Distributed Systems: Security

1
Distributed SystemsSecurity

• CS 654Lecture 21December 4, 2006

2
Authentication Using Public Key Cryptography

• What could happen if KB (public key) is fake?
• How can we assure that it is not?
• Is there some way to digitally sign a piece of
  information?

3
Message Integrity

• Suppose you are conducting a transaction through
  e-mail, and Alice promises to buy your fake
  moustache collection for 500.
• Your girlfriend said only a loser would have a
  fake moustache collection.
• Say you send Alice your collection, and she said
  you 300 check. You are being ripped-off. How can
  you prove that she agreed to 500?
• Say that you try to get back at her, and claim
  that she actually offered 700. How can she prove
  that she only offered 500?
• Two things need to be taken care of
• You cant claim that she actually offered 700.
• She cant deny sending the offer.

4
Digital Signatures

• How can you verify that a document is real?
• What do we use in the real world?
• What if we really need to be certain?
• What if it were encrypted with the private key of
  of the sender?
• You could decrypt it with As public key. If it
  decrypted properly, then A must have encrypted it.

5
Digital Signatures

• Signing by encrypting the whole message.

6
Optimization

• Encrypting with PKC is slow. Can we leverage
  hashes somehow?
• Compute hash of the message (message digest).
  Encrypt the hash.
• This known as a digital signature.

7
Digital Signatures

• Signing just the hash.

8
Secure Replicated Servers

• Figure 9-22. Sharing a secret signature in a
  group of replicated servers.

9
Example Kerberos

• Ticket Granting Service (TGS), and Authentication
  Server (AS).
• A ticket is a special message used to convince a
  server that the client is who he or she claims to
  be.
• User A and AS share a secret key (derived from
  password). AS and TGS share a key.

10
Setting Up A Secure Channel

• First send message to Bob, with timestamp to
  prevent replay attacks.
• Bob sends back, also to prevent replay attacks.

11
Access Control
12
Access Control

• Imagine a server with a number of entities (which
  we will call objects) under its control. Requests
  come in, but are allowed only if the sender has
  sufficient access rights.
• Authorization is how to grant rights. Access
  control is how to verify rights. Very similar,
  and frequently used interchangeably.

13
General Model

• Reference monitor is like a security perimeter.

14
Access Control Matrix

• To model the rights, use a matrix. Each row is a
  subject, each object is a column. So Ms,o is an
  entry, which contains the allowed methods.

15
Access Control Lists

• Matrix is large, and often empty. So use a list
  instead, granting or removing rights.
• Bob, readAlice, writeChuck, check timestamp

16
Capabilities

• ACLs require the server to keep track. This can
  be cumbersome, especially if the authority
  granting rights is different.
• Capabilities grant rights, they are like a
  ticket, or a voucher.
• If you have the capability, you are allowed the
  operation.
• How can we implement this? PKI? Kerberos?

17
Protection Domains

• Figure 9-27. The hierarchical organization of
  protection domains as groups of users.

18
Firewalls

• Figure 9-28. A common implementation of a
  firewall.

19
Mobile Code

• Suppose you have an agent moving around for you,
  trying to find the best airplane ticket, visiting
  different airlines.
• As the mobile agent moves around, who/what might
  need protection?

20
Protecting Mobile Agents

• Can we protect a mobile agent from being
  destroyed?
• How about detecting modifications?
• Suppose you are sending an agent out to book
  airline tickets. Your agent first goes to Chucks
  Cheap Planes, then will go to Alices
  Safety-Last. Could Chuck change your agent so
  that it will think it already went to Alices?
• Detect changes to read-only state.
• Sign the state, so when it arrives, can detect
  modifications. How good?
• Cannot detect if it was using this during
  execution, though.
• Append only logs.
• Initially, log is emptyCinit Kowner(N)
• If a server S appends new data X, S appends X to
  log, and computes new checksum Cnew
  Kowner(Cold, sig(S, X), S)
• Selective revealing of state.
• Provide an array of data items. Each entry is
  only for a designated server, and is encrypted
  with that servers public-key.

