DEWATERING PUMP

1
DEWATERING PUMP
2
Honda WH20, 2" General Purpose High Pressure Pump
3
Description

• High Pressure, Centrifugal, Self-priming 2" Pump
• Easy-start Honda OHV Commercial engine
• 132 gal./min capacity
• Cast Iron Impeller Volute
• Lightweight Aluminum Case
• Easy Carry Handle

4
Specification

• Honda 4-stroke, single cylinder, air cooled
  engine GX160
• Displacement 163cc
• Bore and stroke 2.7" x 1.8"
• Compression Ratio 8.51
• Oil Alert N/A

5
Specification

• Pump type High Pressure Centrifugal Self-priming
• Volute Rigid Mounted Cast Iron
• Impeller Cast Iron
• Mechanical Seal Carbon/Ceramic
• Priming time 60 sec. at 16.4 ft.
• Drive system Direct

6
Specification

• Discharge capacity 134 gals./min.
• Suction port diameter 2" NPT
• Discharge port diameter 2" NPT
• Total head lift 141 ft.
• Suction head lift 26 ft.
• Maximum pressure 61 psi
• Solids handling N/A

7
Specification

• Dimensions (LxWxH) 16.7" x 14.8" x 15.9"
• Dry weight 51.8 lbs.
• Strainer Part 78325-YB7-702

8
Specification
9
Components
10
Components

• Pump
• Nozzle 1
• Discharge Hose
• Foam Nozzle
• Foam Suction
• Foam Concentrate
• Suction Hose Strainer

11
Components

• Discharge outlet
• Controls
• Pull cord
• On/ Off Switch

12
Operation
13
Operation

• Check pump is full of fuel.

14
Operation

• The discharge hose should be connected to the
  discharge outlet of the pump.

15
Operation

• Connect the nozzle to the end of the hose

16
Operation

• The suction hose should be set up and held,
  strainer away from the pump, and coupling end
  towards pump.

17
Operation

• Holding both ends of the hose, the coupling end
  level with the pump, lower the strainer end into
  the water and fill the hose with water.

18
Operation

• Lift the strainer end level with the pump.

19
Operation

• Connect the coupling end to the suction
  connection of the pump, keeping the strainer at
  the same level as the pump.

20
Operation

• Throttle
• Midway (shown for starting, - all the way to the
  left for operation

21
Operation

• Choke (white)
• Full to left (shown) for cold starting, - all the
  way to the right for operation

22
Operation

• Fuel (black)
• Full to the right for ON

23
Operation

• On / Off Switch This to be turned on on prior to
  starting

24
Operation

• Pull on the starter cord until the pump starts.
• Lower the suction strainer into the water.

25
Operation

• Wait for 5 to 10 seconds and then close the choke
  and open the throttle to full for maximum pumping
  rate.

26
Operation

• The pump set up when pumping
• Throttle to the left
• Choke to the right
• Fuel open (full to the right)

27
Operation

• As soon as the pump is running, the end of the
  hose needs to be held before water comes out.
• The hose is set to jet for distance.

28
Operation

• The nozzle to water wall to provide heat
  protection to self and boat when closing in to
  pick persons off burning boats.

29
Operation

• When using the pump for de-watering, do not have
  a nozzle on the end of the hose to maximise the
  discharge rate.

30
Operation

• When pumping out a vessel, have the pump as low
  as possible, and the suction as low as possible
  to maximise the discharge.
• The noise of the pump in an enclosed space will
  be loud.
• The exhaust of the pump in an enclosed space will
  be dangerous.
• Blocks as many leaks as possible in the early
  stages.

31
Operation

• On / Off Switch This to be turned off to stop the
  pump.

32
Operation

• Now
• PRACTISE, PRACTISE
• and PRACTISE some more
