Introduction to Visual Studio Team System

1
Testing Best Practices with VSTS
Shahidul Islam, MPH QA Manager Emerging Health
Information Technology 12/4/08
2
Agenda

• Visual Studio Test Edition for Software Testers
  (VSTEST)
• Manual Tests
• Web Tests
• Load Tests
• TFS Work Item Tracking
• TFS Reporting

3
Sources for Test Cases by Test Type
VSTS Web Tests
4
Test Plan

• Documents project-specific strategy for all test
  types.

5
VSTEST

• Visual Studio Test Edition for Software Testers
• Author Tests
• Run Tests
• Publish and Share the results
• Reporting with TFS

6
VSTEST Basics

• Test Projects are Visual Studio Projects
• Compile/deploy like any assembly in .NET
• Visual Studio options under Test Tools
• The solution should be stored within source
  control (like any other piece of code)
• Tool set integrated in VS allows for easy
  adoption from developers.
• Testers are more integrated with the development
  process

7
Requirements Management
8
Manual Tests
9
VSTS Manual TestsExcel

• FilegtProperties
• Custom
• TestType Manual Test
• TestID Get a GUID from VSTSgtToolsgtCreate a
  GUID
• Save As .mht file

10
Web Testing

• Uses a recorder for test creation
• Records web requests using Internet Explorer
• Analyzes the HTML traffic each response can be
  validated for expected behavior
• Ordered series of HTTP requests against a target
  web applications
• Integrates with Visual Studio
• Available only via VSTS Team Edition for Software
  Testers
• Runs with Test Manager
• Integrated with Team Build

11
Web Testing

• Web Tests are of two types
• Recorded Tests
• Launch the browser
• Record session steps
• Playback recorded session
• Convertible to (Coded Tests) C or VB code to
  handle complex scenarios and flow control
• Coded Tests
• Scripted
• Better, adapted from recorded tests
• Playback
• Supports ASP.NET, HTTP based, Web Page, Web
  Services
• Compatible with HTTPS

12
Web Test Demo

• Demo then proceed to slide 43

13
Recording a Web Test

• Record a browser session using the Web Test
  Recorder
• Analyze the http requests being recorded
• Can pause in between requests
• Recording can be a good baseline for coded Web
  tests

14
Recording a Web Test

• Steps
• Test..New Test
• Choose Web Test
• Choose Default Visual C test project
• Create
• A new Internet Explorer instance opens up

15
Recording a Web Test

• Two windows open
• A new Internet Explorer instance
• Web Test Recorder on the left pane of the IE
  instance
• Each request or page navigated is displayed
• Options available to stop or pause recording
• Can add comments during recording

16
Recording a Web Test

• Once stopped, recorded test can be run from Test
  Window

17
Editing a Web Test

• Web Test Editor available once recording is
  stopped
• Features
• Toolbar for basic commands
• Expandable Request Tree view of requests in the
  execution order
• Can expand to see Query String parameters or
  Form Post parameters
• Properties Window
• Properties and Settings of the Web Test

18
Editing a Web Test

• Adding a New Request
• Right click on request to add new request
• Clean up unnecessary recorded steps
• Remove extraneous or wrong user actions
• Modify the order of requests
• Be conscious of dependent requests

19
Editing A Web Test Properties

• Properties
• Description Text for describing the test
• Pre-authenticate
• True Every request includes authentication
  header (default)
• False Authentication header sent when requested
• User Name and Password Values set using the Set
  Credentials button on Web Test Editor for sites
  using
• Basic authentication or
• Integrated Windows authentication
• Credentials can be edited directly on properties
  window or
• Can bind to data source for multiple runs with
  different credentials (recommended)

20
Editing A Web Test Requests

• Requests HTTP request steps which are executed
  in given order and whose response is processed
• Request Tree in Web Test Editor consolidates
  child requests to be executed in order for main
  request
• Properties of a Request
• Cache Control
• Encoding
• Follow Redirects
• Method
• Parse Dependent Request
• Record Results
• Response Time Goal
• Think Time
• Timeout
• URL
• Version

21
Editing A Web Test Requests

• Cache Control True/False directive to simulate
  browser caching
• Encoding Text format for requests - usually
  UTF-8 for HTTP traffic
• Follow Redirects True/False to honor status
  codes 300-307 (redirect) to final page or stop
  and treat the redirect as final page
• Method GET or POST
• Parse Dependent Request True/False to process
  dependent requests such as loading image files.
  True will get standard behavior (load images)

