Title: An Introduction to the Expectation-Maximization (EM) Algorithm


1
An Introduction to the Expectation-Maximization
(EM) Algorithm
  • CSE 802, Spring 2006
  • Department of Computer Science and Engineering
  • Michigan State University

2
Overview
  • The problem of missing data
  • A mixture of Gaussian
  • The EM Algorithm
  • The Q-function, the E-step and the M-step
  • Some examples
  • Summary

3
Missing Data
  • Data collection and feature generation are not
    perfect. Objects in a pattern recognition
    application may have missing features
  • In the classification problem of sea bass versus
    salmon, the lightness feature can still be
    estimated if part of the fish is occluded. This
    is not so for the width feature
  • Features are extracted by multiple sensors. One
    or multiple sensors may be malfunctioning when
    the object is presented
  • A respondent fails to answer all the questions in
    a questionnaire
  • Some participants quit during the middle of a
    study, where measurements are taken at different
    time points
  • An example of missing data dermatology from UCI

4
Missing Data
  • Different types of missing data
  • Missing completely at random (MCAR)
  • Missing at random (MAR) the fact that a feature
    is missing is random, after conditioned on
    another feature
  • Example people who are depressed might be less
    inclined to report their income, and thus
    reported income will be related to depression.
    However, if, within depressed patients the
    probability of reported income was unrelated to
    income level, then the data would be considered
    MAR
  • If not MAR nor MCAR, the missing data phenomenon
    needs to be modeled explicitly
  • Example if a user fails to provide his/her
    rating on a movie, it is more likely that he/she
    dislikes the movie because he/she has not watched
    it

5
Strategy of Coping With Missing Data
  • Discarding cases
  • Ignore patterns with missing features
  • Ignore features with missing values
  • Easy to implement, but wasteful of data. May bias
    the parameter estimate if not MCAR
  • Maximum likelihood (the EM algorithm)
  • Under some assumption of how the data are
    generated, estimate the parameters that maximize
    the likelihood of the observed data (non-missing
    features)
  • Multiple Imputation
  • For each object with missing features, generate
    (impute) multiple instantiations of the missing
    features based on the values of the non-missing
    features

6
Mixture Of Gaussian
  • In DHS chapters 2 and 3, the class conditional
    densities are assumed to be parametric,
    typically Gaussian
  • What if this assumption is violated?
  • One solution is to use non-parametric density
    estimate (Ch 4)
  • An intermediate approach a mixture of Gaussian

7
Gaussian Mixture
  • Let x denote the feature vector of an object
  • A Gaussian mixture consists of k different
    Gaussian distributions, k being specified by the
    user
  • Each of the Gaussian is known as component
    distribution or simply component
  • The j-th Gaussian has mean mj and covariance
    matrix Cj
  • In practice, k can be unknown
  • Two different ways to think about a Gaussian
    mixture
  • The pdf is a sum of multiple Gaussian pdfs
  • Two stage-data generation process
  • First a component is randomly selected. The
    probability that the j-th component is selected
    is aj
  • The component selected is referred to as
    component label
  • The data x is then generated according to

8
Gaussian Mixture
  • Let f(x, mj, Cj) denote the Gaussian pdf
  • Let z be the random variable corresponding to the
    identity of the component selected (component
    label)
  • The event zj means that the j-th component is
    selected at the first stage of the data
    generation process
  • p(zj) aj
  • The pdf of a Gaussian mixture is a weighted sum
    of different Gaussian pdf

9
Gaussian Mixture and Missing Data
  • Suppose we want to fit a Gaussian mixture of k
    components to the training data set x1, , xn
  • The parameters are aj, mj and Cj
  • The log-likelihood is given by
  • The parameters can be found by maximizing
  • Unfortunately, the MLE does not have a closed
    form solution
  • Let zi be the component label of the data xi
  • A simple algorithm to find the MLE views all the
    zi as missing data. After all, the zi are not
    observed (unknown)!
  • This falls under the category of missing
    completely at random, because all the zi are
    missing. So, the missing phenomenon is not
    related to the value of xi

10
The EM Algorithm
  • The EM algorithm is an iterative algorithm that
    finds the parameters which maximize the
    log-likelihood when there are missing data
  • Complete data the combination of the missing
    data and the observed data
  • For the case of Gaussian mixture, the complete
    data consist of the pairs (xi, zi), i1, ..., n
  • The EM algorithm is best used in situation where
    the log-likelihood of the observed data is
    difficult to optimize, whereas the log-likelihood
    of the complete data is easy to optimize
  • In the case of a Gaussian mixture, the
    log-likelihood of complete data (xi and zi) is
    maximized easily by taking a weighted sum and a
    weighted scatter matrix of the data
  • Note that the log-likelihood of the observed data
    is obtained by marginalizing (summing out) the
    hidden data

11
The EM Algorithm
  • Let X and Z denote the vector of all observed
    data and hidden data, respectively
  • Let qt be the parameter estimate at the t-th
    iteration
  • Define the Q-function (a function of q)
  • Intuitively, the Q-function is the expected
    value of the complete data log-likelihood
  • Fill in all the possible values for the missing
    data Z. This gives rise to the complete data, and
    we compute its log-likelihood
  • Not all the possible values for the missing
    features are equally good. The goodness of a
    particular way of filling in (Zz) is determined
    by how likely the r.v. Z takes the value of z
  • This probability is determined by the observed
    data X and the current parameter qt

