A Randomized Linear-Time Algorithm to Find Minimum Spanning Trees

1
A Randomized Linear-Time Algorithm to Find
Minimum Spanning Trees

• David R. Karger
• Philip N. Klein
• Robert E. Tarjan

2
Talk Outline

• Objective related work from literatures
• Intuition
• Definitions
• Algorithm
• Proof Analysis
• Conclusion and future work

3
Objective

• A minimum spanning tree is a tree formed from a
  subset of the edges in a given undirected graph,
  with two properties
• 1. it spans the graph, i.e., it includes every

• vertex in the graph, and
• 2. it is a minimum, i.e., the total weight of
• all the edges is as low as possible.

Find a minimum spanning tree for a graph by
linear time with very high probability!!
4
Related Work

• Boruvka 1926, textbook algorithms
• Yao 1975
• Cheriton and Tarjan 1976
• Fredman and Tarjan 1987
• Gabow 1986
• Chazelle 1995

Deterministic results! How about the randomized
one??
5
Intuition

• Cycle Property
• Cut Property
• Randomization

6
Intuition

• For any cycle C in a graph, the heaviest edge in
  C does not apper in the minimum spanning tree.

7
Cycle Property
8
Cycle Property

• For any graph, find all possible cycles and
  remove the heaviest edge from each cycle. Then we
  can get a minimum spanning tree??
• How about the time complexity?
• How to detect the cycles in the graph??

9
Cut Property

• For any proper nonempty subset X of the
  vertices, the lightest edge with exactly one
  endpoint in X belongs to the minimum spanning
  tree.

10
Cut Property
11
Boruvka Algorithm

• For each vertex, select the minimum-weight edge
  incident to the vertex. Contract all the selected
  edges, replacing by a single vertex each
  connected component defined by the selected edges
  and deleting all resulting isolated vertices,
  loops (edges both of whose endpoints are the
  same), and all but the lowest-weight edge among
  each set of multiple edges.

O(m log n)
12
Randomization

• How the randomization can help us to achieve our
  goal?
• Boruvka Cycle Property Randomization
• Linear time with very high probability

13
Definition
14
Definition

• Let G be a graph with weighted edges.
• w(x, y) the weight of edge x, y
• If F is a forest of a subgraph in G,
• F(x, y) the path (if any) connecting x and y
  in F, the maximum weight of an edge on
  F(x, y), with the convention that
  if x and y are not
  connected in F.

15
Definition

• F-heavy
• Otherwise, x, y is F-light.

16
F-heavy F-light
F-heavy
F-light
17
F-heavy F-light

• Note that the edges of F are all F-light.
• For any forest F, no F-heavy edge can be in the
  minimum spanning forest of G.

Cycle Property!!
18
Recursive function call Input A undirected
graph Output A minimum spanning forest Time
for the worst case O(m) with very high
probability
Algorithm
19
Algorithm

• Step 1. Apply two successive Boruvka steps to the
  graph, thereby reducing the number of vertices by
  at least a factor of four.

20
Algorithm
21
Algorithm

• Step 2. In the contracted graph, choose a
  subgraph H by selecting each edge independently
  with probability 1/2. Apply the algorithm
  recursively to H, producing a minimum spanning
  forest F of H. Find all the F-heavy edges (both
  those in H and those not in H) and delete them.

22
Algorithm
Back to analysis
23
Algorithm

• Step 3. Apply the algorithm recursively to the
  remaining graph to compute a spanning forest
  . Return those edges contracted in Step 1
  together with the edges of .

24
Algorithm
Back to analysis
25
Algorithm
F - light
Those not in H
F - heavy
Edges of H
26
Analysis

• Correctness?
• Worst-case time complexity?
• Expected time complexity?

27
Correctness

• Completeness
• By the cut property, every edge contracted
  during Step 1 is in the minimum spanning forest.
  Hence the remaining edges of the minimum spanning
  forest of the original graph form a minimum
  spanning forest of the contracted graph.

28
Correctness

• Soundness
• By the cycle property, the edges deleted in Step
  2 do not belong to minimum spanning forest. By
  the inductive hypothesis, the minimum spanning
  forest of the remaining graph is correctly
  determined in recursive call of Step 3.

29
Worst-case time complexity

• The worst-case running time of the mini-spanning
  forest algorithm is
  , the same as the bound for Boruvkas algorithm.
• Count the total number of edges. Step 1 reduces
  the size to ¼ as its original. A subproblem at
  depth d contains at most edges. Summing
  all subproblems gives an bound on the
  total number of edges.

30
Worst-case time complexity

• Parent E(G)
• Left child E(H)
• Right child
• Number of edges in next recursion level
• E(G) E(F)
• E(G) V(G)/2 V(G)/4

31
Worst-case time complexity
m edges
32
Worst-case time complexity

• The total time spent in Steps 1-3 is linear in
  the number of edges
• Step 1 is just two steps of Boruvkas algorithm.

• Step 2 takes linear time using the modified
  Dixon-Rauch-Tarjan verification algorithm.
• - F-heavy edges of G can be computed in time

• linear in the number of edges of G.