22
Editing A Web Test Requests

• Record Results Used only with Load Testing to
  determine if timing and performance data need to
  be included
• Response Time Goal Used with Load Test reporting
  to record how long the request took to process
• Think Time Delay (in seconds) to pause on page
  before processing next request
• Timeout Maximum time (in seconds) to wait for
  response before timing out and logging a failure
• URL URL of the request
• Version Versions of HTTP to use default 1.1

23
Editing a Web Test Request Sub Items

• Request Sub-items Simple requests can be
  enhanced with sub-items like validation rules
  etc.
• Dependent Requests
• A normal HTTP request which has a parent request
• Example Load image on a page
• Handled by Parse Dependent Requests property
• Can have own dependent requests
• Can be added explicitly example, extraction or
  validate rule

24
Editing a Web Test Request Sub Items

• Query String Parameters
• NameValue pairs set in the Property window
• Show Separate Request Results
• Used to group results in Load Testing
• Result data is grouped if False (default) if
  True, displays separate grouping for data
  (response time etc)
• URL Encode Determines if Name/Value will be URL
  encoded
• Form Post Parameters If the request method is
  POST, enables two form POST parameters
• Common Form Post Parameter
• File Upload Parameter
• Headers NameValue pair to be included in HTTP
  header. Ex Refererwww.microsoft.com
• Validation Rules Add validation rules to verify
  if response from the request is expected one
• Extraction Rules Capture data from response

25
Editing a Web Test Transactions

• Allow grouping of requests as a unit to
• Document
• Move/Copy
• Capture timing information
• To insert
• Right click at the request where the transaction
  is to be inserted
• Complete the Add Transaction dialog
• Requests can be moved between transactions using
  drag and drop.

26
Editing a Web Test Comments, Context Parameters

• Comments Tests can be documented with comments
• Context Parameters
• Replace static values with dynamic values for
  property, value or parameter
• Variables expand to real values at runtime to
  make the test flexible and dynamic
• Usually done through Parameterizing Web Servers

27
Editing a Web Test Parameterizing Web Servers

• Select web test, and right-click
• Select Parameterize Web Servers
• Allows changing URLs from static to
  context-parameterized variables to re-target the
  test
• Parameterize Web Servers dialog lists web servers
  used with a default Context Parameter Name
• Can be changed using the Change button to change
• Web Server
• Local ASP.NET Development Web Server

28
Editing a Web Test Parameterizing Web Servers

• After changing, the Context Parameters node
  appears in the web test
• Values can be edited via right click on
  Properties of newly added
• parameternamevalue
• Context Parameter can then be used in requests
  using
• .. notation
• Example WebServer6/live/search/search.xml

29
Editing Web Tests Extraction Rules

• Data from POST/GET requests can be extracted for
• Subsequent requests
• Providing debugging information
• Extraction rules verify that a Web application is
  working correctly by
• extracting data from the responses to Web
  requests
• storing results in the test context as name value
  pairs.
• Extraction rules can extract
• form fields
• Text
• Attributes
• Headers
• regular expressions
• hidden fields.

30
Editing Web Tests Extraction Rules

• To Extract, right-click on a request and choose
  Add Extraction Rule
• Extraction rules define what data is to be
  extracted from an HTTP response and store the
  data in context parameters
• Dynamic data generated via requests can be passed
  down to later requests.

31
Editing Web Tests Extraction Rules
32
Editing Web Tests Extraction Rules

• To add Extraction Rule
• Right-click on request
• Choose Add Extraction Rule
• Modify/add parameters
• Set Context Parameter to a unique name

33
Annoying Error Messages!!

• RequestFailed Context parameter
  'HIDDEN1.__VIEWSTATE' not found in test
  context.
• Add Extract Hidden Fields

34
Annoying Error Messages!!

• Web Test ran flawlessly right after recording but
  Next Morning?
• 500 Server Error
• Search for parameters you think may be dynamic
  (Session Variable)
• Add Extract Text Rule
• Example Context Parameter Name ControlID, Ends
  With , HTMLDecode True, Ignore Case False,
  Index 0, Required True, Starts With
  ControlID , Use Regular Expression false.

35
Editing Web Tests Validation Rules

• Validation rules validate existence of
• Text
• tags,
• or attributes
• on the page returned by a request.
• Validation rules also verify the amount of time
  it takes a request to finish, and the existence
  of form fields and their values.

36
Editing Web Tests Validation Rules
37
Editing Web Tests Validation Rules

• To add a validation rule
• Select a request
• Right-click
• Add Validation rules in dialog
• Validation Level
• Used only during a load test
• Higher validation levels effect speed, hence
  slower tests
• Does not mean priority
• Determines when the validation rule is used in a
  load test.
• Setting to High means that the rule is executed
  only when the load test validation level is set
  to high.

