NEW HORIZONS

1
NEW HORIZONS
NASAs Pluto-Kuiper Belt Mission The First
Mission to the Last Planet
2
Toward New Frontiers
New Horizons is Demonstrating That Exciting,
Lower Cost Outer Planet Missions Are Indeed
Feasible.
3
Pluto A Little Background
Pluto was discovered in January-February 1930, by
Clyde Tombaugh at Lowell Observatory, Arizona.

• Pluto is a Small, Distant World
• lt1 Marss Max Apparent Diameter (0.1 arcsec)
• And 50,000 times fainter than Mars (V14)

4
Pluto Some Basic Properties

• Rotation Period 6.4 days (retrograde)
• Axial Tilt (obliquity) 118 deg
• Mass 0.2 Earths (1.5x1025 gm)
• Diameter 18 Earths (1180 km)
• Reflectivity 50 (due to its icy surface)

The Best Hubble Images of Pluto Are Still Crude
5
Pluto A Misfit?

• Distance from the Sun varies from 30 to 50 AU
• Orbital Period 248 years
• Eccentricity 0.25
• Inclination 16 deg

6
1976 Discovery of Methane On Plutos Surface

• N2 and CO ices were later discovered.
• The CH4, N2, CO distribution is patchy.
• But N2 dominates almost 101

True Color Map
7
1988 Discovery of Plutos Atmosphere

• Pluto has an atmosphere it was definitively
  detected in 1988 by a refractive signature seen
  in a stellar occultation.
• It is composed of N2, CO, and CH4, plus trace
  species there is evidence for hazes.
• The atmosphere is thought to be escaping to
  space hydrodynamically.
• An occultation in 2003
• revealed distinct structural and pressure changes.

8
1978 Discovery of Plutos Moon Charon

• Charon was discovered, by accident, in July 1978
  by Jim Christy
• of the U.S. Naval Observatory.
• Charon is in synchronous orbit 19,400 km from
  Pluto, and spin-spin-orbit locked with a 6.4 day
  period.

0.9 arc-sec
9
2005 The Discovery of Two New Moons
10
And Do Not Judge This Book By Its Cover
From the Densities of Pluto and Charon, One Can
Derive Crude Interior Models.
Pluto is a primarily rocky, not icy body!
11
Pluto A Clear Outlier Among The Giant Planets
A Dwarf Planet and A True Binary World

• Charons radius is 50 of Plutos.
• Charons mass is about 10 of Plutos.

12
But the 1990s Clearly Revealed Plutos Context
The Kuiper Belt
13
The Discovery Of the Kuiper Belt

• 1992 Jewitt Luu found a 100 km sized object in
  a near-circular orbit, well beyond Pluto.
• 1993 4 more KBOs found.
• 1994 10 KBOs found.
• 2005 Over 1000 KBOs are now known.

14
The Kuiper Belt

• Over 140,000 KBOs predicted with diameters gt100
  km, orbits 30-50 AU (assuming 4 reflectivity).
• Billions of smaller comets are also predicted to
  exist there.
• The largest KBOs are well over
• 2000 km in diameter.
• Three Orbit Types
• Plutinos Neptune resonant, alt50 AU
• Classical Non-resonant, alt50 AU
• Scattered Distant (agt50 AU), Neptune ejected

15
Large KBOs Abound

• The large KBOs are planetary embryos.
• These objects reached the mid-stage of planetary
  accretion.
• They are dwarf planets.

16
As Do KBO Satellites

• Pluto/Charon was only the first binary object
  (1978).
• Next up 1998 WW31 (2001).
• 16 KBO binaries discovered so far (late 2004).
• Implication gt20 of all KBOs have satellites.

17
A Historic Journey
The Initial Reconnaissance of The Solar Systems
Third Zone
Pluto-Charon July 2015
KBOs 2016-2020
Jupiter System March 2007
Launch Jan 2006
18
Project Philosophy
Offer early and highly-leveraged science. Do so
on time, within budget, and at low risk. Provide
Intensive Public Outreach Keep It Simple
19
Launch Vehicle Atlas V 551 With A STAR-48 Upper
Stage
20
Instrument Payload
REX
LORRI
ALICE
PEPSSI
RALPH

• CORE
• REX radio science radiometry
• RALPH VIS/IR imaging spectroscopy
• ALICE UV imaging spectroscopy
• Supplemental
• LORRI High-resolution imager
• SWAP plasma spectrometer
• PEPSSI energetic particle spectrometer
• SDC EPO Student Dust Counter

SWAP
Student Dust Counter
21
The Student Dust Counter A New Kind of EPO

• EPO Goal Give students a chance to design,
  build, operate, study data from a planetary
  flight experiment.
• Science Goal Make the first dust density
  size spectrum observations beyond 18 AU.
• Students have the primary responsibility for the
  design and development of the SDC over 35 first
  generation students were involved at CU, with
  dozens more participating across the U.S.
• Four Generations of Students To Be Involved.

SDC Student Team Leaders
22
Launch Windows Overview

• 2006 Primary
• Jan 11-Feb 14 Jan 06
• Window 34 days
• C3 164 km2/s2
• Earliest Arrival 2015
• 2007 Backup
• 0215 Feb 07
• Window 14 days
• C3 166 km2/s2
• Earliest Arrival 2019
• Requires KBO Fuel Removal

23
Jupiter Flyby Science
Jupiter science will include studies of Jovian
meteorology, satellite geology and
composition, Auroral phenomena, and
magnetospheric physics.
24
Pluto-Charon Encounter Highlights

• Six months of encounter science.
• Exceed Hubble resolution for months.
• Map all of Pluto and all of Charon.
• Make global composition maps of Pluto and
  Charon.
• Map their surface temperature fields.
• Directly measure Plutos escape rate and assay
  its atmospheric structure and composition.
• Improve interior models and determine if either
  Pluto or Charon differentiated.
• Locate additional Pluto-system satellites lt1 km
  in diameter.

The most exciting discoveries will likely be the
ones we Dont anticipate.
25
New Horizons Will Yield Dramatic Results at
Pluto-Charon
Triton from Voyager
Triton and Pluto at Best HST Resolution
26
New Horizons at the Cape
27
Atlas V-010 in Denver
28
Mission Status Summary
Project Element Status
Spacecraft GO
Payload GO
RTG GO
Atlas V GO
STAR-48 GO
PI Science GO
