SYDNEY HARBOUR BRIDGE

1
SYDNEY HARBOUR BRIDGE

• CHRIS BROWN
• JOE ROGERS

2
(No Transcript)
3

• Although considered by some to have heavy
  characteristics, such as large masonry towers and
  a thick arch, the Sydney Harbour Bridge is very
  much an example of structural art for its
  contributions to the social and symbol appeal of
  Sydney, Australia.

4
BACKGROUND

• Located in Sydney, Australia
• The Old Coat Hanger
• Dr J.J.C Bradfield prepared the design
• Finished in February of 1932
• Carries Cars, Train, Foot, and Bike Traffic

5
Scientific

• Total Length of 1149 meters and its arch span is
  503 meters
• 2 Hinges at footings of Pylons
• 52,800 tons of steel
• 39,000 tons in the arch

6
Scientific

• Masonry towers provide no support for main span
• Tension in deck supports, Compression in the
  arch, Huge reactions at the foundations

7
Symbolic

• Irony is
• 2000 Sydney Olympics
• Combined with opera house to create beautiful
  harbor entrance

8
Social

• Links the city with North Sydney, by carrying
  eight lanes of traffic and two railroad tracks
• BridgeClimb Sydney for the climb of your
  life

9
Sydney Harbour vs. Hell Gate
Hell Gate Sydney Harbour
Completed 1916 1932
Designer Gustav Lindenthal Dr. J.J.C. Bradfield
Span 298 meters 503 meters
Weight 20,000 tons 52,800 tons
10
Hell Gate Bridge
Sydney Harbour Bridge
11
(No Transcript)
