ECE6130: Computer Architecture: Instruction Level Parallelism ILP

1
ECE6130 Computer ArchitectureInstruction Level
Parallelism (ILP)

• Dr. Xubin He
• http//www.ece.tntech.edu/hexb
• Email hexb_at_tntech.edu
• Tel [phone], Brown Hall 319

2

• Previous Class
• Dynamic Scheduling
• Tomasulo
• Today
• Tomasulo (Contd.)
• Speculation
• Speculative Tomasulo
• Multiple instructions issue

3
Several Small Questions

• Why RAW is a real hazard?
• What technique allows out-of-order execution?

4
Several Small Questions

• Why RAW is a real hazard?
• WAW and WAR can be eliminated by register
  renaming if we have enough resources
• RAW can only be avoided, not eliminated
• EX. A Load instruction followed by an integer
  ALU instruction that directly uses the load
  result will always lead to a RAW hazard. SO
  compiler has to try to avoid such situations
• What technique allows out-of-order execution?
• Split ID pipe stage of simple 5-stage pipeline
  into two stages issue and Read operands?in-order
  issue, out-of-order execution and out-of-order
  completion

5
Tomasulo Loop Example

• Loop LD F0 0 R1
• MULTD F4 F0 F2
• SD F4 0 R1
• SUBI R1 R1 8
• BNEZ R1 Loop
• This time assume Multiply takes 4 clocks
• Assume 1st load takes 8 clocks (L1 cache miss),
  2nd load takes 1 clock (hit)
• To be clear, will not show clocks for SUBI, BNEZ
• Reality integer instructions ahead of Floating
  Point Instructions
• Show 2 iterations

6
Loop Example
7
Loop Example Cycle 1
8
Loop Example Cycle 2
9
Loop Example Cycle 3

• Implicit renaming sets up data flow graph

10
Loop Example Cycle 4

• Dispatching SUBI Instruction (not in FP queue)

11
Loop Example Cycle 5

• And, BNEZ instruction (not in FP queue)

12
Loop Example Cycle 6

• Notice that F0 never sees Load from location 80

13
Loop Example Cycle 7

• Register file completely detached from
  computation
• First and Second iteration completely overlapped

14
Loop Example Cycle 8
15
Loop Example Cycle 9

• Load1 completing who is waiting?
• Note Dispatching SUBI

16
Loop Example Cycle 10

• Load2 completing who is waiting?
• Note Dispatching BNEZ

17
Loop Example Cycle 11

• Next load in sequence

18
Loop Example Cycle 12

• Why not issue third multiply?

19
Loop Example Cycle 13

• Why not issue third store?

20
Loop Example Cycle 14

• Mult1 completing. Who is waiting?

21
Loop Example Cycle 15

• Mult2 completing. Who is waiting?

22
Loop Example Cycle 16
23
Loop Example Cycle 17
24
Loop Example Cycle 18
25
Loop Example Cycle 19
26
Loop Example Cycle 20

• Once again In-order issue, out-of-order
  execution and out-of-order completion.

27
Summary

• Reservations stations implicit register renaming
  to larger set of registers buffering source
  operands
• Prevents registers as bottleneck
• Avoids WAR, WAW hazards
• Allows loop unrolling in HW
• Not limited to basic blocks (integer units gets
  ahead, beyond branches)
• Today, helps cache misses as well
• Dont stall for L1 Data cache miss (insufficient
  ILP for L2 miss?)
• Lasting Contributions
• Dynamic scheduling
• Register renaming
• Load/store disambiguation
• 360/91 descendants are Pentium III PowerPC 604
  MIPS R10000 HP-PA 8000 Alpha 21264

28
Speculation to greater ILP

• Greater ILP Overcome control dependence by
  hardware speculating on outcome of branches and
  executing program as if guesses were correct
• Speculation ? fetch, issue, and execute
  instructions as if branch predictions were always
  correct
• Dynamic scheduling ? only fetches and issues
  instructions
• Essentially a data flow execution model
  Operations execute as soon as their operands are
  available

29
Speculation to greater ILP

• 3 components of HW-based speculation
• Dynamic branch prediction to choose which
  instructions to execute
• Speculation to allow execution of instructions
  before control dependences are resolved
• ability to undo effects of incorrectly
  speculated sequence
• Dynamic scheduling to deal with scheduling of
  different combinations of basic blocks

