GENERAL THEORY FOR

1
GENERAL THEORY FOR DISTRIBUTED
REFLECTORS J. BUUS Gayton Photonics Ltd 6
Baker Street Gayton Northants NN7 3EZ UK Tel
44 (0) 1604 859253 Fax [phone]
859256 Email buus_at_compuserve.com
2
OVERVIEW

• 1. ADDITION RULES FOR MULTIPLE REFLECTORS
• 2. PERIODIC STRUCTURES, COUPLED MODE THEORY
• 3. MORE GENERAL STRUCTURES
• 4. MODULATED PERIODIC STRUCTURES
• APPROXIMATIONS
• CONCLUSIONS AND OUTLOOK

3
ADDITION OF REFLECTIONS
For more on this tanh substitution and its
applications see 1
4
SMALL REFLECTIONS
If the reflection per unit length is k and all
reflections are in phase
This gives a differential equation which leads to
5
TRANSFER MATRICES
Er1
Er2
Er3
Es1
Es2
Es3
6
PERIODIC INDEX VARIATION
Assume that the solution is of the form
R(z) and S(z) are the amplitudes of a forward and
a backward wave, and they vary slowly with z
7
COUPLED MODE EQUATIONS
Direct substitution gives 20 terms! 4 combine to
2, leaving 18 2 contain second derivatives of
R(z) and S(z) 6 contain Dn2 4 are not phase
matched The remaining 6 are in 2 sets with the
same exp factor
For an alternative derivation of the C.M.E. see
2
8
SOLUTION
Note that this can be written as a transfer matrix
9
GENERAL REFLECTION EQUATION
Phase factor Depletion term Differential
Fresnel coefficient
Ordinary, first order, nonlinear differential
equation No general analytical solution
10
APPLICATION TO PERIODIC STRUCTURES
For a modulated periodic structure
higher terms
11
LINEARIZATION
Neglecting the higher order terms, replacing j by
-1
dividing by (1-r2) and using ratanh(r)
and replacing r/(1-r2) by r gives a linear
equation for r
This substitution was proposed in ref 3
12
GRATING REFLECTION
The phase factor in front of tanh depends on the
reference plane used and has no significance The
integral of rapidly varying terms will average to
0 Introduce window function w(z) and use db-b0
13
FOURIER TRANSFORM
for rectangular window
If g(z) or f(z) are periodic, the FT becomes a
Fourier series, with each term corresponding to
a reflection peak. Each of these peaks will have
sidelobes due to the FT of the window function w.
14
UNIFORM GRATING
For high values of kL it is more accurate to use
a modified detuning
The modified detuning was derived in ref 4
15
REFLECTION AS FUNCTION OF DETUNING
0.7000
0.6000
0.5000
0.4000
0.3000
0.2000
0.1000
0.0000
0.00
2.00
4.00
6.00
8.00
10.00
Uniform grating with kL1 (left) and 3 (right)
16
SAMPLED GRATING
1
g(z)
0
0
Lg
Ls
Ideal comb for M specific
values of N
Consider phase modulated gratings
For g(z)1, Parcevals theorem
17
PHASE MODULATED GRATING
Grating design from ref 5
18
CONCLUSIONS AND OUTLOOK

• Several powerful tools are available
• Analytical solutions or good approximations
  can be
• found for many special cases
• Good test cases for numerical methods
• Basis for synthesis of reflection functions
• Challenges
• Find better modified detuning
• Find an expression for the reflection phase

19
REFERENCES
1 S.W. Corzine et al, IEEE J. Quantum
Electron., Vol. 27, 2086-2090, 1991. 2 D.G.
Hall, Optics Comm., Vol. 82, 453-455,
1991. 3 D.L. Jaggard and Y. Kim, J.O.S.A. A,
Vol. 2, 1922-1930, 1985. 4 M.C. Parker et al,
J. Optics A, Vol. 3, 171-183, 2001. 5 H. Ishii
et al, IEEE J.S.T.Q.E. Vol. 1, 401-407,
1995. 6 Some of the material from this
presentation is discussed in more detail in J.
Buus et al, Tunable laser diodes and related
optical sources, Wiley, 2005.