33
Analysis

• Given graph G with n vertices and m edges
• After one Boruvka step, Boruvka step forms
  connected components and replaces each by single
  vertex. Since each component connects more than 2
  edges, there are at most n/2 vertices remained.
• For component with k vertices, exactly k 1
  edges are removed. Thus the edges removed is at
  leastwhere ? is set of connected components.
  Since there is at most n/2 components, there is
  at least n/2 edges removed.

34
Analysis

• Given F MST(H), for (x, y) in H
• If (x, y) is in F, (x, y) is F-light
• If (x, y) is not in F, assume (x, y) is F-light,
  the heaviest edge in cycle P ?(x, y) would be on
  P, and is belong to no MST according to cycle
  property. This causes contradiction, thus (x, y)
  is F-heavy.
• Thus, each F-light edge in H is also in F, and
  vice versa.

35
Analysis
According to the distribution of edges used by H
and G', edges of F are used twice by calling
MST(H) and MST(G').
36
Analysis
The binary tree represents the recursive
invocation of MST
Left child represents invocation of
MST(H). Right child represents invocation of
MST(G').
Since 2 Boruvka step are performed before
invocation of MST(H) and MST(G'), number of
vertices is reduced in factor of 4. Thus, the
height of invocation is at most log4n.
37
Analysis - Worst Case

• Given graph G with m edges and n vertices
• After 2 Boruvka steps, at most n/4 vertices and m
  n /2 edges remain for G. This is true also for
  H and G' which are subgraph of G.
• Since F MST(H), F has at most vH 1 edges, and
  thus less than n/4.
• According to the edge distribution,eH eG' ?
  eG eF ? m n/2 vH ?
  m n/2 n/4 ? mThus, the number of edges in
  subproblems is less than originals.

38
Analysis - Worst Case

1. Since total edge number of subproblems at the
   same depth is bound by m, and the depth is at
   most log4n, the overall edge number is at most m
   log4n.
2. Since vertex number for submproblem at depth d is
   at most n/4d, the edge is at most (n/4d)2.
   Overall edge number is also bound by

1. Since running time of the algorithm is
   proportional to edge number, we could give time
   complexity as

O(minn2, m log n)
39
Analysis Average Case
Here, we analyze the average case by partitioning
the invocations as left paths (red paths
above). After reckoning edges of subproblems
along each left path, sum them up and we will
get the overall estimate.
40
Analysis Average Case

1. For G with k edges, after sampling with 1/2
   probability for each edge, EeH k/2.Since G
   ? G, we have EeG ? E(eG) and
   EeH EeG/2 ? EeG/2.
2. Along the left path with starting EeG k, the
   expected value of total edges is

41
Analysis Average Case
Given vG n, F MST(H) where H ? G

1. For each F-light edge, there is 1/2 probability
   of being sampled into H.
2. Since each F-light edge in H is also in F and F
   includes no edges not in H, the chance that an
   F-light is in F is also 1/2.
3. For edge e with weight heavier than the lightest
   of F is never F-light since there would be cycle
   with e as heaviest edge.
4. Thus, the heaviest F-light edge is always in F.
   Given eFk, eG' is the number trials before k
   successes (selected into H), and it forms a
   negative binomial distribution.

42
Analysis Average Case
Given vG n, F MST(H) where H ? G

1. For eF k, eG' is of negative binomial
   distribution with parameter 1/2 and k. Thus
   EeG' k/(½) 2k.
2. Summing all cases, we get

43
Analysis Average Case

1. For all right subproblems, expected sum of edges
   is at most

1. For each left path, the expected total number of
   edges is twice of the leading subproblem, which
   is root or right child. So the overall expected
   value is at most 2(m n).
2. Since running time is proportional to overall
   edge number, so its expected value is O(m) O(m
   n).

44
Analysis Probability of Linearity
Chernoff Bound Given xi as i.d.d. random
variables and 0lt i ? n, and X is the sum of all
xi, for t gt 0, we have
Thus, the probability that less than s successes
(each with cance p) within k trail is
45
Analysis Probability of Linearity

• Given a path with leading problem G, eG k
• For each edge in G, it has 1/2 less chance to be
  kept in next subproblem. and each edge-keep
  contributes 1 to the total edge number. The path
  ends when the k-th edge-move occurs.
• The probability there are 3k more total edges is
  probability there are k less edge-remove in k3k
  trail. According to Chernoff bound, the
  probability is exp(-?(k)).

46
Analysis Probability of Linearity

1. Given vG n'. For each edge in G', it has 1/2
   chance to be in F. Since eF n' 1, the
   probability that eG' gt 3n' is probability there
   are n' - 1 less F edge in 3k trail. According to
   Chernoff bound, the probability is exp(-?(n')).
2. There is at most n/2 total vertices in all G. If
   we take all the trail as a whole, the probability
   that there are more than 3n/2 edges in all right
   subproblem is exp(-?(n)).

47
Analysis Probability of Linearity
Combined with previous two analysis, there is at
least probability as below that total edges never
exceeds 3(m3n/2), where ? is the set of all
right problems

Thus, the probability that time complexity is
O(m) is1 exp(?(m)).