12
The EM Algorithm
  • An improved parameter estimate at iteration (t1)
    is obtained by maximizing the Q function
  • Maximizing
    with respect to q is often easy because
    maximizing the complete data log-likelihood
    .
    is assumed to be easy
  • The EM algorithm takes its name because it
    alternates between the E-step (expectation) and
    the M-step (maximization)
  • E-step compute Q(q qt)
  • M-step Find q that maximizes Q(q qt)
  • Note the difference between q and qt one is
    variable, while the other is given (fixed)

13
The EM Algorithm
  • From a computation viewpoint, the E-step computes
    the posterior probability p(ZX,qt) based on the
    current parameter estimate
  • The M-step updates the parameter estimate to get
    qt1 based on update equations derived
    analytically by maximizing Q(q qt)
  • The EM Algorithm requires an initial guess q0 for
    the parameter
  • Each iteration of E-step and M-step is guaranteed
    to increase . , the
    log-likelihood of the observed data, until a
    local maximum of is reached. (See
    DHS Problem 3.44)
  • That explains why the EM algorithm can find the
    MLE
  • Note that

14
The EM Algorithm Applied to Gaussian Mixture
  • The missing data are the component labels (z1, ,
    zn)
  • The parameter vector is q (a1, , ak, m1, ,
    mk, C1, , Ck)
  • The E-step computes the posterior probability of
    the missing data
  • Let rij denote p(zijxi, q)

15
The EM Algorithm Applied to Gaussian Mixture
Weight of the missing data
Complete data log-likelihood
16
The M-step
  • To maximize Q(q qt) with respect to ml, set the
    gradient to zero
  • This is the update equation for the new ml at
    (t1)-th iteration
  • ril is computed based only on the parameter at
    the t-th iteration
  • Similarly, we have
  • If all ril are binary (component labels are
    known), these formulae reduce to the standard
    formulae for mean, covariance matrix and the
    class prior

17
Complete EM Algorithm for Gaussian Mixture
  1. Start with an initial guess of the parameter, q0
    (a1, , ak, m1, , mk, C1, , Ck)
  2. Set t0
  3. While the log-likelihood of observed data,
    , is still increasing, do
  4. Perform the E-step by computing rij P(zijxi,
    qt)
  5. Perform the M-step by re-estimating the parameter
    using the following update equation
  6. Form qt1 based on for all l
  7. Set tt1

18
An Example
  • 8 Data points in 2D. Fit a Gaussian mixture of
    two components
  • For simplicity, a1 and a2 are fixed to be 0.5
  • 17 iterations for convergence

19
Some notes on the EM Algorithm and Gaussian
Mixture
  • Since EM is iterative, it may end up in a local
    maxima (instead of the global maxima) of the
    log-likelihood of the observed data
  • A good initialization is needed to find a good
    local maxima
  • The EM algorithm may not be the most efficient
    algorithm for maximizing the log-likelihood
    however, the EM algorithm is often fairly simple
    to implement
  • If the missing data are continuous, integration
    should be used instead of the summation to form
    Q(q qt)
  • The number of components k in a Gaussian mixture
    is either specified by the user, or advanced
    techniques can be used to estimate it based on
    the available data
  • A mixture of Gaussians can be viewed as a
    middle-ground
  • Flexibility non-parametric gt mixture of
    Gaussians gt a single Gaussian
  • Memory for storing the parameters non-parametric
    gt mixture of Gaussians gt a single Gaussian

20
A Classification Example
  • Different types of class conditional densities
    are considered to classify the two-ring data set
  • 1. Gaussian with common covariance matrix 2.
    Gaussian with different covariance matrix 3. A
    mixture of Gaussian

31 training errors
No training error number of Gaussians is 4 per
each class
25 training errors
21
Summary
  • The problem of missing data is regularly
    encountered in real-world applications
  • Instead of discarding the cases with missing
    data, the EM algorithm can be used to maximize
    the marginalized log-likelihood (the
    log-likelihood of data observed)
  • A mixture of Gaussians provides more flexibility
    than a single Gaussian for density estimation
  • By regarding the component labels as missing
    data, the EM algorithm can be used for parameter
    estimation in a mixture of Gaussians
  • The EM algorithm is an iterative algorithm that
    consists of the E-step (computation of the Q
    function) and the M-step (maximization of the Q
    function)

22
References
  • http//www.uvm.edu/dhowell/StatPages/More_Stuff/M
    issing_Data/Missing.html
  • An EM implementation in Matlab
    http//www.cse.msu.edu/lawhiu/software/em.m
  • http//www.lshtm.ac.uk/msu/missingdata/index.html
  • DHS chapter 3.9
  • Some recent derivations of the EM algorithm in
    new scenarios
  • M. Figueiredo, "Bayesian image segmentation using
    wavelet-based priors", IEEE Computer Society
    Conference on Computer Vision and Pattern
    Recognition - CVPR'2005.
  • B. Krishnapuram, A.  Hartemink, L. Carin, and M.
    Figueiredo, "A Bayesian approach to joint feature
    selection and classifier design", TPAMI, vol. 26,
    no. 9, pp. 1105-1111, 2004.
  • M. Figueiredo and A.K.Jain, "Unsupervised
    learning of finite mixture models", TPAMI, vol.
    24, no. 3, pp. 381-396, March 2002. http//www.lx.
    it.pt/mtf/mixturecode.zip for the software
Write a Comment
User Comments (0)
About PowerShow.com
