Oxford

1
Multi-vessel disease Le Mans implications
Oxford
The John Radcliffe Hospital
Dr Adrian Banning
2
Multi-vessel diseaseLe Mans - implications ?

• Lemans trial J Am Coll Cardiol 2008
• Small randomised trial of CABG vs PCI for
  patients with left main disease
• Syntax Lemans
• Subset of the Syntax trial
• patients with left main disease
• follow up angios at 15 months (both surgical and
  PCI)
• To be reported at PCR 09

3
Why is the Left Main important?
It supplies at least 2/3 of the blood to the
heart!!!
4
Why is the left main special?

• Large vessel
• Prone to calcification
• Large volume of plaque required to cause stenosis
• Intubated by the diagnostic catheter ostium?
• By definition terminates in a bifurcation at
  least
• Untreated LMS stenosis gt 20 mortality at 1yr

5
Results of initial intervention on the LMS- the
early years

• 1980s Hartzler using POBA
• 10 procedural mortality in hospital
• 64 3yr mortality
• Early 1993-8 ULTIMA
• 279 pts unprotected LMS
• 14 procedural mortality in hospital
• 25 mortality at one year
• NB if 46 inoperable are excluded
• 97 1yr survival in these low risk pts

6
Can we predict risk when stenting the LMS?
7
Stent the LMS with BMS safe, but high rate of
MACE due to restenosis
Am J Cardiol. 20039112-6.
8
A Randomized Comparison of Paclitaxel-ElutingSten
ts Versus Bare-Metal Stents for Treatmentof
Unprotected Left Main Coronary Artery Stenosis

• 103 patients
• BMS (n 50) or PES (n 53).
• All IVUS guidance and Cutting balloon
  pretreatment x 3 to cover entire lesion
• Ostium and body were treated with a single stent
• Single stent 49/50 and 52/53
• Final kissing balloon dilation was performed
  only in cases with
• suboptimal result at the LCX ostium (6 and 19)
• Follow-up 6 months angio and IVUS
• No late stent thrombosis in either group

Erglis et al JACC 2007
9
A Randomized Comparison of Paclitaxel-ElutingSten
ts Versus Bare-Metal Stents for Treatmentof
Unprotected Left Main Coronary Artery Stenosis
Erglis et al JACC 2007
10
A Randomized Comparison of Paclitaxel-ElutingSten
ts Versus Bare-Metal Stents for Treatmentof
Unprotected Left Main Coronary Artery Stenosis
Erglis et al JACC 2007
11
A Randomized Comparison of Paclitaxel-ElutingSten
ts Versus Bare-Metal Stents for Treatmentof
Unprotected Left Main Coronary Artery Stenosis
Erglis et al JACC 2007
12
A Randomized Comparison of Paclitaxel-ElutingSten
ts Versus Bare-Metal Stents for Treatmentof
Unprotected Left Main Coronary Artery Stenosis
Erglis et al JACC 2007
13
Location matters
Ostium
Distal- bifurcation
Shaft
14
What makes the left main special?

• Anatomy matters
• Ostial Needs 1 stent
• Body Needs 1 stent
• Bifurcation Usually gt1 stent, 2 wires, gt6F

15
Preliminary DES in LMS disease?
16
Long-Term Outcome After DES in Nonbifurcation
Lesions that involve Unprotected LMS

• Population 147 pts
• elective (only) consecutive pts SES or PES in 5
  centers
• - stenosis in the ostium and/or the mid-shaft of
  an unprotected LMCA
• PCI instead of surgery was considered either
• (1) suitable anatomy for stenting and preference
  patient and physician
• (2) suitable anatomy for stenting and EuroSCORE
  6 and/or Parsonnet score 13 and/or prior bypass
  surgery with failure of all conduits (n2).

Chieffo et al Circulation 2007
17
Favorable Long-Term Outcome After Drug-Eluting
Stent Implantation in Nonbifurcation Lesions That
Involve Unprotected Left Main Coronary

• Medications
• IIb/IIIa inhibitors at the discretion of the
  operator.
• Dual antiplatelet therapy for at least 6 months
  after. All patients were advised to maintain
  lifelong use of aspirin (100 mg/d).
• Clinical follow-up at 1, 6, 12, and 24 months.
• Patients eligible for longer clinical follow-up
  were contacted at 36 and 48 months.
• Angio follow-up 4 and 9 months or earlier if
  neccesary
• Total follow up mean 886 days

Chieffo et al Circulation 2007
18
Favorable Long-Term Outcome After Drug-Eluting
Stent Implantation in Nonbifurcation Lesions That
Involve Unprotected Left Main Coronary
Chieffo et al Circulation 2007
19
Favorable Long-Term Outcome After Drug-Eluting
Stent Implantation in Nonbifurcation Lesions That
Involve Unprotected Left Main Coronary
Chieffo et al Circulation 2007
20
Favorable Long-Term Outcome After Drug-Eluting
Stent Implantation in Nonbifurcation Lesions That
Involve Unprotected Left Main Coronary
Chieffo et al Circulation 2007
21
Favorable Long-Term Outcome After Drug-Eluting
Stent Implantation in Nonbifurcation Lesions That
Involve Unprotected Left Main Coronary
Chieffo et al Circulation 2007
22
Favorable Long-Term Outcome After Drug-Eluting
Stent Implantation in Nonbifurcation Lesions That
Involve Unprotected Left Main Coronary
No proven late stent thrombosis 4 unexpected
deaths
Chieffo et al Circulation 2007
23
Favorable Long-Term Outcome After Drug-Eluting
Stent Implantation in Nonbifurcation Lesions That
Involve Unprotected Left Main Coronary
Chieffo et al Circulation 2007
24
What about late stent thrombosis in LMS disease?

