Microsoft%20SQL%20Server%20Database%20Engine%20I/O

1
Microsoft SQL ServerDatabase Engine I/O

• by Bob Dorr, Microsoft SQL Server Principle
  Escalation Engineer, 1994 PresentBuilt Jan
  2008

2
Areas Covered

• Write Ahead Logging (WAL) Protocol
• Synchronous vs Asynchronous I/O
• Scatter / Gather I/O
• Sector alignment, Block Alignment
• Latching and a page A read walk-through
• SQL Server I/O Sizes
• Data cache maintenance
• PAE and AWE
• Read Ahead
• User Mode and Kernel Mode (SYSTRAP)
• Sparse Files and Copy On Write (COW) Pages
• Locked Pages
• Scribbler(s) and Bit flips
• Page Protection and Constant Pages
• Checksum vs Torn
• Stale Read
• Stalled I/O

3
WAL Protocol

• Write Ahead Logging
• ACID (Durability Property)
• Log records secured before data
• Hardened / Stable Media
• Log contains parity bit

• Commit
• Rollback
• Trigger Snapshot

4
Synchronous vs Asynchronous I/O

• Sync Wait for Completion
• Async Post and Continue
• Overlapped
• Event
• Completion Port
• SQL Server
• 98 Async Usage
• Overlapped and HasOverlappedIoCompleted
• Network Layers Use Completion Port
• Backup/Restore Use Sync Sequential Patterns

• dm_io_pending_io_requests
• Overlapped Structure
• Async Processing CPU
• Package vs Phone

5
Scatter / Gather I/O

• Consolidates or Distributes
• APIs
• ReadFileScatter
• WriteFileGather
• Increases Efficiency
• Used by SQL I/O Paths
• Used by Windows Page File

Memory
Gather
Scatter
Disk

• Old Design 6.x Sorting
• AWE Availability
• WriteMultiple
• of 8K Pages
• Forward and Backward
• Buffer Pool Ramp-up

6
Sector AlignmentBlock Alignment

• Sector Log Writes
• Block Performance
• Avoid Crossovers
• DiskPart/DiskPar Utilities
• Discuss with your Vendor

Alignment http//support.microsoft.com/kb/929491
To verify that an existing partition is aligned,
divide the size of the stripe unit by the
starting offset of the RAID disk group. Use the
following syntax ((Partition offset) (Disk
sector size)) / (Stripe unit size) Example of
alignment calculations in bytes for a 256-KB
stripe unit size (63 512) / 262144
0.123046875(64 512) / 262144 0.125(128
512) / 262144 0.25(256 512) / 262144
0.5(512 512) / 262144 1 These examples
shows that the partition is not aligned correctly
for a 256-KB stripe unit size until the partition
is created by using an offset of 512 sectors (512
bytes per sector).

• Double Touch
• Rewrites
• Defragment
• 4K Sectors

7
Latch

• Multiple Readers (SH)
• One Writer (EX)
• Protects In-Memory Data Page
• Latch Physical Protection
• Lock Logical Protection
• User Mode
• UMS/SQLOS Aware
• Optimized FIFO Ordering

Memory (Data Pages)
BUF Array
BUF StatusLatchDatabasePageIdHash

• Flushed Rollback
• Latch Timeout
• Sub-latch

8
Reading A Page

• Get Free Buffer for Read
• Acquire Exclusive (EX) Latch
• Is already in-memory/hashed?
• Add Entry to Page Hash
• Post and Record Asynchronous Read
• Continue Processing .
• Check Status (Scheduler Switch)
• Complete Validate I/O and Release Latch

0000gt uf ZwWriteFile mov r10,rcx mov
eax,5 Syscall ? Kernel Transition ret

• Page Audits
• Read retry
• Stalled I/O Warnings
• Error raised at Acquire
• Shared (SH) waiters
• PAGE_IO vs PAGE Latch
• Writing A Page

kernel transition Stuck I/O?ntdll!ZwWriteFile0
xa kernel32!WriteFile0xf6 sqlservr!DiskWriteAsy
nc0xee
9
Myth Single Worker Per FileTruth Each Worker
Issues I/O
Vol 1
Vol 2
Create Database Workers Assigned by Volume
IDPrimary dbTest.MDFSecondary
dbTest.NDFLog dbTest.LDF
Worker 4
dbTest.MDF
dbTest.NDF
dbTest.LDF
Worker 5
Worker 3
Worker 1
Worker 2
Serial Planselect from dbTest.dbo.tblTestinser
t into dbTest.dbo.tblTest
Parallel Planselect from dbTest.dbo.tblTest ins
ert into dbTest.dbo.tblTest
10
Data Cache Maintenance

• Memory Pressure LazyWriter
• Per NUMA Node
• Time Of Last Access (TLA)
• Recovery Interval Checkpoint
• Queue
• I/O Targets
• .LDF Usage Triggers
• Alternate Triggers (Backup, Restore, )
• Scatter/Gather Usage (WriteMultiple)

