IPM Overview

1
IPM Overview
Elliot Lieberman U.S. Environmental Protection
Agency Washington, D.C. 20460
2
Documentation on Web
www.epa.gov/airmarkets/epa-ipm
3
What is IPM?

• The Integrated Planning Model (IPM) is a tool
  developed by ICF Consulting and used by EPA for
  policy analysis.
• IPM is a long-term capacity expansion and
  production costing model for analyzing the
  electric power sector.
• It is a multi-regional, deterministic, dynamic
  linear programming model.
• IPM finds the least-cost solution to meeting
  electricity demand subject to environmental,
  transmission, fuel, reserve margin, and other
  system operating constraints.

4
Linear Program Advantages

• Finds optimal solution
• Comprehensive, integrated approach
• Bottom-up detail
• Allows fine grain parameter variations
• Analysis based on detailed disaggregate
  information

5
Typical IPM Constraints and Variables
140,225 Constraints
1,980,251 Variables

• Electricity Demand Constraints
• Reserve Margin Constraints
• Environmental Constraints
• Transmission Constraints
• Fuel Constraints
• Other Operational Constraints

• Model plants
• Existing Units
• Planned/Committed Units
• Potential Units
• Retrofit options
• Repowerings and retirements

(x load segments x coal or fuel types x run
years x seasons)
6
(No Transcript)
7
Model Regions
8
(No Transcript)
9
Reserve Margin Assumptions
Reserve margin is a measure of the systems
generating capability above the amount required
to meet peak load requirements.
Planning Reserve Margins
10
Generating Resources
Categories represented

• Existing units
• Planned/committed units
• New potential units that the model can build
• Repowerings, relicensings, and retirements

11
Potential Units

• Pulverized Coal
• Integrated Gasification Combined Cycle
• Combined Cycle
• Combustion Turbine
• Nuclear

• Biomass Gasification Combined Cycle
• Wind
• Solar
• Geothermal
• Landfill gas
• Fuel cells

12
Emission Control Technologies

• SO2 Scrubbers
• Limestone Forced Oxidation (LSFO)
• Magnesium Enhanced Lime (MEL)
• Lime Spray Dryer (LSD)
• NOx Post-Combustion Controls
• Selective Catalytic Reduction (SCR)
• Selective Non-catalytic Reduction (SNCR)
• Gas Reburn

• Mercury Removal
• Activated Carbon Injection (ACI)
• By-product of SO2, NOx, and particulate controls
• Other
• Combustion Optimization
• Biomass cofiring

13
First Stage Retrofit Assignment Scheme in EPA
Base Case 2000
14
Run Year Mapping in EPA Base Case 2000
15
Model Plant Aggregation
16
Categories Used in Aggregation Scheme

• Model Region
• Unit Technology Type
• Fuel Demand Region
• Environmental Regulations
• NOx SIP Call Participation
• State Specific Regulations in CT, MO and TX
• State
• Texas
• Connecticut
• Missouri
• Unit Configuration
• Boiler Type
• Firing Type
• SO2 Pollution Control
• NOx Pollution Control
• Particulate Matter Control
• Heat Rate
• Low Efficiency Group
• Mid Efficiency Groups

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
Typical Model Plants
21
Financial Assumptions
22
Financial Assumptions

• Discount Rate
• Represents the time value of money
• Allows for inter-temporal analysis
• Capital Charge Rate
• Allows annualized capital payments to be
  calculated for an investment

23
Discount Rate
Key parameters considered

• Capital structure
• Pre-tax debt rate
• Post-tax equity rate

24
Capital Charge Rate
Key parameters considered

• Capital structure
• Pre-tax debt rate (or interest cost)
• Debt life
• Post-tax return on equity
• Taxes and insurance
• Depreciation schedule
• Book life

25
Factors Affecting the FinancingOf Different
Technologies

• Risk profile
• Medium risk
• High risk
• Financing scheme
• Project financing
• Corporate financing

26
(No Transcript)