38
Editing Web Tests Validation Rules

• Validation Levels
• Used only during a load test
• Higher validation levels means slower tests
• Does not mean priority
• Determines when the validation rule is used in a
  load test.
• Setting to High means that the rule is executed
  only when the load test validation level is set
  to high.

39
Running Web Tests

• Settings can be configured from .testrunconfig
  file
• Choose Web Test from dialog
• Number of iterations
• Browser Type
• Network Type
• Simulate Think Times
• These settings are overridden when run under a
  Load Test

40
Running Web Tests

• From the tool bar
• Run Test
• From the command line
• Invoke MSTEST

41
Interpreting Web Test Results

• Results Viewer
• Results Panel
• Request The full URL requested
• HTTP Status HTTP status returned from the server
  typically 200 OK
• Response Time Time web server took to respond
• Size Size of response

42
Interpreting Web Test Results

• Details Panel
• Web Browser Tab Response rendered as browser
  page
• Request Contents of the selected request
• Response Contents of the response to selected
  request
• Context Current context parameters, useful for
  debugging extraction rules
• Details Results of extraction and validation
  rules for selected request.

43
Coded Web Tests

• Written in C or Visual Basic
• Incorporates flow of control as opposed to
  sequential recorded tests
• Use Recorded tests for baseline and then convert
• Select web test
• Right-click
• Generate Code

44
Why Coded Web Tests?

• Can read expected results from a data source
• Flexibility of conditionals and looping
• Copy set of request from one test to another
• Factor out sections of requests and other
  operation into methods that any test can call

45
AJAX in Web Tests

• VSTS 2008 now records AJAX requests
• Freeware Fiddler need not be used, although its
  still useful for diagnosing
• See http//www.fiddlertool.com/fiddler/

46
Test Case Management

• Test List Editor
• New Test List per release/project/cycle
• PropertiesgtAssociated Work Items
• Run Test
• Run one or multiple tests
• Debug tests

47
Test Results Window

• Run/Debug
• Pause/Stop Run
• Import/Export Results
• Group results by

48
LOAD TESTS

• Step 1 Identify Objectives.
• Step 2 Identify Key Scenarios.
• Step 3 Identify Workload.
• Step 4 Identify Metrics.
• Step 5 Create Test Cases.
• Step 6 Simulate Load.
• Step 7 Analyze the Results.

49
Understanding Load Test

• Primary goal of a Load Test is to simulate many
  users accessing server at the same time
• By adding Web Tests to a Load Test you can,
• Simulate multiple users opening simultaneous
  connections to a server
• Make multiple HTTP requests
• Set other properties that apply to individual Web
  Tests

50
Understanding Load Test Continues..

• Load Tests are used in several different types of
  testing
• Smoke How your application performs under light
  loads for short duration
• Stress To determine if the application will run
  successfully for a sustained duration under heavy
  load
• Performance To determine how responsive your
  application is
• Capacity To determine how many users and/or
  transactions a given system will support and
  still meet performance goals

51
Identify Objectives

• Write down the performance objectives for your
  application.
• Response time. For example, the product catalog
  must be displayed in less than 3 seconds.
• Throughput. For example, the system must support
  100 requests per second.
• Resource utilization. A frequently overlooked
  aspect is how much resource your application is
  consuming, in terms of CPU, memory, disk I/O, and
  network I/O.
• Maximum User Load. Determining how many maximum
  users can run on a specific hardware
  configuration

52
Identify Key Scenarios

• What are scenarios?
• Scenarios are anticipated user paths that
  generally incorporate multiple application
  activities.
• How do you identify scenarios?
• Key scenarios are those for which you have
  specific performance goals or those that have a
  significant performance impact.
• For example
• Login to the site.
• Browse albums.
• Register to the site.

53
Identify the workload

• Identify the distribution
• IIS Logs (Exist).
• Research (Not exist).
• Identify the user loads
• What are the max expected
• concurrent users?

53
54
Identify Metrics

• Metrics provide information about how close your
  application is to your performance objectives.
• Metrics help you identify problem areas and
  bottlenecks.
• Network-specific metrics.
• System-related metrics.
• Platform-specific metrics.
• Application-specific metrics.

55
Create Load Test Cases

• What is a Load test case?
• An group of activities involved in a scenario.
• For example Place an Order.
• The test cases are created based on the scenarios
  and the profile mix identified in the previous
  steps.
• Each test case should mention the expected
  results in such a way that each test case can be
  marked as a pass or fail after execution.

