Safe

1
Safe SoundBridge Improvement Program
2
Largest Bridge Program in Missouris History

• Statewide system improvement
• Modified Design-Bid-Build 248 bridges
• Design-Build Package 554 replacements
• 802 bridges repaired or replaced
• Construction begins in Spring 2009
• MoDOT will finance the project.

3
Program Costs

• Design/Construction Costs 700 million.
• Applies to all 802 bridges.
• MoDOT will issue GARVEE bonds.
• Bonds sold as needed.
• Approximately 50 million annual cost to MoDOT
  1/3 of annual federal bridge funds.

4
How are bridges rated?
TIME
NEW
VERY GOOD
GOOD
CLOSED
SATISFACTORY
FAIR
POOR
SERIOUS
Sub-structure Super-structure Deck
5
Guidelines for Bridges Selected

• Eliminate Condition 3 4 on Major Highways
• Eliminate Condition 3 on Minor Highways
• Eliminate as Many Condition 4 on Minor Highways
• No Mississippi/Missouri River structures
• No structures gt1,000 feet long
• Minimize R/W needs and roadway work

6
The Typical Safe Sound Bridge is

• 147 feet long, 24 feet wide
• 60 years old
• Rehabs 48 years old Replacements 66 years
  old
• In a rural location
• Avg. daily traffic of 1900 vehicles, but about
  300 carry less than 400 vehicles per day.

7
Vernon County Bridges
8
Vernon County Bridges
9
Vernon County Bridges
10
Vernon County Bridges
11
Vernon County Bridges
12
Vernon County Bridges
13
Vernon County Bridges
14
Vernon County Bridges
15
Vernon County Bridges
16
Vernon County Bridges
17
For More Information
Questions?

• Safe Sound District Coordinator Jim Conley
• E-mail safeandsound_at_modot.mo.gov
• www.modot.org/safeandsound
• 1.888.ASK.MODOT