• Specific worries
• Late thrombosis for all DES gtBMS
• Late thrombosis higher off label
• Higher risk of incomplete expansion?
• Left main occlusion will be fatal
• Reassurances
• Big vessel

25
Late and very late stent thrombosis following
DES in ULM. Chieffo et al, EHJ Sept 2008.

• Multicentre registry of 731 pts with
• Elective DES stenting of ULM disease.
• Definite ST
• 4 pts (0.5). 3 early (30d), 1 late ( 1 yr).
  No VLST.
• Probable ST 3 pts. All early (30d)
• Definite or probable ST 7 / 731 0.95
• All were on dual AP Rx.
• Possible ST
• (8 late, 12 very late) in 20 (2.7) pts.

26
Late and very late stent thrombosis following
DES in ULM. Chieffo et al, EHJ Sept 2008.

• Outcomes after 29.513.7 months follow up
• Death 6.2 (n45).
• Cardiac death 4.2 (n31)
• TVR 12.9 (n95)
• TLR 10.9 (n76)
• Restenosis rate 14.1 on angiographic follow-up
  of 548 pts.
• (NB 76 of lesions involved the distal LM.)
• Predictors of ST at logistic analysis
• Euroscore
• LVEF
• Consistent with general PCI population.
• No unique ST predictor among ULM pts identified
  in this analysis.
• Conclusion Elective DES stenting of ULM is safe
  - low rates of ST.

27
358 consecutive patients 7 centres All DES
28
Elective Urgent MACE free 74 68 Mortality 6
21 Reinfarction 8 10 TLR 7
3 TVR 16 7
Delft J Am Coll Cardiol 2008 51 2212-9
29

• So can stents replace surgeryin left main
  disease?

30
Unprotected left main stenting vs CABGSeung et
al, NEJM April 2008.

• Long term follow up of 1102 patients stenting for
  ULM disease,
• vs propensity-matched cohort of CABG patients
• No significant difference in the risk of death
  and the composite outcome of death, Q-wave MI, or
  stroke between the two groups.
• TVR higher in the stents group, even with DES.

Seung KB et al. N Engl J Med 20083581781-1792
31
Study of unprotected LEft MAiN Stenting versus
bypass surgery J Am Coll Cardiol 2008 51 538-45
32
Lemans study design
33
PCI technique Direct stenting preferred if not
poss predil with 2 or 2.5 Bifurcation technique
Initial stent to LAD then Cullotte or Prov T if
necessary No crush stenting IVUS advised DES if
diameter lt 3.8mm (35) LeMans study 2008
34
(No Transcript)
35
(No Transcript)
36
Improved EF with PCIETT similar by 12 months
more angina PCI initially
Lemans trial 2008
37
LeMans survival
38
SYNTAX Eligible Patients
De novo disease

• Limited Exclusion Criteria
• Previous interventions
• Acute MI with CPKgt2x
• Concomitant cardiac surgery

Left Main Disease (isolated, 1, 2 or 3 vessels)
3 Vessel Disease (revasc all 3 vascular
territories)
39
Syntax Lemans (reports PCR 09)

• All left main pts in the randomised Syntax n710
• Follow up angio at 15 months
• Asses late angio outcomes with clinical outcomes
• Asses utility of angio follow up
• Stats
• Surgery occlusion rate rate 5-12
• 100 surgery pts 95 confidence interval
  (/-0.043) if occlusion is 5 or (/-0.043) if
  occlusion is 12
• PCI Expected Patency rate 74-97
• 100 PCI pts 95 confidence interval (/-0.078) if
  patency is 80
• Expected attrition 30

40
12 Month LM Subgroup MACCE Rates
Patients ()
All LMN705
41
12 Month Subgroup MACCE Rates
Patients ()
3VD (All) N1095
LM3VD N258
All LMN705
LM1VDN138
LM isolatedN91
LM2VDN218
42
So why is the left main special?

• The left main is unforgiving during PCI
• Because large volumes of myocardium are at risk
• Large volumes of plaque may move
• Calcification is restrictive to stent expansion
• loss of branches will have immediate and
  profound haemodynamic consequences
• The left main is unforgiving in the long term
• All ostial disease has a very high restenosis
  rate (particularly if the stent is incompletely
  expanded).

43
What do we know about left main PCI?

• Procedural risk fallen from 10-20 to lt1
• (in all but shock cases)
• Ostial and shaft disease is different to terminal
  disease of the main
• Left main PCI should be definitely considered in
  all emergency cases and many urgent cases

44
What do we know about left main PCI in 2008?

• DES are almost certainly better than BMS
• Risks of treating left main disease with PCI or
  surgery are probably the same
• Long term results of DES in elective ostial and
  shaft disease are very encouraging
• Those cases treatable with one properly expanded
  stent

45
What do we know about left main PCI in 2008?

• However
• How do we treat distal bifurcation disease best?
• Perhaps the cullotte? Not the crush for me
• LMS 2VD / 3VD
• surgery still has lower rates of TVR particularly
  in diabetics

46
Isolated left main stenting in 2008