21
Protecting the Target (Host)

• What kinds of malicious mobile code might attack
  your computer?
• Virus
• Applets, ActiveX controls, etc.
• How do you protect your computer against
  malicious mobile code?
• Sandboxing two steps
• Make sure that retrieving the remote code is
  secure (secure classloader).
• Verifying the byte code
• What could happen if the first step was not
  secure?

22
Protecting the Target

• Class loaders are trusted, verified.
• Class verifier to make sure that no illegal
  things are done. Such as?
• A security manager is used at run-time. What will
  it allow/disallow?
• What if it needs local files for state, etc.?
• A sandbox is very restrictive. Jail is probably
  a better term.

23
Playgrounds

• It makes sense that an untrusted agent should be
  able to create a file in its own space.
  Playgrounds allow a group of untrusted agents to
  create and use local resources.
• Should it be a separate machine?
• Another policy is to authenticate source, and use
  a specific security policy based on source. In
  other words, tailor the sandbox to the degree of
  trust. If very trusted, then no need for sandbox.

24
Object References as Capabilities

• This fine-grained control might be implemented
  using capabilities via object refs.

25
Stack Introspection

• How about more fine-grained?
• All calls to a method m of a resource first call
  enable_privilege to check authorization. Upon
  return, call disable_privilege.
• Java interpreter can handle this automatically.
• Can also use this to check chains. Suppose O1 can
  call O2, but the specific method is not allowed
  to the original invoker of O1. Stack
  introspection can check this.

26
Distributed Denial of Service

• What is it?
• Can be classified into two kinds, roughly.
  Denying bandwidth and hogging up server
  resources.
• How does a typical DDoS work? How can we protect
  against them?

27
Distributed Denial of Service

• No single way to protect, need comprehensive
  plan.
• Protect machines from getting taken over.
• Monitor egress routers.
• Monitor ingress (how well does this work?)
• Monitor overall network.

28
Security Management
29
Key Establishment

• Figure 9-33. The principle of Diffie-Hellman key
  exchange.

30
Key Distribution (1)

• Figure 9-34. (a) Secret-key distribution. see
  also Menezes et al. (1996).

31
Public Key Distribution

• Earlier we talked about how we can be assured
  that a publiic key is genuine.
• Public key distributed with authentication.
  Private with confidentiality and authentication.

32
PK Certificates

• How do we generate a PPK pair, for use in PKI?
  How do we verify that the public key is real?
• User generates pair.
• Encrypts cert request (containing public key)
  with public key of CA.
• How do we know the public key is correct?
• Send it to the CA.
• CA decrypts it, then sends back a signed
  document.
• A user, when it needs a public key for Bob, can
  now ask for a certificate. It computes the hash,
  then decrypts the hash in the cert with the
  public key of the CA. If there is a match, then
  the public key must be valid.

33
Digital Certificates Verification

• How can you verify that the public key you have
  for Bob is the real one?
• Compute the hash. Decrypt the signature with the
  public key of the signer. If it matches, must be
  correct.
• What would it take to break?
• Cant change, because dont know private key.
• Can we create a message that has the same hash?

34
Hierarchies of Trust

• Suppose you are a CA, and there are 1000 requests
  per week going to you from, say SUNY Albany. That
  is too many! What do you do?
• Delegate. Tell them to be their own CA. What is
  the disadvantage?
• Multiple trusted root CA certs.
• Instead, use chains of trust.

35
Trust Chains

• There is no solution. Eventually you must trust.
• So, use a chain of trust. Assume that you have
  the public key of the root authority, RA, and
  that you got it in a way that you trust it is
  correct.
• If you have a PK of B, that you can verify was
  encrypted with RAs private key, then RA vouches
  for the authenticity of Bs public key.
• You can chain this trust, so RA encrypts RA1s
  public key, RA1 encrypts RA2s public key, etc.

36
Secure Group Management

• Figure 9-35. Securely admitting a new group
  member.

37
Capabilities and Attribute Certificates (1)

• Figure 9-36. A capability in Amoeba.

38
Capabilities and Attribute Certificates (2)

• Figure 9-37. Generation of a restricted
  capability from an owner capability.

39
Delegation (1)

• Figure 9-38. The general structure of a proxy as
  used for delegation.

40
Delegation (2)

• Figure 9-39. Using a proxy to delegate and prove
  ownership of access rights.