30
Adding Speculation to Tomasulo

• Must separate execution from allowing instruction
  to finish or commit
• This additional step called instruction commit
• When an instruction is no longer speculative,
  allow it to update the register file or memory
• Requires additional set of buffers to hold
  results of instructions that have finished
  execution but have not committed
• This reorder buffer (ROB) is also used to pass
  results among instructions that may be speculated

31
Exceptions and Interrupts

• Speculation guess and check
• Important for branch prediction
• Need to take our best shot at predicting branch
  direction.
• If we speculate and are wrong, need to back up
  and restart execution to point at which we
  predicted incorrectly
• This is exactly same as precise exceptions!
• Technique for both precise interrupts/exceptions
  and speculation in-order commit
• Exceptions are handled by not recognizing the
  exception until instruction that caused it is
  ready to commit in ROB
• If a speculated instruction raises an exception,
  the exception is recorded in the ROB
• This is why reorder buffers in all new processors

32
Reorder Buffer (ROB)

• In Tomasulos algorithm, once an instruction
  writes its result, any subsequently issued
  instructions will find result in the register
  file
• With speculation, the register file is not
  updated until the instruction commits
• (we know definitively that the instruction should
  execute)
• Thus, the ROB supplies operands in interval
  between completion of instruction execution and
  instruction commit
• ROB is a source of operands for instructions,
  just as reservation stations (RS) provide
  operands in Tomasulos algorithm
• ROB extends architectured registers like RS

33
Reorder Buffer Entry

• Each entry in the ROB contains four fields
• Instruction type
• a branch (has no destination result), a store
  (has a memory address destination), or a register
  operation (ALU operation or load, which has
  register destinations)
• Destination
• Register number (for loads and ALU operations) or
  memory address (for stores) where the
  instruction result should be written
• Value
• Value of instruction result until the instruction
  commits
• Ready
• Indicates that instruction has completed
  execution, and the value is ready

34
Reorder Buffer operation

• Holds instructions in FIFO order, exactly as
  issued
• When instructions complete, results placed into
  ROB
• Supplies operands to other instruction between
  execution complete commit ? more registers
  like RS
• Tag results with ROB buffer number instead of
  reservation station
• Instructions commit ?values at head of ROB placed
  in registers
• As a result, easy to undo speculated
  instructions on mispredicted branches or on
  exceptions

Commit path
35
Recall 4 Steps of Speculative Tomasulo Algorithm

• 1. Issueget instruction from FP Op Queue
• If reservation station and reorder buffer slot
  free, issue instr send operands reorder
  buffer no. for destination (this stage sometimes
  called dispatch)
• 2. Executionoperate on operands (EX)
• When both operands ready then execute if not
  ready, watch CDB for result when both in
  reservation station, execute checks RAW
  (sometimes called issue)
• 3. Write resultfinish execution (WB)
• Write on Common Data Bus to all awaiting FUs
  reorder buffer mark reservation station
  available.
• 4. Commitupdate register with reorder result
• When instr. at head of reorder buffer result
  present, update register with result (or store to
  memory) and remove instr from reorder buffer.
  Mispredicted branch flushes reorder buffer
  (sometimes called graduation)