• Checkpoint Assignments
• By Ordinal Sweep
• Stalled I/O LW 0
• I/O Queue Depth gt 2

11
PAE and AWE

• Physical Address Extensions
• /PAE in Boot.ini
• Boots Kernel with 36 bit addressing
• Physical Memory gt 4GB
• Virtual Address Unchanged (/2gb or /3GB)
• Automatic for Hot Add Memory Computers
• Address Windows Extension
• Windows APIs (AllocateUserPhysicalPages)
• Physical Memory Allocations
• Un/Mapped in or out of Virtual Address Range

• 32 Bit Address 4294967295 (0xFFFFFFFF) 4GB
• Interlocked Instruction lock xadd dword ptr
  ecx,eax
• 36 Bit Address 68719476735 (0xFFFFFFFFF) 64GB
• Multiple Instructions

• Data Pages-Only
• Locked Pages
• Windows Paging
• Windows 2000 Bugs

12
Read Ahead

• 128 Pages Standard SKU
• 1024 Pages Enterprise SKU
• Uses ReadFileScatter
• Plan Based Decisions
• Power of Asynchronous I/O

• Read Over Write
• Ramp-up

13
Sparse Files Copy On Write

• Usage
• Online DBCC
• Snapshot Databases
• Buffer Pool PrepareToDirty
• File Control Block (FCB) Chaining

• Sparse Allocation
• FCB Tracking
• Windows Limits
• New Page Allocations

14
Advanced Protection

• What is a Scribbler?
• Data Page Audits
• None
• Torn Bits
• Checksum
• Log Block Checksum
• Constant Page
• Backup with Checksum

• DBCC Page Audit
• Stale Read Check
• SQLIOSim

15
References
16
Overview

• SQL Server Always Onhttp//www.microsoft.com/sql/
  alwayson
• SQL Server I/O Basics Chapter 1http//www.microso
  ft.com/technet/prodtechnol/sql/2000/maintain/sqlIO
  basics.mspx
• SQL Server I/O Basics Chapter 2http//www.microso
  ft.com/technet/prodtechnol/sql/2005/iobasics.mspx

17
Fundamentals and Requirements

• KB230785 - SQL Server 7.0, SQL Server 2000 and
  SQL Server 2005 logging and data storage
  algorithms extend data reliability
• KB917047 - Microsoft SQL Server I/O subsystem
  requirements for the tempdb database
• KB231347 - SQL Server databases not supported on
  compressed volumes (except 2005 read only files)

18
Subsystems

• KB917043 - Key factors to consider when
  evaluating third-party file cache systems with
  SQL Server
• KB234656- Using disk drive caching with SQL
  Server
• KB46091- Using hard disk controller caching with
  SQL Server
• KB86903 - Description of caching disk controls in
  SQL Server
• KB304261- Description of support for network
  database files in SQL Server
• KB910716 (in progress) - Support for third-party
  Remote Mirroring solutions used with SQL Server
  2000 and 2005
• KB833770 - Support for SQL Server 2000 on iSCSI
  technology components (applies to SQL
  Server 2005)

19
Design and Configuration

• White paper - Physical Database Layout and Design
• KB298402 - Understanding How to Set the SQL
  Server I/O Affinity Option
• KB78363 - When Dirty Cache Pages are Flushed to
  Disk
• White paper - Database Mirroring in SQL Server
  2005
• White paper - Database Mirroring Best Practices
  and Performance Considerations
• KB910378 - Scalable shared database are supported
  by SQL Server 2005
• MSDN article - Read-Only Filegroups
• KB156932 - Asynchronous Disk I/O Appears as
  Synchronous on Windows NT, Windows 2000, and
  Windows XP

20
Diagnostics

• KB826433 - Additional SQL Server Diagnostics
  Added to Detect Unreported I/O Problems
• KB897284 - SQL Server 2000 SP4 diagnostics help
  detect stalled and stuck I/O operations (applies
  to SQL Server 2005)
• KB828339 - Error message 823 may indicate
  hardware problems or system problems in SQL
  Server
• KB167711 - Understanding Bufwait and Writelog
  Timeout Messages
• KB815436 - Use Trace Flag 3505 to Control SQL
  Server Checkpoint Behavior
• KB906121 - Checkpoint resumes behavior that it
  exhibited before you installed SQL Server 2000
  SP3 when you enable trace flag 828
• WebCast- Data Recovery in SQL Server 2005

21
Certification Policy

• KB913945- Microsoft does not certify that
  third-party products will work with Microsoft SQL
  Server
• KB841696 - Overview of the Microsoft third-party
  storage software solutions support policy
• KB231619 - How to use the SQLIOStress utility to
  stress a disk subsystem such as SQL Server

22
Utilities

• Download - SQLIO Disk Subsystem Benchmark Tool
• Download - SQLIOStress utility to stress disk
  subsystem (applies to SQL Server 7.0, 2000, and
  2005 - replaced with SQLIOSim and SQL Server 2008
  installed in BINN)

