in several ways -

• Sorting measure of the variation in the
• range of grain sizes in a clastic rock or
• sediment
• Well-sorted sediments indicate that they have
  been subjected to prolonged water or wind action.
• Poorly-sorted sediments are either not
  far-removed from their source or deposited by
  glaciers.

7
Sorting
Well-sorted
Poorly-sorted
8
Well-sorted Sand
Rex Elliott
9
Poorly-sorted Sand
Rex Elliott
10
Transport affects the sediment in several ways -
SHAPE

• Roundness measure of how rounded the corners
  are
• Sphericity measure of how much it is like a
  sphere
• Sorting, roundness, and sphericity all
  increase with LENGTH of transport.

11
Sorting
Roundness
12
(No Transcript)
13
Types of detrital rocks

• Largely based on the size of the particles, which
  may be anything.
• Conglomerate (poorly sorted/round)
• Breccia (poorly sort/angular)
• Sandstone (quartzite, arkose, greywacke)
• Mudstone
• Siltstone
• Shale - most common rock on continents

14
Conglomerate
Breck Kent
15
Sandstone
Breck Kent
16
Shale
D. Cavagnaro/Visuals Unlimited
17
SEDIMENTARY ROCKS

• CHEMICAL ROCK- Rock formed by the precipitation
  of minerals from solution by either organic or
  inorganic processes

18
Types of chemical sedimentary rocks

• Limestone CaCO3
• Chert SiO2
• Salt NaCl, KCl
• Gypsum CaSO4 2H2O
• Coal altered organic debris

19
Limestone
Breck Kent
20
Halite
Breck Kent
21
Chert
Breck Kent
22
Fossiliferous Limestone
Peter Kresan
23
Chemical environments Evaporites

• Restricted environments such as Mediterranean
  Sea Texas coast
• Minerals precipitate according to
  solubility.
• Gypsum Halite
• CaSO4 2H2O NaCl

24
One Model for the Formation of Evaporites
25
Chemical environments Carbonates

• Clear water away from big rivers (or volcanoes)
• Warm water subtropical to tropical
• Shallow water -- two reasons
• Organic sunlight only penetrates to
• about 100 m
• Inorganic CCD so carbonates dissolve

26
Foraminifer in the Eye of a Needle
Chevron Corporation
27
Coral Reef Surrounding Volcanic Island
Jean-Marc Truchet/Tony Stone Worldwide
28
Common Sedimentary Environments
29
Clues to interpreting sedimentary depositional
environments

• Sedimentary structures
• Sorting, roundness, sphericity
• Sequence kinds of beds

30
Sedimentary structures

• Particular structural features can give
  information about the environment of deposition.
• Structures also help determine if a bed is
  right-side-up important in deformed rocks

31
Cross-bedded Sandstone
Peter Kresan
32
Varves record annual cycles in glacial lakes
Turbidity currents
S. C. Porter
33
Modern Rippled Sand
Raymond Seiver
34
Ancient Ripple-marked Sandstone
Reg Morrison/Auscape
35
Fig. 7.9
36
Mudcracks
MODERN
ANCIENT
37
Bioturbation Tracks and Tunnels
Chip Clark
38
From Peat to Coal
39
The end
