Ch'13 Metropolitan Area Networks

1
Ch.13 Metropolitan Area Networks

• Lecturer Tae-Hyong Kim (B201-4)
• thkim_at_cespc1.kumoh.ac.kr

2
Contents

• Introduction
• IEEE 802.6 (DQDB)
• Distributed Queue Dual Bus
• SMDS
• Switched Multimegabit Data Service

3
Metropolitan Area Network

• A network designed to extend over an entire city
• privately owned connecting infrastructure (e.g.
  cable, routers, gateway) is impractical
• have to use the services of existing utilities,
  such as the telephone company
• SMDS (Switched Multimegabit Data Service)
• DQDB (Distributed Queue Dual Bus)
• WAN (Wide Area Network)
• national, continental, world-wide
• X.21, X.25, ISDN, ATM, Frame Relay

4
13.1 IEEE 802.6 (DQDB)

• Similar to LAN standard but designed for MAN
• Access method dual bus (two unidirectional
  buses)
• Access to these bus is granted by the distributed
  queue mechanism
• Station 1 Head of bus A, end of bus B
• Station 5 Head of bus B, end of bus A

5
IEEE 802.6 (DQDB) (cont.)

• Directional traffic
• Each bus supports traffic only one direction
  opposite direction each other
• Upstream and Downstream stations
• For Bus A, stations 1 and 2 are considered
  upstream wrt station 3, while stations 4 and 5
  are considered downstream wrt station 3
• Transmission slots
• Data travels on each bus as a steady stream of
  53-byte slots not packets but continuous
  streams of bits
• The head of each bus generates empty slots for
  use on it
• The source station must choose the bus for which
  the destination station is considered downstream

6
IEEE 802.6 (DQDB) (cont.)
7
IEEE 802.6 (DQDB) (cont.)

• Slot Reservation
• To send data downstream, a station must wait for
  the arrival of an unoccupied slot
• To stop an upstream station from monopolizing the
  bus and occupying all the slots
• To send data on one bus, a station must use the
  other bus to make a reservation
• The station sets a reservation bit in a slot on
  the other bus to tell each station it passes that
  a station is reserving a slot on the bus
• No station may send data without first making a
  reservation, even if it sees slot after slot pass
  by empty.
• Even a station that has made a reservation cannot
  claim just any empty slot ? it must wait for the
  arrival of the specific slot it reserved

8
IEEE 802.6 (DQDB) (cont.)

• Distributed Queues
• Each station has two queues one for each bus
• ? A kind of waiting list
• To make reservations
• To track the reservations of the other stations

9
IEEE 802.6 (DQDB) (cont.)

• Using a queue for Bus Access
• Station X uses virtual tokens to track
  reservations
• adds a token at the rear of the queue each time a
  slot passes on the other bus with a reservation
  bit set
• When the station needs to make a reservation for
  itself, it sets one of the reservation bits, then
  insert its own token into its queue
• For each empty slot that passes, it removes one
  token from the queue
• Each time the station reads its queue, it can
  tell how many downstream reservations have been
  made by counting how many tokens are in the queue

10
IEEE 802.6 (DQDB) (cont.)

• Ring Configuration
• DQDB can be implemented as a ring
• Advantage Reconfigurable whenever a link or a
  station fails

11
IEEE 802.6 (DQDB) (cont.)

• DQDB Layers
• The IEEE defines both the medium access control
  (MAC) sublayer and the physical layer for DQDB
• MAC sublayer
• splits the data stream coming from upper layers
  into 48-byte segments and adds 5-byte header to
  create 53 bytes each
• Having 53 bytes make a DQDB slot compatible with
  the size of a cell in ATM

12
IEEE 802.6 (DQDB) (cont.)
13
IEEE 802.6 (DQDB) (cont.)

• DQDB Header
• Access field
• Busy (B) indicates if the slot is carrying data
• Sot type (ST) packet transmission or
  isochronous transmission
• Previous slot read (PSR) 2 bits, set to 0 by
  the receiving station, once it has read the
  contents of the slot
• Request (RQ) three bits, set by stations to
  make reservations for slots, represent eight
  levels of priority (station level)
• Address field
• 20-bit virtual channel identifier for MAN and WAN
  transmission
• When used in LAN, this field contains all 1s and
  an additional header is added for MAC address
• Type field 2 bits
• identifies the payload user data, management
  data, ...
• Priority field the priority of the slot
• Implementation coaxial or fiber-optic cable

14
13.2 SMDS

• Connecting LANs using Leased Lines
• Expensive n LANs require n?(n-1)/2 connections
• SMDS provides the solution
• Packet-switched datagram service for high-speed
  MAN by common carriers
• subscribers pay only for the time they use
• Subscriber LANs link to SMDS through routers
  using DQDB architecture

15
SMDS (cont.)

• SMDS Architecture
• SIP (SMDS Interface Protocol) three levels

DQDB architecture
16
SMDS (cont.)

• SIP Levels

17
SMDS (cont.)

• SIP Level 3
• accepts the user data less than 9188 bytes
• Header and trailer are added
• management and control fields
• sender and receiver addresses 8 bytes
• The first 4 bits defines the type of address
• The next 60 bits (15 4bit sections) each
  section define a digit (09) ? telephone numbers
  (country/area/local number) ?WAN
• the packet is divided into 44 byte sections
• To each section, 2-byte header and 2-byte trailer
  are added

18
SMDS (cont.)

• SIP Level 2
• DQDB comes into play
• add 5-byte header to 48-byte sections
• ? 53 byte output to slot and carried to its
  destination
• SIP level 1 Physical level
• Other Features
• The data rate ranges from 1.544Mbps to 155Mbps
• Each user is assigned an average data rate
• Addressing system telephone number
• Multicasting is available
