BioPhotonic Scanner

1
BioPhotonic Scanner

• Scan Operator Training (v2.0)

By Scott Ferguson
2
Scanner Training - Goal

• To ensure that the Scan Operator is fully trained
  in the proper operation of the BioPhotonic
  Scanner.
• This will lead to precise, accurate and
  reproducible results.

3
Scanner Training - Overview

• Unpacking Parts ID
• Scanner Setup
• Calibration
• Operation - Performing Scans
• Uploading Data (How, When, Why)
• Software - View Reports
• Software - Scanner Help
• Scanner Shutdown

4
Unpacking Parts Identification

• Scanner
• Laptop
• Serial Cable
• Laptop Power
• Scanner Power
• Laser Key
• Safety Interlock
• Phone Cord
• Thermometer

5
Bar Code Reader

• Optional Accessory
• Help with data entry of certificate number
• Hooks into PS2 Port
• No drivers or software required
• Cost 150

6
Temperature Requirements

• Recommended Operating Conditions
• Temperature 72 - 74ºF
• Storage Conditions
• Temperature 45 - 100ºF
• The Scanner may NOT be
• used outdoors!

7
Laser Safety (1 of 2)

• Laser Classifications (Scanner is Class IIIb)
• Class IIIb Moderate Powered Laser
• Eye Contact Hazardous
• Skin Contact Not Hazardous (e.g. Safe)
• Injuries to the eye can result
• from direct laser exposure!

8
Laser Safety (2 of 2)

• Safety Warning
• DO NOT Remove Laser Shield
• DO NOT Modify Laser Shield
• DO NOT Remove Scanner Cover

9
Scanner Setup (1 of 3)

• Plug in Scanner Laptop.
• Connect Laptop to Scanner w/ Serial Cable.
• Insert Safety Interlock, and Laser Key into the
  rear of the Scanner.

10
Scanner Setup (2 of 3)
Key
OFF ON

• Turn Scanner Main Power switch to the ON
  position.
• Turn Laser Key to the ON position (Verify that
  laser is now on).

11
Scanner Setup (3 of 3)

• Boot-up the laptop using the main power button.
• At the Windows XP
• log in screen, select
• SCAN OPERATOR.
• The Scanner
• software will load
• automatically.

12
Laptop Lock Down

• No external software may be loaded onto the
  laptop.
• Every time the software connects with the
  corporate servers, a list of all installed
  applications will be delivered to NSE. Violators
  will have their scanner turned off.

13
(No Transcript)
14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
Calibration

• The BioPhotonic Scanner requires calibration
  before each scan session.
• The standards used to calibrate the instrument
  are contained in the calibration cap (attached to
  the scanner with a lanyard)
• There are two reference materials. One with a
  high BDS, the other with a low BDS.
• These Calibration Caps are specific to each
  Scanner. If lost or damaged, it will become
  necessary to be re-calibrated at factory
  (returned at lessees expense)

19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
When will Scanner Shutdown?
USING THE SCANNER
Uploaded Data
Scanner is not being Used
First Scan Since Upload
Scanner Shutdown
38
(No Transcript)
39
(No Transcript)
40
Shutting Down the Scanner

• Click EXIT on the Pharmanex BioPhotonic Software.
• Shut off the Laptop with the power button.
• Turn the Laser Key to the OFF position.
• Remove the Safety Interlock Plug.
• Flip the Back Rocker Switch to the OFF
  position. Note You should hear the cooling fan
  turn off.
• Remove the power cords, and Serial Cable.

ON OFF
OFF ON
Laser Key
41
Scanner Lights

• There are two indicator lights
• Red On Laser in Not Ready mode. Performing
  an automatic laser optimizing routine.
• Yellow On Laser is on.
• If the red light comes on during a scan or
  calibration, the process will need to be
  repeated. The software will alert you to this
  condition.
• NOTE Rebooting the scanner will not speed the
  process!

Red Yellow Indicator Lights
42
Scanner Lights (2 of 2)

• There is light on the back of the scanner. It
  indicates the status of the communications
  between the Laptop and the Scanner.
• A Red Light indicates normal or ready status.
  A Yellow Light indicates that the scanner is
  communicating to the laptop in the process of
  performing a scan.

Rear Communication Light
43
Traveling with the Scanner

• Only travel with the Scanner with the appropriate
  Scanner custom case!
• DO NOT leave the Scanner in a car overnight or in
  a cold climate
• You may check the Scanner onto an airplane. The
  case is to large to carry on a plane.
• For airline travel, we suggest that you check the
  Scanner at the gate. This will allow you to
  escort the Scanner through security.

44
Other Important Information

• UPS is a good idea, but not required.
• If security sticker is breached, a 7000 fee will
  be assessed, and the scanner will be kept by
  Pharmanex.
• Remove laser key and safety interlock plug prior
  to packing.
• Ship scanner in a cardboard box w/ foam or bubble
  wrap. Operator will be held responsible for
  damage to the black case.

45
Conclusion

• Have fun using the scanner. It is a incredible
  tool for demonstrating the power of LifePak!
• Roll with the punches! With this early
  opportunity to get a Version 1.0 scanner, some
  challenges may occur.
• You are not on your own. We have a tremendous
  support staff to make this technology work for
  you.
• Give us feedback as to your experiences. It will
  provide us with invaluable information for
  improving the scanner in the future.

46
Congratulations!
Certified BioPhotonic Scan Operator