56
Performance Test Cases

• Load Test Case example
• Expected Results example

57
VS Performance Test

• Load patterns and Real world test analogy
• Constant pattern ? Load test, Stress test
• Step pattern ? Compatibility test, Performance
  test, Benchmarks
• Goal based pattern ? Stress test , Capacity test

58
Load Test Life Cycle http//blogs.vertigosoftware.
com/teamsystem/archive/2006/02/06/VSTS_Load_Testin
g_Lab_Setup.aspx
59
Demo

• Add a blank web test
• Call web test from another web test (Login and
  LinkToLos)
• Data binding-csv-LoginPage
• Run WebTest once then edit run settings to run
  per row
• Validation rule passing
• Show Load Test setup and run
• Analyze LoadTest Result

60
Control Load Modeling

• Load Tests now offer additional load-modeling
  options that enable us to create load tests that
  more accurately model the expected real-world
  usage of an application
• Number of tests run
• Determines which test is run when a virtual user
  starts a iteration
• Follow this model when you are basing test mix on
  transaction percentages in an IIS log or
  production data

61
Control Load Modeling continues..

• The amount of time spent on each test
• Determines the percentage of virtual users who
  will run a particular test
• Follow this model when you are basing the test
  mix on the percentage of users running particular
  test
• The pace/speed at which the users run the tests
• Each test is run the specified number of times
  per user per hour
• Follow this model when you want virtual users to
  run tests at a certain pace throughout the load
  test

62
How should the test mix be modeled
63
Improved Load Test Analyzer Views

• New Summary View with key indicators in a single
  page
• Four new built-in graphs display key information
  at the same time
• Easily accessed table view

64
Load Tests Summary

• Test Run Information
• Name, Description, Start/End times, Controller
• Overall Results
• Number of request/sec
• Number of failed requests
• Average response time
• Average page time

65
Load Test Summary Continues

• Key Statistics Top 5 Slowest Pages
• URL (Can click the link to see details)
• and average page load time
• Key Statistics Top 5 Slowest Tests
• Test name (Can click the link to see details)
• Average test time
• Key Statistics Top 5 Slowest SQL operation
• Name of the operation (Can click the link to see
  details)
• Duration in Microseconds

66
Load Tests Summary Continues..

• Test Results
• List of all tests and scenarios
• Number of time each scenario ran
• Number of times it failed
• Average test time

67
Load Tests Summary Continues..

• Page Results
• List of all web pages in the load test
• Total count of requests made for the web page
• Average page time

68
Load Test Summary Continues..

• Transaction Results
• NOT A DATABASE TRANSACTION
• Web Test Transaction
• List of all the transactions in the Load Test
• Response Time
• Elapsed Time
• Total Counts

69
Load Test Summary Continues

• Controller and Agent Resources
• Contains list of computers that are used to run
  the test
• processor time
• Available memory at the end of test run

70
Load Test Summary Continues

• System Under Test Resources
• List of computers that are the set of target
  computers for which load is being generated
• Includes any computer from which you collect
  counter sets other than Agent or Controller.

71
Load Test Summary Continues

• Errors
• List of all errors
• Type i.e. HttpEerror
• Sub Type i.e. LoadTestException
• Error count
• Number of each error type
• Error message i.e. 404-NotFound

72
(No Transcript)
73
Graphs View
74
Table View

• Errors-Displays a list of errors that occurred
  during the load test run
• Pages-Displays a list of pages accessed during a
  load test run
• Requests-Displays details for individual requests
  issued during a load test
• SQL Trace-Displays the results of SQL tracing
  only if SQL tracing was enabled with right
  connection string
• Tests-Displays details for individual tests run
  during a load test
• Thresholds-Displays a list of threshold rule
  violations that occurred during a load
• Transactions-Displays a list of transactions that
  occurred during a load test run

75
Load Test Result Repository Management

• Information gathered during a Load Test run is
  stored in the Result Repository
• Repository contains performance counter data and
  error data
• You can manage your load result from the Load
  test editor
• Open
• Import
• Export
• Remove
• You do not have to go the dbase to clean up the
  repository

76
Defects Tracking Using TFS
77
Defects Tracking Using TFS Continues..
78
Reporting Using TFSRemaining Work Items
79
Reporting Using TFSBug Rates
80
References

• http//blogs.msdn.com/slumley/pages/how-to-debug-a
  -web-test.aspx
• http//blogs.msdn.com/slumley/pages/web-test-corre
  lation-helper-feature-in-orcas.aspx
• http//msdn.microsoft.com/en-us/library/aa730850(v
  s.80).aspx