36
Tomasulo With Reorder buffer
Done?
FP Op Queue
ROB7 ROB6 ROB5 ROB4 ROB3 ROB2 ROB1
Newest
Reorder Buffer
Oldest
F0
LD F0,10(R2)
N
Registers
To Memory
Dest
from Memory
Dest
Dest
Reservation Stations
FP adders
FP multipliers
37
Tomasulo With Reorder buffer
Done?
FP Op Queue
ROB7 ROB6 ROB5 ROB4 ROB3 ROB2 ROB1
Newest
Reorder Buffer
Oldest
Registers
To Memory
Dest
from Memory
Dest
2 ADDD R(F4),ROB1
Dest
Reservation Stations
FP adders
FP multipliers
38
Tomasulo With Reorder buffer
Done?
FP Op Queue
ROB7 ROB6 ROB5 ROB4 ROB3 ROB2 ROB1
Newest
Reorder Buffer
Oldest
Registers
To Memory
Dest
from Memory
Dest
2 ADDD R(F4),ROB1
Dest
Reservation Stations
FP adders
FP multipliers
39
Tomasulo With Reorder buffer
Done?
FP Op Queue
ROB7 ROB6 ROB5 ROB4 ROB3 ROB2 ROB1
Newest
Reorder Buffer
Oldest
Registers
To Memory
Dest
from Memory
Dest
2 ADDD R(F4),ROB1
6 ADDD ROB5, R(F6)
Dest
Reservation Stations
1 10R2
5 0R3
FP adders
FP multipliers
40
Tomasulo With Reorder buffer
Done?
FP Op Queue
ROB7 ROB6 ROB5 ROB4 ROB3 ROB2 ROB1
Newest
Reorder Buffer
Oldest
Registers
To Memory
Dest
from Memory
Dest
2 ADDD R(F4),ROB1
6 ADDD ROB5, R(F6)
Dest
Reservation Stations
1 10R2
5 0R3
FP adders
FP multipliers
41
Tomasulo With Reorder buffer
Done?
FP Op Queue
ROB7 ROB6 ROB5 ROB4 ROB3 ROB2 ROB1
Newest
Reorder Buffer
Oldest
Registers
To Memory
Dest
from Memory
Dest
2 ADDD R(F4),ROB1
6 ADDD M10,R(F6)
Dest
Reservation Stations
FP adders
FP multipliers
42
Tomasulo With Reorder buffer
Done?
FP Op Queue
ROB7 ROB6 ROB5 ROB4 ROB3 ROB2 ROB1
Newest
Reorder Buffer
Oldest
Registers
To Memory
Dest
from Memory
Dest
2 ADDD R(F4),ROB1
Dest
Reservation Stations
FP adders
FP multipliers
43
Tomasulo With Reorder buffer
Done?
FP Op Queue
ROB7 ROB6 ROB5 ROB4 ROB3 ROB2 ROB1
Newest
Reorder Buffer
F2
DIVD F2,F10,F6
N
F10
ADDD F10,F4,F0
N
Oldest
F0
LD F0,10(R2)
N
Registers
To Memory
Dest
from Memory
Dest
2 ADDD R(F4),ROB1
Dest
Reservation Stations
FP adders
FP multipliers
44
Avoiding Memory Hazards

• WAW and WAR hazards through memory are eliminated
  with speculation because actual updating of
  memory occurs in order, when a store is at head
  of the ROB, and hence, no earlier loads or stores
  can still be pending
• RAW hazards through memory are maintained by two
  restrictions
• not allowing a load to initiate the second step
  of its execution if any active ROB entry occupied
  by a store has a Destination field that matches
  the value of the A field of the load, and
• maintaining the program order for the computation
  of an effective address of a load with respect to
  all earlier stores.
• these restrictions ensure that any load that
  accesses a memory location written to by an
  earlier store cannot perform the memory access
  until the store has written the data

45
Getting CPI below 1

• CPI 1 if issue only 1 instruction every clock
  cycle
• Multiple-issue processors come in 3 flavors
• statically-scheduled superscalar processors,
• dynamically-scheduled superscalar processors, and

• VLIW (very long instruction word) processors
• 2 types of superscalar processors issue varying
  numbers of instructions per clock
• use in-order execution if they are statically
  scheduled, or
• out-of-order execution if they are dynamically
  scheduled
• VLIW processors, in contrast, issue a fixed
  number of instructions formatted either as one
  large instruction or as a fixed instruction
  packet with the parallelism among instructions
  explicitly indicated by the instruction (Intel/HP
  Itanium)

46
Multiple Issue Processors

• Taking Advantage of More ILP with Multiple Issue
• Superscalar issue varying numbers of
  instructions per cycle that are either statically
  scheduled (using compiler techniques, thus
  in-order execution) or dynamically scheduled
  (using techniques based on Tomasulos algorithm,
  thus out-order execution)
• VLIW (very long instruction word) issue a fixed
  number of instructions formatted either as one
  large instruction or as a fixed instruction
  packet with the parallelism among instructions
  explicitly indicated by the instruction (hence,
  they are also known as EPIC, explicitly parallel
  instruction computers). VLIW and EPIC processors
  are inherently statically scheduled by the
  compiler.

47
Limits of ILP

• Paper Limits of instruction-level parallelism,
  by David Wall, Nov 1993
• What were defaults in number of instructions
  issued per clock cycle, instruction window size,
  execution latency, number of execution units?
• How did loop unrolling change results?
• How did realistic functional unit execution
  latencies change results?
• Paper was written in 1993
• Which ideas still too optimistic in 2008?
• Which ideas seem tame in 2008?

48
Next

• Memory Hierarchy
• Read Chapter 5.1-5.3
