Electricity and Magnetism

1
Electricity and Magnetism
2
Atomic Review

• An atom consists of 3 particles
• Protons-positively charged
• Neutrons-no charge
• Electrons-negatively charged

3
What is Electricity?

• A form of energy caused by moving electrons.

4
How charges act

• Like charges repel
• Opposites charges attract
• Electrons flow from a negatively charged area to
  a positively charged area

5

• Most objects are electrically neutral

6
Static Electricity
7
Phenomena

• Lightning
• Leather car seats
• Ben Franklin and the kite.
• Sliding your feet on a rug

8
How are charges transferred?
9

• When you rub two substances together you do work
  and thus you add energy.
• This removes electrons from one substance and
  adds it to the other.

10
This creates IONS which are charged particles.
11
Summary

• The energy used to rub two things together is the
  energy that gets involved in removing and
  transferring electrons.

12
Electrical Charge

• Can be Transferred.
• It cannot be created or destroyed.

13
Conductors

• A conductor allows charges to flow easily
• Some conductors are better than others
• Examples
• Copper
• Iron

14
Insulators

• An insulator prevents electric charges from
  flowing easily
• Examples
• Rubber Cork
• Wood Plastic

15
Electric Current

• Electric Current is the flow of electrons
  through a conductor
• There are two types of electric current
• Alternating Current
• Direct Current

16
Alternating Current

• Changes direction at a regular rate
• Most commonly used type of electricity because it
  does not create as much heat
• Examples
• Appliances
• Houses
• Christmas lights

17
Direct Current

• Always flows in one direction
• Always flows from negative to positive
• Example
• Battery
• Creates a lot of heat

18
What is a Battery?

• A series of electrochemical cells
• Two types
• A wet cell
• A dry cell

19
Wet cell

• Electrolyte is a liquid
• Example
• Car battery

20
Dry cell

• Electrolyte is a moist paste
• Example
• AA battery

21
What is a circuit?

• The path an electric current follows
• Consists of four parts
• Source Load
• Wires Switch
• Current flows only through a closed circuit

22
Diagrams

• Source Resistance
• Lamp Motor
• Wire
• Switch

23
What is a series circuit?

• A circuit where current follows only one path
• If one light goes out, the whole circuit goes out

24
Diagram of a Series Circuit
25
What is a parallel circuit?

• Current follows more than one path
• If one light goes out, the others remain on.
• Used in
• Homes
• Schools
• Buildings

26
Diagram of a Parallel Circuit
Circuit diagrams are a pictorial way of showing
circuits. Electricians and engineers draw circuit
diagrams to help them design the actual circuits.
Here is an example of a circuit.


27
What are volts?

• Electromotive force (EMF) is the force that moves
  electrons in a circuit.
• A volt is the unit used to measure EMF.

28
What are amps?

• The amount of current depends on the number of
  electrons flowing in the circuit.
• An ampere (amp) is the unit used to measure
  current.

29
What are ohms?

• Resistance opposes the flow of electrons in a
  circuit.
• Resistance of a wire depends on length,
  thickness, material, and temperature.
• An ohm is the unit used to measure resistance.

30
Magnetism
31
Where do magnets come from?

• Earth is a magnet
• Iron can be made into magnets
• 3 things stick to magnets iron, nickel, cobalt

32
Magnetic Pole

• A pole is the area of the magnet where the
  magnetic effect is the strongest.
• One pole of the magnet will always point north
  this is the north pole.
• The south pole will point south.
• The north and south poles are unlike and
  therefore attract.

33
Magnetism

• Magnetic
• Fields

34
Magnetic Fields

• Exist in regions surrounding magnets.
• Exerts a torque on a compass needle. (Demo)
• Compass needles allow us to map out magnetic
  fields.

35
(No Transcript)
36

• Magnetic field lines flow out of the north pole
  and into the south pole.
• They are continuous and never cross

37
The Earth itself is a magnet!
38
(No Transcript)
39

• Earths magnetic field causes compasses to line
  up.
• Magnetic north/south pole is about 11º off from
  geographic north/south pole.

40
Why?

• Scientists are not sure why the Earth is a giant
  magnet but some believe that it is due to the
  circulation of molten metal (iron and nickel)
  within the Earths core.

41
Oersteds Discovery!

• The presence of an electric current in a wire
  causes a torque in a compass nearby.
• A current carrying wire generates a magnetic
  field.
• Electromagnetism.

42
Electric Current

• The flow of charge through a material
• The amount of charge that passes through the wire
  in a unit of time is the rate at which the
  electric current flows. The unit of current is
  the ampere or amp.

43
An electric current produces a magnetic field.
44
The direction of the current determines the
direction of the magnetic field in a current
carrying wire.
45
Cause

• All magnetism is caused by the movement of
  charges.

46
Electromagnet

• An electromagnet is a strong magnet that can be
  turned on and off.

47
Increase strength

• Increase the strength of a magnet by
• Increasing the current
• Increasing the number of loops of wire to the
  solenoid.
• Wind the coils of a solenoid closer together.
• Use stronger ferromagnetic material for the core.
