Relief Portrayal

• January 23, 2006
• Geog 258 Maps and GIS

2
Outlines

• How relief is portrayed?
• Absolute-relief portrayal methods
• Relative-relief portrayal methods
• Combining relief portrayal methods
• Dynamic relief portrayal
• Digital data for relief portrayal
• DEM (Digital Elevation Model)

3
1. Absolute-relief methods

• Provides relief in a numeric scale
• You can determine exact value of elevation or
  water depth at individual points from this kind
  of map
• Designed to give precise measurements
• You can measure slope from this kind of map
• You can create profile from this kind of map
• Common methods include
• Contours lines of equal elevation
• Isobath lines of equal water depth
• Hypsometic tints color-coded contour interval

4
Contours

• Think of contours as lines obtained by cutting
  terrain horizontally with imaginary planes in
  equal intervals
• Contours are lines of equal elevation

5
Types of contours

• What would terrain look like inside depression
  contour?
• Not all contours are labeled index contour is
  labeled, shown as thick lines

6
What is contour interval from this map?
7
Isobaths

• Lines of equal water depth

Further questions Any difference compared to
contour map?
8
Hypsometric tinting

• Space between contour lines is color-coded

Does this look better than a contour map? Why do
you think so?
9
Hypsometric tint
Is color coding scheme good?
10
Hypsometric tint
11
Spectral color progression
12
Vignetted hypsometric tints
13
2. Relative-relief methods

• Designed to give a general impression of relative
  heights of landform rather than its exact values
  at individual points
• Focused on providing realistic presentation of
  relief
• Different ways to create 3D effect
• Commonly used methods include
• Physical relief model raised relief
• Perspective view oblique vantage point
• Relief shading imaginary light source

14
Physical model of relief

• Physical 3D model of relief

Raised relief globes
Raised relief topographic map
Relief models
15
Perspective views

• Creates 3D effect with oblique vantage points

16
Perspective views
Landscape drawings
17
Perspective views
Fishnet maps (terrain profiles)
Block diagram
18
Relief shading

• Creates 3D effect using an imaginary light source

Shaded relief map
Vertical aerial photo
19
3. Combining relief methods

• Absolute methods are good for making
  measurements, but it is hard to have a general
  sense of terrain variation
• Relative methods are good for gaining a general
  impression, but it does not give precise
  measurements
• Why not combine both?

20
Which methods are combined in this map?
Absolute Relative
Contour Physical model
Isobath Perspective views
Hypsometric tinting Relief shading
21
Which methods are combined in this map?
Absolute Relative
Contour Physical model
Isobath Perspective views
Hypsometric tinting Relief shading
22
Which methods are combined in this map?
Absolute Relative
Contour Physical model
Isobath Perspective views
Hypsometric tinting Relief shading
23
Which methods are combined in this map?
Absolute Relative
Contour Physical model
Isobath Perspective views
Hypsometric tinting Relief shading
24
Which methods are combined in this map?
Absolute Relative
Contour Physical model
Isobath Perspective views
Hypsometric tinting Relief shading
25
Which methods are combined in this map?
Absolute Relative
Contour Physical model
Isobath Perspective views
Hypsometric tinting Relief shading
26
Which methods are combined in this map?
Absolute Relative
Contour Physical model
Isobath Perspective views
Hypsometric tinting Relief shading
27
Which methods are combined in this map?
Absolute Relative
Contour Physical model
Isobath Perspective views
Hypsometric tinting Relief shading
28
4. Dynamic relief portrayal

• Putting relief portrayal into motion
• Can gain dynamic impression of landform
• Animated methods
• A sequence of maps is animated ? detect changes
• A series of images taken from different vantage
  points are combined to create animation ?
  fly-over
• Interactive methods
• You can choose the location, vantage points, and
  so on
• Demo
• http//www2.jpl.nasa.gov/srtm/
• http//geology.asu.edu/reynolds/topo_gallery/topo
  _gallery.htm
• http//www.truflite.com/

29
5. Digital Elevation Model

• Some maps can be made by hand
• Relief globe, hachures, block diagram
• These days maps are increasingly generated by
  computers
• Shaded relief map, profile map, fly-over
• Combining methods are easily manipulated
• Basis of computer-generated terrain mapping is
  Digital Elevation Model (DEM)
• DEM stores elevation or water depth in regularly
  sampled points
• DEM can be thought of as varying elevation values
  stored in matrices