23
Blog Content

• SQL Server Urban Legends Discussedhttp//blogs.ms
  dn.com/psssql/archive/2007/02/21/sql-server-urban-
  legends-discussed.aspx
• How It Works SQL Server Checkpoint (FlushCache)
  Outstanding I/O Targethttp//blogs.msdn.com/psssq
  l/archive/2008/04/11/how-it-works-sql-server-check
  point-flushcache-outstanding-i-o-target.aspx
• How It Works SQL Server Page Allocationshttp//b
  logs.msdn.com/psssql/archive/2008/04/08/how-it-wor
  ks-sql-server-page-allocations.aspx
• How It Works Shapshot Database (Replica) Dirty
  Page Copy Behavior (NewPage)http//blogs.msdn.com
  /psssql/archive/2008/03/24/how-it-works-shapshot-d
  atabase-replica-dirty-page-copy-behavior-newpage.a
  spx
• How It Works SQL Server 2005 I/O Affinity and
  NUMA Don't Always Mixhttp//blogs.msdn.com/psssql
  /archive/2008/03/18/how-it-works-sql-server-2005-i
  -o-affinity-and-numa-don-t-always-mix.aspx
• How It Works Debugging SQL Server Stalled or
  Stuck I/O Problems - Root Causehttp//blogs.msdn.
  com/psssql/archive/2008/03/03/how-it-works-debuggi
  ng-sql-server-stalled-or-stuck-i-o-problems-root-c
  ause.aspx
• How It Works SQL Server 2005 Database Snapshots
  (Replica)http//blogs.msdn.com/psssql/archive/200
  8/02/07/how-it-works-sql-server-2005-database-snap
  shots-replica.aspx
• How It Works File Stream the Before and After
  Image of a Filehttp//blogs.msdn.com/psssql/archi
  ve/2008/01/15/how-it-works-file-stream-the-before-
  and-after-image-of-a-file.aspx
• Using SQLIOSim to Diagnose SQL Server Reported
  Checksum (Error 824/823) Failureshttp//blogs.msd
  n.com/psssql/archive/2008/12/19/using-sqliosim-to-
  diagnose-sql-server-reported-checksum-error-824-82
  3-failures.aspx
• How to use the SQLIOSim utility to simulate SQL
  Server activity on a disk subsystem
  http//support.microsoft.com/kb/231619
• Should I run SQLIOSim? - An e-mail follow-up from
  SQL PASS 2008 http//blogs.msdn.com/psssql/archiv
  e/2008/11/24/should-i-run-sqliosim-an-e-mail-follo
  w-up-from-sql-pass-2008.aspx
• What do I need to know about SQL Server database
  engine I/O? http//blogs.msdn.com/psssql/archive/
  2006/11/27/what-do-i-need-to-know-about-sql-server
  -database-engine-i-o.aspx
• SQLIOSim is "NOT" an I/O Performance Tuning Tool
  http//blogs.msdn.com/psssql/archive/2008/04/05/
  sqliosim-is-not-an-i-o-performance-tuning-tool.asp
  x
• How It Works SQLIOSim - Running Average, Target
  Duration, Discarded Buffers ...
  http//blogs.msdn.com/psssql/archive/2008/11/12/h
  ow-it-works-sqliosim-running-average-target-durati
  on-discarded-buffers.aspx
• How It Works SQLIOSim Audit Users and .INI
  Control File Sections with User Count Options
  http//blogs.msdn.com/psssql/archive/2008/08/19/h
  ow-it-works-sqliosim-audit-users-and-ini-control-f
  ile-sections-with-user-count-options.aspx
• Understanding SQLIOSIM Output http//sqlblog.com/
  blogs/kevin_kline/archive/2007/06/28/understanding
  -sqliosim-output.aspx

24
Additional Learning Resources

• Inside SQL Server 7.0 and Inside SQL Server 2000
• Written by Kalen Delaney her husband is Paul
  Randle who wrote the core dbcc checks for SQL
  7.0, 2000 and 2005
• The Gurus Guide to SQL Server Architecture and
  Internals ISBN 0-201-70047-6
• Written by Ken after he joined Microsoft SQL
  Server Support
• Many chapters reviewed by developers and folks
  like myself
• SQL Server 2005 Practical Troubleshooting ISBN
  0-321-44774-3 Ken Henderson
• Authors of this book were key developers or
  support team members
• Cesar QP developer and leader of the QP
  RedZone with Keithelm and Jackli
• Sameert Developer of UMS and SQLOS Scheduler
• Santeriv Developer of the lock manager
• Slavao Developer of the SOS memory managers
  and engine architect
• Wei Xiao Engine developer
• Bart Duncan long time SQL EE and now
  developer of the Microsoft Data Warehouse
  performance focused
• Bob Ward SQL Server Support Senior EE
• Advanced Windows Debugging ISBN 0-321-37446
• Written by Microsoft developers excellent
  resource
• Applications for Windows Jeffrey Richter
• Great details about Windows basics
